Cell culture study of degenerative articular cartilage and its - - PowerPoint PPT Presentation

• Dr. Rohit Prasad V

MS Ortho PG Under the Guidance of

• Dr. B. K. Dinakar Rai:

Department of Orthopaedics:

Cell culture study of degenerative articular cartilage and its comparison with normal articular cartilage

INTRODUCTION

Study is aimed at finding the degenerative process Of cartilage Composition : water > collagen > proteoglycan > noncollagenous protein > cells

STRUCTURE

AIM

• To find out the difference between normal and degenerated cartilage

using cell culture

OBJECTIVES

• To optimize the in vitro articular cartilage cell culture
• To perform a comparative studies on degenerative and normal articular

cartilage using cell counting, doubling time and extracellular matrix analysis in different age groups

INCLUSION CRITERIA

• The patients of all ages and both sex who require interventional procedure
• f joints (young patients who are subjected to any arthroscopic procedures,

and older patients subjected to joint replacement surgeries)

EXCLUSION CRITERIA

• Chronic inflammatory arthritis

1) Rheumatoid arthritis 2) Seronegative arthritis 3) Connective tissue disorders

• Infective arthritis
• Congenital skeletal anomalies
• Malignancy
• Age < 20 years

Extracellular matrix

• Water : makes up 65% to 80% of mass of the cartilage
• Collagen: makes up 10 to 20% of total cartilage mass
• type II collagen accounting for 90% to 95% of the total collagen content.
• functions to provide cartilaginous framework and tensile strength
• Proteoglycans : makes up 10 to 15% of cartilage
• Functions to provide compressive strength and attract water
• Aggrecan is most responsible for hydrophilic behavior
• composed of GAG subunits
• chondroitin sulfate
• keratin sulfate

Composition of Articular cartilage

• Glycosaminoglycans (GAGs) are one of the major constituents in the

cartilage

• There are two types of the chondroitin sulphate (type 4 and type 6) .

Type 6 remains constant throughout life, whereas type 4 decreases with the age.

Importance of GAG in Articular cartilage

Mourão PA. Distribution of chondroitin 4–sulfate and chondroitin 6–sulfate in human articular and growth cartilage. Arthritis &

• Rheumatology. 1988 Aug 1;31(8):1028-33.

Aging changes in Articular cartilage

• Increases in:
• chondrocytes size
• protein content
• stiffness (passive glycation leads to increased stiffness of collagen)
• increase in ratio of proteoglycan keratin sulfate to chondroitin sulfate

• Decrease in:
• absolute number of cells (individual chondrocytes - hypertrophy)
• water content (in osteoarthritis - water content actually increases)
• solubility
• elasticity

METHODOLOGY

COLLECTION OF ARTICULAR CARTILAGE SAMPLES ENZYMATIC DIGESTION USING COLLAGENASE AND TRYPSIN ISOLATION OF CELLS AND MAINTENANCE UNDER STANDARD CONDITIONS (CELLS CULTURED USING DMEM MEDIUM IN A CO2 INCUBATOR AT 37°c) COMPARATIVE STUDY USING CELL COUNTING DOUBLING TIME GAG AND COLLAGEN ESTIMATION

In vitro cell culture studies

Mince Tissue Collect the cells Enzym atic treatm ent Cell culture using DMEM m edium +10 % FBS Confluent cells viewed under Phase contrast m icroscope Centrifugation

DETAILS OF COLLECTED SAMPLES

Samplе Coding Gеndеr Agе

NI Malе 21 N2 Malе 23 N3 Malе 29 N4 Malе 33 N5 Fеmalе 36 N6 Malе 37 D1 Malе 53 D2 Malе 57 D3 Malе 59 D4 Fеmalе 62 D5 Malе 65 D6 Fеmalе 66 D7 Fеmalе 70 D8 Malе 75 D9 Malе 77 D10 Malе 79 D11 Malе 82 D12 Malе 83

Morphology of cells in vitro

Detached cells from tissue Attached cells Floating tissue with live cells

4 days 12 days

Confluent cells in different passages (28 days)- Normal cartilage

Passage 1 Passage 2 Passage 3 Passage 4 Sample: Male, 21 years

Confluent cells in different passages (28 days)- Degenerated cartilage

Passage 1 Passage 2 Passage 3 Passage 4 Sample: Male, 79 years

NORMAL

DEGENERATED

Chondoitin 4 Sulfate IHC staining

The staining intensities of chondroitin sulfate, a cartilage specific marker was observed to be increased in younger patients.

Observations

• Doubling time - significantly less for the normal group
• Cell count and Nuclear staining - higher in the normal group
• GAG and collagen estimation - higher values in normal in all 4

passages.

• Chondroitin-4 sulfate IHC staining – Higher concentration in young.

• This study revealed that - prolifеration ability - dеcrеasеd in

degenerated group

Cartilagе еxtracеllular matrix synthеsis rеducеd Dеgеnеration of cartilagе.

Conclusion

• Isolatеd chondrocytеs with suitablе growth factors can

rеgеnеratе cartilagе.

• Advancements in these areas may help in identifying factors

which could help in preventing and managing of osteoarthritis.

THANK YOU

Bibliography

• Kock L, van Donkelaar CC, Ito K. Tissue engineering of functional articular

cartilage: the current status. Cell and tissue research. 2012 Mar 1;347(3):613-27.

• Temenoff JS, Mikos AG (2000) Review: tissue engineering forregeneration of

articular cartilage. Biomaterials 21:431–440

• ΕngelA (1968) Osteoarthritis and body measurements. Vital HealthStat 11: 1–37
• Hunziker EB (2002) Articular cartilage repair: basic science andclinical progress. A

review of the current status and prospects.OsteoarthrCartil 10:432–463

• Buckwalter JA, Mankin HJ (1998)Articular cartilage repair and transplantation.

Arthritis Rheum 41:1331–1342

• Sandell LJ, Aigner T. Articular cartilage and changes in arthritis: cell biology of
• steoarthritis. Arthritis Research & Therapy. 2001 Jan 22;3(2):1.
• Buckwalter JA, Mankin HJ. Articular cartilage. Part II: Degeneration and
• stheoarthritis, repair, regenerationand transplantation. JBJS 1997;79:612–32.
• Newman AP. Articular cartilage repair. Am J SportsMed 1998;26(2):309–24.
• Meachim G, Brooke G: (1984) The pathology of osteoarthritis. In Osteoarthritis:

Diagnosis and Management. Edited by Moskowitz RW, Howell D S, Goldberg VM, Mankin HJ. Philadelphia:WB Saunders, 1984:29–42.

• Howell DS: Pathogenesis of osteoarthritis. Am J Med 1986, 80:24–28.
• Adams ME: Pathobiology of knee osteoarthritis. In Clinical Concepts in Regional Musculoskeletal Illness. Edited by

Hadler NM. Orlando: Grune and Stratton, 1987:137–167.

• Hamerman D: The biology of osteoarthritis. N Engl J Med 1989, 320:1322–1330.
• Schnabel M, Marlovits S, Eckhoff G, Fichtel I, Gotzen L, Vecsei V, Schlegel J. Dedifferentiation-associated changes in

morphology and gene expression in primary human articular chondrocytes in cell culture. Osteoarthritis and

• Cartilage. 2002 Jan 31;10(1):62-70.
• Bhosale AM, Richardson JB. Articular cartilage: structure, injuries and review of management. British medical
• bulletin. 2008 Sep 1;87(1):77-95.
• Buckwalter JA, Mankin HJ (1997) Articular cartilage: Part I: tissue design and chondrocytes matrix interactions. J

Bone Joint Surg, 79-A, 600–611.

• Chen ES, Frenkel SR, Di Cesare PE (1999) Repair of articular cartilage defects: Part I. Basicscience of cartilage
• healing. Am J. Orthop, 28, 31–33.
• 5Brittberg M (1996) Cartilage repair: on cartilaginous tissue engineering with the emphasis on chondrocyte
• transplantation. A doctoral thesis, p. 9.
• 6Hunziker E (1992) Articular cartilage structure in humans and experimental animals. In Kuettner KE, Schleyerbach

R, Peyron JG, Hascall VC (eds) Articular Cartilage Structure andOsteoarthritis. New York, NY: Raven Press, 183–199.

• Mankin HJ (1982) Current concepts review: the response of articular cartilage to mechanical injury. J Bone Joint

Surg, 64-A, 460–466.

• Goldring MB. Chondrogenesis, chondrocyte differentiation, and articular cartilage metabolism in health and
• steoarthritis. Therapeutic advances in musculoskeletal disease. 2012 Jun 1:1759720X12448454.
• Blagojevic, M., Jinks, C., Jeffery, A. and Jordan, K.P. (2010) Risk factors for onset of osteoarthritis of the knee in
• lder adults: a systematic review and metaanalysis. Osteoarthritis Cartilage 18: 24–33.
• Felson, D.T., Lawrence, R.C., Dieppe, P.A., Hirsch, R., Helmick, C.G., Jordan, J.M. et al. (2000) Osteoarthritis: new
• insights. Part 1: The Disease and its risk factors. Ann Intern Med 133: 635–646.
• Andriacchi, T.P., Mundermann, A., Smith, R.L., Alexander, E.J.,Dyrby, C.O. and Koo, S. (2004) A framework for the in

vivo pathomechanics of osteoarthritis at the knee. Ann Biomed Eng32: 447–457.

• Goldring, M.B. and Marcu, K.B. (2009) Cartilage homeostasis in health and rheumatic diseases. ArthritisRes Ther11:

224.

• Aigner, T., Fundel, K., Saas, J., Gebhard, P.M., Haag, J., Weiss, T. et al. (2006) Large-scale gene expression profiling

reveals major pathogenetic pathways of cartilage degeneration in osteoarthritis. Arthritis Rheum 54: 3533–3544.

• Ijiri, K., Zerbini, L.F., Peng, H., Otu, H.H., Tsuchimochi, K., Otero, M. et al. (2008) Differentialexpression of

GADD45beta in normal and osteoarthritic cartilage: potential role in homeostasis of articular chondrocytes. Arthritis Rheum 58: 2075–2087.

• Sato, T., Konomi, K., Yamasaki, S., Aratani, S., Tsuchimochi, K., Yokouchi, M. et al. (2006) Comparative analysis of

gene expression profiles in intact and damaged regions of human osteoarthritic cartilage. Arthritis Rheum 54: 808– 817.

• Loughlin, J. (2011) Genetics of osteoarthritis. CurrOpinRheumatol23: 479–483.
• Kannu, P., Bateman, J.F., Belluoccio, D., Fosang, A.J. and Savarirayan, R. (2009) Employing molecular genetics of

chondrodysplasias to inform the study of osteoarthritis. Arthritis Rheum 60: 325–334.

• Barter, M.J., Bui, C. and Young, D.A. (2012) Epigenetic mechanisms in cartilage and osteoarthritis: DNA

methylation, histone modifications and microRNAs. Osteoarthritis Cartilage 20: 339–349.

• Goldring, M.B. and Marcu, K.B. (2012) Epigenomicand microRNA-mediated regulation in cartilage development,

homeostasis, and osteoarthritis. TrendsMol Med 18: 109–118

• Iliopoulos, D., Malizos, K.N., Oikonomou, P. and Tsezou, A. (2008) Integrative microRNA and proteomic approaches

identify novel osteoarthritis genes and their collaborative metabolic and inflammatory networks. PLoS ONE 3: e3740.

• Jones, S.W., Watkins, G., Le Good, N., Roberts, S., Murphy, C.L., Brockbank, S.M.V. et al. (2009) The identification of

differentially expressed microRNA in osteoarthritic tissue that modulate the production of TNF-[alpha] and

• MMP13. Osteoarthritis Cartilage17: 464–472.
• Swingler TE, Wheeler G, Carmont V, Elliott HR, Barter MJ, Abu-Elmagd M, Donell ST, Boot-Handford RP, Hajihosseini

MK, Münsterberg A, Dalmay T. The expression and function of microRNAs in chondrogenesis and osteoarthritis. Arthritis & Rheumatism. 2012 Jun 1;64(6):1909-19.

• Cawston, T.E. and Wilson, A.J. (2006) Understanding the role of tissue degrading enzymes and their inhibitors in

development and disease. BestPract Res ClinRheumatol20: 983–1002.

• Plaas, A., Osborn, B., Yoshihara, Y., Bai, Y., Bloom, T., Nelson, F. et al. (2007) Aggrecanolysis in human osteoarthritis:

confocal localization and biochemical characterization of ADAMTS5-hyaluronan complexes in articular cartilages. OsteoarthritisCartilage 15: 719–734.

• Wu, W., Billinghurst, R.C., Pidoux, I., Antoniou, J., Zukor, D., Tanzer, M. et al. (2002) Sites of collagenase cleavage

and denaturation of type II collagen in aging and osteoarthritic articular cartilage and their relationship to the distribution ofmatrixmetalloproteinase 1 and matrix metalloproteinase 13. Arthritis Rheum 46: 2087–2094.

• Troeberg, L. and Nagase, H. (2012) Proteases involved in cartilage matrix degradation in osteoarthritis.

BiochimBiophysActa1824: 133–145.

• Tchetina, E.V., Squires, G. and Poole, A.R. (2005) Increased type II collagen degradation and very early focal

cartilage degeneration is associated with upregulation of chondrocyte differentiation related genes in early human articular cartilage lesions. J Rheumatol32: 876–886.

• Olivotto, E., Borzi, R.M., Vitellozzi, R., Pagani, S., Facchini, A., Battistelli, M. et al. (2008) Differential requirements

for IKKalpha and IKKbeta in thedifferentiation of primary human osteoarthritic chondrocytes. Arthritis Rheum 58: 227–239.

• BorzÌ, R.M., Olivotto, E., Pagani, S., Vitellozzi, R., Neri, S., Battistelli, M. et al. (2010) Matrix metalloproteinase 13 loss associated with

impaired extracellular matrix remodeling disrupts chondrocyte differentiation by concerted effects on multipleregulatory factors. Arthritis Rheum 62: 2370–2381

• Taniguchi, N., Carames, B., Ronfani, L., Ulmer, U., Komiya, S., Bianchi, M.E. et al. (2009) Agingrelatedloss of the chromatin protein HMGB2

in articular cartilage is linked to reduced cellularity and osteoarthritis. ProcNatlAcadSci U S A106: 1181–1186.

• Grogan, S.P., Miyaki, S., Asahara, H., D’Lima, D.D. and Lotz, M.K. (2009) Mesenchymal progenitor cell markers in human articular cartilage:

normal distribution and changes in osteoarthritis. Arthritis ResTher11: R85.

• Simon TM, Jackson DW. Articular cartilage: injury pathways and treatment options. Sports Medicine and Arthroscopy Review. 2006 Sep

1;14(3):146-54.

• Dowthwaite GP, Bishop JC, Redman SN, et al. The surface of articular cartilage contains a progenitor cell population. J Cell Sci.

2004;117(Pt 6):889–897.

• Borrelli J Jr, Ricci WM. Acute effects of cartilage impact. ClinOrthop. 2004;423:33–39.
• Buckwalter JA. Articular cartilage injuries. ClinOrthop. 2002;402:21–37.
• Fox AJ, Bedi A, Rodeo SA. The basic science of articular cartilage: structure, composition, and function. Sports Health: A Multidisciplinary
• Approach. 2009 Nov 1;1(6):461-8.
• Eggli PS, Herrmann W, Hunziker EB, Schenk RK. Matrix compartments in the growth place of the proximal tibia of rats. Anat Rec.

1985;211:246-257.

• Guilak F, Mow VC. The mechanical environment of the chondrocyte: a biphasic finite element model of cell—matrix interactions in

articular cartilage. J Biomech. 2000;33:1663-1673.

• Muir H. The chondrocyte, the architect of cartilage: biomechanics, structure, function and molecular biology of cartilage matrix
• molecules. Bioessays. 1995;17:1039-1048.
• Poole AR. Cartilage in health and disease. In McCarty DJ, ed.Arthritis and Allied Conditions: A Textbook of Rheumatology. Philadelphia, PA:

Lea &Febiger; 1993:279-333.

• Szirmai JA. Structure of cartilage. In: Engel A, Larsson T, eds. Aging of Connective and Skeletal Tissue. Stockholm, Sweden: Nordiska;

1969:163-200.

• Mow VC, Guo XE. Mechano-electrochemical properties of articular cartilage: their inhomogeneities and anisotropies. Annu Rev Biomed

Eng.2002;4:175-209.

• Alford JW, Cole BJ. Cartilage restoration, part I: basic science, historical perspective, patient evaluation and treatment options. Am J

Sports Med.2005;33:295-306.

• Buckwalter JA, Hunzinker E, Rosenberg L, et al. Articular cartilage: composition and structure. In: Woo SLY, Buckwalter JA, eds. Injury

andRepair of the Musculoskeletal Soft Tissues. Park Ridge, IL: American Academy of Orthopaedic Surgeons; 1988:405-425.

• Maroudas A, Wachtel E, Grushko G, et al. The effects of osmotic and mechanical pressure on water and

partitioning in articular cartilage. BiochemBiophysActa. 1991;1073:285-294.

• Torzilli PA. The influence of cartilage confirmation on its equilibrium water partition. J Orthop Res. 1985;3:473-483.
• Lai WM, Hou JS, Mow VC. A triphasic theory for the swelling and deformational behaviors of articular cartilage. J

Biomech Eng.1991;113:245-258.

• Linn FC, Sokoloff L. Movement and composition of interstitial fluid of cartilage. Arthritis Rheum. 1965;8:481-494.
• Maroudas A. Physiochemical properties of articular cartilage. In: Freeman MAR, ed. Adult Articular Cartilage. Kent,

United Kingdom: CambridgeUniversity Press; 1979:215-290.

• Mow VC, Kuei SC, Lai WM, Armstrong CG. Biphasic creep and stress relaxation of articular cartilage in compression:

theory and experiments. J Biomech Eng. 1980;113:73-84.

• Mow VC, Ratcliffe A, Poole AR. Cartilage and diarthrodial joints as paradigms for hierarchical materials and
• structures. Biomaterials. 1992;13:67-97.
• Hardingham T, Bayliss M. Proteoglycans of articular cartilage: changes in aging and in joint disease. Semin Arthritis
• Rheum. 1990;20(3)(suppl 1):12-33.
• Martin JA, Buckwalter JA. Telomere erosion and senescence in human articular cartilage chondrocytes. J Gerontol

A BiolSci Med Sci. 2001;56:B172-B179.

• Martin JA, Ellerbroek SM, Buckwalter JA. The age-related decline in chondrocytes response to insulin-like growth

factor-I: the role of growth factor binding proteins. J Orthop Res. 1997;15:491-498.

• Monfort J, Pelletier JP, Garcia-Giralt N, Martel-Pelletier J. Biochemical basis of the effect of chondroitin sulphate on
• steoarthritis articular tissues. Annals of the rheumatic diseases. 2008 Jun 1;67(6):735-40.
• Caterson B, Mahmoodian F, Sorrell JM, Hardingham TE, Bayliss MT, Carney SL, etal. Modulation of native

chondroitin sulphatestructure in tissue development and indisease. J Cell Sci 1990;97:411–17.

• Shinmei M, Miyauchi S, Machida A, Miyazaki K. Quantitation of chondroitin 4-sulfateand chondroitin 6-sulfate in

pathologic joint fluid. Arthritis Rheum 1992;35:1304–8.
