LISKEARD CATTLE MARKET ITERATION 01 CIRCULATION PRESENTATION ITERATION 01 INTRODUCTION This document summarises the extent of the progress made to date on the Liskeard Masterplan Proposal. The proposed masterplan has come as Feasibility a

SLIDE 1

LISKEARD

CATTLE

MARKET

ITERATION 01 CIRCULATION PRESENTATION

SLIDE 2

ITERATION 01

INTRODUCTION

This document summarises the extent of the progress made to date on the Liskeard Masterplan Proposal. The proposed masterplan has come as a product of a number of correspondences, meetings and a community planning workshop, which have all helped to inform the design. The masterplan will be continued to be developed through the next iterations, as the project team look to submit the masterplan proposal as an outline planning application and the Workshed as a full planning application by April 2020 as well as an ERDF application submittal by late November this year. This document will help to gain feedback from Cornwall Council and better inform the design team of their aspirations and needs for the site as well as the Workshed proposed as part of the masterplan scheme. With the scheme being broken up into two key elements this document has been structured using the following key headings: 1. Masterplan Proposal 2. The Workshed March February April May June July August September RIBA Stage 2 RIBA Stage 3 October November December

Community Planning Weekend Liskeard Feasibility Studies Masterplan Updates Brief/ Programme Development Planning Submission 13.04.20 Cabinet Meeting - Funding ERDF Funding Submission

Consultation

SLIDE 3

1 masterplan proposal

SLIDE 4

COMMUNITY PLANNING WEEKEND

8TH - 12TH MARCH 2019

SLIDE 5

New Community Vision for Liskeard Cattle Market

Regenerate the Cattle Market to create a new community heart which catalyses the “up-cycling” of the town; provide a mix of uses including community, arts and culture, enterprise, eating and selling; create fmexible, public space for markets and other activities; provide green spaces and accessible community gardens; connect to and serve the whole town, providing something for everyone. These are some of the ideas to emerge from the Liskeard Cattle Market Charrette held between Friday 8 to Tuesday 12 March to create a new Vision for this important site. The Charrette was an interactive planning and design event supported by national government and facilitated by architects and community planners JTP. It was an

pportunity for residents and local stakeholders to share

their local knowledge and ideas through facilitated workshops, walkabouts and hands-on planning groups. After the public workshop, the JTP team used the information gathered to draw up a Vision for the Cattle Market site, including an illustrative masterplan. This was presented back to the local community on Tuesday 12 March at the Eliot House Hotel. Following the Charrette, members of the Liskeard Cattle Market Working Group will review the outcomes of the fjve day event and develop a viable plan with partners and business cases for elements of the scheme, which will be used to support bids for funding. An updated masterplan will then be drawn up for public consultation before a fjnal masterplan and phased delivery plan is presented to key stakeholder groups.

Friday 08 March to Tuesday 12 March 2019

Liskeard Cattle Market Charrette Report Back Broadsheet

For more information on the Liskeard Cattle Market Charrette please visit jtp.co.uk/projects/liskeard or contact the JTP Community Planning team at community@jtp.co.uk or on Freephone 0800 0126730.

Background

In December 2017 the fjnal livestock sale was held at Liskeard Cattle Market and subsequent consultations have shown that there is strong support for redeveloping the site. The Liskeard Neighbourhood Plan 2018 encourages the development of, “a mix of uses that support the vitality and viability of the town centre (Cattle Market Policy TC4)”.

Liskeard Cattle Market Charrette Report Back Broadsheet

Friday 08 March to Tuesday 12 March 2019

Family Hub fronting Varley Lane Market Square looking East Market Square looking West Aerial view looking East

We should be upcycling people, upcycling the town!

Aerial view looking South West

SLIDE 6 For more information on the Liskeard Cattle Market Charrette please visit jtp.co.uk/projects/liskeard or contact the JTP Community Planning team at community@jtp.co.uk or on Freephone 0800 0126730.

D e a n Street B a r n S t r e e t

F a i r p a r k R

Barras Street Varley Lane

Illustrative Masterplan

Liskerrett Square Residential – repurposed Victorian school and high quality new build Flexible Hard Standing for community events / car parking access from Fairpark Rd Bastion Park - with views to south west Children & Family Hub Affordable Workspace “Kres an Rosow” – Community, Arts & Culture Loading Bay “Jynnji” – the engine room viewing tower Junction improvements and GP Surgery Extension Retain Gilberts Outfitters Retain Liskeard Market Cafe Retain and repurpose St John Ambulance building – reprovide for St John elsewhere on site Market Place Retail Units - retain and upgrade “Work Shed” Enterprise Space & Farm Shop Community Garden Hurlers Court Market Approach – pedestrianised with servicing access Barras St / Dean St Junction Remodelling – to improve the pedestrian experience 1 2 3 4 5 6 7 8 9 10 11 12 13

3 6 7 10 9 2 5 14 1 4 8 13 15 11 12 16 17 18

14 15 16 17 18 Key

SLIDE 7

ILLUSTRATIVE MASTERPLAN

PHASING STRATEGY

Phase 01 (including ERDF Work Shed) Phase 02 Phase 03

02 02 03 03

Phase Phase RIBA Work Stage 02 RIBA Work Stage 02 RIBA Work Stage 02 RIBA Work Stage 02 RIBA Work Stage 03 Phase Phase Phase

Access to area and existing properties to be maintained

SLIDE 8

2 the workshed

SLIDE 9

THE BRIEF & PROJECT DESCRIPTION

Develop Creative Workspace scheme to RIBA Stage 3 ahead of submission of an ERDF Full

Application due 1 December; located in the south east corner of the site

Design and build of fmexible managed offjce / workshop space.
Needs to be coherent and aligned with the other phases of the Cattle Market regeneration.
Targeted at small and micro businesses within digital and creative industries.
Designed to be as fmexible as possible (i.e. ability to remove / add partition walls).
Workspace needs a controlled access, overseen by an entrance/cofgee desk with breakout area.

1470 SQ.M.

GEA

1216 SQ.M.

GIA

SLIDE 10

WORKSHED DESIGN FRAMEWORK

STEP 01: DELIVERABLE FOOTPRINT

Work Shed Building Footprint

SLIDE 11

WORKSHED DESIGN FRAMEWORK

STEP 02: MASS BREAKDOWN INTO SMALLER VOLUMES

Collaborate Work Work

SLIDE 12

WORKSHED DESIGN FRAMEWORK

STEP 03: PUSHING MASS TO REVEAL MARKET SPACE

Pedestrian Flow

SLIDE 13

WORKSHED DESIGN FRAMEWORK

STEP 04: CREATING PUBLIC ENTRY POINT

Entrance

SLIDE 14

WORKSHED DESIGN FRAMEWORK

STEP 05: ACTIVE FRONTAGES ON ALL SIDE OF BUILDING

SLIDE 15

WORKSHED DESIGN FRAMEWORK

STEP 06: VISUAL CONNECTIONS THROUGH BUILDING

SLIDE 16

WORKSHED DESIGN FRAMEWORK

STEP 07: INTEGRATION WITH MASTERPLAN PROGRAMME

Community Building Market Square Market Canopy The WorkShed

SLIDE 17

WORKSHED DESIGN FRAMEWORK

ROOF PLAN WITH 1M SURROUNDING PERIMETER

Community Building Market Canopy The WorkShed

Extent of 1m perimeter line surrounding Workshed

SLIDE 18

WORKSHED ARCHITECTURAL LANGUAGE

ELEVATION DEVELOPMENT SKETCH

SLIDE 19

WORKSHED ARCHITECTURAL LANGUAGE

PRECEDENTS

Small Museum Pavillion - Von M Designers Bedales School Art & Design Building - FCB Studios Bedales School Art & Design Building - FCB Studios Small Museum Pavillion - Von M Designers Bedales School Art & Design Building - FCB Studios

SLIDE 20

WORKSHED ARCHITECTURAL LANGUAGE

PRECEDENTS

Manor Works Community building - Architecture 00 Museum Germany, Von M Museum Germany, Von M Manor Works Community building - Architecture 00

SLIDE 21

WORKSHED ARCHITECTURAL LANGUAGE

PRECEDENTS

Dockside - Graham Baba Architects Windermere Jetty Museum - Comardy Groake Newtownards Project - Wm Given Architects Newtownards Project - Wm Given Architects Wilberforce School - Jonathan Tuckey Studio
