SLIDE 1

Bronte Heritage Waterfront Park

13|JAN|31

Presentation for:

Performance Area | Tensile Structure Submitted by:

SLIDE 2

Bronte Heritage Waterfront Park Master Plan Process Initiated February 2008 Public Meeting June 2008 Town Council October 2008 Regional Council March 2009 Implementation Process Phase 1 Donor Recognition Area + Pathways completed Spring 2011 Phase 2 Open Space + Pathways + Grading completed Spring 2012 Phase 3A Stairway + Water Feature start Fall 2012 Phase 3B Gathering Space + Tensile Structure start Fall 2013 Phase 4 Washroom start Fall 2013 CHRONOLOGY

SLIDE 3

Bronte Heritage Waterfront Park REGIONAL PARK CONTEXT Lake Ontario

SLIDE 4

Bronte Heritage Waterfront Park MASTER PLAN (Original)

1. Main Park Entrance 2. Existing Parking 3. Pedestrian Entrance/Rest Node 4. Memorial Celebration Plaza w/Existing Gazebo a) Donor Pavers, Benches and Trees b) Floral Display Gardens 5. Original Lake Ontario Shoreline Feature a) Natural Stone Paving b) Native Plant Garden c) Interactive Water Feature d) Rockery Garden 6. Interpretive Node w/Seatwall and Planting 7. Open/Unstructured Green Space 8. Enhanced Existing Washroom Area 9. Naturalized Area

10. Celebration Plaza w/Bench Seating
11. Low Berm for Informal Seating

w/Sail Shade Structures

12. Waterfront Promenade w/Existing Tree Planting
13. Vegetative Barrier Planting for Geese Control
14. Shared Pedestrian/Service Access
15. Marina Restaurant
16. Marina Mooring Dock

10 1 2 3 3 3 4b 5b 7

8

9 12 2 14 13 2 15 11 6 5d 5a 5c 4a 4

Legend

Existing Deciduous Tree Existing Coniferous Tree Horticultural/Floral Display Native Perennial Planting Original Lake Ontario Shore-line Planting Strip/Rockery

16 16

Proposed Deciduous Tree Plaza/Specialty Paving Proposed Walkway Proposed Crosswalk Proposed Bench Seating Proposed Bike Storage Location

Approved FALL|2009

10 20 30 50 metres 40 5

Naturalized Area Turf/Open Space

Lake Ontario

SLIDE 5

Bronte Heritage Waterfront Park

1. Main Park Entrance (Vehicular + Pedestrian) 2. Existing Parking 3. Pedestrian Entrance/Rest Node (Phase 3) a) Major Pedestrian Entrance Node b) Lookout w/Seating c) Steps w/Planted Terrace and new Walkway d) Memorial w/Plaza Area 4. Phase 1: Memorial Celebration Plaza w/Existing Gazebo a) Donor Pavers, Benches and Trees b) Floral Display Gardens 5. Original Lake Ontario Shoreline Feature (Phase 3) a) Natural Stone b) Native Plant Garden c) Interactive Water Feature d) Rockery Garden 6. Interpretive Node w/Seatwall and Planting 7. Open/Unstructured Green Space 8. Enhanced Existing Washroom Area 9. Naturalized Area

10. Celebration Plaza w/Tensile Structure (Phase 3A)
11. Low Berm for Informal Seating w/Sail Shade

Structures

12. Waterfront Promenade w/Existing Tree Planting
13. Vegetative Barrier Planting for Geese Control
14. Shared Pedestrian/Service Access
15. Marina Restaurant
16. Service Access Entry w/Removable Bollard
17. Marina Mooring Dock

MASTER PLAN (Revised)

10 1 2 3 3 3 4b 5b 7

8

9 12 2 14 13 2 15 6 5d 5a 5c 4a 4

Legend

17 17

10 20 30 50 metres 40 5

3a 3b 3c 3d 11 16

13|JAN|31

Horticultural/Floral Display Native Perennial Planting Original Lake Ontario Shore-line Planting Strip/Rockery Plaza/Specialty Paving Proposed Walkway Proposed Crosswalk Proposed Bench Seating Proposed Bike Storage Location Naturalized Area Turf/Open Space Existing Deciduous Tree Existing Coniferous Tree Proposed Deciduous Tree

Lake Ontario

SLIDE 6

Bronte Heritage Waterfront Park

3A 3A 3B 4 2 2 1

PHASING DIAGRAM

PHASE 1 (MEMORIAL GARDEN: COMPLETED SPRING 2011 ) PHASE 2 (CONSTRUCTION COMPLETED SPRING 2012) PHASE 3A (CONSTRUCTION COMMENCED FALL 2012) LEGEND PHASE 3B (CONSTRUCTION TO COMMENCEMENT FALL 2013) PHASE 4 (WASHROOM BUILDING: COMMENCEMENT FALL 2013) 13|JAN|31

SLIDE 7

Bronte Heritage Waterfront Park

1.

Tensile Sail over Plaza Area

2.

Concrete Plaza/Performance Area

3.

Paved Plaza Area

4.

Walkway Connection to Pier

5.

Sloped Turf Area for informal seating

6.

Original Lake Ontario Shoreline

7.

Planting Areas w/radial Planting Beds

8.

Shade Sails

9.

Open Grass Area

10.

Truck Access to Portable Stage Area @4.0m (13.12 ft.) wide

11.

Existing Concrete Pier w/enhanced paving pattern

12.

Walkway (@2m/6.56 ft. wide)

13.

Armourstone Seatwall

2 1 3 4 4 12 5 6 7 7 7 7 8 9 9 6 11 11 10

PERFORMANCE AREA

Performance Area

LEGEND Key Plan

3 9 13

Existing Light Fixtures to remain 13|JAN|31

Lake Ontario

SLIDE 8

Bronte Heritage Waterfront Park PERFORMANCE AREA

Surface Treatment

Key Plan LEGEND 1a 1b

2b 8 1a 1b 1a 1b 2c 2c 2a 2c 2c 4 4 4 4 4 5 6 6 7 7 7 7 7 9 9 9 9 9 3 2a 7 9

1.

Plaza Area Vehicular Colour Concrete: Pebble Grey by Artevia a) Sandblast Finish b) Light Broom Finish

2.

Precast Unit Pavers by Unilock a) Umbriano Colour: Winter Marvel b) Series 3000 Colour: Ice Grey c) Umbriano Colour: Midnight Sky

3.

P.I.P Concrete (Pedestrian)

4.

Existing Concrete Pier w/enhanced paving pattern

5.

Sloped Turf Area for informal seating

6.

Original Lake Ontario Shoreline

7.

Planting Area w/radial Design Beds

8.

Open Space Turf Area

9.

Concrete Footings for Tensile Structure (protected in planting areas)

10.

Raised Curb planter

11.

Armourstone Seatwall 4/4a 2a 2b 2c

11 11

13|JAN|31

10

Lake Ontario

SLIDE 9

Bronte Heritage Waterfront Park PERFORMANCE AREA

Planting Plan

Key Plan LEGEND

8 1

1.

(Cs) Corus sericea; Red Osier Dogwood (Native Deciduous Shrub) 1.2m/3.9 ft. ht..

2.

(Js) Juniperous sabina; Savin Juniper (Evergreen Shrub) 1.2m/3.9 ft. ht.

3.

(Tm) Taxus x media ‘Wardii’; Wards Yew (Evergreen Shrub) 0.6m- 1.0m/ 1.9 ft.-3.2 ft.ht.

4.

(Ami) Achillea millefolium; Common Yarrow (Naturalized Perennial) 0.3m- 1m/0.9 ft.-3.2 ft.ht.

5.

(Hem) Hemerocallis fulvaTawny; Daylily (Naturalized Perennial) 0.45m-1.5m/1.4 ft.-4.9 ft.ht..

6.

(Rtr) Rudbekia triloba Brown-eyed Susan (Native Perennial) 0.6m-0.9m/1.9 ft-2.9 ft.ht.

7.

(Saj) Sedum ‘Autumn Joy’; Stonecrop (Perennial)

0.3m- 0.45m/0.9 ft.-1.4 ft.ht.

8.

(Snu) Sorghastrum nutans ; Indiangrass (Native Grass) 1.2m-2.0m/3.9 ft.-6.5 ft.ht.

9.

(Szs) Schizachyrium scoparium; Little Bluestem (Native Grass) 1.0m-1.2m ht./3.2 ft.-3.9 ft.ht.

10.

(Qa) Quercus alba; White Oak (Native Deciduous Tree)

11.

Transplanted trees

12.

Existing Trees

2 1 2 2 3 3 3 3 3 3 9 9 4 4 4 5 6 6 6 6 7 7 7 11 11 11 11 10 10 12 12 12 12 12

1 2 3 Shrubs 4 5 6 7 Perennials 8 9 Grasses

1 3 5 metres 1 4 2

13|JAN|31

SLIDE 10

Bronte Heritage Waterfront Park

1 2 5 metres 1 4 3

1 2 3 7 9 10 4 5 6 9 8 3 3 3 6 6 5 5 10 12

PERFORMANCE AREA

Section/Elevation

1.

Corus sericea; Red Osier Dogwood (Native Deciduous Shrub) 1.2m/3.9 ft. ht.

2.

Juniperous sabina; Savin Juniper (Evergreen Shrub) 1.2m/3.9 ft. ht.

3.

Taxus x media ‘Wardii’; Wards Yew (Evergreen Shrub) 0.6m- 1.0m/ 1.9 ft.-3.2 ft.ht.

4.

Hemerocallis fulva; Tawny; Daylily (Naturalized Perennial) 0.45m-1.5m/1.4 ft.-4.9 ft.ht.

5.

Rudbekia triloba; Brown-eyed Susan (Native Perennial) 0.6m-0.9m/1.9 ft-2.9 ft.ht.

6.

Sedum ‘Autumn Joy’; Stonecrop (Perennial) 0.3m-

0.45m/0.9 ft.-1.4 ft.ht.

7.

Sorghastrum nutans ; Indiangrass (Native Grass)

1.2m-2.0m/3.9 ft.-6.5 ft.ht.

8.

Proposed Quercus alba; White Oak (Native Deciduous Tree)

9.

Transplanted existing Trees

10.

Existing Trees to remain

11.

Informal Seating/Earth Berm

12.

Armourstone Seatwall

13.

Paved Plaza Area

14.

2.0m (6.56 ft) wide Concrete Walkway

15.

Raised Curb Planting Area

16.

Colour Concrete Plaza/Performance Area

17.

Planting Area

18.

2.0m (6.56 ft.)Paved Walkway

19.

Existing Concrete Pier

20.

Tensile Structure over Stage Area

11 12 13 15 16 17 18 17 19

Key Plan LEGEND

11 14 14 13 15 20 16 17 17 18 19

13|JAN|31 13.425m (44.0ft) 4.5m (14.8ft) 6.5m (21.83t)

SLIDE 11

Bronte Heritage Waterfront Park

1.

Condo and Proposed Site Development

2.

Ontario Street

3.

3.0m (9.84 ft) wide Concrete Walkway

4.

Park/Open Space w/existing Trees

5.

Shared Service Access

6.

Informal Seating/Earth Berm

7.

Armourstone Seatwall

8.

Proposed Tree Planting

9.

Paved Plaza Area

10.

Colour Concrete Plaza/Performance Area

11.

Raised Curb Planting Area

12.

Planting Area

13.

2.0m (6.56 ft) wide Paved Walkway

14.

Existing Concrete Pier

15.

Tensile Structure over Plaza Area

16.

Transplanted trees

17.

Existing Trees

1 3 5 16 4 8 17 2 6

VIEW SHED From Bronte Road + Condo

7 9 11 15 10 12 13 14

Key Plan

12 4 A A 17 17 17 3 16

5 20 metres 5 15 10

Ontario Street

Lake Ontario

13|JAN|31

SLIDE 12

Bronte Heritage Waterfront Park

Tensile Structures @ Celebration Park, Allen Texas

5 20 metres 5 15 10

13|JAN|31

SLIDE 13

Bronte Heritage Waterfront Park

PERSPECTIVE 1 View West from Harbour

Key Plan 13|JAN|31

Lake Ontario

SLIDE 14

Bronte Heritage Waterfront Park

PERSPECTIVE 2 View Southwest from Promenade

Lake Ontario

13|JAN|31

SLIDE 15

Bronte Heritage Waterfront Park

PERSPECTIVE 3 Bird’s-eye View Southwest

13|JAN|31

Lake Ontario

SLIDE 16

Bronte Heritage Waterfront Park

PERSPECTIVE 4 Eye-level View Southwest

13|JAN|31

SLIDE 17

Bronte Heritage Waterfront Park

PERSPECTIVE 5 Eye-level View Southwest

13|JAN|31

SLIDE 18

Bronte Heritage Waterfront Park

Thank you

Discussion
