Berkenhoff GmbH Company profile Berkenhoff / 30.10.2012
Berkenhoff in detail Under its corporate trademark bedra ( Be rkenhoff Dra ht) Berkenhoff produces and distributes innovative non-ferrous wires for � spark erosion � welding � electronics & special applications Berkenhoff / 30.10.2012
Berkenhoff in detail • 2 production sites � 70 km north of Frankfurt •distribution agencies and partners in more than 80 countries Berkenhoff GmbH 35452 Heuchelheim 35745 Herborn Berkenhoff / 30.10.2012
Berkenhoff in detail Key figures Berkenhoff Employees Areal Turnover Capacity � 346.110 m² � 11.000 to / year � 470 � 111 Mio. €uro Berkenhoff / 30.10.2012
Berkenhoff in detail Turnover by business unit (%) 42 25 33 EDM ELAS Welding Berkenhoff / 30.10.2012
Berkenhoff in detail Turnover by region Rest of world America 1% 19% Europe without Germany Asia 36% 5% Germany 39% Berkenhoff / 30.10.2012
Production Process Plant Kinzenbach Plant Merkenbach bedra pre-material primary drawing, annealing, smelting, continuous casting, electroplating, fine drawing, cold rolling, annealing, drawing profiling EDM wire, electronic wire welding wire, optical & special anchor wire, special wire wire, redrawing wire Berkenhoff / 30.10.2012
Production Process All from one source: the Berkenhoff in-house concept • Own R&D department, numerous patents • Certificated allover quality testing programme • • DIN EN ISO 9001:2008 From melting to final packaging: • bedra products are completely made in Germany Our in-house concept allows complete traceability and quality • control The production process at a glance: • Berkenhoff / 30.10.2012
Production Process Foundry • � More than 100 different alloys � Only high-grade virgin metals � High-level quality, are used reproducible alloys � Extensive analysis � Tightest alloy tolerances Berkenhoff / 30.10.2012
Production Process Annealing • � Prior to rod drawing: � Gentle microstructure long-time annealing under transformation protective atmosphere � Embrittlement of the metal � Followed by: Annealing passes excluded after each rolling / drawing pass � Optimal formability if required Berkenhoff / 30.10.2012
Production Process Wire drawing / rolling • � Fine drawing with diamond � Optimal wire surface, e.g. no grooves dies � Highly precise wire diameter � Permanent laser monitoring � constant quality � Process integrated annealing drawing rolling Berkenhoff / 30.10.2012
Production Process Electroplating • � Modern, high performance � Various coating variants electrolytes � Consistent surface quality � Highly pure tin anodes � Certified quality on the highest level � Multilayer -, Reflow technology � Strict fulfilment of all environmental � Internal inspections in own guidelines laboratory Berkenhoff / 30.10.2012
Overview of the alloys Brass Tin bronze Nickel silver Copper wires wires wires wires 0,05 mm to 0,05 mm to 0,02 mm to 0,10 mm to 8,00 mm 11,50 mm 8,00 mm 8,00 mm plain, electro tin- plain, electro tin- plain, electro tin- plain, electro tin- plated and zinc- plated and silver- plated and silver- plated, silver-plated plated, with Ni and/ plated, with Ni and/ plated, with Ni and / and zinc-plated or Cu barrier layer or Cu barrier layer or Cu barrier layer Special alloys on request Berkenhoff / 30.10.2012
Business Units business units EDM Welding ELAS (wires for spark erosion) (welding & brazing wires) (electronic-/ anchor-/ special wires) plain wires coated wires profiled wires anchor wires for special wires for electronics tooth brushes Berkenhoff / 30.10.2012
Business Units Wire electrodes for spark erosion bedra markets � Tool- and Mouldmaking industry � Automotive industry � Household appliances � Electronics industry � Machine building ind. � Mechanical enginee- ring � Telecommunications Materials � Packaging industry � Plain brass alloys � Watch making industry � Coated brass alloys � Toys industry � Diffusion annealed brass alloys � Composite materials � Aviation industry � Optical industry � Medical technology Berkenhoff / 30.10.2012
Business Units Wires for brazing & welding bedra customers bedra markets � VW Transportation enginee- ring � Audi � Automotive industry � Fiat � Track construction � Seat � Shipbuilding � BMW � Motor bike industry � Skoda � Bicycle industry � Opel � Agricult. mach. ind. � Ford � Military engineering � PSA � Daimler Plant engineering � Hyundai � Offshore / Onshore Materials: � Daewoo � Turbine building � Renault � Mould and tool � Low alloyed copper alloys � Tin bronzes making � Honda � Aluminium bonzes � Mining � Suzuki � Copper nickel alloys � Container building � Yamaha � Maersk Building industry � MTU � Civil engineering � ABB � Building machinery Berkenhoff / 30.10.2012
Business Units Profiled wires for electronics bedra markets bedra customers � Automotive industry � Tyco � Industrial electronics � Molex � Telecommunications � Bosch � Information technology � FCI � Consumer electronics � Delphi � Medical technology � Valeo � Military engineering Materials � Aviation and aero- � Tin bronze alloys space technology � Brass alloys � Lighting engineering � Nickel silver alloys � Civil engineering � Copper materials � Highly conductive alloys � Agriculture & forestry � Spinodal alloys � Special alloys Wire geometries: Round wires, Square profiles, Flat profiles, Serrated wires, Special profiles on request Surface refinement: Electroplated wires, Multi-layer technology, Reflow technology Berkenhoff / 30.10.2012
Business Units Anchor wires bedra markets bedra customers � Colgate- � Toothbrush Palmolive industry � Oral-B � Braun � Gillette � Procter & Gamble Materials � Nickel silver alloys � Brass alloys � Special alloys Wire geometries: Flat profile grooved, Flat profile ungrooved Berkenhoff / 30.10.2012
Business Units Special wires bedra markets � Medical instruments � Optical industry � Jewellery � Bottle nets � Springs, pins, rivets � Decoration, gift articles Berkenhoff / 30.10.2012
Summary of the key facts What makes bedra a premium product? Product range: Quality: � More than 100 alloys � Certified Quality Management System acc. to ISO 9001 � All packagings � Complex product inspection at � Varied diameters each stage of manufacture Berkenhoff: � Tightest tolerances for optimum processing results � Made in Germany Service: � Complete in-house production � Highly qualified employees � Global sales � Expertise in wire � On-site Service � 120 years of experience � Customized solutions � Environmental Management � Extensive sampling System certified acc. to ISO 14001 � Free 3.1 inspection certificate � Own R&D department Berkenhoff / 30.10.2012
What makes bedra a premium product? Berkenhoff: Competition: Own foundry – homogeneous initial Purchase of redrawing material – variations in microstructure, extensive alloy quality control quality Use of virgin metals – high-purity alloys Use of scrap – undesired accompanying elements Tightest alloy tolerances – highest process Wide alloy tolerances acc. to international stability standards– instable process Use of natural diamonds as drawing dies, Industrial diamonds, die polishing performed own die polishing shop – homogeneous by outside contractors – non-uniform wire surfaces surfaces Long-time annealing – gentle microstructural Fast continuous annealing – high porosity of transformation – homogeneous, fine-grained the surface, embrittlement of the wire microstructure, reliable straightness Inhouse R&D – customized alloys Production of standard alloys Reproducible quality at the highest level Variations in quality, lack of process stability Berkenhoff / 30.10.2012
