slide-1
SLIDE 1

ASIC ¡Development ¡for ¡Future ¡ Experiments ¡ ¡

Henrik ¡von ¡der ¡Lippe ¡ LBNL ¡ ¡

slide-2
SLIDE 2

General ¡Outline ¡

  • Introduction ¡
  • A ¡glance ¡at ¡the ¡current ¡ITRS ¡roadmap ¡for ¡analog ¡
  • Some ¡65nm ¡device ¡test ¡results ¡
  • Some ¡examples ¡of ¡current ¡projects ¡
  • FEI4 ¡(ATLAS) ¡
  • ATPIX65 ¡(LBNL) ¡
  • MAPS ¡(LBNL) ¡ ¡
  • HIPPO ¡(LBNL) ¡
  • Conclusions ¡
slide-3
SLIDE 3

Introduction ¡

  • Performance ¡and ¡functionality ¡of ¡integrated ¡circuits ¡continued ¡to ¡

increase ¡over ¡the ¡past ¡few ¡decades. ¡ ¡

  • Technology ¡scaling ¡(down) ¡has ¡fueled ¡what ¡is ¡known ¡as ¡Moore’s ¡law ¡(or ¡

is ¡it ¡vice ¡versa?): ¡the ¡number ¡of ¡components ¡per ¡chip ¡roughly ¡doubles ¡ every ¡24 ¡months. ¡

  • Transistor ¡dimensions ¡(width, ¡length ¡and ¡gate ¡thickness) ¡are ¡

continuously ¡decreased ¡and ¡so ¡are ¡the ¡metal ¡pitch ¡while ¡the ¡number ¡

  • f ¡metal ¡levels ¡has ¡been ¡increased. ¡ ¡
  • Process ¡optimization ¡for ¡some ¡niche ¡market ¡(like ¡RF) ¡has ¡also ¡led ¡to ¡

multi-­‑threshold ¡and ¡multi-­‑supply ¡transistors ¡along ¡with ¡high ¡quality ¡

  • passives. ¡
slide-4
SLIDE 4

Introduction ¡

  • While ¡scaling ¡down ¡is ¡still ¡going ¡on, ¡industry ¡experts ¡are ¡already ¡

introducing ¡the ¡concept ¡of ¡“more ¡than ¡Moore” ¡to ¡prevent ¡the ¡increase ¡

  • f ¡performance ¡of ¡ICs ¡from ¡slowing ¡down ¡(physical ¡scaling ¡down ¡will ¡

ultimately ¡be ¡unpractical). ¡

  • Without ¡ ¡the ¡advances ¡in ¡IC ¡technology, ¡some ¡important ¡HEP ¡projects ¡

(at ¡some ¡crucial ¡time) ¡would ¡not ¡have ¡been ¡feasible ¡or ¡would ¡have ¡ required ¡specialized ¡ ¡low ¡yield, ¡low ¡performance, ¡high ¡cost ¡processes. ¡

  • The ¡future ¡will ¡be ¡no ¡different. ¡Complex ¡and ¡challenging ¡

instrumentation ¡projects ¡(Upgrades, ¡SLHS, ¡new ¡Detector ¡concepts) ¡ will ¡require ¡the ¡adoption ¡of ¡the ¡ever ¡more ¡empowering ¡(and ¡more ¡ complex) ¡IC ¡technologies. ¡This ¡is ¡exemplified ¡by ¡recent ¡design ¡ activities ¡using ¡the ¡65nm ¡CMOS ¡node, ¡which ¡is ¡the ¡state ¡of ¡the ¡art ¡for ¡ this ¡community. ¡This ¡talk ¡will ¡briefly ¡describe ¡some ¡of ¡the ¡prototyping ¡ work ¡in ¡65nm ¡CMOS ¡(mainly). ¡ ¡

slide-5
SLIDE 5

Industry ¡and ¡HEP ¡IC ¡“nodes” ¡

  • A. Baschiro+o, ¡University ¡of ¡Milano-­‑Bicocca ¡

“LV ¡Analog ¡Design ¡in ¡scaled ¡CMOS ¡technology” ¡ ¡ (image ¡without ¡the ¡HEP ¡figures) ¡

250nm, ¡70Mrad ¡special ¡layout ¡ 130nm, ¡250M`rad ¡ 65nm, ¡>200Mrad ¡

HEP ¡projects, ¡even ¡though ¡lagging ¡mainstream ¡technology, ¡are ¡benefi?ng ¡from ¡ Technology ¡scaling. ¡There ¡should ¡be ¡a ¡“topical” ¡Moore’s ¡law. ¡ ICs ¡are ¡only ¡one ¡part ¡of ¡an ¡instrumentaIon ¡system! ¡ ¡Is ¡detector ¡technology ¡keeping ¡pace? ¡ ¡

5 ¡

slide-6
SLIDE 6

ITRS performance RF/Analog roadmap ¡

Year of Production è 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 Supply voltage (V) 1.1 1.05 1.05 1.05 1 0.95 0.95 0.95 0.85 0.85 0.85 0.85 0.75 Tox (nm) 1.2 1.2 1.2 1.2 1.10 1.10 1.10 1.10 1.10 1.00 1.00 0.90 0.90 Gate Length (nm) 38 38 32 29 27 22 18 17 15 14 13 12 11 gm/gds at 5·Lmin-digital 30 30 30 30 30 30 30 30 30 30 30 30 30 1/f-noise (µV²·µm²/Hz) 100 90 80 70 70 60 50 50 40 40 40 30 30 s Vth matching (mV·µm) 5 5 5 5 5 5 5 5 5 5 5 4 4 Ids (µA/µm) 9 9 8 7 7 6 5 4 4 3 3 3 2 Peak Ft (GHz) 240 240 280 310 340 400 480 520 570 630 680 750 820 Peak Fmax (GHz) 290 290 340 380 420 510 610 670 740 820 900 990 1090 NFmin (dB) 0.2 <0.2 <0.2 <0.2 <0.2 <0.2 <0.2 <0.2 <0.2 <0.2 <0.2 <0.2 <0.2

NoIce ¡difference ¡between ¡Performance ¡versus ¡precision ¡(next ¡slide) ¡ ITRS ¡key: ¡Yellow=soluIon ¡known ¡but ¡not ¡opImized. ¡Red= ¡soluIon ¡not ¡known. ¡ ¡ hXp://www.itrs.net/ ¡ 6 ¡

slide-7
SLIDE 7

¡ITRS ¡Precision ¡Analog/RF ¡roadmap ¡

Year of Production è 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 Supply voltage (V) 2.5 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.5 1.5 1.5 Tox (nm) 5 3 3 3 3 3 3 3 3 3 2.6 2.6 2.6 Gate Length (nm) 250 180 180 180 180 180 180 180 180 180 130 130 130 gm/gds at 10·Lmin-digital 220 160 160 160 160 160 160 160 160 160 110 110 110 1/f Noise (µV²·µm²/Hz) 1000 360 360 360 360 360 360 360 360 360 270 270 270 s Vth matching (mV·µm) 9 6 6 6 6 6 6 6 6 6 5 5 5 Peak Ft (GHz) 40 50 50 50 50 50 50 50 50 50 70 70 70 Peak Fmax (GHz) 70 90 90 90 90 90 90 90 90 90 120 120 120

Ø Tox ¡decreasing: ¡beXer ¡ionizing ¡radiaIon ¡resistance. ¡Gate ¡rupture? ¡Other ¡problems? ¡ Ø Gm/gds ¡decreasing: ¡Lower ¡gain ¡ Ø 1/f ¡noise ¡decreasing. ¡ Ø Matching ¡improving ¡(barely ¡and ¡only ¡for ¡analog ¡devices) ¡ Ø Speed ¡increasing ¡ Ø Supply ¡voltage ¡decreasing: ¡reduced ¡Dynamic ¡range. ¡ Ø Other: ¡gate ¡leakage, ¡off ¡current, ¡variability ¡of ¡non ¡analog ¡transistors ¡… ¡ 7 ¡

slide-8
SLIDE 8

¡The ¡main ¡design ¡challenges ¡(some) ¡

8 ¡

Gate ¡leakage ¡ Big ¡problem ¡biasing/controlling ¡large ¡ number ¡of ¡transistors ¡in ¡parallel ¡ (pixels). ¡ Current ¡is ¡proporGonal ¡to ¡gate ¡area: ¡ can ¡be ¡problemaGc ¡for ¡low ¡noise ¡large ¡ cap ¡FENDs ¡(wide ¡input ¡transistor) ¡ ¡ Be ¡aware ¡of ¡the ¡problem. ¡Can ¡be ¡

  • serious. ¡RealisGc ¡simulaGons ¡is ¡a ¡must. ¡

Design ¡bias ¡DACs ¡to ¡handle ¡the ¡excess ¡

  • current. ¡

Use ¡higher ¡voltage ¡devices, ¡if ¡possible ¡ (be ¡aware ¡of ¡radiaGon ¡issues). ¡ Off ¡leakage ¡ current ¡ ¡ Problem ¡for ¡low ¡current ¡circuits. ¡May ¡ lead ¡to ¡higher ¡power ¡(increase ¡

  • peraGng ¡currents ¡to ¡dwarf ¡leakage) ¡ ¡

Use ¡low ¡leakage ¡transistor ¡variants ¡ (order ¡of ¡magnitude ¡lower). ¡ CreaGvely ¡live ¡with ¡it. ¡ Low ¡Supply ¡ voltage ¡ Reduced ¡Dynamic ¡range. ¡May ¡lead ¡to ¡ higher ¡analog ¡power. ¡Problem ¡for ¡high ¡ precision/accuracy ¡systems ¡ ¡ Use ¡rail ¡to ¡rail ¡circuits. ¡LV ¡circuits ¡ techniques… ¡ ¡ Highly ¡layout ¡ dependent ¡ device ¡ parameters ¡ Makes ¡design ¡more ¡complex. ¡Requires ¡ a ¡high ¡quality ¡design ¡kit ¡ Read ¡the ¡manuals ¡(obvious ¡but ¡…). ¡ Check ¡the ¡effects ¡are ¡back ¡annotated ¡ for ¡simulaGons. ¡ ¡

It ¡is ¡only ¡a ¡problem ¡of ¡degree. ¡Analog ¡design ¡has ¡always ¡been ¡about ¡designing ¡working ¡ circuits ¡using ¡imperfect ¡devices. ¡ ¡Good ¡circuits ¡were ¡designed ¡in ¡NMOS ¡only, ¡single ¡metal, ¡ single ¡poly ¡processes! ¡ ¡Read ¡IEEE ¡JSSC! ¡

slide-9
SLIDE 9

ITRS ¡bipolar ¡Roadmap ¡

Year of Production 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 1/f-noise (µV²·µm²/Hz) 2 1.5 1.5 1.5 1 1 1 1 1 1 1 1 1 s current matching (%·µm) 2 2 2 2 2 2 2 2 2 2 2 2 2 High Speed NPN (HS NPN) - Common to mmWave Table Emitter width (nm) 130 120 110 105 95 90 85 80 75 70 65 65 60 Peak fT (GHz) 265 285 305 325 345 365 385 405 425 445 465 485 505 Peak fMAX (GHz) 310 350 390 430 470 510 550 590 630 670 710 750 790 Maximum Available Gain (dB) @ 60 GHz 12.0 12.9 13.6 14.3 15.0 15.6 16.1 16.6 17.1 17.5 18.0 18.4 18.7 Maximum Available Gain (dB) @ 94 GHz 8.0 8.9 9.6 10.3 11.0 11.6 12.1 12.6 13.1 13.5 14.0 14.4 14.7 BVCEO (V) 1.7 1.7 1.6 1.6 1.5 1.5 1.4 1.4 1.4 1.3 1.3 1.3 1.2 High Speed PNP (HS PNP) Emitter width (nm) 500 500 300 300 200 200 200 200 200 150 150 150 150 Peak fT (GHz) 25 40 60 80 85 95 105 115 125 135 145 155 165 Peak fMAX (GHz) 40 50 80 90 95 105 115 130 140 150 160 170 180 BVCEO (V) 5.5 4.0 3.0 2.5 2.2 2.0 1.9 1.8 1.7 1.6 1.5 1.4 1.4

For ¡specialized ¡projects. ¡ Main ¡challenge: ¡breakdown ¡voltage ¡ge\ng ¡lower. ¡

9 ¡

slide-10
SLIDE 10

Advanced ¡IC ¡processes ¡are ¡available ¡thru ¡ brokers ¡

32 ¡nm ¡ ¡ 0.9 ¡/1.5 ¡ ¡ 7th ¡generaGon ¡IBM ¡SOI ¡technology ¡improves ¡energy ¡savings ¡for ¡high-­‑ performance ¡servers, ¡printers, ¡storage ¡devices; ¡networking, ¡mobile, ¡consumer, ¡ and ¡game ¡applicaGons. ¡Trusted ¡foundry ¡access ¡only.1 ¡ ¡ 45 ¡nm ¡ ¡ 1.0 ¡/0.9 ¡ ¡ This ¡energy-­‑saving ¡SOI ¡process ¡is ¡suitable ¡for ¡a ¡broader ¡range ¡of ¡consumer ¡ electronics, ¡including ¡digital ¡TVs ¡and ¡high-­‑end ¡mobile ¡applicaGons. ¡Trusted ¡ foundry ¡access ¡only.1 ¡ ¡ 65 ¡nm ¡ ¡1.0 ¡/1.8, ¡2.5 ¡ ¡Excellent ¡for ¡consumer ¡electronics, ¡wireless ¡communicaGons, ¡and ¡other ¡ applicaGons ¡requiring ¡high ¡performance ¡or ¡system-­‑on-­‑a-­‑chip. ¡Trusted ¡foundry ¡ access ¡only.1 ¡ ¡ 1.2 ¡/2.5 ¡ ¡ Tailored ¡for ¡power-­‑sensiGve ¡applicaGons ¡in ¡wireless ¡communicaGons ¡and ¡ consumer ¡electronics. ¡Trusted ¡foundry ¡access ¡only.1 ¡ ¡ 90 ¡nm ¡ ¡ 1.0 ¡/2.5 ¡ ¡ Ideal ¡for ¡leading-­‑edge ¡microprocessors, ¡communicaGons, ¡and ¡computer ¡data ¡ processing ¡applicaGons. ¡Trusted ¡foundry ¡access ¡only.1 ¡ ¡ 1.2 ¡/2.5 ¡ ¡ Use ¡for ¡low-­‑cost, ¡high ¡performance ¡wireless ¡applicaGons, ¡as ¡Bluetooth, ¡WLAN, ¡ cellular ¡handsets, ¡mobile ¡TV, ¡WiMax, ¡UWB ¡and ¡GPS. ¡Trusted ¡foundry ¡access ¡only.

1 ¡ ¡

130 ¡ nm ¡ ¡ 1.2 ¡/2.5 ¡ ¡ Use ¡for ¡low-­‑cost, ¡high ¡performance ¡wireless ¡applicaGons ¡as ¡Bluetooth, ¡WLAN, ¡ cellular ¡handsets ¡and ¡GPS. ¡ ¡ 1.2 ¡/2.5 ¡ ¡ Similar ¡to ¡8RF-­‑DM, ¡but ¡uses ¡LM ¡top ¡metal. ¡ ¡ 40 ¡ nm ¡ ¡ ¡ Low-­‑power ¡logic ¡ ¡ 65 ¡ nm ¡ ¡ ¡ Standard ¡logic, ¡RPO ¡ ¡ Mixed-­‑mode/RF, ¡RPO, ¡MiM ¡ ¡ 90 ¡ nm ¡ ¡ ¡ Standard ¡logic, ¡RPO ¡ ¡ Mixed-­‑mode/RF, ¡RPO, ¡MiM ¡ ¡ 0.13 ¡ µm ¡ ¡ ¡ Standard ¡logic, ¡RPO ¡ ¡ Mixed-­‑mode, ¡RPO, ¡MiM ¡ ¡ Low-­‑power ¡logic, ¡RPO ¡ ¡ Low-­‑voltage ¡logic, ¡RPO ¡ ¡

TSMC ¡CMOS ¡(mosis) ¡ IBM ¡CMOS ¡(mosis) ¡ 10 ¡ VDD ¡

slide-11
SLIDE 11

Advanced ¡IC ¡processes ¡available ¡thru ¡ brokers ¡

IBM ¡SiGe ¡BiCMOS ¡Processes ¡ ¡ ¡ ¡

Feature ¡ Size ¡ ¡ CMOS ¡ ¡ ¡ Vdd ¡[V] ¡ ¡ ¡ ¡ ¡ SiGe ¡Ft ¡[GHz] ¡| ¡ BVceo(1) ¡[V] ¡ ¡ DescripGon ¡ ¡ HP ¡Ft/ BVceo ¡ ¡ ¡ ¡ HB ¡Ft/ BVceo ¡ ¡ ¡ ¡ 0.13 ¡µm ¡ ¡1.2, ¡2.5, ¡ 3.3 ¡ ¡ ¡ ¡ 200 ¡| ¡1.77 ¡ ¡ ¡ ¡ ¡ ¡ 57 ¡| ¡3.55 ¡ ¡ ¡ ¡ ¡ ¡ 5th ¡generaGon ¡SiGe ¡technology ¡for ¡advanced ¡RADAR ¡and ¡mmWave ¡

  • applicaGons. ¡ ¡

1.2, ¡2.5, ¡ 3.3 ¡ ¡ ¡ ¡ 103 ¡| ¡2.4 ¡ ¡ ¡ ¡ ¡ ¡54 ¡| ¡4.7 ¡ ¡ ¡ ¡ ¡ ¡ Reduced ¡performance, ¡cost ¡effecGve ¡technology ¡for ¡wireless ¡applicaGons. ¡ ¡ 0.18 ¡µm ¡ ¡1.8, ¡2.5, ¡ 3.3 ¡ ¡ ¡ ¡ 120 ¡| ¡2.0 ¡ ¡ ¡ ¡ ¡ ¡ 20 ¡| ¡4.75 ¡ ¡ ¡ ¡ ¡ ¡ 4th ¡generaGon ¡SiGe ¡technology ¡best ¡suited ¡for ¡wireless ¡and ¡high-­‑speed ¡

  • switches. ¡ ¡

1.8, ¡2.5, ¡ 3.3 ¡ ¡ ¡ ¡ 60 ¡| ¡3.3 ¡ ¡ ¡ ¡ ¡ ¡29 ¡| ¡6.0 ¡ ¡ ¡ ¡ ¡ ¡ Reduced ¡performance, ¡yet ¡most ¡cost ¡effecGve ¡SiGe ¡technology ¡offered. ¡ ¡ 0.25 ¡µm ¡ ¡ 2.5, ¡3.3 ¡ ¡ ¡ ¡ 47 ¡| ¡3.3 ¡ ¡ ¡ ¡ ¡ ¡27 ¡| ¡5.7 ¡ ¡ ¡ ¡ ¡ ¡ 3rd ¡generaGon ¡SiGe ¡technology. ¡ ¡ 2.5, ¡3.3 ¡ ¡ ¡ ¡ 60 ¡| ¡3.2 ¡ ¡ ¡ ¡ ¡ ¡29 ¡| ¡6.0 ¡ ¡ ¡ ¡ ¡ ¡ A ¡descendant ¡of ¡7WL, ¡it ¡integrates ¡0.25 ¡µm ¡CMOS ¡with ¡the ¡7WL ¡SiGe ¡NPN. ¡ ¡

IBM ¡BiCMOS ¡SiGe ¡(MOSIS) ¡

28 ¡nm ¡CMOS28LP ¡ ¡ CMOS ¡7LM ¡ 40 ¡nm ¡CMOS040 ¡ ¡ CMOS ¡7LM ¡ 65 ¡nm ¡CMOS065 ¡ ¡ CMOS ¡7LM ¡ 65 ¡nm ¡CMOS065-­‑SOI ¡ ¡ SOI ¡6LM ¡

St ¡Micro ¡CMOS ¡(CMP) ¡

Other ¡less ¡advanced ¡and ¡specialized ¡processes ¡ are ¡available ¡thru ¡mosis, ¡cmp, ¡europracIce ¡ And ¡others! ¡ hXp://www.mosis.com ¡ hXp://cmp.imag.fr/ ¡ hXp://www.europracIce-­‑ic.com/ ¡

11 ¡

slide-12
SLIDE 12

Area ¡reduction ¡mostly ¡for ¡digital ¡systems ¡

For ¡analog ¡design, ¡most ¡of ¡the ¡challenges ¡can ¡be ¡addressed ¡by ¡proper ¡device ¡ selecGon ¡ ¡and ¡design. ¡But ¡at ¡the ¡expense ¡of ¡increased ¡area: ¡Reduce ¡analog ¡ funcGonality ¡to ¡the ¡minimum ¡to ¡benefit ¡from ¡the ¡ever ¡increasing ¡integraGon ¡ density ¡in ¡advanced ¡process. ¡Analog ¡“deficiencies” ¡ ¡can ¡be ¡miGgated ¡by ¡special ¡ digital ¡techniques. ¡

Die ¡area ¡reducGon ¡based ¡on ¡analog/digital ¡mix ¡(A. ¡Baschiro+o ¡) ¡ 12 ¡

slide-13
SLIDE 13

Harnessing ¡digital ¡processing ¡power ¡(a ¡physicist ¡ perspective) ¡

13 ¡

Ø

Complex ¡pa+ern ¡recogniMon ¡on ¡chip ¡

Ø

Cluster ¡formaGon, ¡including ¡NN-­‑style. ¡ ¡

Ø

RejecGon ¡of ¡background ¡clusters-­‑ ¡eg. ¡from ¡beam ¡halo ¡parGcles ¡

Ø

Generic ¡user-­‑programmable ¡DSP ¡

Ø

Pulse ¡shape ¡analysis. ¡ ¡

Ø

Digital ¡correcGons ¡for ¡anything ¡and ¡everything ¡(eg. ¡Time-­‑walk). ¡

Ø

Self-­‑repairing ¡or ¡self-­‑tesMng ¡designs. ¡Either ¡100% ¡yield ¡or ¡chips ¡that ¡automaMcally ¡ report ¡their ¡quality ¡upon ¡power-­‑up ¡(second ¡probably ¡easier) ¡

Ø

Self ¡calibraMng, ¡self ¡Mming-­‑in, ¡etc. ¡ ¡

Ø

No ¡need ¡to ¡save ¡and ¡download ¡threshold ¡tunes, ¡for ¡example, ¡because ¡threshold ¡ is ¡automaGcally ¡tuned ¡on-­‑chip ¡in ¡real ¡Gme. ¡ ¡

Ø

AutomaMng ¡monitoring, ¡interlocking, ¡etc. ¡ ¡

Ø

Configurable ¡geometry. ¡ ¡Not ¡all ¡pixels ¡have ¡to ¡be ¡used. ¡User ¡selects ¡desired ¡density ¡ lower ¡density ¡= ¡lower ¡power ¡and ¡greater ¡bump ¡bonding ¡pitch ¡

Ø

Prompt ¡hit ¡processing ¡(complex ¡and ¡fast ¡processing ¡of ¡hits ¡from ¡pixel ¡columns) ¡

¡ ¡

  • M. ¡Garcia-­‑Sciveres, ¡Atlas ¡Upgrade ¡Week ¡11/16/11 ¡ ¡
slide-14
SLIDE 14

Illustration ¡of ¡the ¡Power ¡of ¡integration ¡ ¡

>One ¡32bit ¡ARM11 ¡processor ¡core ¡Per ¡4 ¡columns ¡(65LP)! ¡ Fits ¡in ¡the ¡dead ¡area! ¡

FEI4: ¡0.13µ ¡ATLAS ¡Pixel ¡ROC ¡ ~ ¡20mm ¡X ¡20mm ¡ Size ¡would ¡probably ¡remain ¡the ¡ same ¡if ¡implemented ¡in ¡ 65 ¡nm ¡

14 ¡

slide-15
SLIDE 15

65nm: ¡Some ¡transistor ¡test ¡result ¡

  • M. ¡Manghisoni ¡ ¡et ¡al. ¡TWEPP ¡2011 ¡

Same ¡gate ¡capacitance ¡

Ø No ¡noise ¡degradaGon ¡at ¡lower ¡nodes ¡ Ø No ¡thermal ¡noise ¡increase ¡with ¡radiaGon ¡ ¡ Ø No ¡or ¡lirle ¡1/f ¡noise ¡increase ¡with ¡radiaGon ¡ 15 ¡

slide-16
SLIDE 16

65nm: ¡Some ¡radiation ¡tolerance ¡results ¡

Threshold ¡voltage ¡ Leakage ¡current ¡

  • S. ¡Bonacini ¡ ¡et ¡al. ¡TWEPP ¡2011 ¡

65 ¡nm ¡devices ¡seem ¡to ¡outperform ¡their ¡130nm ¡counterparts ¡in ¡their ¡ tolerance ¡to ¡ionizing ¡radiaGon ¡! ¡

16 ¡

slide-17
SLIDE 17

Example ¡1: ¡FEI4A ¡(ATLAS ¡PIXELS ¡FOR ¡IBL) ¡

FEI4A ¡ FEI3 ¡ Year ¡ 2010 ¡

2003 ¡

Technology ¡ 130nm ¡

250nm ¡

Chip ¡size ¡ 20x19mm2 ¡

7.6x10.8mm2 ¡

AcGve ¡area ¡ 89% ¡

74% ¡

Array ¡ 80x336 ¡ (26880) ¡

18x160 ¡ (2880) ¡

Pixel ¡size ¡ 50x250μm2 ¡

50x400μm2 ¡

Number ¡of ¡ transistors ¡ 87M ¡

3.5M ¡

Data ¡rate ¡ 320 ¡Mb/s ¡

40Mb/s ¡

Wafer ¡yield ¡ 65% ¡ ¡

80% ¡

FEI4A ¡0.13u ¡process ¡ Performs ¡also ¡most ¡of ¡a ¡module ¡ Controller ¡chip ¡duGes ¡ FEI3 ¡0.25u ¡ process ¡ § Copes ¡with ¡higher ¡hit ¡rate: ¡regional ¡architecture ¡and ¡smaller ¡pixel ¡size ¡ § Improved ¡cost ¡effecGveness: ¡Large ¡chip ¡with ¡large ¡acGve ¡area ¡ § Lower ¡power: ¡Improved ¡design ¡and ¡architecture ¡ § Increased ¡radiaGon ¡tolerance ¡ ¡(~250Mrad) ¡ 17 ¡

slide-18
SLIDE 18

FEI4 ¡(cont’d) ¡

  • Column ¡drain ¡architecture ¡(a ¡la ¡FEI3) ¡saturates ¡at ¡high ¡rate ¡

– All ¡pixel ¡hits ¡are ¡sent ¡to ¡periphery ¡ ¡ – Column ¡based ¡readout ¡induces ¡dead-­‑Gme ¡(during ¡data ¡transfer ¡to ¡ periphery ¡and ¡column ¡readout) ¡ ¡ ¡

  • ATLAS ¡soluGons ¡for ¡higher ¡rate ¡

→ ¡Development ¡of ¡regional ¡architecture ¡in ¡FEI4 ¡enabled ¡by ¡migraGon ¡ ¡to ¡ a ¡finer ¡process ¡

18 ¡

slide-19
SLIDE 19

FEI4 ¡PIXEL ¡REGION ¡

  • FEI4 ¡is ¡organized ¡in ¡digital ¡regions ¡serving ¡4 ¡analog ¡pixels ¡
  • Hits ¡are ¡stored ¡locally ¡during ¡L1 ¡latency ¡

– 5 ¡ToT ¡memories ¡per ¡pixel, ¡5 ¡latency ¡counters ¡per ¡region ¡

  • Hits ¡are ¡not ¡moved ¡unless ¡triggered ¡ ¡

– only ¡0.25% ¡of ¡hits ¡are ¡sent ¡to ¡periphery ¡

  • Lower ¡digital ¡power ¡consumpGon ¡(6μW/pixel ¡at ¡IBL ¡occupancy) ¡

19 ¡

slide-20
SLIDE 20

FEI4: ¡Pixel ¡front ¡end ¡

Cc

Cf2 Cf1

Preamp Amp2 feedbox feedbox

Inj0 Inj1 injectIn

Cinj1 Cinj2

+

local feedback tune

FDAC

4 Bit

Vfb

+

local threshold tune

TDAC

5 Bit

Vfb2

+

  • HitOut
NotKill

Vth

  • Similar ¡design ¡of ¡analog ¡pixel ¡in ¡FEI3/FEI4 ¡
  • Two-­‑stage ¡amplificaGon ¡
  • Clock ¡is ¡distributed ¡to ¡all ¡digital ¡pixel ¡region ¡
  • ToT ¡counters ¡within ¡pixel ¡digital ¡region ¡
  • ToT ¡together ¡with ¡pixel ¡address ¡sent ¡to ¡periphery ¡

FEI3 ¡ FEI4 ¡ ToT ¡ 8 ¡bit ¡ 4 ¡bit ¡ TDAC ¡ 7 ¡bit ¡ 5 ¡bit ¡ FDAC ¡ 3 ¡bit ¡ 4 ¡bit ¡

20 ¡

slide-21
SLIDE 21

FEI4A: ¡ ¡A ¡result ¡

1500 ¡ ¡ ¡ ¡2000 ¡ ¡ ¡ ¡ ¡ ¡2500 ¡ ¡ ¡ ¡ ¡ ¡3000 ¡ ¡ ¡ ¡ ¡ ¡3500 ¡ ¡ ¡ ¡ ¡4000 ¡ ¡ ¡ ¡ ¡ ¡ ¡5000 ¡ 103 ¡ 102 ¡ 10 ¡ 1 ¡ 10-­‑1 ¡ Constant ¡ ¡ ¡ ¡849 ¡ Mean ¡ ¡ ¡ ¡ ¡ ¡ ¡3178 ¡ Sigma ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡403 ¡ ¡

¡

2700 ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡2900 ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡3100 ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡3300 ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡3500 ¡ 103 ¡ 102 ¡ 10 ¡ 1 ¡ 10-­‑1 ¡ Constant ¡ ¡2865 ¡ Mean ¡ ¡ ¡ ¡ ¡ ¡ ¡3100 ¡ Sigma ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡26 ¡ ¡

¡

  • FEI4 ¡bump-­‑bonded ¡to ¡planar ¡and ¡3D ¡sensors ¡have ¡been ¡successfully ¡
  • perated ¡in ¡lab ¡test, ¡test ¡beams ¡and ¡cosmic ¡data ¡taking ¡
  • Tuned ¡threshold ¡dispersion ¡~30e ¡ ¡
  • FEI4 ¡low ¡threshold ¡operaGon ¡(~700e) ¡shows ¡promising ¡results ¡with ¡

reasonable ¡dispersion ¡

  • IrradiaGon ¡tests ¡with ¡bare ¡chips ¡show ¡no ¡effect ¡on ¡threshold ¡

dispersion ¡and ¡20% ¡increase ¡in ¡noise ¡ ¡ ¡

Threshold ¡tuning ¡at ¡1400e ¡

Threshold ¡[e] ¡ Threshold ¡[e] ¡

before ¡tuning ¡ ¡ aver ¡tuning ¡

21 ¡

slide-22
SLIDE 22

Example ¡2: ¡ATPIX65, ¡next ¡generation ¡Atlas ¡pixel ¡ readout ¡prototype ¡

  • To ¡explore ¡the ¡capabiliGes ¡of ¡advanced ¡CMOS ¡processes ¡to ¡

address ¡future ¡HEP ¡needs ¡(upgrades, ¡SLHC, ¡) ¡

  • To ¡have ¡a ¡feel ¡of ¡what ¡is ¡the ¡best ¡way ¡these ¡processes ¡should ¡

be ¡used ¡to ¡maximize ¡ROI. ¡

  • To ¡evaluate ¡radiaGon ¡hardness ¡(mainly ¡SEU ¡and ¡new ¡damage ¡

mechanisms, ¡if ¡any!) ¡

  • To ¡keep ¡abreast ¡of ¡the ¡state ¡of ¡the ¡art ¡(if ¡one ¡can). ¡ ¡

22 ¡

slide-23
SLIDE 23

Pixel ¡region ¡(2X2) ¡a ¡la ¡FEI4 ¡if ¡implemented ¡ in ¡65nm ¡ ¡

Ø Region ¡logic ¡synthesized ¡from ¡FEI4 ¡verilog. ¡ Ø Neither ¡100% ¡complete ¡nor ¡verified. ¡ Ø Just ¡to ¡have ¡an ¡idea ¡on ¡what ¡is ¡possible ¡ ¡ Pixel ¡size=50X100 ¡(?) ¡ Ø ~FEI4 ¡AFE ¡equivalent ¡ 23 ¡

slide-24
SLIDE 24

“FEI5” ¡2X2 ¡REGION ¡(100X200) ¡

  • SubstanGal ¡ ¡area ¡reducGon ¡
  • UlGmately ¡the ¡width ¡of ¡a ¡pixel ¡will ¡be ¡limited ¡by ¡pracGcal ¡

consideraGons ¡(power ¡distribuGon) ¡and ¡not ¡the ¡number ¡of ¡ transistors! ¡

  • Room ¡to ¡add ¡funcGonality ¡

FIE4 ¡pixel ¡region ¡ ¡Vs ¡Pix65nm ¡region ¡ (assuming ¡y=50u) ¡

FEI4 ¡2X2 ¡REGION ¡(100X500) ¡ If ¡area ¡to ¡be ¡kept ¡the ¡same ¡as ¡FEI4, ¡ about ¡4X ¡more ¡logic ¡can ¡be ¡added ¡

24 ¡

slide-25
SLIDE 25

Snapshot ¡of ¡submitted ¡pixel ¡array ¡

  • 25 ¡µm ¡y ¡cell ¡pitch ¡but ¡50µm ¡bump ¡y ¡picth. ¡ ¡
  • Power ¡distribuGon ¡will ¡be ¡major ¡factor ¡in ¡the ¡ulGmate ¡minimum ¡

dimensions ¡

  • Bump ¡mask ¡not ¡part ¡of ¡the ¡submired ¡layout ¡(same ¡size ¡as ¡FEI4) ¡

25 ¡

slide-26
SLIDE 26

ATPIX65A ¡FEND ¡BLOC ¡DIAGRAM ¡

Inject ¡Bloc ¡

  • Preamp. ¡

17fF ¡Feeback ¡cap. ¡ Variable ¡“Rff” ¡ Single ¡to ¡differenGal+ ¡ Comparator ¡“preamp” ¡ Comparator ¡ TDAC ¡(+/-­‑ ¡ 4b ¡tuning) ¡ 26 ¡ Passive ¡RC: ¡gate ¡ leakage ¡limited ¡ Ø Uses ¡only ¡65nm ¡Transistors ¡ Ø 2µA ¡to ¡25µA ¡@ ¡1.2V ¡

slide-27
SLIDE 27

ATPIX65A: ¡Atlas ¡Pixel ¡prototype ¡array ¡

Pixels ¡ with ¡ Added ¡ sensors ¡ (row ¡ 11:31) ¡

Pixels ¡with ¡ Added ¡ mimcaps ¡ (31,27,22, 18) ¡

16 ¡X ¡32 ¡array ¡ 25µ ¡X ¡125µ ¡pixels ¡

27 ¡

slide-28
SLIDE 28

Preliminary ¡test ¡results ¡

Preamp ¡out ¡ Single ¡to ¡Diff. ¡out ¡ Chan ¡15/32 ¡Qin: ¡2ke ¡ Chip ¡found ¡to ¡work ¡as ¡expected! ¡ VDD=1.2V ¡ I= ¡5µA ¡per ¡pixel ¡(can ¡be ¡as ¡low ¡as ¡2µA) ¡ 28 ¡

slide-29
SLIDE 29

Qin=10ke-­‑; ¡5IFF ¡se\ngs ¡ Chan ¡15/32 ¡Qin: ¡2ke ¡to ¡10ke-­‑ ¡ 29 ¡

slide-30
SLIDE 30

ATPIX65A: ¡Noise ¡and ¡Threshold ¡ distribution ¡

Channels ¡with ¡caps ¡or ¡diodes ¡ 30 ¡

slide-31
SLIDE 31

ATPIX65A: ¡ENC ¡for ¡some ¡columns ¡

. ¡. ¡. ¡. ¡

Channels ¡with ¡ mimcaps ¡ Channels ¡with ¡ Diodes ¡ ¡ (3 ¡types) ¡ 31 ¡

slide-32
SLIDE 32

Fe55 ¡spectrum ¡as ¡detected ¡by ¡one ¡of ¡the ¡ integrated ¡sensors ¡

32 ¡ Chip2 ¡high ¡gain ¡mode. ¡Sensor@-­‑8V ¡

Very ¡preliminary! ¡Work ¡in ¡progress! ¡ ¡

1040e-­‑ ¡pulser ¡injecGon ¡ ~3.7keV. ¡Assuming ¡Cinj ¡ to ¡be ¡nominal. ¡ 2154 ¡KeV ¡(2.9KeV? ¡May ¡be ¡parGal ¡5.9KeV ¡charge ¡collecGon?) ¡ ¡ 5154 ¡KeV ¡(theory; ¡5.9KeV?) ¡ ¡

For ¡the ¡experiment ¡to ¡agree ¡with ¡theory ¡ ¡(for ¡the ¡5.9KeV), ¡injecIon ¡cap ¡has ¡to ¡be ¡ ¡corrected ¡by ¡15% ¡. ¡SIll ¡being ¡reviewed! ¡

Noise ¡arGficially ¡Limited ¡

slide-33
SLIDE 33

Example ¡4: ¡Fast, ¡rad-­‑hard ¡CMOS ¡direct ¡ detectors ¡for ¡TE ¡

33 ¡

0.35 ¡um ¡CMOS ¡ TEAM2k(2009)

¡

9.5µ ¡pixels ¡ 4Mpix, ¡400 ¡f/s ¡

0.18 ¡um ¡CMOS ¡ ¡ K2 ¡sensor ¡(2010) ¡ ¡ 5µ ¡pixels ¡ 16Mpix, ¡400 ¡f/s ¡ ¡ Improved ¡radiaMon ¡ tolerance ¡ Commercial ¡product ¡ 0.35 ¡um ¡ CMOS(2009) ¡ TEAM1k ¡ 1 ¡Mpix ¡ HIPPIX ¡(2011) ¡ 65nm ¡proto ¡

FabricaMon ¡ process ¡ Pixel ¡pitch ¡ [µm] ¡ ¡ ¡ Conversion ¡ Gain ¡ [µV/e-­‑] ¡ Noise ¡ [e-­‑] ¡ Leakage ¡ current ¡ [fA] ¡ Well ¡ depth ¡ [e-­‑] ¡ 0.35 ¡µm ¡ 9.5 ¡ 9.4 ¡ 30 ¡ 10 ¡ 90000 ¡ 0.18 ¡µm ¡ 5.0 ¡ 15.5 ¡ 35-­‑40 ¡ 4 ¡ 23000 ¡ 65 ¡nm ¡ 2.5 ¡ 21 ¡ 50 ¡ 8 ¡ 18000 ¡

¡ ¡

¡ ¡

B.Krieger, ¡TNS ¡2011 ¡

slide-34
SLIDE 34

Example ¡4: ¡HIPPO, ¡a ¡column-­‑Parallel ¡CCD ¡readout ¡ (for ¡X-­‑ray ¡imaging ¡and ¡Mu2E ¡applications) ¡ ¡ Ø Megapixel ¡square ¡sensor ¡has ¡~1000 ¡columns ¡@ ¡50 ¡μm ¡ ¡pitch ¡ ¡à ¡need ¡custom ¡IC ¡ readout ¡ Ø No ¡room ¡for ¡output ¡amplifier ¡à ¡need ¡charge-­‑sensiGve ¡readout ¡ Ø UlGmate ¡applicaGons ¡require ¡ ¡intensive ¡DSP ¡ ¡à ¡advanced ¡CMOS ¡process ¡ Ø 65nm ¡CMOS ¡found ¡to ¡be ¡the ¡most ¡adequate ¡

35 ¡e-­‑ ¡@ ¡10 ¡Mpix/s ¡ Custom ¡65nm ¡CMOS ¡

column-­‑Parallel ¡LBNL ¡CCD ¡ ¡ 34 ¡

  • C. ¡Grace, ¡TNS ¡2011 ¡
slide-35
SLIDE 35

HIPPO ¡prototype ¡chip ¡

4 ADCs 16 SHAs 16 Analog Front ends

4200 ¡μm ¡

SERDES ¡ (480 ¡Mb/s) ¡ 12b ¡(80 ¡Msps) ¡ HV ¡input ¡transistor ¡to ¡achieve ¡the ¡required ¡noise ¡level. ¡Nominal ¡transistor ¡is ¡too ¡leaky! ¡ 35 ¡

slide-36
SLIDE 36

HIPPO ¡results ¡(mixed ¡simulation ¡and ¡ measurements) ¡

ResoluGon ¡ 12 ¡b ¡@80MHz ¡ Noise ¡ 0.77 ¡b ¡ Linearity ¡ 10 ¡b ¡ Serial ¡output ¡ 480 ¡Mb/s ¡ ADC ¡Pitch ¡ 200 ¡μm ¡ ADC ¡Area ¡ ¡ 0.35 ¡mm2 ¡ Power ¡per ¡ADC ¡ 30 ¡mW ¡

36 ¡

Full ¡Scale ¡ 50k ¡/ ¡ 1M ¡e-­‑ ¡ CCD ¡charge ¡ ¡ 200ke-­‑ ¡ Input ¡noise ¡ 35 ¡/24e-­‑ ¡ Serling ¡Gme ¡ < ¡15ns ¡ Charge ¡loss ¡ ¡< ¡1% ¡ Linearity ¡ 10 ¡b ¡ Power ¡ 5 ¡mW ¡

ADC ¡ Preamp ¡ J.P. ¡Walder, ¡ TNS ¡2011 ¡

slide-37
SLIDE 37

Conclusions ¡

37 ¡ Unprecedented ¡advances ¡in ¡IC ¡technology ¡are ¡offering ¡new ¡ways ¡to ¡implement ¡readout ¡ systems ¡(for ¡all ¡kind ¡of ¡detector ¡systems). ¡ New ¡challenges ¡ ¡seem ¡to ¡be ¡more ¡addressable ¡with ¡scaled ¡down ¡technologies. ¡ ¡ Future ¡systems ¡will ¡require ¡smaller ¡geometries, ¡lower ¡power, ¡higher ¡level ¡of ¡ processing, ¡high ¡radiaMon ¡tolerance, ¡lower ¡cost ¡per ¡funcMon, ¡…etc ¡ Among ¡the ¡advantages ¡of ¡newer ¡technologies ¡are: ¡ ¡Very ¡high ¡integraGon ¡density ¡ ¡Inherent ¡high ¡radiaGon ¡tolerance ¡ ¡A ¡reasonable ¡number ¡of ¡device ¡types ¡for ¡extra ¡design ¡flexibility ¡ ¡Availability ¡of ¡high ¡quality ¡passives ¡ ¡A ¡high ¡number ¡of ¡metal ¡levels ¡ Skewing ¡the ¡mix ¡of ¡funcMonal ¡blocks ¡towards ¡digital ¡would ¡result ¡in ¡a ¡be+er ¡area ¡ usage ¡and ¡chip ¡yield. ¡ ¡Not ¡to ¡menMon ¡flexibility ¡(programmability) ¡and ¡ProducMvity ¡ (think ¡advanced ¡digital ¡tools) ¡ A ¡myriad ¡of ¡challenges ¡related ¡to ¡ultra ¡complex ¡processes ¡and ¡ultra ¡small ¡devices ¡are ¡ associated ¡with ¡these ¡technologies. ¡For ¡some ¡of ¡these, ¡miGgaGon ¡techniques ¡are ¡readily ¡ available ¡ A ¡unique ¡challenge ¡to ¡the ¡research ¡community ¡is ¡perhaps ¡the ¡cost ¡of ¡these ¡advanced ¡ processes ¡(given ¡the ¡low ¡volume ¡usually ¡involved). ¡Common ¡wisdom ¡applies: ¡for ¡some ¡ applicaMons ¡plain ¡old ¡technologies ¡would ¡ ¡remain ¡the ¡opMmal ¡choice. ¡

slide-38
SLIDE 38

Acknowledgements ¡

38 ¡

¡ ¡

Thank ¡You ¡

¡ ¡ Many ¡Thanks ¡to ¡all ¡people ¡whose ¡work ¡has ¡been ¡ menGoned ¡and ¡to ¡my ¡colleagues ¡at ¡LBNL ¡For ¡their ¡help. ¡ Please ¡refer ¡to ¡the ¡referenced ¡work ¡for ¡more ¡exciGng ¡

  • details. ¡

¡ ¡
