ARTIFICIAL INTELLIGENCE

Lecturer: Silja Renooij

Motion

Utrecht University The Netherlands

These slides are part of the INFOB2KI Course Notes available from www.cs.uu.nl/docs/vakken/b2ki/schema.html

INFOB2KI 2019-2020

Outline

• Move in 2D
• Individual steering behaviors

– Seek, flee, wander – Obstacle avoidance – Jumping

• Move in 3D

Motion: the action of changing location or position Kinematics:

• branch of classical mechanics
• describes motion of points, (systems of) bodies

((groups of) objects)

• without consideration of the causes of motion

(forces, energies).

Motion & Kinematics

Kinematic quantities:

• Position

– 2D / 3D vector

• Orientation

– (=‘facing’) radians

• Velocity

– (= speed in direction) 2D / 3D vector

• Rotation

– (= change in orientation) radians

In simulation/game: updated each frame

Kinematics

Seek, Flee and Arrive behaviours

character: target: + (can be moving as well)

Kinematic Seek

character #kinematic data character target #kinematic data target maxSpeed #maximum speed of character def getSteering(): steering = new KinematicSteeringOutput() steering.velocity = target.position – character.position # direction of target steering.velocity.normalize() steering.velocity *= maxSpeed # full speed in direction character.orientation = getNewOrientation(character.orientation,steering.velocity) # face in direct. of move steering.rotation = 0 return steering

Computations are done in each frame!

Kinematic Arrive

character #kinematic data character target #kinematic data target input Seek maxSpeed #maximum speed of character radius #satisfaction radius (‘found’ target) timeToTarget = 0.25 #goal: get to target in 0.25s input Arrive def getSteering(): steering = new KinematicSteeringOutput() steering.velocity = target.position – character.position if steering.velocity.length() < radius: return None #arrived! steering.velocity /= timeToTarget #speed=distance/time if steering.velocity.length() > maxSpeed: #unless above max steering.velocity.normalize() steering.velocity *= maxSpeed character.orientation = getNewOrientation(character.orientation,steering.velocity) steering.rotation = 0 return steering

Kinematic Wandering

Simple implementation:

• move with max speed in direction of randomly

chosen orientation  erratic behavior

• behaviour resembles seeking target in a random

spot on a circle surrounding the character: This analogy allows for simple improvements:

Kinematic movement

• Input: static kinematic data (position,orientation);

 output velocity and rotation

• Velocity: speed `on’ or `off’ in target direction
• Orientation usually in travelling direction; otherwise

rotation can be applied

Steering behavior

• Extends kinematic movement by adding changes to

velocity and rotation

• Input: kinematics; output: linear and angular acceleration
• Variable matching: typically one or more characters’

kinematic matched to target kinematic

Kinematic movement vs Steering

Character # kinematic data character target # kinematic data target input Seek maxAcceleration # maximum acceleration maxSpeed # maximum speed of character targetRadius # satisfaction radius input Arrive slowRadius # radius to slow down timeToTarget = 0.1 # 0.1s to achieve target velocity def getSteering(target): steering = new SteeringOutput() direction = target.position – character.position distance = direction.length() if distance < targetRadius: return None # arrived! if distance > slowRadius: targetSpeed = maxSpeed # move with maxspeed else targetSpeed = maxSpeed * distance / slowRadius # slow down if close targetVelocity = direction targetVelocity.normalize() targetVelocity *= targetSpeed steering.linear = target.position – character.position # only for Seek; remove for Arrive steering.linear = target.velocity – character.velocity # accelerate to target velocity steering.linear /=timeToTarget if steering.linear.length() > maxAcceleration: steering.linear.normalize() steering.linear *= maxAcceleration steering.angular = 0 return steering

Seek & Arrive with acceleration

Align - Orientation

Similar to Arrive with accel.:

direction, velocity  rotation position  orientation distance  rotationSize steering.linear  steering.angular

Align - Velocity

Character # kinematic data character target # kinematic data target maxAcceleration # maximum acceleration maxSpeed # maximum speed of character maxRotation # maximum rotation targetRadius # satisfaction radius slowRadius # radius to slow down timeToTarget = 0.1

# 0.1s to achieve target velocity

def getSteering(target): steering = new SteeringOutput() steering.linear = target.velocity – character.velocity steering.linear /=timeToTarget if steering.linear.length() > maxAcceleration: steeringlinear.normalize() steering.linear *= maxAcceleration steering.angular = 0 return steering

= Arrive with acceleration stripped down to velocity matching… Useful in combination with

• ther behaviours in e.g.

flocking.

• Pursue

– predict target’s position, then seek

More complex behaviors

(vanilla) path following:

• Find nearest point N on path
• Target T = point on path at N + fixed offset
• Seek T

Multiple options?

• Often choose for coherence

(new target close to old one) The whole path is a target and should be followed.

Follow path: vanilla

Follow path: predictive

Predictive path following:

• Find nearest point N on path,

from predicted future position

• Proceed as with vanilla pathfinding
• Smoother for complex tasks
• Drawback (?): cutting corners

The whole path is a target and should be followed.

Repulsion or separation

character targets threshold # threshold to take action decayCoefficient # constant for decay maxAcceleration def getSteering(): steering = new Steering for target in targets: direction = target.position – character.position distance = direction.length() target is too close if distance < threshold: strength = min(decayCoefficient / (distance ^2), maxAcceleration) #repulsion strength direction.normalize() steering.linear += strength * direction add acceleration return steering

Context: keeps characters from getting too close and being crowded

Concerns collisions with moving targets Simple:

• Variation of evade/separate;

– engaged if target is within cone in front of character

• Drawback: in-cone doesn’t have to mean collision

and vice versa

Collision avoidance

Concerns collisions with moving targets Better:

• Find target closest to collision
• For each target

– Find out if collide (moment of collision) – If collide, find out when and where – Steer away from that target

Collision avoidance

• Use casting rays to find obstacles
• Multi-ray problem: “corner trap”

Single ray Multiple rays Multiple rays

Obstacle avoidance

One ray Two whiskers

Often used solution

Obstacle avoidance

State of the art

Combining steering

e.g. flocking, swarming,…

Weighted blending

– Combine steering behavior by computing the weighted sum of all blended behaviors – Problem: equilibria and worse

– Alternatives: prioritize; cooperative arbitration; …

target Seek target avoid enemy 1 avoid enemy 2 enemy 2 enemy 1 Wall avoidance result pursue

trapped (do nothing) lost target

Jumping

• Jump might fail! (unlike steering)
• Where to jump?

– Jump pads in level – Jumpable holes (design like walls; jump instead of avoid)

• How to jump?

– Need speed, direction and place to start

• When to jump?

– Often determined by path finding

Moving in 3 dimensions

More than just one more degree of freedom:

• Gravity
• Height of obstacles
• Stairways
• Lines of sight
• Capabilities (jump, fly, …)

Moving in 3 dimensions
