Analytical Clustering Score with Application to Post-Placement Multi-Bit Flip-Flop Merging

Chang Xu1, Peixin Li1, Guojie Luo1, Yiyu Shi2, and Iris Hui-Ru Jiang3

{changxu, gluo} @ pku.edu.cn

2

Background

• Multi-bit flip-flop
• Previous works and limitation

Our method

• Analytical score
• Discrete refinement
• Efficient implementation

Experimental Results Conclusion

Outline

3

Clock power predominates dynamic power

• 𝑸𝒅𝒎𝒍 = 𝜷𝑫𝒅𝒎𝒍𝑾𝒆𝒆

𝟑 𝒈𝒅𝒎𝒍

Clock power optimization

• Reduce 𝜷
• Clock gating technique
• Reduce 𝑾𝒆𝒆
• Sub-threshold voltage
• Multi-supply-voltage
• Reduce 𝑫𝒅𝒎𝒍
• Multi-bit flip-flop
• Resonance clock

Clock Power Optimization

4

What’s MBFF

• Several SBFFs share common inverters in MBFF cell

Multi-Bit Flip-Flop(MBFF)

2-Bit Flip-Flop Source: ICCAD’10 Chang et al.

5

Power saving comes from

• MBFF library
• Simplified clock tree

Multi-Bit Flip-Flop(MBFF)

(a) Common clock tree (b) Simplified clock tree with MBFF

UMC 55nm process Faraday cell library

6

Pre-placement MBFF

• SNUG’10 Chen et al.,

In-placement MBFF

• ISPD’13 Tsai et al.,
• ICCAD’13 Hsu et al.,

Post-placement MBFF

• ICGCS’10 Yan and Chen
• ICCAD’10 Chang et al.,
• ISPD’11 Jiang et al., INTEGRA

Using MBFF at Different Stages

Logic Synthesis Placement Timing Analysis Post-placement Optimization CTS Routing

MBFF Clustering MBFF Clustering MBFF Clustering

7

Input

• Placement of FFs and other gates
• Timing slacks
• MBFF library

Output

• FF clusters (MBFF)

Constraint

• Timing constraint

Post-Placement MBFF Clustering

FF

Input pin Output pin

FF FF FF TVFR

8

Timing violation free region (TVFR)

Post-Placement MBFF Clustering

FF TVFR TVFR1 TVFR2 2-bit FF

Input pin Output pin

9

Intersection graph-based searching [ICCAD’10 ]

• Time consuming: 𝑷(𝑶𝟒)
• Window-based acceleration affects power reduction

Previous Works and Limitation

TVFRs Intersection Graph Complete Graph TVFRs

10

Interval graph-based searching [ISPD’11]

• Efficient: sub-quadratic time complexity
• Effective: best power reduction
• Simple: signal wirelength degradation

Previous Works and Limitation

Random Choice!

Illustration to Interval Graph Source: ISPD’11 Jiang et al.

11

 Difference

• TVFD/AFFD: roughly estimate #FF can be covered within TVFR
• IWLS benchmarks have much more MBFF candidates!

Signal wirelength degradation (for Integra)

• C1-C6: Avg. 3%
• IWLS: Avg. 932%

Benchmarks: C1-C6 Vs. IWLS 2005

C1-C6 TVFD/AFFD FF ratio Vga (IWLS 2005) TVFD/AFFD FF ratio

12

Efficient and great scalability

• Sub-quadratic time complexity

Robust performance

• Power reduction: comparable to Integra
• Signal wirelength: much better than Integra, especially for real

designs

Analytical fashion

• Potential integration in analytical global placement
• Potential usage for clustering algorithms

Our Contribution

13

Optimization Flow

14

Optimization Problem 𝑔

𝑚 𝒚, 𝒛 : signal wirelength

• weighted-average WL[DAC’11]

𝑔

𝑑 𝒚, 𝒛 : #FF groups

• nontrivial to be formulated

Timing constraint

• feasible region

Analytical Step: Basic Idea

𝑛𝑗𝑜 𝛽𝑔

𝑚 𝒚, 𝒛 − 𝑔 𝑑 𝒚, 𝒛

𝑡. 𝑢. 𝑢 𝒚, 𝒛 ≤ 𝑈

TVFRs

2-bit group 3-bit group

15

Dirac delta function

Cluster size

Analytical Step: Def. of Clustering Score

𝑂𝑗 𝒚, 𝒛 = 𝑘=1

𝑂

𝜀( 𝑦𝑗, 𝑧𝑗 − 𝑦𝑘, 𝑧𝑘 , 0) 𝜀 𝑥, 𝑨 = 1 (𝑥 = 𝑨) 0 (𝑥 ≠ 𝑨) 𝜀 𝑦𝑗, 𝑧𝑗 − 𝑦𝑘, 𝑧𝑘 , 0 = 1 𝑦𝑗, 𝑧𝑗 − 𝑦𝑘, 𝑧𝑘 = 0 0 𝑝𝑢ℎ𝑓𝑠𝑥𝑗𝑡𝑓

TVFRs

𝑶𝒌 = 𝟑

𝑮𝑮𝒌 𝑮𝑮𝒋 𝑶𝒋 = 𝟒

16

Objective function: 𝒈𝒅 term

• 4-bit group is most-efficient

Analytical Step: Def. of Clustering Score

𝑛𝑗𝑜 − 𝑔

𝑑 = −𝑛𝑏𝑦𝑔 𝑑 = −𝑛𝑏𝑦 𝑗=1 𝑂

𝜀 𝑂𝑗 𝒚, 𝒛 , 4

17

Gaussian function

Analytical Step: Smoothing

𝜀 𝑥, 𝑨 ≈ 𝐸 𝑥, 𝑨 = exp 𝑥 − 𝑨 2𝑚𝑜𝜗 𝑒0

2

𝐸 𝑥 − 𝑨 = 1 𝑥ℎ𝑓𝑜 𝑥 = 𝑨 𝐸 𝑥 − 𝑨 < 𝜗 𝑥ℎ𝑓𝑜 𝑥 − 𝑨 > 𝑒0

Dirac Delta function Gaussian function

18

Attractive force & repelling force

Analytical Step: Effectiveness

PULL PUSH

𝐺𝐺

𝑗

𝐺𝐺

𝑗

𝐺𝐺

𝑗

PULL

𝐺𝐺

𝑗

19

Analytical Step: Preliminary Clusters

500 1000 1500 2000 2500 3000 3500 500 1000 1500 2000 2500 3000 3500

• Init. Loc.

(a) Initial FFs’ distribution

500 1000 1500 2000 2500 3000 3500 500 1000 1500 2000 2500 3000 3500

NLP Loc. (b) FFs’ distribution after analytical clustering

 𝒈𝒅: maximizes MBFF group numbers  𝒈𝒎: pulls FFs towards their “optimal locations” in terms of WL

20

Two-pass best-choice clustering

• First-pass: discretization
• Second-pass: refinement

Discrete Step: Basic Idea

(a) Proximity relation after analytical step A B C D I H E F G A B C D I H E F G (b) Discrete clustering A B C D I H E F G (c) Discrete refinement (d) Final MBFF groups A B C D I H E F G

First-pass Second-pass

21

First-pass: extract proximity relation

• Bottom-up merging
• Priority queue
• Tuple: 𝑮𝑮𝒋, 𝑮𝑮𝒌, 𝒆 𝒆 = 𝒆𝒋𝒕𝒖(𝑮𝑮𝒋, 𝑮𝑮𝒌)
• Capacity constraint: 4-bit

Second-pass: further refinement

• Improve the ratio of 4-bit groups

Discrete Step: Two-Pass Best-Choice Clustering

22

Discrete Step: Two-Pass Best-Choice Clustering

S(C,D) S(G,F) S(E,G) S(I,H) S(A,C) S(A,B) S(I,E) (a) Proximity relation after analytical step A B C D I H E F G (b) First-pass clustering A B C D I H E F G

x

S(I,E) (c) second-pass clustering A B C D I H E F G (d) Final MBFF groups A B C D I H E F G S(H,F)

23

MBFF Clusters

500 1000 1500 2000 2500 3000 3500 500 1000 1500 2000 2500 3000 3500

• Init. Loc.

500 1000 1500 2000 2500 3000 3500 500 1000 1500 2000 2500 3000 3500

NLP Loc.

500 1000 1500 2000 2500 3000 500 1000 1500 2000 2500 3000 3500

Final Loc.

500 1000 1500 2000 2500 3000 3500

500 1000 1500 2000 2500 3000 3500

• Init. Loc.

NLP Loc. Final Loc.

24

Efficient Implementation

Analytical Step

𝑛𝑗𝑜 𝛽𝑔

𝑚 𝒚, 𝒛 − 𝑔 𝑑 𝒚, 𝒛

𝑡. 𝑢. 𝑢 𝒚, 𝒛 ≤ 𝑈

Discrete Refinement

• Gradient calculation

Fast gauss transformation (FGT) 𝑃 𝑂2 ⇒ 𝑃(𝑂)

• Nonlinear programming solver

Nesterov method Placement-like problem 𝑃(𝑂1.18)

• FF-pair distance

Bin-structure searching 𝑃 𝑂2 ⇒ 𝑃(𝑂) Sub-quadratic timing complexity

25

Setup:

• G++ 4.5.1 −𝑷𝟒
• Intel Xeon CPU @ 2.4GHz with 16 logical threads
• Benchmarks: C1-C6, IWLS-2005 suite
• Synthesis flow for real designs
• Synopsys DC
• Cadence Encounter SOC

Experiment Results:

26

Comparable power reduction 33% WL reduction

Experimental Results: C1-C6

Circuit Integra Ours PWR WLR RT (s) PWR WLR RT (s) C1 82.8 96 0.01 83.5 77.4 0.42 C2 80.9 102 0.01 82.3 76.4 0.97 C3 80.8 104 0.01 82.3 74.9 3.14 C4 81.0 104 0.02 82.4 75.6 10.59 C5 80.7 105 0.05 82.1 76.4 16.66 C6 80.7 105 1.11 82.3 82 217.4 Avg. 1 1.33 1 1.02 1 252

27

Bound-Integra

Experimental Results: Real Designs

Effect of Different Bound Factors to Power Ration and WL Ratio

28

 Comparable power reduction  43% WL reduction compared with Bound-Integra

Experimental Results: Real Designs

Circuit Bound-Integra Ours PWR WLR RT (s) PWR WLR RT (s) Tv80 78.11 109.2 0.01 78.10 95.7 0.94 Wbconmax 78.26 128 0.03 78.02 105 2.3 Pairing 78.00 132 0.03 78.00 109 6.61 Dma 78.04 124 0.05 78.02 96 5.43 Ac97 78.02 120 0.02 78.02 96 4.88 Ethernet 78.00 217 0.63 78.00 88 24.5 Avg. 1 1.43 1 0.99 1 84

29

We propose analytical clustering score to merge

MBFF

• The time complexity is sub-quadratic
• We get comparable power reduction as Integra
• We reduce wirelength by about 25% compared with
• riginal placement

Potential usage:

• Integrated in global placement
• Clustering algorithms

Conclusion

30

Thanks

{changxu, gluo} @pku.edu.cn
