AN INTRODUCTION TO

www.eurovac.com

• Founded in 1984
• 30,000 sq. ft. facility in Toronto, ON
• Leading manufacturer of both portable and central

dust/fume extraction systems and vehicle/transit cleaning systems

• Two additional facilities located in Windsor, ON and

Cleveland, OH

• Employees include in-house equipment installers,

professional engineers, electrical technicians and engineering technologists

COM OMPANY ANY OVE VERVIEW VIEW

• Full in-house manufacturing process from initial CNC

plasma cutting to final powder coat finish and assembly

www.eurovac.com

CLIENTS

Over the last 30 years, Eurovac has worked with companies both large and small across the world. Some of our notable clients include:

www.eurovac.com

EURO UROVAC C POR ORTABL ABLE E SYSTEMS MS

The Eurovac II “Compact” offers the following features:

Eurovac II “Compact”

• Vacuum speed dial
• Disposable paper bag filter and final HEPA filter
• 115/1/60Hz or 50Hz models available with 15ft. plug
• 2.5HP 1300 watt motor (125CFM/115” water column)

APPLICATIONS & USERS:

2 users 1 user 1 user

• Three position vacuum switch: On/Off/Automatic (auto position

means portable will automatically turn on when tool is in use)

• 4,000+ hours brush motor life, 8,000+ hours of brushless motor life

www.eurovac.com

EURO UROVAC C POR ORTABL ABLE E SYSTEMS MS

The Eurovac II “Cyclonic” offers the following features:

Eurovac II “Cyclonic”

• Cyclonic separation with internal wall guarding filter from the dust

upon entry (removes 85+% of dust). Final polyester cartridge filter (99.93% at 3 microns or larger)

• 2.5HP 1300 watt motor (125CFM/115” water column)
• Three position vacuum switch: On/Off/Automatic (auto position

means portable will automatically turn on when tool is in use)

• Vacuum speed dial
• Canister Size: 5 or 10 Gallon
• 115/1/60Hz or 50Hz models available with 15 ft. plug

APPLICATIONS & USERS:

2 users 1 user 1 user 1 user

• 4,000+ hours brush motor life, 8,000+ hours of brushless motor life
• Filter area: 30ft2

www.eurovac.com

EUR UROVAC C VS.

• S. OTHE

HER R SYST STEMS MS

31 sq. ft. of filter media 8 sq. ft. of filter media Cyclonic separation 1440 W of power Middle port entry 1000 W of power 16 ga. Powder coated steel construction Plastic or higher gauge metal construction Speed control dial No speed control dial

www.eurovac.com

EURO UROVAC C II II P POR ORTABL ABLE E OP OPTIO IONS

The following options can be added onto any Eurovac II portable system:

Storage Tray HEPA filtration Cart Pulse Cleaning

www.eurovac.com

EURO UROVAC C CENTRAL AL SYSTEMS MS

The Eurovac I “Board Mount” Single Filter unit is ideal for smaller spaces and features:

Eurovac I “Board Mount” Single Filter

• Automatic pulse jet cleaning system
• 5HP (140 CFM/60” water column) and 10HP (275CFM/60” water

column)

• 208-240, 460 and 575/3/60Hz or 50Hz models available*. Three

phase cord and plug supplied by others

• Starter with overload protection which is pre-wired to blower
• 20,000+ hours of continuous use
• 18” cyclonic filter separator & final cartridge filter (99.93% at 3

microns or larger)

• Includes silencer

APPLICATIONS & USERS*:

3-4 users (5HP) 6 users (10HP) 1-2 users (5HP) 2-3 users (10HP) 1-2 users (5HP) 2-3 users (10HP) 1-2 users (5HP) 2-3 users (10HP)

*Figures illustrated are based off 60Hz model. 50Hz model typically features a 20% decrease in CFM resulting in one less user per application.

• Filter area: 31ft2
• Canister Size: 20 Gallon

www.eurovac.com

EURO UROVAC C CENTRAL AL SYSTEMS MS

The Eurovac I “Combo Unit” Single Filter unit features:

Eurovac I “Combo Unit” Single Filter

• Automatic pulse jet cleaning system
• 5HP (140 CFM/60” water column) and 10HP (275CFM/60” water

column)

• 208-240, 460 and 575/3/60Hz or 50Hz models available*. Three

phase cord and plug supplied by others

• Starter with overload protection which is pre-wired to blower
• 20,000+ hours of continuous use
• 18” cyclonic filter separator & final cartridge filter (99.93% at 3

microns or larger)

• Includes silencer and magnahelic gauge

APPLICATIONS & USERS*:

3-4 users (5HP) 6 users (10HP) 1-2 users (5HP) 2-3 users (10HP) 1-2 users (5HP) 2-3 users (10HP) 1-2 users (5HP) 2-3 users (10HP)

*Figures illustrated are based off 60Hz model. 50Hz model typically features a 20% decrease in CFM resulting in one less user per application.

• Filter area: 42ft2
• Canister Size: 20 Gallon

www.eurovac.com

EURO UROVAC C CENTRAL AL SYSTEMS MS

The Eurovac I “Combo Unit” Dual Filter unit features:

Eurovac I “Combo Unit” Dual Filter

• Automatic pulse jet cleaning system
• 5HP (140 CFM/60” water column), 10HP (275CFM/60” water

column), 15 HP (380CFM/60”WC)

• 208-240, 460 and 575/3/60Hz or 50Hz models available*. Three

phase cord and plug supplied by others

• Starter with overload protection which is pre-wired to blower
• 20,000+ hours of continuous use
• 24” cyclonic filter separator & final cartridge filter (99.93% at 3

microns or larger)

• Includes silencer and magnahelic gauge

APPLICATIONS & USERS*:

*Figures illustrated are based off 60Hz model. 50Hz model typically features a 20% decrease in CFM resulting in one less user per application.

• Filter area: 100ft2
• Canister Size: 30 Gallon

3-4 users (5HP) 6 users (10HP) 6-7 users (15HP) 1-2 users (5HP) 2-3 users (10HP) 3-4 users (15HP) 1-2 users (5HP) 2-3 users (10HP) 3-4 users (15HP) 1-2 users (5HP) 2-3 users (10HP) 3-4 users (15HP)

www.eurovac.com

EURO UROVAC C CENTRAL AL SYSTEMS MS

The Eurovac II 2.5 and 5HP Central High Vacuum unit features:

Eurovac II Central High Vacuum Unit

• Manual pulse jet cleaning system with automatic option
• 2.5HP (120CFM/115” water column) and 5HP (dual 120CFM/115”

water column each)

• 115/1/60Hz (2.5HP) or 1 phase 60Hz 220/120 (4wire: 2 hot, 1 neutral, 1

ground) (5 HP). 50Hz models available*. Nema #L1420P plug provided for the 5HP model.

• 18” cyclonic filter separator & final cartridge filter (99.93% at 3

microns or larger)

• Includes silencer

APPLICATIONS & USERS*:

2 users (2.5HP) 4 users (5HP) 1 user (2.5HP) 2 users (5HP) 1 user (2.5HP) 2 users (5HP) 1 user (2.5HP) 2 users (5HP)

*Figures illustrated are based off 60Hz model. 50Hz model typically features a 20% decrease in CFM resulting in one less user per application.

• Filter area: 31ft2
• Canister Size: 20 Gallon
• 4,000+ hours brush motor life, 8,000+ hours of brushless motor life

www.eurovac.com

EURO UROVAC C CENTRAL AL SYSTEMS MS

The Eurovac III “Centrifugal” Multi-Stage Pump offers the following features:

Eurovac III “Centrifugal” Multi-Stage Pump Central System

• Manual pulse jet cleaning system
• 15HP-75 HP (additional performance details per unit

available upon request)

• 208-240, 460 and 575/3/60Hz or 50Hz models available*
• Starter with overload protection which is pre-wired to blower
• 20,000+ hours of continuous use
• 24”-72” cyclonic filter separator & final cartridge filter

(99.93% at 3 microns or larger)

• Includes silencer & inlet manifold

APPLICATIONS & USERS*:

Consult representative for number of users per application as it relates to size of system

*Figures illustrated are based off 60Hz model. 50Hz model typically features a 20% decrease in CFM resulting in one less user per application.

• Filter area: 100+ft2 depending on HP
• Canister Size: 30-55 Gallons

www.eurovac.com

EURO UROVAC C CENTRAL AL SYSTEMS MS

The Eurovac III “Centrifugal” Multi-Stage system can also be configured in a multiple pump setup to allow for increased HP and performance:

Eurovac III “Centrifugal” Multi-Stage Dual Pump Central System

• Manual pulse jet cleaning system
• Multiple 15HP-75 HP setup (additional performance

details per unit available upon request)

• 208-240, 460 and 575/3/60Hz or 50Hz models available*
• Starter with overload protection which is pre-wired to blower
• 20,000+ hours of continuous use
• 24”-72” cyclonic filter separator & final cartridge filter

(99.93% at 3 microns or larger)

• Includes silencer & inlet manifold

APPLICATIONS & USERS*:

Consult representative for number of users per application as it relates to size of system

*Figures illustrated are based off 60Hz model. 50Hz model typically features a 20% decrease in CFM resulting in one less user per application.

• Filter area: 100+ft2 depending on HP
• Canister Size: 30-55 Gallons

www.eurovac.com

ENG NGINEER NEERED ED LA LAYOUT OUTS

All Eurovac systems are professionally engineered on an individual basis and are created custom to your layout and facility. This ensure all of our equipment is function properly and in the most efficient manner.

www.eurovac.com

EUR UROVAC C PUMP UMP ADVANT NTAGES GES

✓ One piece housing ✓ Custom pump designed to unique layout specifications (5”HG – 9”HG)

www.eurovac.com

PUM UMP P ASS SSEMB MBLY

www.eurovac.com

CYCLONIC NIC SEPARA ARATOR OR

✓ Superior filtration can include cyclonic separator and secondary cartridge filter with either manual / automatic compressed air pulse jet cleaning.

www.eurovac.com

BOD ODYSH SHOP OP DU DUST EXT XTRACT CTION ION

WHIP HOSE 3/4” 3/4” Light weight whip hose for to ensure user friendliness LARGER HOSE 1 ¼” 1 ¼” Hose to ensure sufficient suction SOURCE CAPTURE TOOL “Dust free” sanding with dust Captured at the source

www.eurovac.com

SOU OURCE CA CAPTURE URE HA HAND D TOO OOLS LS

3” Vacuum Ready Orbital Sander 5”-6” Vacuum Ready Orbital Sander 8” Vacuum Ready “Mud Hog” Orbital Sander

Eurovac offers a variety of source capture hand tools that work in conjunction with Eurovac systems:

Orbital and Straightline Vacuum Ready Handsander – 3 sizes (5”, 7.75’, 15.75”) Jitterbug Vacuum Ready Sander Vacuum Ready Roloc Grinder – 2 sizes (2”, 3”) Vacuum Ready Rotary Sanders – 4 sizes (4”, 5”, 6”, 8”) Drills & Routers Trimmer – 5 sizes (2”-6”) Rotary Sanders – 4 sizes (4”-8”)

www.eurovac.com

PIPING PING

Galvanized pipe is used in the majority of dustless sanding systems as static charge can build up in PVC piping causing potential fire hazards.

Galvanized Steel Tubings & Fittings PVC

www.eurovac.com

VACUU UUM M DROP DROPS

Vacuum inlets can be either suspended freely (hanging) or mounted to the wall in double or single configurations.

Double inlet hanging or wall mount Single inlet hanging or wall mount

www.eurovac.com

14’ DOUBLE PIVOT BOOM WITH PENDANT DROP

Articulated Pendant Arms add extra length and range to any work area.

Arm Includes:

• 110v electrical outlet
• Two hose hangers
• Two compressed air inlets
• Two vacuum inlets
• Pendants include on/off toggle switch (optional)

www.eurovac.com

DO DOUB UBLE LE WOR ORK K STATIO ION N PENDAN ANT T DROP DROP

The Pendant Work Station brings all your needs right to the pendant box . Pendant Includes:

• Double work station with two vacuum inlets
• Two hose hangers
• 110v electrical outlet
• Pendants include on/off toggle switch (optional)

www.eurovac.com

CAR CAR DE DETAILING ILING AND ND SH SHOP OP CLE LEAN N UP UP

Eurovac systems can also be used for a variety of other purposes including car detailing.

www.eurovac.com

SH SHOP OP & OFF OFFICE CE CLE LEAN N UP UP

Eurovac systems are also great for general shop and office clean up.

Eurovac offers a variety of cleaning tool packages. Sample cleaning tools include black utility hoses, aluminum wands, floor tools, crevice tools, bend wands, etc.

www.eurovac.com

BENEFIT EFITS S OF OF A DUS DUST EXT XTRACT CTION ION SYSTEM

SANDPAPER SAVINGS HEALTHIER ENVIRONMENT REDUCE PAINT MISHAPS CLEANUP EFFICIENCY PROFESSIONAL IMAGE COMPLIANCE

www.eurovac.com

FOR ORD D SUC UCCESS

In the fall of 2014, Eurovac entered into a partnership with Ford to become their exclusive supplier of wet mix dust collectors for the repair

• f the new aluminum bodied F-150 vehicles.

Aluminum dust requires a dedicated wet collector that meets stringent NFPA and OSHA standards and since Eurovac’s products were produced according to these strict standards, the company became the go-to for all Ford dealerships in the USA, Canada and Mexico. In

• rder for a bodyshop to be approved to repair

the new Ford F150, they were required to use the Eurovac wet mix dust collector and over 1,000 of these units were shipped to dealerships across North America over a 4 month period. Eurovac still leads the industry in aluminum dust collection and continues to sell independent collision shops worldwide.

www.eurovac.com

ALUM UMIN INUM UM REPAIR AIR

When repairing an aluminum structured vehicle, it is essential that EXTREME CARE be taken to capture all the particulates at the source TO PREVENT CROSS METAL

• CONTAMINATION. If cold steel particles come into contact

with bare aluminum, even in microscopic levels, it can lead to a reaction called “GALVANIC CORROSION”. This reaction can corrode the metal or cause blistering or bubbling on the painted surface. To prevent “galvanic corrosion”, automobile manufacturers have ALUMINUM STANDARDS THAT NEED TO BE MET BEFORE A BODY SHOP CAN BECOME AUTHORIZED FOR REPAIR OF THEIR

• VEHICLES. As the leader in aluminum repair

equipment, EUROVAC WILL ENSURE YOU MEET THE AUTOMOBILE MANUFACTURE STANDARDS with the use of their specialized equipment as outlined in the following slides while ensuring the safety of all workers and technicians.

www.eurovac.com

DI DIFFERENCES ERENCES BETWEE WEEN N DR DRY & WE WET SYSTEMS MS

Eurovac offers both wet and dry systems (all systems discussed in the previous section are dry systems). The following diagram illustrates the difference between the two systems:

www.eurovac.com

WHY HY A WE WET MIX IX S SYSTEM M FOR OR ALUM UMINUM INUM?

The safest equipment involved in the capture of aluminum dust from the reparation of aluminum vehicles are wet mix systems as contact between aluminum particulates and oxygen in the right amounts can cause an explosion.

www.eurovac.com

WET MIX IX DUS DUST COL OLLE LECTOR OR – BASE E UN UNIT IT

• Mist eliminator eliminates moisture before motor

How the unit works:

• Dust is thoroughly mixed via venturi entry
• Water separates dust and majority of particles falls to the

bottom

• Remaining particles go through a set of baffles for further

separation

• Dust at bottom of unit is removed through the sludge drain

valve.

www.eurovac.com

POR ORTABL ABLE E WET MIX IX DU DUST COL OLLE LECTORS ORS

The Eurovac II Wet Mix Dust Collector offers the following features:

Eurovac II Wet Mix Dust Collector

• Initial venturi entry (for deep penetration of dust into water), secondary

baffles (to help knock water/dust back down) and final mist eliminator (99% efficient to 5 microns). Optional HEPA filter.

• 2.5HP 1560 watt motor (140CFM/145” water column)
• Three position vacuum switch: On/Off/Automatic (auto position means

portable will automatically turn on when tool is in use)

• 115/1/60Hz or 50Hz models available (with 15ft. Plug)

APPLICATIONS & USERS:

2 users 1 user 1 user

• Manual water intake port
• 2” ball valve, hose & bucket at the bottom of the separator for removing

sludge.

• Water level indicator: plastic site glass indicates when water refill is required
• Hydrogen relief vent
• Stainless steel construction

Note that wet collectors are not used for housekeeping but can be used to connect to a stationary port.

www.eurovac.com

POR ORTABL ABLE E WET MIX IX DU DUST COL OLLE LECTORS ORS

The NFPA Model of the Eurovac II Wet Mix Dust Collector has all of the features

• utlined in the base unit but also features the following to comply with NFPA code

requirements:

Eurovac II Wet Mix Dust Collector – NFPA Model

• Interlocking air supply which turns the unit on when tool is in

use

• Run delay switch and off delay switch
• Low water level shut down detection device

APPLICATIONS & USERS:

2 users 1 user 1 user

www.eurovac.com

CENTRAL AL WET MIX IX DU DUST COL OLLE LECTORS ORS

The Eurovac II Wet Mix Dust Collector offers the following features:

Eurovac II Wet Mix Dust Collector

• Automatic water level control system via an ultra sonic probe situated in a

reservoir of “quiet” water.

• Magnetic starter with overload protection and step down to low voltage (24V)

wiring for automatic on/off switches when the inlet is opened APPLICATIONS & USERS*:

• Initial venturi entry (for deep penetration of dust into water), secondary

baffles (to help knock water/dust back down) and final mist eliminator (99% efficient to 5 microns). Optional HEPA filter

• Manual water intake port
• Automatic hydrogen relief vent

1-2 users (2.5HP) 3-4 users (5HP) 1 users (2.5HP) 1-2 users (5HP) 1 users (2.5HP) 1-2 users (5HP)

• 115/1/60 (2.5HP) or 1 phase 60Hz 220/120 (4wire: 2 hot, 1 neutral, 1

ground) (5 HP). 50Hz models available*. Nema #L1420P plug provided for the 5HP model.

• 2.5HP (120CFM/115” water column) and 5HP (dual 120CFM/115”

water column each)

• 12 gauge steel construction which is epoxy powder painted and treated with

zinc oxide and rust inhibitor. Option to upgrade to stainless steel.

www.eurovac.com

CENTRAL AL WET MIX IX DU DUST COL OLLE LECTORS ORS

The Eurovac I Wet Mix Dust Collector offers the following features:

Eurovac I Wet Mix Dust Collector

• Automatic water level control system via an ultra sonic probe situated in a

reservoir of “quiet” water.

• 5HP (140 CFM/60”WC), 10HP (275CFM/60” WC) and 20 HP

(380CFM/60”WC)

• 208-240, 460 and 575/3/60Hz or 50Hz models available*. Three phase

cord and plug supplied by others

• Starter with overload protection which is pre-wired to blower
• 20,000+ hours of continuous use

APPLICATIONS & USERS*:

• Initial venturi entry (for deep penetration of dust into water), secondary

baffles (to help knock water/dust back down) and final mist eliminator (99% efficient to 5 microns). Optional HEPA filter

• Automatic hydrogen relief vent

3-4 users (5HP) 6 users (10HP) 7-8 users (20HP) 1-2 users (5HP) 2-3 users (10HP) 4-5 users (20HP) 1-2 users (5HP) 2-3 users (10HP) 3-4 users (20HP)

• 12 gauge steel construction which is epoxy powder painted and treated

with zinc oxide and rust inhibitor. Option to upgrade to stainless steel.

www.eurovac.com

CENTRAL AL WET MIX IX DU DUST COL OLLE LECTORS ORS

The Eurovac III Wet Mix Dust Collector offers the following features:

Eurovac III Wet Mix Dust Collector

• Automatic water level control system via an ultra sonic probe situated in a

reservoir of “quiet” water.

• PLC control panel
• 20,000+ hours of continuous use

APPLICATIONS & USERS*:

• Initial venturi entry (for deep penetration of dust into water), secondary

baffles (to help knock water/dust back down) and final mist eliminator (99% efficient to 5 microns). Optional HEPA filter

• Manual water intake port
• Hydrogen relief vent
• 15HP-75 HP (additional performance details per unit available upon

request)

• 208-240, 460 and 575/3/60Hz or 50Hz models available*

Consult representative for number of users per application as it relates to size of system

www.eurovac.com

WET MIX IX INT INTERCEPT EPTOR OR

Eurovac also offers a wet mix interceptor that works in conjunction with existing

• r new Eurovac central systems to capture aluminum dust and can be used to

replace the portable wet mix dust collector.

www.eurovac.com

COM OMPOS OSITE ITE

• Combustible dusts can present explosion hazard in certain conditions
• Carbon fiber has emerged as another popular material in the construction of modern vehicles.
• Carbon fibers can pose health hazard and are electrically conducive (cause short circuiting)

www.eurovac.com

EURO UROVAC C POR ORTABL ABLE E SYSTEMS MS

Eurovac II “Explosion Proof”

• 2.5HP 1300 watt motor (142CFM/68” water column)
• 115/1/60Hz or 50Hz models available. Cord and plug supplied

by others

• Canister Size: 5 or 10 Gallon (5 Gallon required for aluminum applications)

APPLICATIONS & USERS:

1 user 1 user 1 user

• Explosion proof starter and junction box
• Filter area: 30ft2

The Eurovac Explosion Proof vacuum safely collects explosive powders and dust.

• Cyclonic separation removes 85+% of dust. Final polyester

cartridge and HEPA filter (99.97% at 0.3 microns or larger)

www.eurovac.com

EURO UROVAC C POR ORTABL ABLE E SYSTEMS MS

Eurovac II “Single Venturi” Pneumatic

• Single venturi
• Canister Size: 5 or 10 Gallon (5 Gallon required for aluminum applications)

APPLICATIONS & USERS:

2 user 1 user 1 user

• Filter area: 30ft2

The Eurovac II “Single Venturi” Pneumatic features the following:

• Cyclonic separation with internal wall guarding filter from the dust

upon entry (removes 85+% of dust). Final polyester cartridge filter (99.93% at 3 microns or larger)

• Manual flow valve on the air intake to ensure proper amount of

airflow depending on application

www.eurovac.com

WELD LD FUM UME EXT XTRA RACTION ION

Another material that is hazardous to technicians when inhaled are the fumes caused from welding.

Welding is particularly hazardous to the lungs and can cause serious illnesses such as lung damage and various types

• f cancer. Health effects from certain

fumes may also cause kidney damage, stomach ulcers and nervous system damage to name a few.

www.eurovac.com

CENTRAL AL FUM UME EXT XTRACT CTION ION ARM & F FAN

• Steel arm tubes, cast aluminum joins with friction disc

are fully adjustable to desired tension

• Built-in shut off damper in every arm
• Heavy duty 360 degree swivel with safety stop
• Optional extension booms available for added reach
• Standard 6”x14’ arm length & diameter; other sizing
• ptions available

www.eurovac.com

BOXA XAIR IR FIL ILTER R UN UNIT IT

Eurovac’s mobile BoxAir filter unit is designed to capture, filter and exhaust air impurities created during welding, metal processing or workshop activities.

• Self supporting joints and flexible hose for easy

placement

• Optional HEPA Filter
• 700 CFM @ Hood
• Arm Diameter: 6”; Arm Length: 10’ (other sizes

available)

• 115/1/60
• Spark Trap, cartridge filter

www.eurovac.com

POR ORTABL ABLE E FUM UME E EXT XTRACTION TION SYSTEM

• Self supporting joints and flexible hoses for easy placement
• Optional HEPA Filter
• 700 CFM @ Hood

Eurovac’s Portable Filtering unit RollOut:

• Arm Diameter: 6”; Arm Length: 10’ (other sizes

available)

• Metal mesh (sparks), Cartridge Filter and Carbon After Filter
• Pulse Cleaning System
• Spark Trap
• 115/1/60

www.eurovac.com

OE OE APPROVALS ALS

* **

* BMW OE Approval is for the Eurovac II explosion proof system ** Porsche Canada exclusively

The Eurovac Wet Mix Dust Collector and Fume Extraction System is approved by the following automakers for the repair of their respective aluminum vehicles:

www.eurovac.com

QU QUEST STION IONS? S?

www.eurovac.com

44 Milvan Dr Toronto, Ontario M9L 1Z3

PHONE: 1-800-265-3878 (toll free) or 416-744-4276 EMAIL: info@eurovac.com

5927 Center Rd, Unit 3 Valley City, OH 44039
