SLIDE 1
Ove Nilsson Ove Nilsson Ume, Sweden Ume, Sweden Recipient of the - - PowerPoint PPT Presentation
Ove Nilsson Ove Nilsson Ume, Sweden Ume, Sweden Recipient of the - - PowerPoint PPT Presentation
Ove Nilsson Ove Nilsson Ume, Sweden Ume, Sweden Recipient of the 2007 Marcus Wallenberg Recipient of the 2007 Marcus Wallenberg Prize Prize Regulation of Flowering in Trees - Translation into Tree Growth and Development Ove Nilsson
SLIDE 2
SLIDE 3
Annuals and Perennials
Arabidopsis Aspen
SLIDE 4
SLIDE 5
SLIDE 6
SLIDE 7
Daylength is Critical, Not Temperature
16:00 9:00
Garner & Allard 1920
SLIDE 8
The Molecular Basis for the Coincidence Model
SLIDE 9
The Molecular Basis for the Flowering Signal (Florigen)
FT PROTEIN FT Protein FT RNA FD Protein FD Protein + CONSTANS RNA CONSTANS Protein
SLIDE 10
SLIDE 11
The Populus Genome
SLIDE 12
Populus FT/TFL Homologues
SLIDE 13
TFL1 and FT: Functional Conservation
35S::PtTFL1 WT 35S::PtFT1
Böhlenius et al.. 2006. Science 312, 1040-1043
SLIDE 14
Expression of PtFT1 Increases With Age
Time (years)
2 4 6 8 4 3 2 1
Time (years) Time (years)
MAY JUNE
pttFT1/18Sx10
Samples from young shoots of a Poplar clone planted yearly in Oregon Flower initiation
Böhlenius et al., Science 2006
SLIDE 15
35S::PtFT1 Poplars are Extremely Early Flowering!
Flowers 4 weeks after transformation!
Böhlenius et al.. 2006. Science 312, 1040-1043
SLIDE 16
35S::PtFT1 Poplars Produce Catkins
6 month old plants
Böhlenius et al.. 2006. Science 312, 1040-1043
SLIDE 17
35S::PtFT1 Aspens Have Normal Flowers
35S::PtFT1 Catkin 35S::PtFT1 Male flower
SLIDE 18
Bud Set and Dormancy is a Short Day Response in Aspen Trees
WT 6 weeks of short days
SLIDE 19
35S::PtFT1 Inhibits Short Day-Induced Growth Cessation and Bud Set
LD 32 SD 64 SD 5 days 5°C 35S::PtFT1 WT
Böhlenius et al.. 2006. Science 312, 1040-1043
SLIDE 20
PtCO2 expression
Time (hours)
LD SD
pttCO2/18Sx10
Böhlenius et al., Science 2006
SLIDE 21
PtFT1 expression
LD SD
Time (hours)
pttFT1/18Sx10
Böhlenius et al., Science 2006
SLIDE 22
PtFT1 RNAi Induces Premature Bud Set
Böhlenius et al., Science 2006
SLIDE 23
PtFT1 Controls Dual Aspects of Perennial Growth Behaviour
Induction of reproductive phase Growth cessation and bud set
Time (years)
2 4 6 8 4 3 2 1
Time (years) Time (years)
MAY JUNE
Time (hours)
pttFT1/18Sx10
SLIDE 24
Seasonal Regulation of PtFT1
30 year old Populus tremula growing in Umeå (64°N) 21 hrs critical daylength?
SLIDE 25
Critical Daylength for Growth Cessation and Bud Set
Umeå 63°N: 21 hrs Ronneby 56°N: 17 hrs Stockholm 59°N: 19 hrs Dresden 50°N: 15 hrs
Provenances of European Aspen (Populus tremula)
Böhlenius et al., Science 2006
SLIDE 26
At the Critical Daylength PtFT1 is Down-Regulated
(21 hrs) (19 hrs) (17 hrs) (15 hrs)
Böhlenius et al., Science 2006
SLIDE 27
Could the Phase of CO mRNA Oscillation be Setting the Critical Daylength?
16 hrs 12 hrs 8 hrs
SLIDE 28
(21 hrs) (19 hrs) (17 hrs) (15 hrs)
The Phase of CO mRNA Oscillation Predicts the Critical Daylength
Böhlenius et al.. 2006. Science 312, 1040-1043
SLIDE 29
Annuals and Perennials
Arabidopsis Aspen
SLIDE 30
Tree secondary growth produces wood Tree secondary growth produces wood
SLIDE 31
Jeanette Nilsson
Development
Organization of the Vascular Meristem Organization of the Vascular Meristem
Phloem mother cells Xylem mother cells Cambium
SLIDE 32
Primary xylem
Jeanette Nilsson
Expression in cells of provascular tissue Expression in cells of provascular tissue
Pith CambiumPrimary Phloem
SLIDE 33
Jeanette Nilsson
C & D A & B
Pt t HB3 expression defines provascular
development
SLIDE 34
Pt t HB3 RNAi affects secondary growth Pt t HB3 RNAi affects secondary growth
Jeanette Nilsson
SLIDE 35
Jeanette Nilsson
Reduced growth rate of xylem Reduced growth rate of xylem
SLIDE 36
Jeanette Nilsson
Reduced activity in the cambium Reduced activity in the cambium
T89 PttHB3 RNAi
Phloem Xylem
Cambium
Ph Xm
C
SLIDE 37
Conclusions Conclusions
PtFT1 controls the length of the juvenile phase in trees
- Breeding tool! Prevented flowering!
PtFT1 controls the length of the growing season in trees
- Adaptation to new climates?
- PttHB3 controls the activity (and identity?) of the vascular
cambium and hence secondary growth in trees
- The gene that allows a tree to ”grow as a tree”. Tool to increase wood production?
This constitutes three of the most important processes associated with the ”tree life strategy” ”Tailor-made trees”
SLIDE 38
Acknowledgements Acknowledgements
Tree flowering and growth cessation
Henrik Böhlenius Maria Eriksson Stefan Jansson Hans Hönicka Amy Brunner Steve Strauss
PttHB3 and vascular cambium identity
Jeanette Nilsson Bo Zheng Göran Sandberg
