SLIDE 1

An Integrated Laboratory for Collaborative Design in the Air Transportation System Arne Bachmann, Jesse Lakemeier, Erwin Moerland

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 1

SLIDE 2

• Research institution
• Space agency
• Project management facility

www.DLR.de • Folie 3 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

German Aerospace Center – DLR Deutsches Zentrum für Luft- und Raumfahrt

SLIDE 3

≥ 7000 employees across 32 research institutes and facilities at 13 sites International offices in Brussels, Paris and Washington By the way: DLR is the largest software house in Germany

www.DLR.de • Folie 4 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Locations and employees

 Köln  Oberpfaffenhofen

Braunschweig 

 Göttingen

Berlin 

 Bonn  Neustrelitz

Weilheim  Bremen 

 Trauen  Dortmund

Lampoldshausen  Hamburg  Stuttgart 

SLIDE 4

• Customers and partners:

Governments and ministries, agencies and organisations, industry and commerce, science and research

www.DLR.de • Folie 5 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

National and International Networking

World Europe Germany

SLIDE 5

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 8

Aircraft design Requirements Technologies

Mobility Environment Economics

DLR / Airbus Airbus Airbus Airbus Boeing MIT Bauhaus Luftfahrt DLR TU Delft Lockheed Martin DLR General Electrics EADS-IW TERRAFUGIA CARTER Martin Jetpack Airbus

Propulsion Aerodynamics Lightweight & Assembly

SLIDE 6

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 9

Old concepts – New again

SLIDE 7

• Development of an innovative concept for interdisciplinary collaboration
• Design and construction of an highly integrated design laboratory
• Evaluation and improvement of the lab and working methods by continuous

usage in experiments and in cooperation projects

www.DLR.de • Folie 11 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Introduction to project

SLIDE 8

www.DLR.de • Folie 12 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Interdisciplinary co-located design institutions in aerospace applications

SLIDE 9

• Cf. Concurrent Engineering Facility @ DLR Bremen, D (CEF)
• Cf. Concurrent Design Facility @ ESA, ESTEC, Nordwijk, NL (CDF)
• Ricky Curran:
• concurrency (product-oriented)
• collaboration (system-oriented)
• value-driven (value-oriented)
• Nel Wognum et al.:
• concurrent engineering
• collaborative engineering
• collaborative innovation

www.DLR.de • Folie 13 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

How to we relate to CE?

SLIDE 10

• Bandecchi [2007]
• 1. Process
• 2. Multi-disciplinary team
• 3. Facility
• 4. Integrated design model
• 5. Software and hardware infrastructure
• Define interfaces
• Better room
• Use moderation

www.DLR.de • Folie 16 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Concurrent Engineering

SLIDE 11

• 1. Core development of disciplinary analysis tools. Collab by sharing results
• 2. Define a common interface for data transfer and storage, e.g. CPACS
• 3. Combination and interpretation of workflows built up from the tools, connected

via the common interface, MDAO, verify the understanding of the process

• 4. Collaborative workflow application on specific problems, communication
• 5. Feeding back the common generated knowledge into earlier phases –

collaborative development and using or anticipating others‘ reqs in the institutes

www.DLR.de • Folie 17 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Phases for collaborative design

SLIDE 12

• 1st gen: optimization,

efficiency

• 2nd gen: interdisciplinary

communication

• 3rd gen: distributed design

www.DLR.de • Folie 18 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

3 generations of multidisciplinary design & optimization

SLIDE 13

• Handbook methods

VAMPzero LY

• HandbookAero

AS

• Aerodynamics

LiftingLine 1 / POLINT AS

• VSAERO

AS

• Structures

BoxBeam FA

• PARA_MAM / S_BOT

FA, LY

• AC-CRASH 2

BK

• Aeroelastics

MONA AE

• ELWIS 3

LY

• Propulsion

TWDat / GTlab 4 AT

• Landing Gear

LGConcept AE

• Mission Simulation

TCM LY

• MS 5

RM

• T/O LDG

MAPET FT

• Flight Dynamics, Loads

FDS 6 RM

• Handling Qualities

HAREM FT

• Cabin PreDesign

FuMe 7 LY

• Boarding Simulation

TOMICS FW

• Costs

LCC LY

• DOC

LY

• Over-all Noise

PANAM AS

• Engine Noise

HEIDI AT

• Climate Impact

AirClim PA

• ATM simulation / mission

TrafficSim FL

• Radiation

RADIATION ME

• IR Signature

SIGMA MF

• Radar Signature

NIRATAM HR www.DLR.de • Folie 20 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

DLR tools with CPACS interface

COM COM

Power Equation LP Spool Power Equ. HP Sp. HPT Cooling

COM COM

Power Equation LP Spool Power Equ. HP Sp. HPT Cooling

• 2000

2000

• 1000
• 5000

2000 4000 6000

SLIDE 14

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 22

Outer boundaries of research field

(7 M of Ishikawa, fishbone method) „Problem“ Management Milieu Man Material Method Machine Measuring

SLIDE 15

Outer boundaries of research field

• huMan: Ergonomics, physiology, acceptance and success
• Machine: Software interfacing, moderation support, data

management & traceability, visualization & connectivity

• Milieu: Creativity, productivity, relaxation, site reachability
• Material: Display technology, interactivity, conference and

collaboration rooms, cockpit and flight simulators

• Measuring: Describe and test the process, check process evolution

and optimize it (meta-process, meta-method)

• Management: Compare with existing projects, offer to and manage

the laboratory for external partners

• Method: Knowledge management, visualization, moderation,

MDO/MDAO, iterativ and agile processes

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 23

SLIDE 16

• improving interdisciplinary communication
• improving (practical) knowledge

management

• accelerating decision making processes

during conceptual studies

• developing visualization modes for

interdisciplinary knowledge exchange

• improving integration methods with

external partners

• offering integration services and

supporting partners in efficient model integration

Requirements for the lab Goals

• type of video signal (output, distribution, input)
• usage of displays – connection type and signal no.
• layout of visualisation / type of contents to stream
• network connectivity, security and privacy
• available software collection
• support for spontaneous software installations
• remote software and remote desktop access
• mobile computing and input support
• logging and recording
• conduct and moderation
• data exchange and storage
• seating arrangement
• spatial range of motion and interaction
• necessary roles of supporting personnel

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 24

SLIDE 17

• Three-stage concept:
• Prototype
• Research platform
• Application platform

www.DLR.de • Folie 25 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Iterative approach to design room design

SLIDE 18

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 26

Room plan – Integrated Design Laboratory (IDL)

SLIDE 19

• What we thought

would be cool

www.DLR.de • Folie 28 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Lounge design

SLIDE 20

• What our boss thought

would be more decent

www.DLR.de • Folie 29 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Lounge

SLIDE 21

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 30

Lounge

SLIDE 22

www.DLR.de • Folie 31 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Visualization

SLIDE 23

www.DLR.de • Folie 32 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

SLIDE 24

www.DLR.de • Folie 33 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

SLIDE 25

www.DLR.de • Folie 34 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

SLIDE 26

www.DLR.de • Folie 35 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

SLIDE 27

• Cockpit simulator integration
• Handling qualities testing

integrated into the design loop

www.DLR.de • Folie 36 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

More integration

SLIDE 28

• Detailed technical specification for the construction of integrated design rooms

www.DLR.de • Folie 37 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

User connectivity

Telecommunication Net Meeting Periphery HPC Cluster Desktop Computers AppGate AppGate Recording Playback Multi Screen Controller Multi Screen Management Visualization Terminal Input Devices Process Management Terminal Process & workflow control Central Computer Storage & Backup Retrieval & rollback Input Computer Flight Simulator Programs (pre-installed) Interfaces

Display Connections

Output

e.g. CPACS

Collaboration Visualization

Data Interface Integration Framework Workstation Input Cockpit Input Display Input

SLIDE 29

• Security
• DLR Intranet
• Local network
• Public internet
• Ease of connection
• Wireless
• Cable-bound

www.DLR.de • Folie 38 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Network

SLIDE 30

• Bandecchi et al. 2007

www.DLR.de • Folie 39 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Design Room at ESA – CDF

SLIDE 31

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 40

Design Room at ESA – CDF

SLIDE 32

• Too strict for us
• We don‘t know and cannot know all upcoming use cases
• We need flexibility above all
• For experimentation
• But actually, because we expect demands to change a lot

www.DLR.de • Folie 41 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Fixed desks and arrangement

SLIDE 33

Control rooms

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 42

SLIDE 34

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 43

How to stream video to the network

SLIDE 35

• Power distribution
• Power transformators
• Ethernet cables
• Ethernet switches
• VGA switch and button
• VGA splitter
• VGA-VNC converter

www.DLR.de • Folie 44 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Electr(on)ic desk equiment – excerpt

SLIDE 36

• Circuit diagram
• Power
• Network
• Video signals
• Connectors

www.DLR.de • Folie 45 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Working desk design

SLIDE 37

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 47

Seating arrangement – Semicircle

SLIDE 38

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 48

Seating arrangement – Islands

• Workshop at DLR Hamburg, 40 participants

SLIDE 39

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 49

SLIDE 40

End of 2011

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 51

SLIDE 41

16.03.2012

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 52

SLIDE 42

25.04.2012 Project meeting

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 53

SLIDE 43

23.05.2012 Introductory session for visiting students

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 54

SLIDE 44

IDL as a lab for cognitive research on multidisc. collab.

• Challenges pretty well known
• horizontal: communication between the disciplines is difficult
• vertical: across hierarchical structures, different cultures
• Not so much clear how to overcome them
• Basic research is less than well-founded
• Research in multidisciplinary collaboration within the IDL

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 56

SLIDE 45

IDL as a cognition laboratory – basics

• Experiment to assess ergonomics, visualization
• Participants solve a challenging task
• Participants have differing environments:

 No support  Text support  Visual support  Both

• Hypothesis: Participants with visual support find better solutions
• This would affirm the ergonomics approach
• Extend by experiments regarding group collaboration

> An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012 www.DLR.de • Folie 57

SLIDE 46

• Better visualization capabilities – professional display wall

and even more simple connections and connectivity

• Baseline studies for the collaboration experiments – find

meaningful use cases

• More meetings in the lab, internally and externally
• Systematic experimentation with visual feedback, data

detail and group collaboration behaviour

www.DLR.de • Folie 58 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Outlook

SLIDE 47

Arne Bachmann Department of Integrated Aircraft Design DLR Institute of Air Transportation Systems Blohmstraße 18, 21079 Hamburg E-Mail: Arne.Bachmann@dlr.de www.dlr.de/ly/en

www.DLR.de • Folie 60 > An Integrated Laboratory for Collaborative Design in the Air Transportation System > Arne Bachmann > 06.09.2012

Contact information
