AIR TRAFFIC FLOW MANAGEMENT AND FLEXIBLE USE OF AIRSPACE

Contents

Concept of ATFM and FUA Timeline of Implementation Why is FUA required ATFM and FUA About ATFM in India CDM Partners involved in processes Benefits of FUA ATFM and FUA- Practical Process

Fundamental principle of FUA

The airspace should not be designated as either pure civil

• r military airspace, but rather be considered as a

continuum in which all user requirements have to be accommodated to the extent possible.

AIRSPACE RESOURCES BECOME AVAILABLE ON NEED BASIS TO THE STAKEHOLDERS

PROCESS of ATFM

• ATFM is a

collaborative process involving many stakeholders with diverse goals.

• CDM enables the

stakeholders to share the resources

• ptimally.

Identify constraints in the system

ATC

Develop strategies to mitigate constraints Monitor system status and demand

Flight Operators

TFM

Multi- national (ICAO)

Collaborate with service providers and stakeholders

• n solutions

Airport Operators Military

Analyze post-

• peration

Implement and manage actions

ASBU B0-NOPS Requirements

• Provide a solid foundation

for regulating traffic flow

• Predict demand and

capacity including quantified uncertainty measures

• Improved ATFM and ATFM-

AO integration

• Synchronization
• Initial User Driven

Prioritization Process (UDPP)

• Full Flexible Use of Airspace

(FUA)

• Complexity Management

Through the FUA Collaborative Decision Making Process

ATS, ASM and ATFM

AIRSPACE & ROUTE AVAILABILITY

ASM

Airspace management

CDM ATS

Air Traffic Services Provision

ATFCM

Air Traffic Flow & Capacity Management

AIRPORTS MILITARY OPERATORS CCC CIVIL OPERATORS AIRSPACE MANAGEMENT CELLS MILITARY ATS

AIR TRAFFIC DEMAND AIR TRAFFIC CONTROL CAPACITY

CIVIL ATS

FUA

Concept and FUA Timeline

The Flexible Use of Airspace (FUA) Concept has been developed at the three Levels of Airspace Management that correspond to Civil/Military co-ordination task. STRATEGIC COMPONENT ( ASM Level 1 ) Long term planning – large scale military exercises, significant changes to airspace and route structure and special events. This includes but is not limited to Airshows, Large Scale Events, Trade Fairs, etc. PRE-TACTICAL COMPONENT ( ASM Level 2) Airspace users engaged in normal operations e.g.: Aerial Surveys, Para Drop, Fly Past ; Activation of SUAs TACTICAL COMPONENT ( ASM Level 3) Day to day flight operation.

Establishment

• f pre-determined

airspace structures

ASM Level 1

Strategic Level

Day-today allocation of airspace according to users’ requirements

ASM Level 2

Pre-tactical Level

Real-time use

• f airspace allowing

a safe OAT/GAT separation

ASM Level 3

Tactical Level

ASM LEVELS and ATFM Stages

Strategic ATFM PLANNING ; Network Operations Plan CCC and Local FMP ; Impact Analysis and DAP CCC & Local FMP ; ATFM measures

Why is FUA required?

To ensure all stakeholders affected have full understanding of

• perations and requirements. ATC-Military.

To ensure airspace users have sufficient notice of operations via NOTAMs / Supplements. Air traffic planning, efficient flow of air traffic. Equal airspace usage.

Stakeholders for FUA

MILITARY

ATC AIRLINES AIR TRAFFIC FLOW & CAPACITY MANAGEMENT AIRPORTS GENERAL AVIATION HELICOPTERS STATE AIRCRAFT

AIRSPACE

ATFM AND FUA

• Network Wide View Shared

between Civil and Military

• Focus areas of cooperation

– Inclusion of future civil/military airspace requirements – Enhanced cooperation in crisis and contingency situations – ASM system support and data management – ASM Post Ops and Performance Monitoring

• Both ASM and FUA will focus on :
• Enhanced airspace utilisation by civil and

military

• Airspace Configurations
• ASM solutions
• Procedures
• Enhanced cooperation at pre-tactical and

tactical level

• Getting closer together planning and
• perations
• Integrating ASM/ATFCM
• Flexible Route deployment in the Upper

Airspace

AAI CENTRAL ATFM STRUCTURE

ACC- FMP ACC- FMP APP- FMP

TWR- FMP

TWR- FMP APP- FMP APP- FMP

ATFM Command Centre

• Objective is to manage and optimize

traffic flows by actively collaborating with airlines, airport, defense and other stakeholders on daily basis.

• The Central Command Center ( CCC)

will receive strategic and tactical FPL , Weather, Airspace ,Traffic, Airport information for accurate Situational Awareness

• Flow Management Position(FMP) will

be the unit implementing ATFM program

WEB PORTAL

13

MAIN FOCUS AREAS FOR INDIAN ATFM

FUA ASM HUMAN RESOURCE MANAGEMENT DETERMINE AND MEASURE OPERATIONAL PERFORMANCE

ANS STRATEGIC PLAN

Integrated Airports with ATM CDM Philosophy

Framework of FUA & ATFM

Level 1 Strategic

Level 2

Pre- Tactical

Level 3

Tactical

HLAPB

National Level AMC

Regional Level AMC Civil/Military Operators and Users Area Control Centers Civil/Military ATS Units Coordination with ATFM Directorate Coordination with CCC Coordination with ATFM FMPs

CCC POSITIONS

CCC

• perational

supervisor ATFM Manager W ATFM Manager E ATFM Manager N ATFM Manager S Flight data management units

ASM (FUA, routes coordination) CDM (airports, GA, Military Military representative CDM (airlines) Airline representative AIS and CNS facilities monitoring

Replay position Special events monitoring

FUA Elements

• Temporary reserved area (TRA) :An airspace temporarily reserved and

allocated for the specific use of a particular user during a determined period of time and through which other traffic may be allowed to transit ATC Clearance.

• Temporary segregated area (TSA) :An airspace temporarily segregated and

allocated for the exclusive use of a particular user during a determined period of time and through which other traffic will not be allowed to transit.

• Conditional Routes: A conditional route is a non-permanent ATS route or

portion thereof which can be planned and used under specified conditions

NO FUA ( NORMALLY PUBLISHED AS NOT AVAILABLE H-24 ) FUA EFFECT ON ATFM PROHIBITED PROHIBITED NO EFFECT DANGER TSA: RELEASED AS SOON AS ACTIVITY STOPS AIRSPACE CAPACITY INCREASES RESTRICTED TRA: CROSSING POSSIBLE WHEN ACTIVE / RELEASED AS SOON AS ACTIVITY STOPS AIRSPACE CAPACITY INCREASES

Effect of FUA on ATFM

18

CDR 1 CDR 2 CDR 3

Not Plannable Permanently plannable during the times published in AIP  Expected to be available most of the time  Plannable same way as permanent ATS routes Non-permanently plannable  Daily allocated as negotiated  Plannable only in accordance with daily AUP/CRAM  Part of pre-defined routing scenario

CDR Categorisation

 Usable upon ATC instructions only as short notice routing

Benefits of FUA

Access and Equity Participation by the ATM Community Predictability Safety Security Efficiency

20

ATFM & FUA How does it work in practice?

STRATEGIC PHASE

ASM Level 1

• Formulate the national policy for airspace

management,

• Periodically assess the national airspace

structure and ATS route network for flexible airspace structures and procedures in the upper and lower airspace

• Formulate and periodically review the

procedures and efficiency of ASM Level 2 and Level 3 operations

• Ensure a framework for effective co-
• rdination between both civil and military

ATS, ASM and ATFM at the three ASM Levels .

• Approve the airspace change process from

Civil/Military for ensuring optimum utilization

• f Airspace.

Strategic Phase of ATFM

• A Phase for gathering and analysing Capacity and Demand

data: – Flight Schedule Data: – Assess, review and publish:

• Airport capacity
• Airspace capacity

– Major events: Sports events, Elections, Trade Fairs ……. – Weather: long term prediction

• The Strategic Network Plan may recommend (for DCB)

– in the modification of the organization of airspace, – Special Use Airspaces activation / deactivation – Airline schedule updates, – Alternate/mandatory route activation and ; – reporting of possible measures to contain demand as well as the estimated time delay expected in each departure;

PRE-TACTICAL PHASE

ASM LEVEL 2

• Consists of the day-to-day

management and temporary allocation

• f airspace
• AMC at National level, integrated with

C-ATFM Central Command Centre

• AMCs at regional level in four Upper

Area Control Centers at Chennai, Delhi, Kolkata and Mumbai.

• AMCs shall strictly adhere to the

policies formulated by the HLAPB

PRE TACTICAL PHASE of ATFM

• CCC at the national level manages the

airspace resource since civil military co‐ordination is necessary and since arbitrations can also be necessary between different civil requests.

• FMPs at the ACC level along with the AMCs

manage other resources such as actual rostering, sector configuration etc. – FPL – Events – Conditional routes – Rerouting – scenarios if necessary

TACTICAL PHASE

ASM LEVEL 3

• To activate, deactivate or reallocate in real time

the airspace allocated at level 2.

• Real time ASM level 3 coordination is an essential

element to achieve the goals of FUA .

• Quick and efficient coordination and data sharing

preferably achieved through integration of both Civil and Military ATS Automation systems

• The ASM Level 3 activities maximize the potential

for traffic re-routing in real time to use those CDRs that are made available at short notice.

TACTICAL PHASE of ATFM

• CCC monitors DCB at all nodes and initiates action

when necessary.

• The resources are mainly managed at the ACC /

Airport level since the real time workload on the ATC sectors is an essential element. – FPL – Aircraft Operators (AO) messages (CHG, DLA, FCM, SWM) – ATC messages (REA, AFP) – Capacity changes – Regulations slots – Re‐Routeing Proposals (RRP) – CDR-3

A PRACTICAL CASE

SCENARIO

• Air Exercise Planned by IAF
• Airspace Reservation Requisition

sent to AAI

• AAI analysis of Air Traffic impact (

based on report from ATFM system)

• AAI and IAF mutually agree on the

proposal.

• AAI initiates necessary

notifications. Action By ATFM

• Area of Exercise created in ATFM

system

• Air Traffic Impact on activation is

analyzed.

• Suggest any modification/realignment
• f Area of Exercise, if necessary.
• On finalization , CCC initiates a CDM

exercise and initiates necessary ATFM measures ( ground delay, reroutes )

• The concerned FMP executes the

plan.

Report (EXP3 - VIDF GROUP)

State (=):Preview/Finished Total:55 Interval (=):1Min Operation (=):All Activation (=)All Plan Type (=):FPL, RPL, Flight Schedule Begin Time (>=): End Time (<): ADEP (=): ADES (=): Level (>=): Interval (=): Level (<=):

• Acft. Type (=):

Equip Wake Turb: EOBT (=): EET (=): Takeoff (=): Arrival (=): Airline (=):

SAMPLE REPORT

AAI MOD

Next Steps-Establishing Effective Civil-Military

Coordination

Automation System –to–Automation System Automated Tool for FUA Coordination

Civil Military

Airports Authority of India
