NBAA Air Traffic Services An Introduction NBAA ATS | Fall 2017 Todays Topics Air Traffic Services (ATS) Overview Terminology Traffic Management Initiatives (TMIs) FAA web resources Your chance to ask questions 2 Air Traffic

slide-1
SLIDE 1

NBAA Air Traffic Services

An Introduction

NBAA ATS | Fall 2017

slide-2
SLIDE 2

2

Today’s Topics

§ Air Traffic Services (ATS) Overview § Terminology § Traffic Management Initiatives (TMIs) § FAA web resources § Your chance to ask questions

slide-3
SLIDE 3

3

Air Traffic Services

The Air Traffic Services Mission

“To afford a voice for equitable representation of business aviation in the daily strategic plan of operations for the National Airspace System (NAS), ensuring equity in airspace and delay allocation, and to provide current information to NBAA Members about NAS events and constraints.”

slide-4
SLIDE 4

4

Air Traffic Services

What ATS Does Daily

§ Represents business aviation in NAS planning and execution

  • Ensures equity for BA operators
  • Ground delay programs, airspace flow programs, ground stops, reroutes, etc.

§ Provides real-time NAS information to Subscribers and Members

  • Potential constraints/delays
  • Suggested options to avoid delays
  • EDCT notifications
  • TFR information

§ Provides BA industry information to FAA Air Traffic Managers

  • Expected volume increases due to seasonal/special events
slide-5
SLIDE 5

5

Air Traffic Services

What ATS Does Beyond the Command Center

§ Education of FAA personnel on Business Aviation issues

  • Examples:
  • Altitude-capped AFPs
  • LGA RNAV approach

§ Education of Subscribers on ATC and NAS issues

  • Training sessions
  • Articles
  • Web Resources

§ Voice in FAA Collaborative Decision Making (CDM) workgroups:

  • Future Airspace (NextGen), Surface, Weather, etc.
slide-6
SLIDE 6

6

Air Traffic Services

CDM Workgroup Involvement

§ Flow Evaluation Team (FET)

  • Ernie Stellings, Industry Lead

§ Surface CDM Team (SCT)

  • Dean Snell

§ Weather Evaluation Team (WET)

  • John Kosak

§ CDM Automation Team (CAT)

  • Jim McClay

§ Future Concepts Team (FCT)

  • Mike Schwab
slide-7
SLIDE 7

7

Air Traffic Services

What We Can Do for Subscribers

§ Instant Information

  • TFRs, GDPs, ground stops, AFPs, CTOPs, reroutes, etc.

§ Insight (AM, Afternoon, Evening, Overnight Updates)

  • Where and when issues are expected – anticipated impact

§ Alternatives

  • Examples - airports not in GDPs, route-outs for AFPs

§ Flight-specific information

§ Based on the list you send us

slide-8
SLIDE 8

8

Traffic Flow Management

Terminology

§ Balance between plain language and “TFM-speak” § Bridging the gap

  • NBAA-provided training
  • Improved ATS communications
  • New ATS Glossary of Terms – self-education for operators
  • www.nbaa.org/ops/airspace/tfm/glossary/
slide-9
SLIDE 9

9

Traffic Flow Management

What is Traffic Flow Management (TFM)?

§ Definition – “The craft of managing the flow of air traffic in the National Airspace System (NAS) based on capacity and demand.” § Synonymous with Air Traffic Flow Management § Different from providing air traffic separation – TFM looks at overall flow § Accomplished through Collaborative Decision Making (CDM)

  • Collecting information/opinions from all stakeholders before making decisions
slide-10
SLIDE 10

10

Traffic Flow Management

Air Traffic Control System Command Center (ATCSCC)

§ Located in Vint Hill, Virginia (south of Dulles Airport) § Location of NBAA Air Traffic Services § Oversees and manages overall flow of air traffic within the NAS

  • 5,000+ aircraft airborne simultaneously, 50,000+ operations daily

§ Is responsible for coordinating traffic management initiatives

  • Minimizes congestion and delay
  • Maximizes safety and capacity

§ Responsible for managing airspace, not individual aircraft

slide-11
SLIDE 11

11

Traffic Flow Management

Traffic Management Initiatives (TMIs)

§ Two Types

  • Terminal
  • Ground delay programs, ground stops, etc.
  • Enroute
  • Airspace flow programs, reroutes, miles-in-trail, etc.

§ Causes

  • Weather
  • Volume (either terminal or enroute)
  • Equipment (runway construction, approach, approach lighting, etc
  • Other (aircraft incident)
slide-12
SLIDE 12

12

Traffic Flow Management

Scope Explained

§ Scope refers to what flights are captured in an initiative § Can reference:

  • Center
  • Distance
  • Tier (1STTIER, 2NDTIER, etc)

§ Centers are abbreviated by 3-letter codes beginning with the letter “Z”

  • ZNY = New York Center
  • ZDC – Washington Center
  • ZAU = Chicago Center
  • etc.
slide-13
SLIDE 13

13

Traffic Flow Management

Scope Explained - Center

TEB ground stop Scope: ZDC+ZOB

slide-14
SLIDE 14

14

Traffic Flow Management

Scope Explained - Distance

TEB ground stop Scope: 1000 miles+CZY

slide-15
SLIDE 15

15

Traffic Flow Management

Scope Explained - Tier

TEB ground stop Scope: 1STTIER / 2NDTIER

slide-16
SLIDE 16

16

Traffic Flow Management

Ground Stops

§ Designed to rapidly handle an excess number of arrivals at an airport for a relatively short period

  • Only traffic TO the airport
  • Only traffic to THAT airport
  • Departures from the airport not affected

§ Often used during thunderstorm impact or for aircraft incidents § Most restrictive form of terminal TMI § Ground stops do NOT result in EDCTs

  • Why is this important?
slide-17
SLIDE 17

17

Traffic Flow Management

Ground Delay Programs (GDPs)

§ Used to manage traffic to a specific airport

  • Only traffic TO the airport
  • Only traffic to THAT airport
  • Departures from the airport not affected

§ Delays spread out the demand § Expect Departure Clearance Times (EDCTs)

  • Valid +/– 5 minutes
slide-18
SLIDE 18

18

Traffic Flow Management

Airspace Flow Programs (AFPs)

§ Manage traffic through specific airspace

  • Not to specific airports - all airports beyond AFP boundary are impacted
  • Start as Flow Evaluation Areas (FEAs)
  • Line in space
  • Center boundary
  • Straight line
  • Polygons/Circles
  • Become Flow Constrained Areas (FCAs)

§ Become AFPs - generate EDCTs like a GDP

  • Boundary arrival time versus airport in GDPs
  • Same “pop-up factor” issues as with GDPs
slide-19
SLIDE 19

19

Traffic Flow Management

Reroutes

§ Reroutes are issued both by FAA Advisory and tactically by ATC § Types of Reroutes:

  • Preferred Routes
  • Coded Departure Routes (CDRs)—in the Route Management Tool (RMT)
  • Playbook Routes
  • “Ranking” of reroutes
  • REQ / RMD / FYI reroutes

§ When to re-file

  • Don’t re-file inside of 45 minutes from departure, or anytime with an EDCT – work with

clearance or call ATS

  • Otherwise, go ahead and re-file or just enter it into FMS
slide-20
SLIDE 20

20

Traffic Flow Management

FAA TFM Web Resources

slide-21
SLIDE 21

21

Traffic Flow Management

FAA TFM Web Resources - OIS

§ Operational Information System (OIS)

  • Real-time “dashboard” view of the NAS
  • Delay programs
  • Ground stops
  • Arrival/departure delays
  • Airport closures
  • Good “first stop” when checking the NAS
  • http://www.fly.faa.gov/ois/
slide-22
SLIDE 22

22

Traffic Flow Management

FAA TFM Web Resources - OIS

slide-23
SLIDE 23

23

Traffic Flow Management

FAA TFM Web Resources – Advisories Database

§ Advisories Database

  • Advisories issued for significant events in the NAS
  • Numbers reset to 001 at 0000z every day
  • GDPs, ground stops, reroutes, equipment outages, etc
  • http://www.fly.faa.gov/adv/advADB.jsp
slide-24
SLIDE 24

24

Traffic Flow Management

FAA TFM Web Resources – Advisories Database

slide-25
SLIDE 25

25

Traffic Flow Management

FAA TFM Web Resources – Ops Plan Advisory

§ Operations Plan

  • Issued as summary of Planning Telcon
  • Telcon held every two hours starting at 0715ET
  • Planning for following six hours
  • Terminal constraints
  • Enroute constraints
  • Expected delay programs, ground stops, or reroutes
  • Plain-English summary
  • GREAT way to get an overview of the NAS
slide-26
SLIDE 26

26

Traffic Flow Management

FAA TFM Web Resources – Current Reroutes

§ Summary of required, recommended, or FYI routes currently in effect § Reroutes always issued by Advisory, but this page is easier to look at § http://www.fly.faa.gov/ratreader/jsp/index.jsp

slide-27
SLIDE 27

27

Traffic Flow Management

FAA TFM Web Resources – Reading a Reroute

slide-28
SLIDE 28

28

Traffic Flow Management

FAA TFM Web Resources – National Playbook

§ Pre-coordinated routes that can be implemented rapidly § Organized by:

  • Airports
  • Airway Closures
  • East to West Transcon Routes
  • Regional Routes
  • West to East Transcon Routes

§ http://www.fly.faa.gov/playbook/pbindex.html

slide-29
SLIDE 29

29

Traffic Flow Management

FAA TFM Web Resources – National Playbook

§ Example: Vulcan (VUZ) Playbook route § Used when convective weather forms in the upper Midwest or Ohio Valley, obstructing normal transcon routes § Moves traffic south of ZKC, ZID, ZOB and into ZME and ZTL

slide-30
SLIDE 30

30

Traffic Flow Management

FAA TFM Web Resources – National Playbook

slide-31
SLIDE 31

31

NBAA Air Traffic Services

Contact Information

§ Jim McClay – jmcclay@nbaa.org § For more information about ATS - www.nbaa.org/ats
