AE-705: Introduction to Flight Takeoff & Landing by Hemashree Kakar Mechanical Engineering Department RTU Kota AE-705 Introduction to Flight Lecture-18 Capsule-09 Take-off and Landing AE-705 Introduction to Flight Lecture-18

slide-1
SLIDE 1

AE-705 Introduction to Flight Lecture-18 Capsule-09

AE-705: Introduction to Flight Takeoff & Landing

by Hemashree Kakar

Mechanical Engineering Department RTU Kota

slide-2
SLIDE 2

AE-705 Introduction to Flight Lecture-18 Capsule-09

Take-off and Landing

slide-3
SLIDE 3

AE-705 Introduction to Flight Lecture-18 Capsule-09

TAKE-OFF

slide-4
SLIDE 4

AE-705 Introduction to Flight Lecture-18 Capsule-09

slide-5
SLIDE 5

AE-705 Introduction to Flight Lecture-18 Capsule-09

For an aircraft to lift off the ground Lift > Weight Aircraft velocity > Stalling Velocity

Lift-off Velocity (VLO) Usually, VLO > 1.15 Vstall

slide-6
SLIDE 6

AE-705 Introduction to Flight Lecture-18 Capsule-09

PHASES DURING TAKE-OFF

slide-7
SLIDE 7

AE-705 Introduction to Flight Lecture-18 Capsule-09

D W T L μ R Transition Climb Screen Height (15 m) Take-off distance Ground run V

A = Nose wheel lift off speed ≈ 0.85 VTO

V

A

V

A > VTO

Phases Ground run Transition Climb

slide-8
SLIDE 8

AE-705 Introduction to Flight Lecture-18 Capsule-09

The take-off distance(s) and the time (t) taken for it

Distance covered and time taken during ground run Distance covered and time taken during transition phase Distance covered and time taken during climb phase

Estimation of take-off performance

slide-9
SLIDE 9

AE-705 Introduction to Flight Lecture-18 Capsule-09

Distance covered and time taken during ground run

D W T L μ R R

and time taken (t1) is given by :

slide-10
SLIDE 10

AE-705 Introduction to Flight Lecture-18 Capsule-09

Various speeds during Take-off Run

V = 0

Vr Vmc V1 Vs Vmu VLO V2 15 m

slide-11
SLIDE 11

AE-705 Introduction to Flight Lecture-18 Capsule-09

Vs = Stall Speed

speed in steady level flight at W = WTO CL = CLTO Depends upon:

Configuration of the plane

Flaps Slats Lift-control devices

slide-12
SLIDE 12

AE-705 Introduction to Flight Lecture-18 Capsule-09

Vmc : Minimum control speed

Starboard engine fails Yaws to the starboard

Apply port side rudder

Counter moment produced Aircraft balanced Below a certain speed there simply is not enough aerodynamic force generated by the rudder to produce the correcting yaw. This velocity is called Vmc.

Vmcg Vmca

slide-13
SLIDE 13

AE-705 Introduction to Flight Lecture-18 Capsule-09

Vmu

Vmu : Minimum unstick speed

Speed which defines the point at which the aircraft could take

  • ff if the maximum possible rotation angle were reached.

This maximum angle would occur if the tail of the plane were to actually scrape the ground.

slide-14
SLIDE 14

AE-705 Introduction to Flight Lecture-18 Capsule-09

Distance covered (s2) and time (t2) taken during transition phase

Work done by engine = Work done in overcoming drag + Increase in KE Time taken (t2) in transition

slide-15
SLIDE 15

AE-705 Introduction to Flight Lecture-18 Capsule-09

The height attained during transition phase can be obtained by treating the flight path as part of a circle Hint:

slide-16
SLIDE 16

AE-705 Introduction to Flight Lecture-18 Capsule-09

Distance covered (s3) and time (t3) taken during climb phase

Time taken (t3) in climb phase

Screen Height (15 m) Climb

Take-off distance = s1 + s2 + s3 Take-off time = t1 + t2 + t3

slide-17
SLIDE 17

AE-705 Introduction to Flight Lecture-18 Capsule-09

Acceleration force as Thrust

1) Afterburner 2) Rocket Assisted Take-off 3) Catapult Takeoff

Take-off run as accelerating force

slide-18
SLIDE 18

AE-705 Introduction to Flight Lecture-18 Capsule-09

Apply brakes and stop the plane Or Continue to fly with one engine inoperative and take-off

Needs longer runway take-off distance increase

slide-19
SLIDE 19

AE-705 Introduction to Flight Lecture-18 Capsule-09

The speed of aircraft in this condition is called Decision Speed

(sstop)decision speed = (sstop)one engine failure

sstop : Distance taken to stop

slide-20
SLIDE 20

AE-705 Introduction to Flight Lecture-18 Capsule-09

Aircraft flying close to the ground The strength of the wing- tip vortices decreases The downwash and hence induced drag are reduced Ground Effect

h = height of the wing above the ground b = wingspan

slide-21
SLIDE 21

AE-705 Introduction to Flight Lecture-18 Capsule-09

slide-22
SLIDE 22

AE-705 Introduction to Flight Lecture-18 Capsule-09

Phases of Landing

Screen Height (15 m)

Landing distance (s1) Ground run (sg)

V = 0

Float Flare Final approach Roll Touch down

V = VT = 0.9 V

A

V = V

A

Airborne distance(s)

W L μ R D Final approach Steady descent Flare Flight path tends to horizontal Float Main wheel touches the ground (Vy ≤ 4 m/s) Roll Nose wheel lowers to touch the ground Brakes not applied Ground run Decelerates to come to halt Brakes applied

slide-23
SLIDE 23

AE-705 Introduction to Flight Lecture-18 Capsule-09

Estimation of Landing Distance

Braking System Acceleration (a) Simple

  • 1.22 m/s2

Average

  • 1.52 m/s2

Modern

  • 1.83m/s2

Airplanes with modern braking system and reverse thrust on reverse pitch propellers

  • 2.13 to 3.0 m/s2
slide-24
SLIDE 24

AE-705 Introduction to Flight Lecture-18 Capsule-09

LD as wing loading (W/S) LD as wing density (ρ) LD as wing loading (W/S) LD as wing density (ρ)

slide-25
SLIDE 25

AE-705 Introduction to Flight Lecture-18 Capsule-09

How to decrease landing distance ?

Reverse thrust Arresting gear Drag parachute Spoilers

slide-26
SLIDE 26

AE-705 Introduction to Flight Lecture-18 Capsule-09

FLAP SETTINGS DURING TAKE-OFF AND LANDING

slide-27
SLIDE 27

AE-705 Introduction to Flight Lecture-18 Capsule-09

Take-off

High CLmax decreases Take-off run and Landing distance Optimum CLTO and corresponding flap setting Lowest Take-off run CLTO VTO sTO CLTO CD sTO

slide-28
SLIDE 28

AE-705 Introduction to Flight Lecture-18 Capsule-09

Landing

CLL = CLmax and corresponding flap setting Lowest Take-off run CLL VA sTO CLL CD sTO

slide-29
SLIDE 29

AE-705 Introduction to Flight Lecture-18 Capsule-09

(CLmax)TO = 0.8 (CLmax)L

Takeoff Flap setting is lower than Landing Flap setting Take off Flap: 20 - 40 deg Landing Flap: 40 – 60 deg

slide-30
SLIDE 30

AE-705 Introduction to Flight Lecture-18 Capsule-09

HOLDING STACKS @ AIRPORT

Just before final approach to land

slide-31
SLIDE 31

AE-705 Introduction to Flight Lecture-18 Capsule-09

HOLDING STACKS

  • Typical Arrival patterns
  • Busy airports / times
  • Extra Fuel carried
  • Regulatory requirement
  • 60 to 75 minutes

Usual Actual

  • Massive changes needed
  • Usually due to weather
  • Extra Fuel carried
  • Navigational Reserves

APPROACH PATHS

~ 800 km

  • Massive changes needed
  • Usually due to weather
  • One Example
  • Extra Fuel carried
  • Navigational Reserves
slide-32
SLIDE 32

AE-705 Introduction to Flight Lecture-18 Capsule-09

Use of Holding Stacks during bad weather

slide-33
SLIDE 33

AE-705 Introduction to Flight Lecture-18 Capsule-09

X-WIND TAKEOFF & LANDING

Most difficult and dangerous flight operations !

slide-34
SLIDE 34

AE-705 Introduction to Flight Lecture-18 Capsule-09

No crosswind at all with an exact headwind with an exact tailwind with no wind In all other conditions there is a cross wind

slide-35
SLIDE 35

AE-705 Introduction to Flight Lecture-18 Capsule-09

http://www.experimentalaircraft.info/flight-planning/aircraft-performance-41.php

Let angle between wind direction and runway = 70° Let wind velocity = 30 Knots

Crosswind = 28 Knots Ignore the zigzag pattern of wind velocity (red)

slide-36
SLIDE 36

AE-705 Introduction to Flight Lecture-18 Capsule-09

Vertical Take-off and Landing (VTOL)

Vertical lift is achieved by counter rotating propeller blades housed inside a duct. Mainly used in Military Aircraft

slide-37
SLIDE 37

AE-705 Introduction to Flight Lecture-18 Capsule-09

limited application

  • f VTOL in

personal aircraft low fuel efficiency safety high noise levels

high cost of

  • peration

per passenger mile

slow speed

slide-38
SLIDE 38

AE-705 Introduction to Flight Lecture-18 Capsule-09

Look at this and imagine what would happen if one of the engines suddenly stopped working

https://www.quora.com/Why-arent-VTOL-technologies-used-in-airliners

Airbus A350

slide-39
SLIDE 39

AE-705 Introduction to Flight Lecture-18 Capsule-09

Now look at this and imagine what would happen if one of the engines suddenly stopped working

https://www.quora.com/Why-arent-VTOL-technologies-used-in-airliners

Bell Boeing V-22 Osprey (VTOL)

slide-40
SLIDE 40

AE-705 Introduction to Flight Lecture-18 Capsule-09

Future Scope

slide-41
SLIDE 41

AE-705 Introduction to Flight Lecture-18 Capsule-09

http://www.gabriel-project.eu/

Magnetic Levitation

Area of benefit Values
