AE-705: Introduction to Flight Longitudinal Stability and Neutral Point Vijay Gaikwad VJTI, Mumbai AE-705 Introduction to Flight Lecture-15 Capsule-08 Reaction of aircraft when disturbed Stable Returns to its initial position Static

slide-1
SLIDE 1

AE-705 Introduction to Flight Lecture-15 Capsule-08

AE-705: Introduction to Flight

Vijay Gaikwad

VJTI, Mumbai

Longitudinal Stability and Neutral Point

slide-2
SLIDE 2

AE-705 Introduction to Flight Lecture-15 Capsule-08

Reaction of aircraft when disturbed

https://www.nasa.gov/centers/glenn/home/

  • Returns to its initial position

Stable

  • Departs from equilibrium

Static Instability

  • Oscillates with larger amplitude

Dynamic Instability

slide-3
SLIDE 3

AE-705 Introduction to Flight Lecture-15 Capsule-08

STATIC STABILITY

Initial Reaction on disturbing an aircraft !

slide-4
SLIDE 4

AE-705 Introduction to Flight Lecture-15 Capsule-08

Definition:

When disturbed from an equilibrium position, the aircraft tends to return to its original position, without any action from the pilot

Static Stability

Types :

I. Positive static

  • II. Neutral static
  • III. Negative static

www.boldmethod.com

slide-5
SLIDE 5

AE-705 Introduction to Flight Lecture-15 Capsule-08

Ball remains in new position when disturbed

Neutral Static Stability NEUTRAL

slide-6
SLIDE 6

AE-705 Introduction to Flight Lecture-15 Capsule-08

Positive Static Stability STABLE

Ball returns to starting position when disturbed

slide-7
SLIDE 7

AE-705 Introduction to Flight Lecture-15 Capsule-08

Ball moves away from starting position when disturbed

Negative Static Stability UNSTABLE

slide-8
SLIDE 8

AE-705 Introduction to Flight Lecture-15 Capsule-08

Flight Conditions

http://history.nasa.gov

slide-9
SLIDE 9

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://youtu.be/NciePa8sY_U

Example of an unstable aircraft

slide-10
SLIDE 10

AE-705 Introduction to Flight Lecture-15 Capsule-08

DYNAMIC STABILITY

Final Outcome of disturbing an aircraft !

slide-11
SLIDE 11

AE-705 Introduction to Flight Lecture-15 Capsule-08

Dynamic Stability

Positive

Oscillations decrease in amplitude

Neutral

Oscillations constant in amplitude

Negative

Oscillations increase in amplitude

www.boldmethod.com

slide-12
SLIDE 12

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://www.youtube.com/watch?v=YJ1Tt1zSyH4

A Quick Summary

slide-13
SLIDE 13

AE-705 Introduction to Flight Lecture-15 Capsule-08

THE 3 CENTRES OF AN AIRCRAFT

Their relative location affects Stability

slide-14
SLIDE 14

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://zh.scribd.com/document/334413404/XFLR5-and-Stability-analysis-pdf

The Three Key Centers

TWO THREE ONE

slide-15
SLIDE 15

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://zh.scribd.com/document/334413404/XFLR5-and-Stability-analysis-pdf

CENTER OF GRAVITY

TWO THREE

slide-16
SLIDE 16

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://zh.scribd.com/document/334413404/XFLR5-and-Stability-analysis-pdf

CENTER OF PRESSURE

THREE CENTER OF GRAVITY

slide-17
SLIDE 17

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://www.nasa.gov/centers/glenn/home/

Centre of Pressure

slide-18
SLIDE 18

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://zh.scribd.com/document/334413404/XFLR5-and-Stability-analysis-pdf

NEUTRAL POINT

CENTER OF PRESSURE CENTER OF GRAVITY

slide-19
SLIDE 19

AE-705 Introduction to Flight Lecture-15 Capsule-08

  • position of CG where the aircraft would be Neutrally stable.

Neutral Point

The basics of R/C model Aircraft design . Author–Andy Lennon ,ISBN:0-911295-40-2. chapter -06,page 27.

slide-20
SLIDE 20

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://zh.scribd.com/document/334413404/XFLR5-and-Stability-analysis-pdf

All three Centers together!

CENTER OF PRESSURE NEUTRAL POINT CENTER OF GRAVITY

slide-21
SLIDE 21

AE-705 Introduction to Flight Lecture-15 Capsule-08

THE FOURTH CENTRE !

Aerodynamic Center

slide-22
SLIDE 22

AE-705 Introduction to Flight Lecture-15 Capsule-08 https://www.nasa.gov/centers/glenn/home/

Aerodynamic Centre

slide-23
SLIDE 23

AE-705 Introduction to Flight Lecture-15 Capsule-08

EFFECT OF RELATIVE LOCATION

Example of a toy plane

Source: Understanding Flight, D. F. Anderson, S.Eberhardt , 2nd ed, McGraw-Hill, Ch-4, pp. 102 ,ISBN-13: 978-0071626965

slide-24
SLIDE 24

AE-705 Introduction to Flight Lecture-15 Capsule-08

Perturbation in flight increase Angle of Attack Lwing ↑ but Ltail ↓, hence net Nose down Moment created Aircraft is Stable due to this restoring torque

Source: Understanding Flight, D. F. Anderson, S.Eberhardt , 2nd ed, McGraw-Hill, Ch-4, pp. 102 ,ISBN-13: 978-0071626965

When CG is ahead of NP

slide-25
SLIDE 25

AE-705 Introduction to Flight Lecture-15 Capsule-08

Position of AC is independent of angle of attack Moments due to ↑ Lwing & ↑ Ltail balance There is no restoring torque Aircraft is neutrally stable due to this balance of moments

Source: Understanding Flight, D. F. Anderson, S.Eberhardt , 2nd ed, McGraw-Hill, Ch-4, pp. 102, ,ISBN-13: 978-0071626965

When CG is at NP

slide-26
SLIDE 26

AE-705 Introduction to Flight Lecture-15 Capsule-08

As the nose pitches up, ↑ Lwing > ↑ Ltail The aircraft nose pitches up further Aircraft is unstable due to unbalanced moments

When CG is behind NP

Source: Understanding Flight, D. F. Anderson, S.Eberhardt , 2nd ed, McGraw-Hill, Ch-4, pp. 102 ,ISBN-13: 978-0071626965

WHY ??

slide-27
SLIDE 27

AE-705 Introduction to Flight Lecture-15 Capsule-08

EFFECT OF CG POSITION

w.r.t. AC and NP

slide-28
SLIDE 28

AE-705 Introduction to Flight Lecture-15 Capsule-08

CG ahead of AC and NP

Andy Lennon, The basics of R/C model Aircraft design, Chapter-06, pp. 27, ISBN:0-911295-40-2

Aircraft is HIGHLY stable !

slide-29
SLIDE 29

AE-705 Introduction to Flight Lecture-15 Capsule-08 Andy Lennon, The basics of R/C model Aircraft design, Chapter-06, pp. 27, ISBN:0-911295-40-2

Aircraft is stable !

CG at AC but ahead of NP

slide-30
SLIDE 30

AE-705 Introduction to Flight Lecture-15 Capsule-08 Andy Lennon, The basics of R/C model Aircraft design, Chapter-06, pp. 27, ISBN:0-911295-40-2

Aircraft is LESS stable !

CG behind AC but ahead of NP

slide-31
SLIDE 31

AE-705 Introduction to Flight Lecture-15 Capsule-08 Andy Lennon, The basics of R/C model Aircraft design, Chapter-06, pp. 27, ISBN:0-911295-40-2

Aircraft is NEUTRALLY STABLE !

CG behind AC and at NP

slide-32
SLIDE 32

AE-705 Introduction to Flight Lecture-15 Capsule-08

In summary : Effect of CG Position

Andy Lennon, The basics of R/C model Aircraft design, Chapter-06, pp. 27, ISBN:0-911295-40-2

slide-33
SLIDE 33

AE-705 Introduction to Flight Lecture-15 Capsule-08

EFFECT OF CG ON FLIGHT

Effect of CG on Longitudinal Stability of plane

slide-34
SLIDE 34

AE-705 Introduction to Flight Lecture-15 Capsule-08

Longitudinal stability

Payload position CG Position

BOTTOM VIEW TOP VIEW 5 4 3 2 1

1 2 3 4 5

slide-35
SLIDE 35

AE-705 Introduction to Flight Lecture-15 Capsule-08 1 BOTTOM VIEW TOP VIEW

BACK

Payload Location CG Location

CG Position at 1

100 200 300 100 200 300 400 500 600

slide-36
SLIDE 36

AE-705 Introduction to Flight Lecture-15 Capsule-08 2 BOTTOM VIEW TOP VIEW

BACK

Payload Location CG Location

CG Position at 2

100 200 300 100 200 300 400 500 600

slide-37
SLIDE 37

AE-705 Introduction to Flight Lecture-15 Capsule-08 3 BOTTOM VIEW TOP VIEW

BACK

Payload Location CG Location

CG Position at 3

100 200 300 100 200 300 400 500 600

slide-38
SLIDE 38

AE-705 Introduction to Flight Lecture-15 Capsule-08 4 BOTTOM VIEW TOP VIEW

BACK

Payload Location CG Location

CG Position at 4

100 200 300 100 200 300 400 500 600

slide-39
SLIDE 39

AE-705 Introduction to Flight Lecture-15 Capsule-08 5 BOTTOM VIEW TOP VIEW

BACK

Payload Location CG Location

CG Position at 5

100 200 300 100 200 300 400 500 600

slide-40
SLIDE 40

AE-705 Introduction to Flight Lecture-15 Capsule-08

Flights with different CG position

BACK

100 200 300 100 200 300 400 500 600 CG at 1 CG at 2 CG at 3 CG at 4 CG at 5

slide-41
SLIDE 41

AE-705 Introduction to Flight Lecture-15 Capsule-08

Why ??

Lets see !

slide-42
SLIDE 42

AE-705 Introduction to Flight Lecture-15 Capsule-08

Vs α graph

𝛽

2 3 4 5

𝛽

1

slide-43
SLIDE 43

AE-705 Introduction to Flight Lecture-15 Capsule-08

Comparison of Flight Path with Graph

100 200 300 100 200 300 400 500 600 CG at 1 CG at 2 CG at 3 CG at 4 CG at 5

Different CG positions Corresponding α positions

𝛽

1 3 4 5 2

slide-44
SLIDE 44

AE-705 Introduction to Flight Lecture-15 Capsule-08

NEUTRAL POINT

Longitudinal stability concept explanation

slide-45
SLIDE 45

AE-705 Introduction to Flight Lecture-15 Capsule-08

Longitudinal stability

Payload position CG Position

BOTTOM VIEW TOP VIEW 5 4 3 1

1 3 4 5

slide-46
SLIDE 46

AE-705 Introduction to Flight Lecture-15 Capsule-08

Comparison of flights (CG at 1)

without Vertical Gust with Vertical Gust

100 200 300 100 200 300 400 500 600 100 200 300 100 200 300 400 500 600

slide-47
SLIDE 47

AE-705 Introduction to Flight Lecture-15 Capsule-08

Comparison of flights(CG at 3)

without Vertical Gust with Vertical Gust

100 200 300 100 200 300 400 500 600 100 200 300 100 200 300 400 500 600

slide-48
SLIDE 48

AE-705 Introduction to Flight Lecture-15 Capsule-08

Comparison of flights (CG at 4)

without Vertical Gust with Vertical Gust

100 200 300 100 200 300 400 500 600 100 200 300 100 200 300 400 500 600

slide-49
SLIDE 49

AE-705 Introduction to Flight Lecture-15 Capsule-08

100 200 300 100 200 300 400 500 600

Comparison of flights (CG at 4)

Back

slide-50
SLIDE 50

AE-705 Introduction to Flight Lecture-15 Capsule-08

Comparison of flights (CG at 5)

without Vertical Gust with Vertical Gust

100 200 300 100 200 300 400 500 600 100 200 300 100 200 300 400 500 600

slide-51
SLIDE 51

AE-705 Introduction to Flight Lecture-15 Capsule-08

Comparison of flights (CG at 5)

Back

100 200 300 100 200 300 400 500 600

slide-52
SLIDE 52

AE-705 Introduction to Flight Lecture-15 Capsule-08

Flights with changing AOA

  • Angle of attack = 4°
  • Angle of Attack = 8°
  • Angle of Attack = 12°
  • Angle of attack = 0°
slide-53
SLIDE 53

AE-705 Introduction to Flight Lecture-15 Capsule-08

Comparison of flights
