Takeoff/Landing Lecture 20 ME EN 415 Andrew Ning aning@byu.edu - PowerPoint PPT Presentation

Aug 25, 2022 •316 likes •444 views

Takeoff/Landing Lecture 20 ME EN 415 Andrew Ning aning@byu.edu High Lift Systems s 2 W V stall = S ref C Lmax Flaps c l Source: Ahmed Al Makky Slats c l Source: Ahmed Al Makky Critical Section Theory Takeoff Field Length h

Takeoff/Landing Lecture 20 ME EN 415 Andrew Ning aning@byu.edu
High Lift Systems s 2 W V stall = ρ S ref C Lmax
Flaps c l α
Source: Ahmed Al Makky
Slats c l Source: Ahmed Al Makky α
Critical Section Theory
Takeoff Field Length h
Balanced Field Length distance (decision speed) V 1
Landing Field Length h d glide d ground d decel
