4K Initiative in Poland: 4K Initiative in Poland: 4K Node in PSNC 4K Node in PSNC

TF-Media Meeting 5 Nov 2009, Prague Maciej Glowiak - mac@man.poznan.pl

What is 4K?

• The technology of displaying and processing high resolution video
• Resolutions of 8-9 Mpixel (~4K pixels horizontally):

– DCI (Digital Cinema Initiatives) – 4096x2160 – Quad HD – 3840x2160

Resolution comparison

4K is: 21x SD 10x HD720p 4x HD1080p

You can see more details…

Or a wider perspective…

Uncompressed 4K video stream

• 4K Resolution (4096x2160): ~9 Mpixels
• Single 4K frame size (RGB, 24 bit/pixel - TrueColor): 26 MBytes
• Video stream 24 fps

– 625 MBytes / s = 5 Gbit/s – 37,5 GBytes / minute – 2,25 TBytes / hour

4K video stream Data stream Network interface 4K JPEG2000 (DCI) 250 Mbit/s 1 Gbit/s 4K JPEG2000 (DCI) 3D 2x 250 Mbit/s 1 Gbit/s 4K uncompressed ~6 Gbit/s 10 Gbit/s 4K uncompressed 3D ~12 Gbit/s 40 Gbit/s

4K initiative in Poland (1)

• 4K technology popularization

– Demonstration of 4K equipment and 4K productions – Participation in media fairs, workshops and conferences – Technology support for Schools of Art, Film schools and independent, alternative young producers

• 4K Content production and post-production

– Use of digital production and post-production of 4K material – Cultural and science events – 3D rendering, 3D visualization of scientific and computational processes

• 4K network streaming, JPEG2000 encoding

– JPEG2000 hardware and software compression and encoding – Compressed and uncompressed 4K live streaming over optical network – HD and 4K videoconferencing

4K initiative in Poland (2)

• Integration with digital cinema and television

– Cooperation with film producers, Schools of Art, television studios – Cooperation with audio/video equipment vendors – Participation in international media initiatives and projects

• Research on network and storage aspects of future media

– Digital media repositories development – Optimization of storage and network parameters for 4K transmission – Development of new protocols for 4K transmission

• 4K stereoscopy research

– 4K 3D production and projection – 4K 3D streaming

• Beyond 4K

– 8K

4K Node in PSNC

• In the year 2008 PSNC started the development of the first Polish 4K

node in Poznan. Today the node consists of: – IntoPIX encoder and decoder for JPEG2000 streaming – DOREMI DSV-J2 Player for movie projection and presentation purposes – SONY SRX-T105 projector for large venues – Astro DM-3400 56” LCD display for small presentations and laboratory tests – RED One camera for 4K content recording – Mac Pro workstation for post-production – Sun Fire x4540 storage servers as media repositories – Digital AES/EBU audio equipment – HD cameras

PSNC 4K Node architecture

Events 2009 (1)

• Poznan Media Expo 2009, Poznań
• Microsoft Innovation Center 2009, Poznań

Events 2009 (2)

• Film festival CineMagic.pl 2009, Płock
• (The night of the science) Noc Naukowcow 2009, Poznan

Planned events 2009

• Next week (12 Nov) – 4K live transmission between PSNC and

University of Essex

Future media as services in PIONIER network

• 4K initiative
• PLATON

– Scientific HDTV Services – HD Videoconferencing

• Digital libraries
