Advanced Network Security

• 6. Self-stabilisation

Jaap-Henk Hoepman // Radboud University Nijmegen //

Self-stabilisation: a different failure model

n Instead of (permanent) processing failures we study transient memory failures

• State of a node stored in RAM,

which can be changed arbitrarily

• Program code stored in ROM,

never changed

n State of network can also change

• So study shared memory systems

to simplify analysis

• But self-stabilisation in message

passing systems is also possible

7-3-2016 // Fault Tolerance - Self-stabilisation 2

system state program code ROM RAM network transient error node

Jaap-Henk Hoepman // Radboud University Nijmegen //

System model

n 𝑜 nodes

• Uniform (all with the same state) or non-uniform
• With or without known node identifiers (stored in ROM, i.e. cannot

change) n Communicating through shared memory

• Modelled through graph 𝐻 = (𝑊, 𝐹)
• State reading model: 𝑤, 𝑥 ∈ 𝐹 means 𝑥 can read entire state of 𝑤
• Link register model: 𝑤, 𝑥 ∈ 𝐹 means 𝑤 writes a register 𝑆-. read by 𝑥

n Configuration 𝐷 ∈ 𝒟 consists of the Cartesian product of states of all nodes (and the registers on the edges).

7-3-2016 // Fault Tolerance - Self-stabilisation 3

27/04/2017 2

Jaap-Henk Hoepman // Radboud University Nijmegen //

Synchronous system

n System 𝒟, 𝐺 proceeds in rounds

• Program of a node 𝑗 is a function 𝑔

5 ∈ 𝐺 describing the resulting state (plus

registers it writes) given the current state (and the registers it writes)

• Uniform: 𝑔

5 = 𝑔 6 for all 𝑗, 𝑘

• Known identities: 𝑔

5 𝐷

may depend on 𝑗

n Central daemon

• Scheduler fairly selects one node 𝑗 to take a step: 𝐷

5

→ 𝐷’ (i.e. 𝐷: = 𝑔

5(𝐷))

n Distributed daemon

• Scheduler fairly selects one or more nodes 𝐽 to take a step: first all nodes

read their own state and the states/registers they can read, then compute the new state and then store the new state and the registers they write: 𝐷

<

→ 𝐷’

7-3-2016 // Fault Tolerance - Self-stabilisation 4 Jaap-Henk Hoepman // Radboud University Nijmegen //

Self-stabilisation

n Consider a system S = 𝒟, 𝐺 n Define some set of legitimate configurations ℒ ⊂ 𝒟

• Typically defined using a predicate
• These are the good configurations that we want the system to be in
• Note that a node may not be able to determine whether its local state is part
• f a global configuration that is legitimate!

n System 𝑇 is self-stabilising to ℒ if

• Convergence: when we start the system in an arbitrary initial configuration

𝐷 ∈ 𝒟 it always reaches a legitimate configuration 𝐷: ∈ ℒ within a finite number of steps (the convergence time)

• Closure: Once the system is in a legitimate configuration it stays in a

legitimate configuration after each system step

7-3-2016 // Fault Tolerance - Self-stabilisation 5 Jaap-Henk Hoepman // Radboud University Nijmegen //

Some questions

n Why does a self-stabilising system recover from transient memory faults? n Can a self-stabilising system terminate?

7-3-2016 // Fault Tolerance - Self-stabilisation 6

27/04/2017 3

Jaap-Henk Hoepman // Radboud University Nijmegen //

Some toy problems

n Suppose the system consists of a single node

• Then you can simply reset the node to a legitimate configuration

n Suppose the system is a complete graph, and the legitimate configurations are those where all nodes have the same state

• The transition function simply checks this condition, and if false sets

the state of a node to a default state n Let’s add a progress condition and suppose the state of a node is a clock that needs to by in sync with all other nodes and increases in every round

• How to stabilise in this case… Take majority? You can only change

your own state… What about unwanted parallelism?

7-3-2016 // Fault Tolerance - Self-stabilisation 7 Jaap-Henk Hoepman // Radboud University Nijmegen //

Mutual exclusion on a ring (Dijkstra)

n Refresher: what is mutual exclusion?

• Here: a token circulating on a ring

n Impossibility of symmetric solution for rings of non-prime size

• Non-prime: break ring in equal size chords >1;
• Assume symmetric states for all chords
• Schedule same location nodes one by one or all at once: still

symmetric

7-3-2016 // Fault Tolerance - Self-stabilisation 8 Jaap-Henk Hoepman // Radboud University Nijmegen //

Mutual exclusion on a ring: construction

n 𝑂 + 1 nodes 0, … , 𝑂, node 0 is special

• On an oriented, state reading ring: node 𝑗 + 1 𝑛𝑝𝑒 𝑂 reads state of node 𝑗

n Each node has state 𝑦 𝑗 ∈ {0, … , 𝐿 − 1} for 𝐿 > 𝑂 n Protocol

• Node 0: if 𝑦[0] = 𝑦 𝑂 then 𝑦 0 ← 𝑦 0 + 1 𝑛𝑝𝑒 𝐿
• Node 𝑗 ≠ 0: if 𝑦[𝑗] ≠ 𝑦 𝑗 − 1 then 𝑦 𝑗 ← 𝑦 𝑗 − 1

n Privileged (i.e. has the token)

• Node 0 if 𝑦 0 = 𝑦 𝑂
• Node 𝑗 ≠ 0 if 𝑦 𝑗 ≠ 𝑦[𝑗 − 1]
• I.e. node is privileged if it can take a step (which turns it unprivileged

n Legitimate states ℒ

• All states where there is an 𝑗, 0 ≤ 𝑗 ≤ 𝑂 and 𝑑 ∈ {0, …, 𝐿 − 1} such that for all 𝑘, 0 ≤

𝑘 ≤ 𝑗 we have 𝑦 𝑘 = 𝑑 + 1 𝑛𝑝𝑒 𝐿 and for all 𝑘, 𝑗 < 𝑘 ≤ 𝑂 we have 𝑦 𝑘 = 𝑑

7-3-2016 // Fault Tolerance - Self-stabilisation 9

27/04/2017 4

Jaap-Henk Hoepman // Radboud University Nijmegen //

Proof of correctness (1)

n Note: always at least one node enabled, so there is no deadlock n In a legitimate configuration exactly one node enabled/privileged n Assume a central daemon, and 𝐿 ≥ 𝑂 n Closure

• Let the system be in a legitimate configuration for some choice of 𝑗, 𝑑,

i.e. 𝑄(𝑗, 𝑑) = “for all 𝑘, 0 ≤ 𝑘 ≤ 𝑗 we have 𝑦 𝑘 = 𝑑 + 1 𝑛𝑝𝑒 𝐿 and for all 𝑘, 𝑗 < 𝑘 ≤ 𝑂 we have 𝑦 𝑘 = 𝑑” holds.

• Then only 𝑙 = 𝑗 + 1 𝑛𝑝𝑒 𝑂 is enabled
• If 𝑙 ≠ 0, then after the step 𝑦 𝑙 = 𝑑 + 1 𝑛𝑝𝑒 𝐿 and hence 𝑄 𝑙, 𝑑 holds
• If 𝑙 = 0, then after the step 𝑦 𝑙 = 𝑑 + 2 𝑛𝑝𝑒 𝐿 while for all other 𝑗 still

𝑦 𝑗 = 𝑑 + 1 𝑛𝑝𝑒 𝐿. Hence 𝑄(0, 𝑑 + 1 𝑛𝑝𝑒 𝐿) holds

7-3-2016 // Fault Tolerance - Self-stabilisation 10 Jaap-Henk Hoepman // Radboud University Nijmegen //

Proof of correctness (2)

n Convergence

• Initially colour all nodes white
• Colour node 0 blue the first time it takes a step; after that it stays blue forever
• Nodes colour blue when they copy a blue value from their counterclockwise neighbour

(and then stay blue forever)

• Let ℎ be the number of times node 0 takes a step while node 𝑂 is still white
• Then ℎ ≤ 𝑂: after the first step of 0, there are at most 𝑂 − 1 white nodes that can provide

𝑂 with at most 𝑂 − 1 new white states

• W.l.o.g. let 𝑦[0] initially be 𝐿 − 1; after the first step 𝑦[0] becomes 0; so after 𝑗-th step, 𝑦[0] =

𝑗 − 1

• Starting at 0, we observe that all blue nodes form a decreasing chain of values
• Now let 0 be about to take the ℎ + 1 th step (i.e. 𝑂 is blue). Then before that step 𝑦[0] = ℎ −
• 1. As ℎ ≤ 𝑂 ≤ 𝐿 we see that 𝑦 0 did not wrap around.
• All nodes are blue at this point, and 𝑦 𝑂 = 𝑦 0 .
• As now all nodes are blue, and have decreasing values, we must have 𝑦 𝑗 = ℎ − 1 for all

nodes

7-3-2016 // Fault Tolerance - Self-stabilisation 11
