MODEL OVERVIEW

CS-16W

1” Polymer Soft Dome Tweeter 6.5” Polymer Woofer MSRP: $139 / Each

CS-16C II

1” Polymer Soft Dome Tweeter 6.5” Polymer Woofer MSRP: $129 / Each

CS-18C

1” Polymer Soft Dome Tweeter 8” Polymer Woofer MSRP: $149 / Each

CS-16CSM

2 x 1” Polymer Soft Dome Tweeters 6.5” Polymer Woofer MSRP: $179 / Each

HIGH VALUE ACOUSTICS

POLYMER TWEETER

• Polymer dome tweeter diaphragm provides smooth,

dynamic high frequencies

POLYPROPYLENE WOOFERS

• Molded polypropylene provides a much more rigid cone

surface than paper or pulp, for less cone break up and less distortion at high SPL

ALL NEW, BEZEL-FREE GRILLE

INCLUDED IN BOX

• All new, completely redesigned powder

coated steel grille eliminates the bezel for seamless, pristine integration into any living space.

SKYHOOK™ INSTALLATION SYSTEM

EXCLUSIVELY ON AND

• Exclusive tool-free installation system
• Spring loaded dogs automatically engage when speaker is inserted into cut out
• Preset clamping force eliminates possibility of breaking the dog leg or cracking the drywall
• Reduces installation time by up to 75%

SERIES COMPARISON

Model Description Step up from Aimable Drivers Woofer Material Tweeter Material Horn Type Installation System Grille Type Protected Distribution DESIGNER SERIES NEW

DS-160C 6.5" 2-Way In-Ceiling R-2650-C II Yes Polypropylene Silk Dome 90° x 90° ABS Tractrix™ Horn Tool Free Installation System Bezel Free Flat Magnetic Yes, No online DS-160CDT 6.5" 2-Way In-Ceiling with CDT CDT-2650-C II DS-180CDT 8" 2-Way In-Wall with CDT CDT-2800-C II DS-160W 6.5" 2-Way In-Wall R-2650-W II DS-160CSM 6.5" Stereo In-Ceiling R-2650-CSM II DS-180CSM 8" Stereo In-Ceiling R-2800-CSM II DS-250W-LCR Dual 5.25" 2-Way In-Wall LCR R-2502-W II

2000 SERIES

R-2650-C II 6.5" 2-Way In-Ceiling Yes Polypropylene Silk Dome 90° x 90° ABS Tractrix™ Horn Standard Dog Ear Minimum Bezel Flat Magnetic No CDT-2650-C II 6.5" 2-Way In-Ceiling with CDT CDT-2800-C II 8" 2-Way In-Wall with CDT R-2650-W II 6.5" 2-Way In-Wall R-2650-CSM II 6.5" Stereo In-Ceiling R-2800-CSM II 8" Stereo In-Ceiling R-2502-W II Dual 5.25" 2-Way In-Wall LCR

CUSTOM SERIES NEW

CS-16C II 6.5" 2-Way In-Ceiling R-1650-C No Polypropylene Polymer None Tool Free Installation System Flat Magnetic Yes, No online CS-18C 8" 2-Way In-Ceiling R-1800-C CS-16CSM 6.5" Stereo In-Ceiling R-1650-CSM CS-16W 6.5" 2-Way In-Wall R-1650-W

1000 SERIES

R-1650-C 6.5" 2-Way In-Ceiling No Polymer Polymer None Standard Dog Ear Press Fit with Bezel No R-1800-C 8" 2-Way In-Ceiling R-1650-CSM 6.5" Stereo In-Ceiling R-1650-W 6.5" 2-Way In-Wall

REPLACES REFERENCE 1000 WHAT’S NEW

• SUPERCHARGED DRIVER DESIGN

All new woofer and tweeter designs utilize larger motor structures for smoother frequency response, better dynamics, and higher sensitivity than 1000 Series.

• FAST INSTALLATION SYSTEM

The all new patent pending installation method is completely tool free, reducing speaker installation time by up to 80%, and providing a more secure, robust installation method over 1000 Series

• BEZEL-FREE MAGNETIC GRILLE

All new design completely eliminates the bezel, for a much more seamless integration in the living space over 1000 Series

OPTIMIZE YOUR PERFORMANCE

KLIPSCH KDA DSP AMPLIFIERS

DSP PRESETS

• For all Klipsch Pro Series, Designer Series,

and Custom series architectural models

• Optimize EQ equalization and limiter

settings for each model beyond what is capable with traditional crossover network

• Each preset created specifically by Klipsch

engineers

OPTIMIZE YOUR PERFORMANCE

KLIPSCH KDA DSP AMPLIFIERS

DSP MAIN PAGE

• OUTPUT LEVEL
• OUTPUT METERING

GENERAL

• NETWORK INFO / IP ADDRESSING
• POWER CONFIGURATION
• AMPLIFIER INFORMATION/NAME
• PASSWORD SETTINGS

INPUT

• CUSTOMIZED CHANNEL NAMING
• INPUT/OUPUT MATRIXING
• VOLUME CONFIGURATION

EQ

• 5-BAND PARAMETRIC EQ
• CROSSOVER – LO-PASS/HI-PASS
• SHELVING EQ
• CHANNEL DELAY
• OUTPUT PHASE CONTROL

OUTPUT

• KLIPSCH SPEAKER PRESETS
• LIMITER
• IMPEDANCE SELECT
• CHANNEL BRIDGING / OUTPUT MODE
