CobraNet CobraNet Audio Network Audio Network Overview Overview - PowerPoint PPT Presentation

Jun 15, 2023 •352 likes •434 views

CobraNet CobraNet Audio Network Audio Network Overview Overview Developed by Peak Audio Real-time, high quality, uncompressed digital audio Using standard Ethernet packets and infrastructure => works with any 100 Mbit,

CobraNet CobraNet Audio Network Audio Network
Overview Overview ● Developed by Peak Audio ● Real-time, high quality, uncompressed digital audio ● Using standard Ethernet packets and infrastructure => works with any 100 Mbit, Multicast-enabled Ethernet devices ● Up to 64 channels in each direction over a single 100 meter CAT-5 cable (100 Mbit connection, 48 kHz, 20 bit) ● Advantages: + Cabling Cost + Flexibility + Reliability + Audio Quality CobraNet Audio Network CobraNet Audio Network
Omnitronic Transmitters: NAT-series Omnitronic Transmitters: NAT-series ● AD / DA Conversion and connection to CobraNet NAT-88 8 XLR Inputs 8 XLR Outputs CobraNet Audio Network CobraNet Audio Network
Omnitronic Processors: NAP-series Omnitronic Processors: NAP-series ● Process the audio signals in DSPs using Effects NAP-26 2 XLR Inputs 6 XLR Outputs CobraNet Audio Network CobraNet Audio Network
RS 1200 Software RS 1200 Software ● Wiring devices CobraNet Audio Network CobraNet Audio Network
RS 1200 Software RS 1200 Software ● Wiring effects in DSPs CobraNet Audio Network CobraNet Audio Network
DSP Effects DSP Effects ● Dynamic ● Router ● Mixer ● Delay ● Crossover ● Filter ● Graphic Equalizer CobraNet Audio Network CobraNet Audio Network
