2013 EPFL Team Project The 2013 EPFL iGEM Team 2 Problem Colorectal cancer: 3 rd most diagnosed Bacterial infection cancer in the world Crohns disease Parasites 3 3 Modular Targeted Delivery 4 Interdisciplinary Approach

slide-1
SLIDE 1

2013 EPFL Team Project

slide-2
SLIDE 2

2

The 2013 EPFL iGEM Team

slide-3
SLIDE 3

Problem

Bacterial infection Parasites Colorectal cancer: 3rd most diagnosed cancer in the world Crohn’s disease

3 3

slide-4
SLIDE 4

Modular Targeted Delivery

4

slide-5
SLIDE 5

Interdisciplinary Approach

TAXI.COLI TAXI.COLI

SYNTHETIC BIOLOGY SYNTHETIC BIOLOGY CHEMISTRY CHEMISTRY DISEASE TREATMENT DISEASE TREATMENT MATERIAL SCIENCE MATERIAL SCIENCE PHARMACOLOGY PHARMACOLOGY

5

slide-6
SLIDE 6

Taxi.Coli

6

slide-7
SLIDE 7

Taxi.Coli

7

slide-8
SLIDE 8

8

http://www.youtube.com/watch?v=2oGyBahBHuI

slide-9
SLIDE 9

Project

Sensing Effector Cell Surface Display Nanoparticles Sensing Effector Cell Surface Display Nanoparticles Sensing Effector Cell Surface Display Nanoparticles Sensing Effector Cell Surface Display Nanoparticles

9

slide-10
SLIDE 10

Sensing Effector Cell Surface Display Nanoparticles

10

slide-11
SLIDE 11

Sensing

  • pH sensitive promoters:

– Hya-promoter, isolated from the E.coli K-12 MG1655 – Cad-promoter, isolated from the E.coli K-12 MG1655

  • Positive control: constitutive promoter

Sensing Effector Cell Surface

Display

Nano particles

11

slide-12
SLIDE 12

Constitutive Promoter

Positive Control

Cloning strategy

BBa_I746908

Sensing Effector Cell Surface

Display

Nano particles

Cad Promoter Hya Promoter

BBa_K1111002 BBa_K1111004 BBa_K1111005

12

slide-13
SLIDE 13

Characterization: Microscopy

pH = 5.5 pH = 7.0 pH = 8.5 pH = 5.5 pH = 7.0 pH = 8.5 pH = 5.5 pH = 7.0 pH = 8.5

Sensing Effector Cell Surface

Display

Nano particles

Constitutive Promoter Cad Promoter Hya Promoter

13

slide-14
SLIDE 14

Plate Reader

Sensing Effector Cell Surface

Display

Nano particles

0.5 1 1.5 2 5 10 OD600 # of measurements [30min]

pH: 5.5

Hya-Promoter Cad-Promoter Constitutive Promoter 0.5 1 1.5 2 5 10 OD600 # of measurements [30min]

pH: 6.5

Hya-Promoter Cad-Promoter Constitutive Promoter 0.5 1 1.5 2 2.5 5 10 OD600 # of measurements [30min]

pH: 7

Hya-Promoter Cad-Promoter Constitutive Promoter 0.5 1 1.5 2 5 10 OD600 # of measurements [30min]

pH: 8.5

Hya-Promoter Cad-Promoter Constitutive Promoter

14

slide-15
SLIDE 15

15

Achievements

  • Extraction of Genomic DNA
  • Promoter Insertion
  • 100% Sequencing Match
  • Positive Control Creation
  • Proof of Functionality

Next Steps

  • Improve characterization
  • Develop new constructs
slide-16
SLIDE 16

Sensing Effector Cell Surface Display Nanoparticles

16

slide-17
SLIDE 17

Effector

  • Enzymes degrade gelatin nanoparticles
  • Two Different Enzymes

– Gelatinase E (GelE) from E.faecalis – Matrix Metalloprotease 2 (MMP2) from H.sapiens

Sensing Effector Cell Surface

Display

Nano particles

17

slide-18
SLIDE 18

Effector

BBa_K1111009

Sensing Effector Cell Surface

Display

Nano particles

BBa_I746908 BBa_K1111007

His-Tag His-Tag

18

slide-19
SLIDE 19

Achievements

  • Extraction of Genomic DNA
  • Protein cDNA insertion into plasmid
  • Protein Purification
  • Nanoparticles Degradation with the enzyme
  • Sensor and effector cloning into the same

plasmid

Next Steps

19

slide-20
SLIDE 20

Sensing Effector Cell Surface Display Nanoparticles

20

slide-21
SLIDE 21

Streptavidin Display

  • Streptavidin fused to an Outer Membrane

Protein

  • Chose Ice Nucleation Protein from

Pseudomonas syringae

Sensing Effector Cell Surface

Display

Nano particles

21

slide-22
SLIDE 22

22

Cloning INP_Streptavidin Protein

Streptavidin from Registry

BBa_K1111013 BBa_K1111012 BBa_K1111014

Streptavidin Dead Streptavidin Alive

Sensing Effector Cell Surface

Display

Nano particles

slide-23
SLIDE 23

ImmunoFluorescent Staining

Negative Control

Composite image

FITC conjugated Anti-streptvidin Ab, 100x FITC conjugated Anti-streptavidin Ab, 100x

INP-Streptavidin-Alive

Composite image

No Fluorescence → No AnDbody Binding

Sensing Effector Cell Surface

Display

Nano particles

23

slide-24
SLIDE 24

FITC conjugated Biotin, 100x

Biotin Staining

Sensing Effector Cell Surface

Display

Nano particles

Zoom-In

Composite images

INP-Streptavidin-Alive

Composite image

24

slide-25
SLIDE 25

FITC conjugated Biotin, 100x FITC conjugated Biotin, 100x

Biotin Staining

Sensing Effector Cell Surface

Display

Nano particles

Negative Control

Composite image

INP-Streptavidin-Alive

Composite image

25

slide-26
SLIDE 26

Edinburgh 2011 BBa_K523013

Control: YFP in the Cytoplasm BBa_K523013 transformed cells

More Characterization Needed

Sensing Effector Cell Surface

Display

Nano particles

26

slide-27
SLIDE 27

Improved Characterization

Confocal Microscopy: BBa_K523013 transformed cells

Zoom

Sensing Effector Cell Surface

Display

Nano particles

27

slide-28
SLIDE 28

Improved Characterization

YFP Fluorescence, 100x , FITC filter Anti-YFP Ab fluorescence , 100x, Cy5

Merge image of A & B

Inverted Microscopy BBa_K523013 transformed cells Proves Surface Localisation

Sensing Effector Cell Surface

Display

Nano particles

28

slide-29
SLIDE 29

29

WT E.coli, neg ctl, Merge image

Improved Characterization

Sensing Effector Cell Surface

Display

Nano particles

Inverted Microscopy Negative Control

slide-30
SLIDE 30

INP-Streptavidin Expression

Western Blot of Cell Pellets containing INP-Streptavidin

  • ~ 50 kDa expected
  • Cell pellets
  • FITC conjugated

Anti-Streptavidin Antibody

  • Typhoon Scanner

Sensing Effector Cell Surface

Display

Nano particles

30

slide-31
SLIDE 31

New Cloning

Added EYFP

Sensing Effector Cell Surface

Display

Nano particles

31

slide-32
SLIDE 32

32

ImmunoFluorescent Staining

Sensing Effector Cell Surface

Display

Nano particles

Anti-YFP Ab fluorescence , 100x, Cy5 Anti-YFP Ab fluorescence , 100x, Cy5

Merge image of A & B Merge image of A & B

YFP Fluorescence, 100x , FITC filter YFP Fluorescence, 100x , FITC filter

INP_YFP_Streptavidin INP_Streptavidin_YFP

slide-33
SLIDE 33

33

ImmunoFluorescent Staining Controls

Sensing Effector Cell Surface

Display

Nano particles

Positive Control: BBa_K523013 Negative Control: Competent Cells

Anti-YFP Ab fluorescence , 100x, Cy5

Merge image of A & B

YFP Fluorescence, 100x , FITC filter Anti-YFP Ab fluorescence , 100x, Cy5

Merge image of A & B

YFP Fluorescence, 100x , FITC filter

slide-34
SLIDE 34

Achievements

  • BBa_K523013 Characterization
  • Fusion Protein Cloning
  • Sequencing Confirmation
  • ImmunoFluorescent Assays
  • Biotin Staining Assays
  • Fusion protein IYS & ISY

34

slide-35
SLIDE 35

Sensing Effector Cell Surface Display Nanoparticles

35

slide-36
SLIDE 36

Nanoparticles

Sensing Effector Cell Surface

Display

Nano particles

36

slide-37
SLIDE 37

Making & Characterizing Nanoparticles

Two Step Desolvation Method DLS: Dynamic Light Scattering

Sensing Effector Cell Surface

Display

Nano particles

Average size ~ 160 nm

Size Distribution by Intensity

37

slide-38
SLIDE 38

Two Types of Cargo

Nanoparticles containing fluorescently labeled dextran

Internal Loading External Labeling

CY5 attached to nanoparticles

Sensing Effector Cell Surface

Display

Nano particles

38

Inverted Microscopy Inverted Microscopy

slide-39
SLIDE 39

Biotinylation

  • Chemical Reaction using NHS-ester

Sensing Effector Cell Surface

Display

Nano particles

Biotin Gelatin Nanoparticle Biotinylated Nanoparticles

39

slide-40
SLIDE 40

Biotinylated Nanoparticles

ELISA-like Assay

Sensing Effector Cell Surface

Display

Nano particles

HRP-conjugated Avidin (commonly used in ELISA) Biotin Gelatin Nanoparticle Plate’s Well

40

slide-41
SLIDE 41

Microfluidics: MITOMI Experiment

Digestion of nanoparticles by MMP2

Sensing Effector Cell Surface

Display

Nano particles

41

Before wash After wash After MMP2 flow

slide-42
SLIDE 42

Attaching Nanoparticles to E.coli

Nanoparticles Biotin E.coli chemically linked to streptavidin

+

Sensing Effector Cell Surface

Display

Nano particles

Zoom-In Inverted Microscopy

42

slide-43
SLIDE 43

Achievements

  • Successful Creation and Characterization of 5 batches
  • f nanoparticles:

Naked Biotinylated CY5-labeled biotinylated FITC-Dextran loaded Biotinylated FITC-Dextran loaded

43

slide-44
SLIDE 44

Outreach

Women&Engineering’s day Educational Kit

44

slide-45
SLIDE 45

Educational kit

« Education that is challenging and fun is really at the heart of what we do- and it sounds like what you do

  • too. »
Natalie Kuldell: President of Biobuilder

educational foundation

FUN & SHARING EDUCATION & SAFETY

45

slide-46
SLIDE 46

46

Women&Engineering’s day

slide-47
SLIDE 47

Amazing Summer Documentation and Registry entry

  • f new Biobricks

Design and Characterization of new Biobricks Improved Characterization of BBa_K523013 Autonomous Organization Careful scientific approach Exceptional microscopy assays Fantastic Human Practice Autonomous Wetlab work Functionality of BBa_K1111005 proved Nanoparticles

47

slide-48
SLIDE 48

Thanks

EPFL School of Engineering EPFL School of Life Sciences Our Sponsors The Biobuilder foundation and Natalie Kuldell The EPFL Equal Opportunities Office and Farnaz Moser

  • Dr. Daniel Bonner, Dr. David Scott Wilson and Alexandre De Titta

Thierry Laroche

  • Prof. Eric Allémann
  • Prof. Matthias Lutolf and Prof. McKinney

Michael Fairhead Nicole Paduwat and Stéphane Karlen Sabrina Leuenberger Sander Kromwijk

  • Dr. Sacha Sidjanski

48

slide-49
SLIDE 49

Questions?
