1 Beijing Puran Railway Braking High Tech Co., Ltd. was established in 2008 as a manufacturer specialized in organic and sintered railway friction material covering the full product cycle: R&D, Production, Sales & After Sales 2 4 200 motivated employees of which 20 are Industry acknowledged certifications such as experienced R&D engineers IRIS, ISO 9001:2008, UIC, … 3 5 Owner of multiple patents for organic and European subsidiary Puran Europe was founded sintered pads in 2011 to better service European clients COMPANY
HEAD QUARTER, BEIJING • R&D facility + individual and small series production in Beijing • Located in Changping High Tech Park • Annual capacity of 300.000pcs; 4.000m ² EUROPEAN HEAD QUARTER, • Dynamometer test bench NEUSS / DÜSSELDORF, GERMANY • Quality assurance & Customer care • Cargo Distribution & Warehousing MAIN FACTORY, HEZE, SHANDONG PROVINCE LOCATIONS • Highly automated & intelligent production • Construction started in 2014; Producing since 2016 • Annual capacity of 2.5 million pcs; 40.000m ²
DISTRIBUTION OF PRODUCT PORTFOLIO Organic Block Cargo … Sinter Pad Highspeed Organic Pad Metro Organic Pad … Organic Pad RIC
PRODUCT PORTFOLIO WE WE OWN WN PATENTS FOR ORGAN ANIC C AN AND SINTERED PAD ADS ORGANIC SINTER ORGANIC PADS PADS BLOCKS Properties according requirements HST, EMU, DMU, Metro, Freight wagons High Speed Trains Passenger coaches, regional Locomotive Very High Speed Trains and commuter trains Metro / Sub-Urban
ORGANIC PADS BZP625 BZP826 SPEED SPEED 140 kph 200 kph 200 kph 300 kph (in process for UIC Certificate) 300 kph FRICTION COEFFICIENT FRICTION COEFFICIENT 0,30 – 0,45 0,30 – 0,45 0,35 0,35
SINTER PADS CRH5/PR34S CRH3/PRF1103 SPEED SPEED 320 kph 240 kph (UIC Certificate) 300 kph BRAKE FORCE BRAKE FORCE 22kN 25kN FRICTION COEFFICIENT FRICTION COEFFICIENT μ = 0.37 μ = 0.37
ORGANIC BLOCKS K-BLOCK 309F-C LL-BLOCK SPEED SPEED 120 kph 120 kph (UIC Certificate in progress) BRAKE FORCE BRAKE FORCE 38kN 100kN FRICTION COEFFICIENT FRICTION COEFFICIENT μ = 0.30 – 0.40 μ = 0.08-0.17 AXLE LOAD DIMENSION AXLE LOAD 18 ton Bg, BgU, 2*Bg, 2*BgU 22,5 ton
APPLICATION CRH 5: 200-250 km/h Sinter pads are used in Chinese Very High Speed Trains and High Speed Trains for several years. Customer satisfaction and service record is outstanding. Malaysia Airport Train CRH380: 300-350 km/h CRH 1: 200-250 km/h
APPLICATION PRODUCTS PERFORM UNDER EXTREME CONDITIONS In Heilongjiang (the northernmost province) with average temperature of -30° to -15° in Winter (lowest -50°) In Hunan province with an average temperature of 25° to 34° in Summer (highest 45°)
In Inner Mongolia with deserts and sandstorms In Qinghai Province at high altitude (> 3000m) with large temperature differences between night and day In Xinjiang Province (Urumqi – Kaxgar), with violent winds and high altitude
CUSTOMERS CHINA EUROPE ASIA AFRICA 18 railway bureaus AUSTRIA SOUTH KOREA SOUTH AFRICA servicing 65 regions MALAYSIA GERMANY Some Customers: INDIA DENMARK CRH • KAZACHSTAN CRRC • BST Transportation •
WHY PURAN ? ☞ Motivated to meet and exceed your requirements ☞ Proven track records for both sintered & organic components under extreme conditions ☞ PURAN owns the IP rights for all of their products ☞ State of the art production facility and quality assurance ☞ Professional R & D team and facilities
Mail us your inquiry. You will appreciate the result! Europe Headquarter PURAN Europe GmbH Beijing Puran Railway High-Tech Co Ltd 41469 Neuss 100161 Beijing Germany China Tel: +49 (2137) 9124083 Tel: +86 (10) 8828 6972 Email: info@puran-europe.de Email: export@puranparts.com
