Zimi Product Presentation

Zimi Corporation September, 2016

How do we make Products

We Lead the industry tide We Create professional standard We Improve user experience

PB810

Power Bank is our Speciality

USB Type A Micro USB LED Power

A ZMI Tour De Force 10000mAh Power Bank Conversion Rate

Super slim and light for your easily carry(10000mAh) Premium Polymer Li-ion battery for your safety World class chips for managing power better Intelligent identification for all kinds of digital products Corrugated design and unique painting for better feel

We have thoughts in Power Bank

Up to

• 93% conversion rate

Added

• 100 Using Rounds

Increas ed

• 10% power output

efficiency

What’s the optimization of our Power Bank

Heat-sensitive and temperature control mechanisms ensure Li-ion batteries operate within a safe range.

Temperature Resistance

The motherboard and battery are automatically protected if short circuit

• ccurs.

Short-circuit protection

Reset the power bank if it stops responding by simply pressing the Power button

Reset Mechanism

OVP circuit prevents voltage surges from damaging the device.

Input Over-Voltage Protection

Detects when the charger is inserted incorrectly and will automatically stop charging.

Automatic Charger Protection

Monitors output current and shuts off when current exceeds the maximum limit to protect the device.

Protection from Output Overcurrent

Monitors output voltage and shuts off when voltage exceeds the maximum limit to protect the device.

Output Overvoltage Protection

Japanese technology is used to prevent

• vercharging and over-discharging from

damaging the Li-ion batteries.

Protection from Overcharge and Over-discharge

Imported battery cells are equipped with PTC to effectively control and protect batteries when temperature and current exceed the maximum limit.

PTC Protective Circuits for the Cell

Nine layers of Protection in our Power Bank

Reliability Test

Micro USB port Plug Testing 5,000 times USB port Plug Testing 1,500 times ESD Testing Touch 8KV/Air 12KV

Environmental Test

High Temperature Storage 70℃, 96hours Low Temperature Storage

• 40℃, 96hours

High Temperature and Humidity 60℃/H95% , 96hours Temperature Shock

• 40 ~ 70℃, 10 cycles

There’re much more Tests

Quality is our Foundation

Power Bank plus MiFi is more desirable

MF855

5 mode technology supports worldwide network 7800mAh built-in power bank powers you everywhere Use Micro SIM to create your private network Up to 8 WiFi hotspots plus one USB modem Manage connected device through APP or Web page

Why MF855 is a desirable product

Perfect complements to power bank

USB Cable USB Fan USB LED Light 2A Adaptor

Our Accessories are all Refined

Intelligent Recognition for Apple&Android Products

ZMI 2A Adaptor (Intelligent)

Expand your Output and Keep small devices Safe

USB Male Protection IC USB Female Micro USB

 It looks just like a normal USB cable, but it can expand more.  Quick charge adaptor is up to 12V, it’s much overloaded to a LED light, the built- in IC will restrict the voltage and avoid the damage.  Use it as a secondary charging output, or provide power to a LED light, all bring more convenience to you.

Power Check LED Indicator Micro USB (input) USB Port (output)

Zimi Power Bank 10000mAh

Model Name PB810 Battery Type Polymer Li-ion Typical Capacity 3.7V/10000mAh Power IC TI BQ24195 Conversion Rate Up to 93% Charging Ability 3.5 full charges for iPhone 6 1.5 full charges for iPad mini Recharge Time About 6 hours @5V/2A Load Detection Autodetect Input Voltage DC 5V Output Voltage DC 5.1V Input Current 2.0A (TYP) Output Current 2.1A (TYP) Protection ① Temperature Resistance ②Short-circuit protection ③Reset Mechanism ④Input Over-Voltage Protection ⑤Automatic Charger Protection ⑥Protection from Output Overcurrent ⑦Output Overvoltage Protection ⑧Overcharge and Over-discharge Protection ⑨PTC Protective Circuits for the Cell Protection Recovery Use adaptor to recharge Charging Temp. 0°C-45°C(TYP) Discharging Temp.

• 20°C~+60°C(TYP)

Finishing ABS+PC,Painting Dimension 148*71*10.5mm Weight 198g

Zimi Power Bank 10000mAh(Smart&Quick Charge)

Industrial Design same as PB810

Model Name HB810 Battery Type Polymer Li-ion Typical Capacity 3.7V/10000mAh Conversion Rate Up to 93% Recharge Time About 4 hours @12V/1.5A,9V/2A Charging Ability 3.5 full charges for iPhone 6 Load Detection Autodetect Input Voltage DC 5V/9V/12V Output Voltage DC 5.1V Input Current 2.0A@5V/9V,1.5A@12V Output Current 2.1A (TYP) Bluetooth Function (APP Client) ①Indicate charging times for connected device. ②Indicate Charging and Recharging current and battery level. ③Indicate remaining Charging and Recharging time. ④Indicate the location when used last time. ⑤Control the on/off of the connected accessories suck like Xiaomi LED light and USB Fan Protection ①Temperature Resistance ②Short-circuit protection ③Reset Mechanism ④Input Over-Voltage Protection ⑤Automatic Charger Protection ⑥Protection from Output Overcurrent ⑦Output Overvoltage Protection ⑧Overcharge and Over-discharge Protection ⑨PTC Protective Circuits for the Cell Protection Recovery Use adaptor to recharge Charging Temp. 0°C-45°C(TYP) Discharging Temp.

• 20°C~+60°C(TYP)

Finishing ABS+PC,Painting Dimension 148*71*10.5mm Weight 198g

Zimi 4G MiFi+Power Bank 7800mAh

Micro USB Port(input) Power USB Port (output） LED Indicator

Model Name MF855 CPU Marvell MP1802 Memory NOR Flash 32MB+DDR32MB Communication TDD-LTE/FDD-LTE WCDMA/TD-SCDMA/GSM SIM Card Support Micro SIM WiFi 802.11 b/g/n WiFi Security WPA-PSK/WPA2-PSK (TKIP/AES) Power Bank 3.6V/7800mAh(TYP) USB Modem DHCP OTA NAT IPv6 MAC Address Filter WEB Client Android Client iOS Client Dimension 102.2*75*22.3mm Weight 220G Software Feature

Model Name AP511 Product Type AC Adaptor Rated Input Voltage 100—240VAC Rated Output 5V@2A Applicable models Android&Apple products Protection ①Short-circuit protection ②Protection from Output Overcurrent ③Output Overvoltage Protection Safety Standard 3C/GB4943-2011 Working Temp. 0°C-40°C Storage Temp.

• 25°C~+70°C

Dimension 46.0*36.0*23.5mm

Zimi 2A Adaptor

Zimi Quick Charge Adaptor

Support QC2.0 protocal

Model Name HA511 Product Type AC Adaptor Rated Input Woltage 100—240VAC 12V@1.5A 9V@2A 5V@2A Quick Charge Depend on the connected device Protection ①Short-circuit protection ②Protection from Output Overcurrent ③Output Overvoltage Protection Working Temp. 0°C-40°C Storage Temp.

• 10°C~+70°C

Dimension 46.0*49.5*23.4mm Rated Output

TopTurbo Lightning to USB

Apple Original MFi Certified ModelName MF-SC03 ProductType Apple Lightning To USB Applicable Models Apple LightningTo Series Certification Apple Mfi Certicaition Length 105cm

Model Name AL910 Product Type Multifunctional USB Cable Applicable models

• Main Path

Android Phone, Tablet, etc. Applicable models

• Second Path

Xiaomi LED Light, USB Fan, etc. Length 120cm

Zimi Multifunctional Cable

USB Type A Male ② USB Type A Female ① Micro USB

Zimi Micro USB Cable（100cm）

USB Type A Male Micro USB

Model Name AL600 Product Type USB Cable Applicable Models-MainPath AndroidPhone,Tablet,etc. Length 100cm

Zimi Micro USB Cable（30cm）

USB Type A Male Micro USB

Model Name AL610 Product Type USB Cable Applicable Models-MainPath AndroidPhone,Tablet,etc. Length 30cm

Zimi Power Bank 5000mAh（Quick Charge）

USB Port (output) LED Indicator Power Check Micro USB (input)

Model name QB805 Battry Type Polymer Li-Ion Typical Capacity 3.7V/5000mAh Conversion Rate Up to 85% Charging Ability 1 full charges for iPhone 6 Power IC TI BQ25895 TPS61088 Input Voltage DC 5V/2A 9V/1.2A 12V/1A Output Voltage DDC 5V/2A 9V/1.2A 12V/1A Protection 1、Temperature Resistance 2、Short-Circuit protection 3、Reset Mechanism 4、Input Over-Voltage Protection 5、Automatic Charge Protection 6、Protection from Output Overcurrent 7、Output Overvoltage Protection 8、Oercharge and Over-discharge Protection 9、PTC Protective Circuits for the Cell Protection Recovery Use adaptor to recharge Charging Temp 0℃~45℃（TYP） Discharging Temp ’-20℃~60℃（TYP） Finishing ABS+PC，Painting Dimension 130*98*8.5mm Weight 112g

Zimi Power Bank 10000mAh（Quick Charge）

USB Port (output) LED Indicator Micro USB (input) Type-C USB (input) Model name QB810 BattryType PolymerLi-Ion Typical Capacity 3.85V/10000mAh Conversion Rate Upto 90% Power IC P02QQCC Type-C Input Voltage DC 5V/2A 9V/2A 12V/1.5A Micro USB Input Voltage DC 5V/2A 9V/2A 12V/1.5A Output Voltage DC 5V/2A 9V/1.6A 12V/1.2A Protection 1、Temperature Resistance 2、Short-Circuit protection 3、Reset Mechanism 4、InputOver-Voltage Protection 5、Automatic Charge Protection 6、Protection from Out put Over current 7、Output Over voltage Protection 8、Oerchargeand Over- discharge Protection 9、PTC Protective Circuits for the Cell Protection Recovery Use adaptortore charge ChargingTemp 0℃~45℃（TYP） DischargingTemp ’-20℃~60℃（TYP） Finishing ABS+PC，Painting Dimension 127*69*12.7mm Weight 177g

Zimi Power Bank 20000mAh（Quick Charge）

USB Port (output) LED Indicator USB Port (output) Type-C USB (input) Model name QB820 BattryType LG 18650 Typical Capacity 5V/12000mAh（TYP 2.4A） Conversion Rate Upto 90% MCU ABOV MC96F6432AU Power IC Intersil ISL95538 Type-C Input Voltage 5-20V/2.4A MAX 45W Micro USB Input Voltage 2*5V/2.4A 9V/2A 12V/1.5A MAX 18W Output Voltage MAX 50W Protection 1、Temperature Resistance 2、Short-Circuit protection 3、Reset Mechanism 4、InputOver-Voltage Protection 5、Automatic Charge Protection 6、Protection from Out put Over current 7、Output Over voltage Protection 8、Oerchargeand Over-discharge Protection 9、PTC Protective Circuits for the Cell Protection Recovery Use adaptortore charge ChargingTemp 0℃~45℃（TYP） DischargingTemp ’-20℃~60℃（TYP） Finishing Anodized aluminum shell，Painting Dimension 160.34*81.74*21mm Weight 404g

Zimi Car Charger（Quick Charge）

 USB Port (output) LED Indicator  USB Port (output)

Model name AP821 Interface type Double USB interface Input Voltage 12V-24V(MAX 3.6A) Output Voltage 5V/2.4A*2 (MAX 3.6A) 9V/2A*2 12V/1.5A*2 ChargingTemp 0℃~30℃（TYP） Dimension 59.4*24.6mm Weight 51.5g
