Wooster Group

Process & Build System Technology

Introduction to our smart technology

 Wooster Group smart build systems are designed

& engineered to International Standards using the latest in global technologies.

 Our integrated 3D modelling software allows us

to model all the required components of the building including the structure, services, fixtures & fittings as one, ensuring seamless connectivity.

 The site process becomes an assembly of pre

manufactured components that simply connect together.

 Reliance on site labour skills to achieve quality

is all but eliminated

 The end result is an exact replication of the 3D

building assembly.

Key Building Technology

 The building structural elements are made

from laser profiled structural steel tube members that facilitate the connection of the building frame, claddings, linings and the installation of all its internal services to millimetre accuracy.

 Our building floors, walls, ceilings & roof

elements are airtight cavities, achieved through a structural bonding process that allows climate controlled AC to operate within these cavities and eliminate the transfer of heat and cold into the rooms of the building.

 Roofs are fully integrated with solar panels

generating power and reticulated hot water.

3D Performance

 We link seamlessly to global

architectural software Rivet & ArchiCAD.

 We build 3D building assemblies of the

required components and have those manufactured to worlds best practises.

 Reverse packaging of the buildings with

3D shipping models allows smart logistics that ensures fast & efficient on site installation.

 We totally eliminate local sourcing of

building components.

 At the same time, we use the 3D data to

produce Virtual Reality models that are embedded in every home automation system.

 Smart controls provide occupiers with a

real sense of living in a 21st century building.

Environmental Impact

 Our buildings will come with UAE

Estidama Pearl 3/ LEED 3 rating

 Focus is on minimal energy, low

water usage through sensors & low use devices

 Recycling of waste water  Robust low carbon footprint can

be maintained throughout the life

• f the building

Sustainability

Speed of Delivery

 We will get your projects completed in less than half the time of traditional

construction.

 Its simply achieved by having the manufacturing happening while the

infrastructure and site preparation are being completed.

 We include the foundation framing & piling system in the site preparation to

allow all services to be connected to the building and external works completed before the arrival of the main building elements.

 The crane in modules allow rapid & safe installation in record time.

Home Automation



Every home comes with touch screen Home Automation.



The embedded 3D models play an active part in future maintenance and any changes the client may want to make.



Even consumer products can be uploaded into the VR model to see what they will look like before purchasing.



The controls system are open ended meaning anything and everything can be controlled by either voice or Wi-Fi activated devices.



Remote access is now standard.

Quality of build

 Having manufactured components derived

from the smart 3D models producing everything from the first foundation member to the last roof member and everything in between means we get everything engineered as one.

 Quality is guaranteed.  This results in as close to zero maintenance

as you will get.

 No decisions are left to onsite interpretation.

Working Together

 Our services start by working with architectural concept designs.  We provide major cost & technical engineering inputs in the early stages to

produce exceptional outcomes in record times.

 We have a major international player delivering our supply chain components.  We will help you reaching positive cash flow for your project by:

❖ Offering trading terms against bank security without the need for deposits &

progress payments.

❖ Extended settlement terms of up to 180 days are available. ❖ Fast and efficient project implementation in phases

➢

Build to Client Architectural Requirements

➢

Build Structure that Exceed Local and International Building Codes

➢

Design Meet LEED/Estidama Standards

➢

Build Exactly to 3D Virtual Reality Model - “What You See is What You Get”

➢

Attractive Financial/Payment Terms for Positive Project Cash Flow

➢

Superior Guaranteed Quality Finished Building

➢

Smart Building Management

➢

Virtually No Building Maintenance

➢

Construction Time Savings

➢

Direct Project Cost Savings

➢

Innovative Reduction in Energy Utilization

➢

Building Warranty for 10 years

Our Competitive Advantages

Architectural Concept Options for Maximum Attraction

Architectural Concept Options for Maximum Attraction

Architectural Concept Options for Maximum Attraction

Architectural Concept Options for Maximum Attraction

Architectural Concept Options for Maximum Attraction

Architectural Concept Options for Maximum Attraction

Government of Dubai

Interior Pleasing Options for Maximum Comfort

Smart Closet for maximum Storage

We look forward to working with you on your next project in the near future.
