Why Virtualization is Essential for 5G

Francis Chow VP & GM, Communications Business Unit November 16, 2015

What’s Hot?

2

2010 2015

Evolution of Wireless Technology

3

1G

• 1st

Generation

Wireless Network

• Basic voice
• NMT, AMPS

2G

• 2nd

Generation

Wireless Network

• Mobile voice

quality

• Coverage and

Capacity

• First digital

standards [GSM, CDMA]

3G

• 3rd

Generation

Wireless Network

• Voice plus some

data [Multimedia, Text, Internet]

• First Mobile

Broadband [WCDMA, CMDA-2000, TDSCDMA]

4G

• 4th

Generation

Wireless Network

• Designed for

data

• IP based

protocols [Voice over IP]

• True mobile

broadband

• Heterogeneous

Network [FDD-LTE, TD-LTE]

2.4kbps 64kbps 2Mbps

100Mbps 1984 1991 2002 2010 Speed& Coverage Time

5G

Voice Data Vertically integrated applications

Traditional Wireless Cellular Network

4

• OPEX dominates expenses

− Power bill − Site acquisition/renting costs

increasing

• Insufficient Flexibility and Scalability

− Overprovision capacity to handle load dynamics

• Office vs Residential area/time

− Proprietary Custom solution

• Unable to support diverse application services

− Challenge to launch different network configurations

• Self-Organizing Networks, New Spectrum & Access Technologies

Processing Load

idle utilized

RRU BBU Source: China Mobile

5G Vision

5

• Massive capacity and massive connectivity

− 100x connected device with 100x user data rates

• Efficient use of spectrum and network resource to

reduce Total-Cost-of-Ownership

• Flexible and scalable infrastructure to enable value

added services

Requirements to Realize 5G vision

6

• Enhance Network Smartness

− Smart capacity/spectrum allocation − Application awareness − Coordinated communication

• Enable Telecom Cloud

− Move cloud to mobile edge − Ultra Low-latency and high bandwidth − Hardware Platform Standardization

Network Efficiency Capacity Increase User Experience Network Virtualization Market Creation Business Model

Not Only Any Time, Any Where … But also Any Thing, Any Service …

Figure source:: ZTE

Evolution to Centralized RAN

7

• Centralized Radio Access

Network (C-RAN) with pooled baseband

− Site Reduction − Lower Cooling cost

• Coordinated processing

− Lower Blocking Rate − Improve capacity

RRU RRU RRU RRU BBU Pool

Cloud RAN

8

• Virtualized Cloud-RAN

− Generic hardware platform − Network Virtualization − Load Balance − Multiple Radio Access Technologies

• New service enablement

− Location-based services − “Zero” latency provision

• Virtualized function support

− Seamless upgrades − Processing resource reuse when idle

RRU RRU RRU RRU BBU Servers

Processing Load

UHD Video Steam Location Service Low Latency App

9

Layer 2/3 Core PHY Layer FEC 5G LTE-U Layer 2/3 Core PHY Layer PHY + FEC

RRU RRU RRU RRU

Cloud RAN

• Virtualized Cloud-RAN

− Generic hardware platform − Network Virtualization − Load Balance − Multiple Radio Access Technologies

• New service enablement

− Location-based services − “Zero” latency provision

• Virtualized function support

− Seamless upgrades − Processing resource reuse when idle

10

Layer 2/3 Core PHY + FEC Gaming 5G LTE-U LTE-IoT

Augmented Reality Location Services

RRU RRU RRU RRU

Cloud RAN

• Virtualized Cloud-RAN

− Generic hardware platform − Network Virtualization − Load Balance − Multiple Radio Access Technologies

• New service enablement

− Location-based services − “Zero” latency provision

• Virtualized function support

− Seamless upgrades − Processing resource reuse when idle

Cloud-RAN Architecture

11

• CPU Elements

−

Multiple radio access technology stacks and protocols

−

New application services

−

Control and monitor interfaces

• FPGA Elements

−

Acceleration for real-time function

−

Switching for scalable load-balancing

−

Peripherals for high bandwidth interfaces/ connections

L1 Accelerator

V M V M V M FPGA

External connectivity External connectivity

CPU V M Hypervisor Interconnect

Interconnect Priority Management Switch L2/3 Accelerator Video/Security Accelerator Other Services Accelerator

2G/3G Service

SW Stack

LTE-IoT Service

SW Stack

5G Service

SW Stack

Low Latency Services

CDN Cache

Other Services

CloudM vEPC

Sell spare processing capacity Lease additional capacity

Virtualized RAN Example

• Centralized Processing Capability

− Traffic and Load-balancing − Network optimization

• Virtualized Processing

− Reuse or resell unused capacity − Value-added (e.g. location based) services

• Low-cost radio end-points

− Independent processing for each end-point

improves capacity over traditional DAS

− Connectivity with fiber, radio fronthaul or

Ethernet

Loading M T W T F Sa Su

New local capacity design

Total Levi Stadium Convention Center Great America

V-CRAN Data Center Conventional local capacity design

Infrastructure Business Model

Service Provider Site and Infrastructure RAN Hardware RAN Software Network Optimization Value Add Services

N e t w

• r

k O p e r a t

• r

T r a d i t i

• n

a l O E M

• Current business

model is dominated by large incumbents

• Limited opportunity

for disruption

Service Provider Site and Infrastructure RAN Hardware RAN Software Network Optimization Value Add Services

Enhanced Network Operator

Infrastructure Business Model

Virtualized Cloud-RAN enables new business models

• Expanded Operator

Capability

−

Value-added services

−

Hardware access for network/application

• ptimization

Service Provider Site and Infrastructure RAN Hardware RAN Software Network Optimization Value Add Services

T r a d i t i

• n

a l O E M

Infrastructure Business Model

Virtualized Cloud-RAN enables new business models

• Expanded Operator

Capability

• Enlarged OEM

Scope

−

Value-added services

Service Provider Site and Infrastructure RAN Hardware RAN Software Network Optimization Value Add Services

Software Provider

Infrastructure Business Model

Virtualized Cloud-RAN enables new business models

• Expanded Operator

Capability

• Enlarged OEM Scope
• New Entrants

−

Data Center Providers to enable RAN hardware

−

New-style OEM with hardware-agnostic, software solution

−

Vertical market applications migrate to new software providers

Summary

17

• 5G means smartness, efficiency and business model

disruption

• Virtualized CRAN provides an effective solution for 5G
• CPU and FPGA reprogrammable acceleration enables

5G vision
