Westbury UFSD Capital Improvements Program Construction Update July 10, 2019

• High School Program

– Review of Project Scope – Renderings of Facility – Construction Update – Minority / Women / Local Business Involvement

• Middle School Program

– Review of Project Scope – Renderings of Facility – Construction Update (Roofing Project / Additions & Alterations)

Presentation Overview

• 14 classroom addition
• Cafeteria addition with warming kitchen and connecting

link to existing building

• Science Lab Alterations
• Boilers, pumps and controls
• Floors and ceilings
• Site Work – parking lot modifications
• Masonry Restoration – areas of work impact
• Upgrade Electrical Service

Project Scope for HS

EVT-1 EVT-2 T-1 T2

TERRAZZO BASIS OF DESIGN

T4 EVT-2 EVT-3 T3 EVT-3

Terrazzo Basis of Design

1 3884 FROST -FORBO MARMOLEUM FRESCO 2 3708 FOSSIL -FORBO MARMOLEUM CONCRETE 33736 GREEN SHIMMER -FORBO MARMOLEUM CONCRETE T-4 3711 CLOUDY SAND -FORBO MARMOLEUM CONCRETE

Enhance Vinyl Tile

EVT-1 AD521 LIMO -ALTRO DOLCE TILE EVT-2 AD512 LECHE -ALTRO DOLCE TILE EVT-3 AD605 CILANTRO -ALTRO DOLCE TILE

TERRAZZO BASIS OF DESIGN

Terrazzo Basis of Design

1 3884 FROST -FORBO MARMOLEUM FRESCO 2 3708 FOSSIL -FORBO MARMOLEUM CONCRETE 33736 GREEN SHIMMER -FORBO MARMOLEUM CONCRETE T-43711 CLOUDY SAND -FORBO MARMOLEUM CONCRETE

Sheet Linoleum

LS-1 3711 CLOUDY SAND -FORBO MARMOLEUM CONCRETE LS-2 3240 WILLOW -FORBO MARMOLEUM CONCRETE LS-3 3711 CLOUDY SAND -FORBO MARMOLEUM CONCRETE

Cladding Panel System

PRODEX CREAM -PRODEMA PANELS

Brick Veneer / Thin Brick

PENNSYLVANIA MOLDED -BERKS WATSONTOWN BRICK COMPANY

Thin Cast Limestone

SMOOTH OAK RIDGE RENAISSANCE MASONRY UNITS ARRISCRAFT INTERNATIONAL BUILDING STONE

• Poured concrete for footings and foundation walls for Classroom

Addition

• Installed in-ground sanitary plumbing piping and electrical

conduits in preparation of concrete slab at Classroom Addition

• Placed and compacted soil and stone bed in preparation for

concrete slab pour

• Installed vapor barrier and slab reinforcement
• Poured concrete slab for Classroom Addition
• Received delivery for cold metal framing and commenced work
• n perimeter walls

Construction Update

• Performed abatement and demolition of boilers: 66%
• Formed and poured concrete pads for new boilers: 66%
• Received boiler sections and relocated material to boiler room

for assembly

• Existing sanitary system at Cafeteria Addition remediation: 100%
• Installation of new sanitary structures and interconnecting

piping at Cafeteria Addition: 95%

• Commenced excavation for foundation walls at Cafeteria

Addition

Construction Update

• Termination of feeders at new transformer in driveway: 60%
• PSEG installed pole for new electrical service to transformer
• Delivered new panelboards to electric room in basement
• Commenced asbestos abatement operations at 2nd floor

classrooms

• New Storm Drainage Installation: 60%
• Working on drainage system for new courtyard by locker room
• Completed foundations and concrete slab for East Connecting

Corridor

Construction Update

Classroom Addition – Prep for Pour

Classroom Addition – Slab Pour

Cafeteria Addition – Sanitary System

Boiler Room Operations – Demo & Assembly

Classroom Addition – Interior and Exterior Wall Framing

Electrical Service – Installation of New Transformer Vault

Electrical Service – Switchgear and Conduit Runs

Minority / Women / Local Business Involvement

Elite Construction has been actively meeting with each contractor on a weekly basis to examine their contract and workforce program. The contractors and consultants affiliated with the project are making a “Good Faith Effort” to achieve the District’s goals.

• As the project continues, different skills will be required and

personnel currently assigned to the project will be modified accordingly.

• Individuals are required to obtain their OSHA 10 hour certification and

provide to our office.

• Individuals are also required to be part of the Local Unions that will

man this project: (Carpenters, Brick Masons, Laborers, Abatement, Plumbing, Mechanical, Electrical )

Minority / Women / Local Business Involvement

• VRD Contracting, Inc. – General Construction (WBE)

– A&S Rebar, Inc. – Rebar Supplier (WBE) – Baybrent Construction – Ceramic Tiling (MBE) – Linda Lee Construction - Taping (WBE) – Park Ave Building Materials – Bldg Materials (MBE) – Island Nursery – Landscaping (WBE) Minority / Women / Local Business Involvement

• Thermo Tech Combustion – Mechanical (HVAC)

– DemoTec Mechanical – Boiler Demolition (WBE)

• WHM Plumbing & Heating, Inc.– Plumbing

– AMG Demolition – Hot Water Tank Removal (WBE)

• Roland’s Electric, Inc. – Electrical & Fire Alarm

– Advance Sound Co – PA/ Clocks / Smartboards (WBE) – CMT Lighting Co. – Lighting Supplies (WBE) Minority / Women / Local Business Involvement

• 12 classroom addition with connection to existing building
• Café addition-standard construction
• Alterations to existing kitchen/cafeteria
• Roof replacement and masonry
• Mechanical system: replacement and abatement
• Plumbing with abatement
• Alterations-Increase corridor width, handicapped toilets

and handicapped access throughout building Project Scope for MS

• P/A intercom, clocks, security, F/A
• Ceilings, floors, and casework in all spaces
• Site Work to include parking lot reconstruction
• Upgrade Electrical Service
• Abatement in Crawl Space, Floors & Ceilings

Project Scope for MS

Wiedersum Associates Architects

PERSPECTIVE VIEW 1

Wiedersum Associates Architects

PERSPECTIVE VIEW 2

Wiedersum Associates Architects

PERSPECTIVE VIEW 3

• Middle School Existing Roof Replacement Project

– Contract was awarded to Niko K Construction – Work is scheduled to commence on July 15, 2019 – Contract is scheduled for Summers of 2019 and 2020 – Contract requires abatement, masonry reconstruction and roof replacement of all existing surfaces – Requires coordination with prime contractors on Middle School Additions and Alterations Project

• Middle School Additions and Alterations Project

– Project is currently out of bidding – Bids due date to be established; Anticipate bid opening prior to August 31, 2019

Construction Update

Westbury UFSD Capital Improvements Program Construction Update Question and Answer
