SLIDE 1 Hybrid Construction Hybrid Construction Hybrid Construction Hybrid Construction
1 VP University VP University
SLIDE 2 2 VP University VP University
WHEN DO YOU USE HYBRI D CONSTRUCTI ON?
Hybrid Construction is an economical alternative to
“conventional” steel structures that can exceed the capabilities of traditional Pre-Engineered building systems due to loads imposed by:
- Bridge Cranes
- Monorails
- Industrial Equipment
- Mezzanines
- Building Heights
- Large Building Spans
SLIDE 3 3 VP University VP University
ADVANTAGES OF HYBRI D CONSTRUCTI ON
Cost savings up to 30% and greater on some projects when compared to “conventional” steel design. Shortened time frame for design and construction
- Reduces design time allowing for faster construction
starts.
- Faster erection reduces the cost of field labor
- Faster erection allows earlier occupancy resulting in
additional revenue for the end user
SLIDE 4
TUBI NG PLANT - 100 FT. WI DE AI SLE
SLIDE 5
TUBING PLANT - LACED COLUMNS
SLIDE 6
STEEL PROCESSI NG FACI LI TY
SLIDE 7
STEEL PROCESSI NG FACI LI TYSTRUCTURAL FRAMI NG SYSTEMS
SLIDE 8
STEEL MILL FACILITY
SLIDE 9
STEEL ROLLI NG MI LL
SLIDE 10
ROLLI NG MI LL AND REHEAT FURNACE
SLIDE 11
Continental Express Hangar Knoxville, Tennessee
SLIDE 12
Continental Express Hangar Knoxville, Tennessee
SLIDE 13
Continental Express Hangar Knoxville, Tennessee
SLIDE 14
Structural Steel Beam Compared to Pre-engineered Beam of Equivalent Strength
SLIDE 15 15 15 VP University VP University
HYBRI D CONSTRUCTI ON
- ECONOMICAL ALTERNATIVE TO
“CONVENTIONAL” STEEL CONSTRUCTION
- FASTER DESIGN AND ERECTION TIME FRAME
- EARILER OCCUPANCY DATE RESULTING IN
ADDITIONAL INCOME FOR END USER
- SINGLE SOURCE FOR DESIGN AND FABRICATION
OF COMPLETE BUILDING STRUCTURE AND ENCLOSURE
