WELCOME

WILL IT DOMO?

MQTT TRANSACTIONS TO GET ANY IOT DATA INTO DOMO Ryan Wells

3

WILL IT DOMO?

Ryan Wells

Vice President of Information Technology

Angelica

Trey Hoffman

Enterprise Applications Manager

Angelica

Jared Schumacher

Enterprise Systems Manager

Angelica

4

5

WHAT WE WERE TOLD ABOUT IOT

• That it stands for “Internet of Things”
• It was going to be “the future”
• Thing “X” will talk to thing “Y” and that will

somehow order milk, call your mom, lower your blood pressure, etc.

6

A NARRATIVE REALITY OF IOT

• I have an individual app for my water meter, my electrical

breaker box, my light switches, my Amazon Echo, my thermostat, my camera system, my bathroom scale and my

• fridge. Which, by the way…won’t tell me if the door was left
• pen
• What I really want to know is:
• Is my 2008 GE Freezer…well, freezing?
• If not, can something notify me?
• A new smart freezer is 5x the cost of a regular one; worth it?
• Which member of my household keeps leaving the lights on?

My Light app doesn’t talk to my camera or location app.

7

THE REALITY OF IOT - SYNTHESIS

• The destination of IOT data is usually proprietary
• The source of the IOT data must be purpose built
• There is no standard for IOT communications

supported by multiple vendors

• If you’re lucky, you get an API that you have to

develop custom code to use

• Then you get to set up a server and database to

collect and synthesize the information before sending to a reporting system

8

I REJECT YOUR REALITY AND SUBSTITUTE MY OWN

• Make or retrofit IOT devices inexpensively
• Use common communication

protocols/languages

• Interface those devices into a single,

common output

9

THE BUSINESS “ASK”

• Find a low cost way to collect cycle data from

legacy linen equipment (the “thing”)

• Use that same mechanism to also collect
• perator efficiency, machine effectivity, quality,

temperature and humidity information

• Synthesize and compare the information

without having to build another database

10

CONSTRAINTS

• There was not a repeatable way to get IOT data

into a reporting system

• Vendors that specialized in this field, would only

provide data to their own platform or “API coming spring two- thousand and never”

• Many machines would have to be completely

replaced to gain IOT functionality and recurring costs were significant

11

PARALLEL TECHNOLOGY – THE AHA! MOMENT

• Many of us had been doing machine integrations in our homes

for years, so we knew that our vision was technically possible

• Some parallel systems
• Temperature from hot tub
• Temp and humidity of legacy deep freeze
• Lights and other switches in our homes
• All these devices, natively speak MQTT protocol and run

common hardware (ESP8266)

• We could potentially parse this output and ingest it into DOMO

12

IOT HOT TUB: WILL IT DOMO?

13

IOT FREEZER: WILL IT DOMO?

14

IOT LIGHTS: WILL IT DOMO?

15

WE DON’T CELEBRATE MEDIOCRITY

• The Manager: “This is all really great but how to I

combine this data into something meaningful?”

• The Developer: “I see the data outputs, and I can

ingest them into DOMO but that will require development work!”

• The Infrastructure team: “It will require another

server and database, don’t you have enough already?”

16

The Missing Link

MQTT

• MQTT – Message Queuing Telemetry

Transport

• MQTT is a machine-to-machine (M2M)/"Internet of Things"

connectivity protocol. It was designed as an extremely lightweight publish/subscribe messaging transport

• It uses a broker to handle transactions. It does not require that

thing “X” trust or even know about thing “Y” and vice versa

• It is fault tolerant, messages do not leave queue until they’re

consumed by a subscriber to their specific “topic”

18

GETTING THE DATA TO DOMO

Domo developed a direct-connect MQTT Broker We changed the outputs of the MQTT devices to point directly at DOMO, tied it to a dataflow, created some cards and dropped them in a page

19

LINEN MACHINE: WILL IT DOMO?

Technically, a linen machine is a heap of metal, switches and temperature sensors This was no different than what we’d already proven to work

20

• Project “Tempo” was born
• Initial prototype was built by Jared and I
• We included some additional hardware

to provide real-time information

• Initial pilot was done
• Install was 10% cost of the next best
• ption
• The board asked us to make 400 more
• The question ceased to be “Will it

DOMO?” and became “Will it Scale?”

• Additional production was outsourced
• Total cost delivered is $210/each

LINEN MACHINE: WILL IT DOMO?

21

• The Operator Interface
• Touch Screen on

Raspberry pi

• Barcode Scanner
• Information
• Current pace
• 5 Min average
• Quality check

system

• Machine problem

“Andon” tools

LINEN MACHINE: WILL IT DOMO?

Would we be talking about it if it didn’t?

22

KEY TAKEAWAYS FROM TEMPO

23

• Our Tempo implementation is more complex than needed for

many applications and might make this technology seem overly complex

• If there is a way to measure qualities in the real world, it will

DOMO

• Many different hardware/firmware platforms can be used

(Nodemcu, Sonoff, Raspberry Pi, Tasmota, ESPhome, ESPeasy, MQTTpubsub)

• If it can speak MQTT, you can get the data into DOMO.

COTTAGE CHEESE: WILL IT DOMO?

24

• Let’s domo something together – Cottage Cheese
• Why cottage cheese?
• Because that’s weird
• It’s “hard” to DOMO
• I happen to have some right here

COTTAGE CHEESE: WILL IT DOMO?

25

• What do we want to measure?
• Weight? - HX711 sensor
• Moisture? I2C sensor
• Temperature? AM2301, DHT11
• Hits with a hammer? load cell, binary switch
• For simplicity, let’s go with Temperature and Hammer

strikes

• Temperature is an analog signal (converted to digital)
• Hammer strikes are a digital signal

COTTAGE CHEESE: WILL IT DOMO?

26

• Buy a Node MCU and a temp sensor (DS18B20) - amazon <$20
• Buy some breadboard jumper wires - amazon - get a kit of M-F, M-

M, F-F <$6

• Buy a resistor kit – amazon – will last your lifetime <$12
• Download Arduino IDE – https://www.arduino.cc
• Download the Tasmota firmware package

https://github.com/arendst/Tasmota

COTTAGE CHEESE: WILL IT DOMO?

27

• Open sonoff.ino in the

Arduino IDE

• Edit my_user_config.h to set

WIFI, Topic, MQTT and IP information

COTTAGE CHEESE: WILL IT DOMO?

28

• Plug the

NodeMCU into a USB port

• Change the

board and firmware info as shown

• Click checkbox to

compile and upload the firmware to the NodeMCU

COTTAGE CHEESE: WILL IT DOMO?

29

• Unplug the NodeMCU to wire it
• Wire a switch between GND and

D5

• Wire sensor signal (yellow) to D0
• Wire sensor power (red) to 3v3
• Wire sensor Ground (black) to

GND

• The pin numbers will become

clear when we look at the software interface

• If you think this is too complicated,

I’ll introduce you to the 12 year old girl that did this one

COTTAGE CHEESE: WILL IT DOMO?

30

• Plug in the

NodeMCU to USB for power and configure

• Test it
• Wait for

DOMO to collect data

• Visualize it

DEMONSTRATION

• Node MCU
• Connection to Broker
• Temperature
• Binary Switch

31

WE DON’T CELEBRATE MEDIOCRITY - SOLVED

• The Manager: “This is all really great but how to I combine this

data into something meaningful?” – INJEST INTO DOMO

• The Developer: “I see the data outputs, and I can ingest them

into DOMO but that will require development work!” – USE MQTT INSTEAD OF CUSTOM APPS

• The Infrastructure team: “It will require another server and

database, don’t you have enough already?” – ALL DATA AND INFRASTRUCTURE EXISTS AT DOMO

32
