Welcome to CityPlace Burlington PROJECT REDESIGN SESSION 24 JAN. - - PowerPoint PPT Presentation

Welcome to CityPlace Burlington

PROJECT REDESIGN SESSION

24 JAN. 2020

NORTH BUILDING SOUTH BUILDING 100 BANK

67 CHERRY LL BEAN CHERRY STREET ST PAUL STREET PINE STREET BANK STREET PUBLIC PARKING ACCESS PARKING ENTRANCE PARKING ENTRANCE SOUTH BUILDING ENTRANCE NORTH BUILDING ENTRANCE LOADING DOCK BICYCLE ENTRANCE LOADING DOCK PARKING

CityPlace Burlington- Program Summary

357 Housing units, including 72 affordable units 196 Room Hotel 45,000sf of Street Level Retail Reconnect St Paul and Pine Streets 550 Parking spaces (297 bike parking spaces) 763,200 total gross square feet

2

1

NORTH BUILDING SOUTH BUILDING

MEP BEYOND AMENITIES MEP 93'-6" 60'-0" 60'-0" 19'-8" 40'-0" 57'-6" 9'-0" EAST WING BEYOND 10'-0" 65'-0" 127'-8" 55'-0" 65'-0" 10'-0" RESIDENTIAL RETAIL AMENITIES HOTEL ROOMS HOTEL FUNCTION & COMMUNITY SPACE RETAIL PARKING MEP 17'-0" 17'-0"

PREVIOUS DESIGN OUTLINE PREVIOUS DESIGN OUTLINE

25'-4" 143'-3" BANK ST AVG GRADE 207'-9" CHERRY ST AVG GRADE 216'-0" 122'-0" 52'-10"

SCHEMATIC DESIGN

N-S SECTION LOOKING EAST

PR-300a

NORTH BUILDING SOUTH BUILDING

MEP BEYOND 93'-6" 60'-0" 60'-0" 19'-8" 40'-0" 57'-6" 9'-0" EAST WING BEYOND 10'-0" 65'-0" 127'-8" 55'-0" 65'-0" 10'-0" 17'-0" AMENITIES MEP RESIDENTIAL RETAIL AMENITIES HOTEL ROOMS HOTEL FUNCTION & COMMUNITY SPACE RETAIL PARKING MEP

BANK ST AVG GRADE 207'-9" CHERRY ST AVG GRADE 216'-0" 128'-3" 15'-0" 122'-0"

SCHEMATIC DESIGN

N-S SECTION LOOKING EAST

PR-300

3

RENDERING IN PROGRESS

PUBLIC BENEFITS

More downtown housing, including affordable units Two reconnected public streets - Pine and St. Paul Sustainable Design LEED Gold certification Green roof areas and Solar PV panels 100% treatment of stormwater runoff from site Community Access Community Meeting Space Observation deck open to the public Bike Parking Enhanced Grand List & Rooms and Meals tax revenues

24 JAN. 2020

FIN.
