Walkable Places Planning and Development Department City of Houston Walkable Places Committee March 6, 2019 Project Schedule Jun - Aug 2019 Mar - Apr 2019 Ordinance language Bridge proposals Policy guidance Finalize

slide-1
SLIDE 1

Walkable Places

Planning and Development Department City of Houston Walkable Places Committee March 6, 2019

slide-2
SLIDE 2

Mar Apr May Jun Jul Aug Sep Oct

Project Schedule

Mar - Apr 2019

  • Bridge proposals
  • Finalize framework
  • Test pilot area plans

May - Jun 2019

  • Preliminary approval by WPC
  • Preliminary approval by PC
  • Public engagement

Jun - Aug 2019

  • Ordinance language
  • Policy guidance

Sep - Oct 2019

  • Public hearing
  • PC recommendation
slide-3
SLIDE 3

Agenda

  • Transit Corridor Map Amendment Update
  • Walkable Places Project Update
  • Public Comment
slide-4
SLIDE 4

Existing Transit Corridor Map

slide-5
SLIDE 5

Proposed amendments to the Transit Corridor Map:

Current Transit Corridor Map Proposed Transit Corridor Map w/ Required Compliance Boundary

slide-6
SLIDE 6

Proposed amendments to the Transit Corridor Map:

Proposed Revised Type A Street Boundary Sensitive to Local Context Current Designated Type A Streets

slide-7
SLIDE 7

Proposed amendments to the Transit Corridor Map:

Proposed Designating More Streets w/ Appropriate Context Current Designated Type A Streets

slide-8
SLIDE 8

Transit Corridor Map Amendment Update

  • Transit

Station Analysis

slide-9
SLIDE 9

Proposed No Transit Corridor Map Amendments – Fannin South Station

Fannin South

Transit Corridor Existing Type A Streets Major Thoroughfare

slide-10
SLIDE 10

Proposed Transit Corridor Map Amendments – Coffee Plant/ Second Ward Station

Existing Potential Required & Optional Compliance Boundary

Coffee Plant/ Second Ward

650’ 800’ 800’ 450’ 450’ 800’

Coffee Plant/ Second Ward

slide-11
SLIDE 11

Transit Corridor Map Amendment Update

  • Consideration

Factors

  • Distance from station
  • Land use characteristics
  • Existing restrictions:
  • Deed restrictions
  • Minimum lot size/ building line; Historic preservation
  • Other factors
  • Proximity to commercial corridors, public institutions/ facilities
  • Public investment in rights-of-way
  • Area characteristics:
  • Activity population
  • Car ownership & Metro ridership
  • Street grid system/ intersection density
slide-12
SLIDE 12

Elgin Station – Southeast Line

slide-13
SLIDE 13

Type A Non-S Family Public & Institutional S Family Vacant Potential Optional Potential Mandatory

Land Use w/ Current Boundary Potential Mandatory and Optional Boundary

Elgin Station

slide-14
SLIDE 14

Stations

slide-15
SLIDE 15

Palm Center – Southeast Line

slide-16
SLIDE 16

Land Use w/ Current Boundary Potential Mandatory and Optional Boundary

Palm Station

Type A Non-S Family Public & Institutional S Family Vacant Potential Optional Potential Mandatory

slide-17
SLIDE 17

Stations

slide-18
SLIDE 18

Quitman Station – North Line

slide-19
SLIDE 19

Quitman Station

Type A Non-S Family Public & Institutional S Family Vacant

Land Use w/ Current Boundary Potential Mandatory and Optional Boundary

slide-20
SLIDE 20

Stations

slide-21
SLIDE 21

Montrose Station – University Line

slide-22
SLIDE 22

Montrose Station

Land Use w/ Current Boundary Potential Mandatory and Optional Boundary

slide-23
SLIDE 23

Stations

slide-24
SLIDE 24

Uptown BRT

slide-25
SLIDE 25

Ambassador Guilford

Type A Non-S Family Public & Institutional S Family Vacant

Land Use w/ Current Boundary Potential Mandatory and Optional Boundary

slide-26
SLIDE 26

Stations

slide-27
SLIDE 27

Transit Corridor Map Amendment Update

  • Criteria

Discussion

  • Distance from station
  • Land use characteristics
  • Existing restrictions:
  • Deed restrictions
  • Minimum lot size/ building line; Historic preservation
  • Other factors
  • Proximity to commercial corridors, public institutions/ facilities
  • Public investment in rights-of-way
  • Area characteristics:
  • Activity population
  • Car ownership & Metro ridership
  • Street grid system/ intersection density
slide-28
SLIDE 28

Montrose Station

Land Use w/ Current Boundary Potential Mandatory and Optional Boundary

slide-29
SLIDE 29

Transit Corridor Map Amendment Update

  • Criteria

Discussion

  • Distance from station
  • Land use characteristics
  • Existing restrictions:
  • Deed restrictions
  • Minimum lot size/ building line; Historic preservation
  • Other factors
  • Proximity to commercial corridors, public institutions/ facilities
  • Public investment in rights-of-way
  • Area characteristics:
  • Activity population
  • Car ownership & Metro ridership
  • Street grid system/ intersection density
slide-30
SLIDE 30

Discussion

slide-31
SLIDE 31

Agenda

  • Transit Corridor Map Amendment Update
  • Walkable Places Project Update
  • Public Comment
slide-32
SLIDE 32

Previous Proposed Framework

  • Potential applicants could be:
  • Property owner(s)
  • City of Houston
  • Management districts/ TIRZ
  • The submitted application shall:
  • Define the application area
  • Describe context of the application area
  • Identify unique rules from the Walkable Places Element

Menu

slide-33
SLIDE 33

Previous Proposed Framework

slide-34
SLIDE 34

Previous Proposed Framework

slide-35
SLIDE 35

Challenges

  • f Previous

Proposed Framework

  • Who should be the applicants?
  • How to create rules sensitive to the local context?
  • How to create a simplified process to encourage

designation?

slide-36
SLIDE 36
  • Similar to Major Thoroughfare and Freeway Plan
  • Create a WPP map
  • Create a WPP amendment process to allow
  • New designation of walkable places
  • Amendments to the designated walkable places
  • WPP amendments will
  • Focus on planning standards along each street segment
  • Address the following planning standards:
  • Walkable Street standards
  • Building and site design standards
  • Parking standards

Current Proposed Framework

  • Walkable

Places Plan (WPP)

slide-37
SLIDE 37

Current Proposed Framework

  • Walkable

Places Plan (WPP)

slide-38
SLIDE 38

Street segment means

  • Street right-of-way between 2 intersecting streets; or
  • Street right-of-way between an intersecting street and the

logical termination of the roadway

Current Proposed Framework

  • Walkable

Places Plan (WPP)

slide-39
SLIDE 39

Who starts the process?

Previous Proposal Current Proposal

Current Proposed Framework

  • Walkable

Places Plan (WPP)

City of Houston Property owners representing at least 10% geography area Management districts/ TIRZ/ other entities representing property

  • wners

City of Houston Property owners representing at least 50% linear street frontage

slide-40
SLIDE 40

Size requirements

Previous Proposal Current Proposal

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Min 1 block No max requirements Min 1 street segment No max requirements

slide-41
SLIDE 41

Compliance requirements No Changes

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Required compliance

  • - all properties

Allow variance requests subject to PC approval

slide-42
SLIDE 42

Submittal requirements No Changes

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Pre-submittal meeting * Boundary map * Proposed walkable place plan

slide-43
SLIDE 43

Review Procedures

Previous Proposal Current Proposal

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Planning Dept Review Public meeting(s) Voting by property

  • wners

Public hearing Planning Commission Recommendation City Council action Planning Dept Review Public meeting(s) Public hearing Planning Commission Recommendation City Council action

slide-44
SLIDE 44

Walkable Places Planning Standards

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Categories of Walkable Places Elements Related Elements within Public R.O.W. Pedestrian Realm Building/ Site Design Parking Walkable Street Standards Building/ Site Standards Regular Standards Special Parking Standards

slide-45
SLIDE 45

Walkable Street Standards

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Walkable Street Components Designated R.O.W. Width Building Setback Unobstructed Sidewalk Safety Buffer Building line Pedestrian realm 6’ 8’ 10’

For example:

  • Emancipation Ave:

80’ R.O.W. – 18’ PR – 8’ SW

  • Hogan St:

70’ R.O.W. – 5’ BL – 6’ SW

slide-46
SLIDE 46

Building Line

Safety Buffer Unobstructed Sidewalk

Property Line

Safety Buffer Unobstructed Sidewalk

Edge of Paving Property Line Building Facade Pedestrian Realm

Building line vs. Pedestrian realm

VS.

Building line:

Measures distance b/w property line & building

Pedestrian realm:

Measures distance b/w edge of paving & building

slide-47
SLIDE 47

Building/ Site Standards

Single family residential vs. Non-single family residential

No Changes

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Public entrance Ground floor façade Opening interval Use of pedestrian realm Driveway location & dimensions

slide-48
SLIDE 48

Parking requirements

No Changes

Current Proposed Framework

  • Walkable

Places Plan (WPP)

Regular parking requirements Special Parking Area application

slide-49
SLIDE 49

Current Proposed Framework

  • Special

Parking Arrangement

WPP

(Ch 33)

SPA

(Ch 26)

WPP

w/ special parking elements

slide-50
SLIDE 50

Current Proposed Framework

  • Ordinance

Structure

WPP amendment procedure (Chapter 33) Walkable Places Planning Standards

  • Walkable Street classification, building setback, building/site

design (Chapter 42)

  • Unobstructed sidewalk & safety buffer (Chapter 40)
  • Landscape requirements (Chapter 33)
  • Special parking arrangements (Chapter 26)

Walkable Places Policy Guide

  • WPP objectives
  • Guiding principles for WPP amendments
  • Requirements of WPP amendment proposal
  • Guidance for walkable places components
  • Other tools to promote walkable development
slide-51
SLIDE 51

Discussion

slide-52
SLIDE 52

Agenda

  • Transit Corridor Map Amendment Update
  • Walkable Places Project Update
  • Public Comment
