Visualization Project

Arch Media Elective 4341 Fall 2012 Kyle Kenerley – Final Presentation

Project Proposal

My proposal for this project was to model a Parisian Café. How I came up with this concept is based on my experiences I had on my summer study abroad trip in Paris. I spent a lot of time in Cafes, considering they are a huge part of Parisian culture and because they were more than common to find through out Paris. Due to this commonality I decided to create my own Café taking ideas and concepts from other sources. A couple characteristics that define cafes in Paris are their number of condensed seating both inside and out, street side locations, location near important or famous sites, curtain wall (most of the time), and in my opinion the higher quality cafes are always on a street corner. Taking these characteristics and

• thers from my personal experiences I began to develop my

cafe.

Images by Kyle Kenerley

Resources Used

Programs:

• Rhino Nurbs Modeling
• Vray Plug-in
• Paneling Tools Plug-in
• Adobe Photoshop

Reference Images: Using these images, I found ideas and objects I could individually model and develop in my own style for the scene. One of the main issues is the amount of

• bjects in each of

these scenes that would be difficult to render in.

Modeling

The process of modeling this project started with the exterior and the structural mass and then the detailed modeling of the interior and props.

Modeling - Seating

The model of the booth consists of extruded curves to Form the cushions as well as scaled box geometry to Form the frame. Framing surrounds the geometry of the cushion The model of the chair consists of piped geometry to form The legs and back as well as extruded and lofted curves to Form the seat. Piped legs and back Flat surface seats

Modeling - Tables

Both the versions of the table consist of simple extruded geometry on the table top and stands. Square Table top Cylinder Table top

Modeling - Counter Area

Both the counter and display were first formed by box framing which where then modified by a series of bending and extruding. To add more detail to the model of the display there are different sized shelving and a curved shell. Separate geometries for different materials Shelves can only be seen in wireframe

Modeling - Small Props

The light fixtures and the dishware including the bowl and cake holder are made of displaced curves that are then lofts together. The Glasses and Spice shakers are made of simple extruded cylinders. CakeHolder Spice Shaker Glass Bowl

Modeling - Aw ning

The Awning is made of lofted and extruded curves surrounding the main mass of the building. Simple extruded boxes are used to Form the structure underneath the awning. Awning Fabric Shaded Awning Fabric Wireframe Structure Full Wireframe

Modeling - Aw ning

The deformations in the awning are developed by a series of added curvature meaning there are more control points in the

• Surface. The actual deformations themselves are formed maneuvering varying control points with in each surface.

Wireframe Control points

Modeling – Paneling Tools

The Charrette decoration is designed using paneling tools plug-in in Rhino.

Modeling – Paneling Tools

Paneling Step 1 - Surface Paneling Step 2 – Point Grid Paneling Step 3 – Paneling Object Paneling Step 4 – Paneling to Grid

Materials - Exterior

Sidewalk Concrete Flooring Curtain Wall Glazing Upper Window Glass Awning Fabric Exterior Brick

Materials - Interior

Stucco Ceiling Interior Brick Curtain wall Frame Stucco Wall

Materials - Interior

Booth Frame Booth Cushion Flooring

Materials - Seating

Table Top Metal Stand Chair Material Metal Chair Legs and Back

Materials

Counter Top Counter Back wall Shelves

Materials

Décor Image 1 Décor Image 2 Décor Image 3

Materials - Charrette

Materials - Props

Bowl Ceramic Glass Holder Pepper Shaker Plastic Salt Shaker Plastic

Renderings

• 1. Interior Sun Light, Day Scene
• 2. Interior Artificial Light, Night Scene
• 3. Exterior Sun Light, Day Scene
• 4. Exterior Artificial Light, Night Scene
