SLIDE 1
Visible Physics
Ben Rogers
Director of Curriculum and Pedagogy: Paradigm Trust
problem solving
Visible Physics
Ben Rogers - Director of Curriculum and Pedagogy: Paradigm Trust
memory teaching gesture
Visible Physics Ben Rogers Director of Curriculum and Pedagogy: - - PowerPoint PPT Presentation
Visible Physics Ben Rogers Director of Curriculum and Pedagogy: - - PowerPoint PPT Presentation
Visible Physics Ben Rogers Director of Curriculum and Pedagogy: Paradigm Trust Visible Physics Ben Rogers - Director of Curriculum and Pedagogy: Paradigm Trust problem teaching gesture memory solving Memory The Ebbinghaus Forgetting
SLIDE 2
SLIDE 3
Memory
SLIDE 4
The Ebbinghaus Forgetting Curve - 1885
time recall
SLIDE 5
kinetic energy kinetic energy kinetic energy gravitational potential gravitational potential gravitational potential thermal thermal thermal
The Surprisingly Powerful Influence of Drawing on Learning
The Picture Superiority Effect
Source: Fernandez et al 2018
SLIDE 6
kinetic energy kinetic energy kinetic energy gravitational potential gravitational potential gravitational potential thermal thermal thermal
The Surprisingly Powerful Influence of Drawing on Learning
The Picture Superiority Effect
Source: Fernandez et al 2018
SLIDE 7
Source: Fernandez et al 2018
The Surprisingly Powerful Influence of Drawing on Learning
The Picture Superiority Effect
SLIDE 8
Teaching
SLIDE 9
Should I explain a visual?
5N F
SLIDE 10
Should I explain a visual?
Source: Kalyuga, Chandler and Sweller (2000)
5N F
SLIDE 11
How should I explain my visual?
SLIDE 12
... ... ...
This chart shows the temperature level rise over the past 170 years. Scientists say this is at least in part attributable to human activity - the artificial increase in CO2 levels globally....
How should I explain my visual?
verbal labeled separate text
SLIDE 13
... ... ...
This chart shows the temperature level rise over the past 170 years. Scientists say this is at least in part attributable to human activity - the artificial increase in CO2 levels globally....
How should I explain my visual?
verbal labeled separate text
Source: Moreno and Mayer 1990
retrieval
SLIDE 14
Long Term Memory Working Memory External Memory
SLIDE 15
Long Term Memory Working Memory External Memory
visual audio
SLIDE 16
Teaching
Organising Knowledge
SLIDE 17
Compare Group Sequence Cause and Effect
SLIDE 18
Different Different Similar
SLIDE 19
The Earth orbits the Sun. The Earth has liquid oceans. The Earth has an atmosphere. Both are approximately spherical. Both rotate. Both have gravity. The Moon orbits the Earth. The Moon has no atmosphere. The Moon’s orbital period is the same as its rotation period. Different Different Similar
SLIDE 20
Ishikawa Diagram - Cause and Effect
SLIDE 21
Ishikawa Diagram - Cause and Effect
Why do I a need to keep pedalling to stay at the same velocity?
SLIDE 22
Ishikawa Diagram - Cause and Effect
Friction between the road and the wheels Force resisting motion Air resistance Friction between the axles and wheels Force resisting motion Force resisting motion
Why do I a need to keep pedalling to stay at the same velocity?
SLIDE 23
Teaching
Tidy Layouts Reduce Cognitive Load
SLIDE 24
Using the Grid
SLIDE 25
Using the Grid
SLIDE 26
... ... ...
This chart shows the temperature level rise over the past 170 years. Scientists say this is at least in part attributable to human activity - the artificial increase in CO2 levels globally....
How should I explain my visual?
verbal labeled separate text
Source: Moreno and Mayer 1990
retrieval
SLIDE 27
Should I add ‘seductive’ details?
Source: Harp and Mayer 1997
seductive illustration
1000s killed by lightning …..
seductive text core information
assessment performance core only core with seductive illustration core with seductive text core with both
Adding detail intended to motivate and engage has a detrimental effect on learning.
☁
- --
Source: Harp and Mayer 1997
SLIDE 28
Summary
Explaining Images
- Explain images to
novices (not to experts)
- Verbal beats
labeled Labelling Images
- Dual coding
increases retention
- Avoid the Split
Attention Effect Tidiness Matters
- Use ‘the grid’ to
design slides
- Insist on tidy
working
SLIDE 29
Problem Solving
SLIDE 30
Computational Efficiency: Search and Inference
One end of a rope is secured to the floor while the other end is passed through a pulley directly above. The free end of the rope is attached to a 5N weight. The weight is suspended by the rope. What is the size of the force required to suspend the pulley?
Why a Diagram is (Sometimes) Worth Ten Thousand Words: Larkin and Simon (1987)
SLIDE 31
Computational Efficiency: Search and Inference
5N F One end of a rope is secured to the floor while the other end is passed through a pulley directly above. The free end of the rope is attached to a 5N weight. The weight is suspended by the rope. What is the size of the force required to suspend the pulley? T T
Why a Diagram is (Sometimes) Worth Ten Thousand Words: Larkin and Simon (1987)
SLIDE 32
mg T x Retort stand masses spring
How much detail?
A demonstration, photo or video often shows too much detail for a novice. This is a representational visual: it shows where the parts go. This is an explanatory visual: it shows the relationship between parts.
SLIDE 33
mg T x Retort stand masses spring
How much detail?
concrete pictorial abstract
SLIDE 34
mg T x Retort stand masses spring
How much detail?
concrete pictorial abstract
SLIDE 35
v t
Concrete and Abstract
SLIDE 36
v t
Concrete and Abstract
SLIDE 37
1 2 3 4
Concrete
SLIDE 38
GPE
1 2 3 4
GPE KE
1 2 3 4
thermal
KE
thermal
KE
thermal
Concrete Abstract
SLIDE 39
Concrete
GPE KE GPE KE
thermal thermal
KE
thermal
Abstract
SLIDE 40
Concrete Abstract
GPE KE thermal
SLIDE 41
Concrete Abstract
SLIDE 42
Potential Difference
Charges travelling pd
Concrete Abstract
SLIDE 43
Summary
Computational Efficiency
- Design diagrams and visuals to
reduce search and inference. Concrete Pictorial Abstract
- Move up and down the ladder
- f abstraction.
SLIDE 44
Drawing with the Body
“When thought overflows the mind, the mind puts it back into the world.” Tversky 2018
SLIDE 45
1 3 2
Iconic - representing an action through gesture. Deitic - pointing at imaginary objects. Metaphoric - hand signals which represent abstract ideas. Beats - gestures to punctuate a list. Emblem - classroom gestures with agreed meaning.
Gestures for Thinking
SLIDE 46
1 3 2
Gestures for Explaining
Kang, Hallman, Son and Black 2012
SLIDE 47
1 3 2
Gestures for Explaining
Kang, Hallman, Son and Black 2012
SLIDE 48
post test #1 post test #2 video - talk alone video - talk + gesture n=184
Transfer test 24h
Does Teacher Gesture Improve Learning?
Cook, Duffy and Fenn 2013
SLIDE 49
Cook, Duffy and Fenn 2013
SLIDE 50
Source: Novac, Congdon Hemani-Lopez Goldin-Meadow (2002)
Learners encouraged to use concrete action Learners encouraged to use concrete gesture
Learners encouraged to use abstract gesture
n=90
Should we encourage learners to use gesture?
SLIDE 51
Summary
Gestures Support Memory
- When learners use
gesture, retrieval is enhanced.
Gestures Support Teaching
- When teachers use
gesture, learning is enhanced.
Gestures Support Problem Solving
- When learners are
encouraged to use gesture, problem solving is enhanced.
SLIDE 52
Theoretical Influences in this Presentation
Oliver Caviglioli Clark and Lyons Barbara Tversky
SLIDE 53
Graphical Influences in this Presentation
Byrne’s Euclid Grid System xkcd
