VERILOG Deepjyoti Borah, Diwahar Jawahar Outline 1. Motivation 2. Basic Syntax 3. Sequential and Parallel Blocks 4. Conditions and Loops in Verilog 5. Procedural Assignment 6. Timing controls 7. Combinatorial Logic in

slide-1
SLIDE 1

VERILOG

Deepjyoti Borah, Diwahar Jawahar

slide-2
SLIDE 2

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 2

slide-3
SLIDE 3

What is Verilog ?

 Verilog is a hardware description language(HDL)  Verilog is used to model digital circuits 

Verilog is a data flow language

 The way it differs from the programming language is by

describing propagation time and signal strength

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 3

slide-4
SLIDE 4

Verilog Timeline

 1983/84-Developed by Prabhu Goel and Phil Moorby as

Automated Integrated Design System

 1985-Renamed as Gateway Design Automation  1990-Cadence Design Systems purchase it  1995-Released in public domain: IEEE 1364-1995 or

Verilog-95

 2001-Verilog 2001  2005-Verilog 2005

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 4

slide-5
SLIDE 5

Why Verilog ..?

Easy verification of circuits : replacement of breadboard and hand layout

Concurrency of processes in hardware elements

Logic synthesis

Abstract level description of design without choosing specific fabrication technology

Functional verification is early in the design process to meet requirements

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 5

slide-6
SLIDE 6

How Verilog works

Behavioural Description(Algorithm level) Specification Register Transfer Level Gate Level Modeling

Logic synthesis/ Manual modeling

Approach: Top----- Down Bottom--------Up Mixed

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 6

slide-7
SLIDE 7

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 7

slide-8
SLIDE 8

Modules

module test; reg clk, reset; wire [3:0] q; ripple_carry_counter rcc(q, clk, reset); initial begin …… …… …… end endmodule module tff(q, clk, reset);

  • utput reg q;

input clk, reset; always @(………) begin ……. ……. ……. end endmodule module ripple_carry_counter(q, clk, reset);

  • utput[3:0] q;

input clk, reset; tff tff0(q[0], ~clk, reset); ………….. ………….. endmodule

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 8

slide-9
SLIDE 9

A Verilog Module

Module Name Port list, port declaration Parameters Declaration of Variables, wires etc. Instantiation of lower end modules Tasks &functions Data flow statements: Always and initial blocks (All behavioural statements) End module

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 9

slide-10
SLIDE 10

Ports

 Allow communication between a module and its

environment.

 Three types of ports:  Input  Output  Inout

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 10

slide-11
SLIDE 11

Data Types

 Register – Something that stores a value  Nets- Connection between elements (commonly

known as wire)

 Value set: 0, 1, x(unknown), z(high impedance)  Reg unsigned variable  Integer signed variable ( 32 bits )  Time unsigned integer ( 64 bits )  Real double precision floating point variable

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 11

slide-12
SLIDE 12

Definition of Constants

 Little – Endian convention is widely used.  <width> `<base letter> <number>  Constants can be specified in decimal,

hexadecimal, octal or binary format E.g. x = 4'd1

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 12

slide-13
SLIDE 13

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 13

slide-14
SLIDE 14

Sequential Blocks

reg a,b,c,d; initial begin a = 1`b0; b= 1`b1; c = a; d = b; end All statements within the block runs sequentially a = 0 b = 1 c = 0 d = 1

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 14

slide-15
SLIDE 15

Parallel Blocks

 Fork and Join

initial fork a = 1`b0; #5 b = 1`b1; #10 c = a; #20 d = b; join All statements after fork runs in parallel a = 0 After 5 cycle b = 1 After 10 cycle c = 0 After 20 cycle d = 1 What happens without delay?? RACE !!!

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 15

slide-16
SLIDE 16

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 16

slide-17
SLIDE 17

Conditional statement

If condition Type1 if ( <expression>) true statement ; Type2 if (<expression>) true statement; else false statement; Type 3 if( <expression1>) true statement1; else if (expression2>) true statement2 ; else if (<expression3>) true statement3; else default_statement;

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 17

slide-18
SLIDE 18

Multi way branching

Keywords : case, endcase, default

case (expression) alternative1: statement1; alternative2: statement2; alternative3: statement3; … … default: default statement; endcase

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 18

slide-19
SLIDE 19

While loop

initial begin count = 0; while ( count < 128) begin $display(“Count = %d”, count); count = count +1; end end

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 19

slide-20
SLIDE 20

For loop

initial for ( count= 0; count <128; count = count+ 1) $display (“count = %d”, count);

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 20

slide-21
SLIDE 21

repeat

initial begin count = 0; repeat(128) begin $display(“count = %d”, count); count = count + 1; end end

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 21

slide-22
SLIDE 22

forever

initial begin clock = 1`b0; forever #10 clock = ~clock; end

 Use forever loop instead of always. (will be clarified in the next chapter)

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 22

slide-23
SLIDE 23

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 23

slide-24
SLIDE 24

Structured procedures

Initial

 Initial - process exactly

  • nce

initial begin a = 1; #1; b=a; end

Always

 Always – rescheduled many

times always @ (a or b ) begin if (a) c=b; else d= ~b; end

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 24

slide-25
SLIDE 25

Structured procedures

 Initial forever

initial forever begin

clk = 0; #1; clk = 1; #1;

end

 All behavioural statements can appear only within structured

procedures

 Nesting between initial and always is not possible

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 25

slide-26
SLIDE 26

Procedural Assignment

 Blocking Assignment ( = )

 Used for purpose of logic  Used for sequential execution of statements

 Non- Blocking Assignment ( <= )

 The simulator can schedule any statement non

deterministically within a block

 switch values without using temporary storage

variables.

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 26

slide-27
SLIDE 27

Blocking Assignment

 Example:

initial begin x=0; y= 1; z=0; #15 count = count + 1; count = 1; end

 Values  At time 0 : X=0, Y=1 and Z=0  At time 15 :

initially count is assigned a junk value and then it changes to 1 in the next assignment

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 27

slide-28
SLIDE 28

Non- Blocking Assignment

 Values  At time 0 : x =0; y=1; z=0; count = 1  At time 15 : count <= 2

 Example

initial begin x <= 0; y <= 1; z <= 0; #15 count <= count + 1; count <= 1; end

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 28

slide-29
SLIDE 29

Uses of Non Blocking Assignment

 Values for flop1 and flop2 ..?

always @ (posedge clock) always @ (posedge clock) flop1 = flop2; begin always @ (posedge clock) flop <= flop2; flop2 = flop1; flop2 <= flop1; end

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 29

slide-30
SLIDE 30

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 30

slide-31
SLIDE 31

Delay based timing control

 Specifies the time duration between when a statement

is encountered and when it is executed.

Delay can be specified by

#Number statement; #identifier statement; #(expression) statement;

 Regular delay control  Intra assignment delay control  Zero delay control

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 31

slide-32
SLIDE 32

Regular delay control

parameter latency = 20; parameter delta = 2; reg a, b, c, d; initial begin a = 0; #10 b = 1; #latency c = 0; #( latency + delta ) d = 1; end

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 32

slide-33
SLIDE 33

Intra assignment delay control

 Assign delay to the right of the assignment operator  Alters the flow of activity in a different manner

initial begin x = 0; z = 0; y = #5x + z; end

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 33

slide-34
SLIDE 34

Zero delay control

 Statements are executed last within the same

simulation time

initial begin x=0; y=0; end initial begin #0 x=1; #0 y=1; end

Used to eliminate race condition

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 34

slide-35
SLIDE 35

Event based timing control

 Event can be change in value of a register or net  The @ symbol is used to specify an event control  Statements can be executed at a positive or negative

transition of a signal value

@ ( clock ) q = d; @ ( posedge clock ) q = d; @ ( negedge clock ) q = d; q = @ ( posedge clock ) d;

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 35

slide-36
SLIDE 36

Level sensitive timing control

 The ability to wait for a certain condition to be true  The keyword wait is used for level sensitive constructs.

always wait (count_enable) #20 count = count + 1;

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 36

slide-37
SLIDE 37

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 37

slide-38
SLIDE 38

Combinatorial logic in Verilog

 Combinatorial logic vs Sequential logic  Blocking assignments which happen sequentially are used

for combinational logic

 Non- Blocking assignments which happen in parallel are

used for sequential logic

 Assign keyword for blocking statements

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 38

slide-39
SLIDE 39

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 39

slide-40
SLIDE 40

Race Conditions

 Verilog does not guarantee order of execution

initial a=0; initial b=a; initial begin #1; $display(“Value a=%a Value of b=%b”,a,b); end Possible values for a and b ..?

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 40

slide-41
SLIDE 41

Outline

 1. Motivation  2. Basic Syntax  3. Sequential and Parallel Blocks  4. Conditions and Loops in Verilog  5. Procedural Assignment  6. Timing controls  7. Combinatorial Logic in Verilog  8. Race conditions  9. Summary

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 41

slide-42
SLIDE 42

Summary

 Complex logic simulation  Easier to develop and debug circuits  Easy to code and learn ( constructs similar to

programming languages )

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 42

slide-43
SLIDE 43

So its now time for demo!

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 43

slide-44
SLIDE 44

Example – x=ax+y

module test(); initial begin $dumpfile("myfirsttask1.vcd"); $dumpvars(0,test); end reg [3:0] x; reg [3:0] a; reg [3:0] y;

initial begin x = 4'd1; a = 4'd1; y = 4'd2; $display( "x= ax+y"); $monitor("%g x = %b a = %b y = %b", $time, x, a, y); #5 $finish; end always #1 x = x*a +y; endmodule

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 44

slide-45
SLIDE 45

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 45

slide-46
SLIDE 46

Modules

module test; reg clk, reset; wire [3:0] q; ripple_carry_counter rcc(q, clk, reset); initial begin $dumpfile("dump.vcd"); $dumpvars(0, test); clk = 1'b0; reset = 1'b1; #20 reset = 1'b0; #200 reset = 1'b1; #30 reset = 1'b0; #30; $finish; end always #5 clk = ~clk; endmodule module tff(q, clk, reset);

  • utput reg q;

input clk, reset; always@ (posedge reset or posedge clk) begin if(reset)begin q<=1'b0; end else begin q<= ~q; end end endmodule module ripple_carry_counter(q, clk, reset);

  • utput[3:0] q;

input clk, reset; tff tff0(q[0], ~clk, reset); tff tff1(q[1], ~q[0], reset); tff tff2(q[2], ~q[1], reset); tff tff3(q[3], ~q[2], reset); endmodule

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 46

slide-47
SLIDE 47

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 47

slide-48
SLIDE 48

References

Verilog Hardware Descriptive Language 5th edition, Donald Thomas, Philip Moorby, 2002,Kluwer Academic.

Verilog HDL, A guide to digital design and synthesis, Samir Palnitkar, Sun Soft Press

Verilog HDL Synthesis ( A practical primer ), J Bhasker, Star galaxy publishing

Verilog Non Blocking assignment with Delays, Myths and Mysteries, Clifford E. Cummings, 2002, Sunburst Design Inc, 1-18, 44-47

Graphics source Wikipedia.org

http://www.edaplayground.com/

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 48

slide-49
SLIDE 49

Credits

 Deepjyoti Borah  Need for Verilog  Sequential and Parallel blocks  Conditions and Loops in Verilog  DEMO – Ripple carry counter 4 bit  Diwahar Jawahar  Behaviour modelling in Verilog  Event and delay based timing controls  Procedural assignment and Structured procedures  Combinatorial Logic in Verilog & DEMO

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 49

slide-50
SLIDE 50

Questions ?

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 50

slide-51
SLIDE 51

Thank you!

SEMINAR HPC : Deepjyoti Borah, Diwahar Jawahar 51
