Using DE S to Implement ATM Cell E ncryption on the APIC

David Ruppel

• Dr. Mansoor Alam

Department of Electrical Engineering and Computer Science The University of Toledo

Data E ncryption Standard (DE S) Data E ncryption Standard (DE S)

!Algorithm proposed by Federal Information Processing

Standards (FIPS) within National Bureau of Standards

!Approved by US Secretary of Commerce in 1977 !Reaffirmed in 1983, 1988, 1993 and 1999 !Available for non-government use !Is being replaced to Triple Data Encryption Algorithm

(TDEA) and Advanced Encryption Standard (AES)

Why Use DE S? Why Use DE S?

!TDEA uses 3 keys

!Encryption is:

!DES encrypt with key 1 !DES decrypt with key 2 !DES encrypt with key 3

!Decryption inverts the operations in reverse order

!Currently, the US government recommends either TDEA

• r AES for non-classified applications

!DES underlies TDEA and is thus a starting point

Main Points Main Points

!Recirculating 64-bit block product cipher !Uses a 64-bit key

!56 bits are random !8 bits used for odd parity

!Permutations and selection tables are static !Key is the only variable in the algorithm

E ncryption E ncryption

!64-bit data block is

permuted (IP)

Data 64 bits L block 32 bits R block 32 bits Permuted Data 64 bits P

!Resulting 64-bit block is

divided into two 32-bit subblocks (L and R)

E ncryption (cont) E ncryption (cont)

!56 random key bits are

partitioned into two subblocks

Key - 56 bits

!Subblocks are shifted and

permuted

!Subblocks are

concatenated and 48 bits are selected for the key

Key - 48 bits concatenate and shift Permuted and shifted C block Permuted and shifted D block permute and shift C block 28 bits D block 28 bits partition

E ncryption (cont) E ncryption (cont)

!A key and one data

subblock (R) are combined using a non- linear function (F)

Key Subblock R

!The function result is

XOR’d with the other data subblock (L)

New subblock R XOR

• utput from F

Subblock L F

E ncryption (cont) E ncryption (cont)

!The two subblocks are interchanged

!L’ = R !R’ = L XOR F(R,K)

!Process is repeated for a total of 16 iterations !The two subblocks are interchanged and

concatenated into a 64-bit block

!64-bit block is permuted (IP-1)

F unction (F ) F unction (F )

!32-bit data subblock is

expanded to 48 bits by repetition of selected bits

32- bit subblock R

!Two 48-bit subblocks are

XOR’d

48- bit key 48- bit subblock XOR 48- bit subblock repeat bits

F unction (F ) (cont) F unction (F ) (cont)

! Result is divided into eight 6-bit

sub-subblocks

48 bits

! Each sub-subblock is associated

with a different 4 x 16 static table

! 4-bit values ! 0 to 15 in each row

! The 6 bits in the sub-subblock are

used as look-up indices into a table (4 x 16) of 4-bit values

! 1st & 6th bits are row ! Remaining bits are column

! The results from the 8 tables are

concatenated into a 32-bit block

6 6 6 6 6 6 6 6 partition 4 4 4 4 4 4 4 4 Table lookup 32 bit result conatenate

F unction (F ) (cont) F unction (F ) (cont)

!Concatenation result is

permuted (P)

Previous 32 bit result Output of F P

Decryption Decryption

!Repeat the encryption process on the encrypted

data

!Use the encryption keys in reverse order !The usage of L and R are interchanged, i.e., L is

used as input to F rather than R

E ncrypting ATM Cells E ncrypting ATM Cells

!Encrypt entire 53-byte cell

! Hides the VC !Masks destination

!One cell generates 6-5/8 blocks of encrypted

data

!Eight input cells will be encrypted in nine output

cells

!12.5 % traffic load overhead

APIC/ SPC Processing APIC/ SPC Processing

!Assume VC is set up between two end-users !Assume two APICs are on the route !APICs establish a different VC between them !Original VC between APICs can be torn down or

left unused

!APIC captures traffic on original VC

!Encrypts !Forwards to the other APIC

APIC/ SPC Processing (cont) APIC/ SPC Processing (cont)

!Traffic arrives at second APIC

!Decrypts !Forwards to end-user recipient

!When done, VCs are torn down

Alternate Approach Alternate Approach

!Only encrypt payload !No traffic load overhead !No wasted VC
