- Use of Drilled MicroPile Walls in Scandinavia Hkan Bredenberg www.bredenbergteknik.se 1 Scandinavia ? www.bredenbergteknik.se 2 Drilled MicroPile Walls www.bredenbergteknik.se 3 i Index c s applications & examples

slide-1
SLIDE 1

www.bredenbergteknik.se 1

  • Use of Drilled MicroPile Walls in Scandinavia

Håkan Bredenberg

slide-2
SLIDE 2

www.bredenbergteknik.se 2

Scandinavia … ?

slide-3
SLIDE 3

www.bredenbergteknik.se 3

Drilled MicroPile Walls …

slide-4
SLIDE 4

www.bredenbergteknik.se 4

i c s

  • applications & examples
  • drilled MicroPile wall elements
  • supports
  • cover
  • costs
  • equipment
  • design

Index

slide-5
SLIDE 5

www.bredenbergteknik.se 5

Applications

  • excavation temporary cut off walls
  • same, also serving as permanent support
  • bridge support /foundation
slide-6
SLIDE 6

www.bredenbergteknik.se 6

Excavation cut off wall

slide-7
SLIDE 7

www.bredenbergteknik.se 7

Temporary wall & permanent support

slide-8
SLIDE 8

www.bredenbergteknik.se 8

Temporary wall & permanent bridge support

slide-9
SLIDE 9

www.bredenbergteknik.se 9

Drilled MicroPile Walls, usual Drilling metods

slide-10
SLIDE 10

www.bredenbergteknik.se 10

Drilled MicroPile Walls – the Klemm 806

slide-11
SLIDE 11

www.bredenbergteknik.se 11

Drilled MicroPile Walls - equipment

” The Basement Mouse”

slide-12
SLIDE 12

www.bredenbergteknik.se 12

Drilled (micro) Pile Walls – equipment, drilling rigs

slide-13
SLIDE 13

www.bredenbergteknik.se 13

Drilled MicroPile Walls – equipment for drilling

Pilot Ring drill crown ( left at bottom of casing) Casing Drill shoe (welded to casing)

slide-14
SLIDE 14

www.bredenbergteknik.se 14

Drilled MicroPile Walls – Equipment at tube front

Pilot (recovered) Ring crown – welded to tube, left at tip

slide-15
SLIDE 15

www.bredenbergteknik.se 15

Drilled pile walls – drill bit for 600 mm tubes

slide-16
SLIDE 16

www.bredenbergteknik.se 16

Excavation

  • How to keep soil in place between space between tubes ?
  • Which spacing between tubes ?
  • If ground water level above excavation bottom ?
  • Which material for cover ? Wood, steel, shotcrete ?
slide-17
SLIDE 17

www.bredenbergteknik.se 17

Jet grouting to prevent soil inflow

slide-18
SLIDE 18

www.bredenbergteknik.se 18

Drilled MicroPile Wall – extending into rock

slide-19
SLIDE 19

www.bredenbergteknik.se 19

Drilled MicroPile Wall during construction

slide-20
SLIDE 20

www.bredenbergteknik.se 20

Drilled MicroPile Wall in rock fill

slide-21
SLIDE 21

www.bredenbergteknik.se 21

Excavation before cover

slide-22
SLIDE 22

www.bredenbergteknik.se 22

5 mm steel sheet cover beeing spot welded to drilled soldier beams

slide-23
SLIDE 23

www.bredenbergteknik.se 23

5 mm steel cover plates beeing cut to size (from 2 x 1 m)

slide-24
SLIDE 24

www.bredenbergteknik.se 24

Drilled MicroPile Wall sealed with shotcrete

slide-25
SLIDE 25

www.bredenbergteknik.se 25

After excavation to final level … some case pictures from 2007.

slide-26
SLIDE 26

www.bredenbergteknik.se 26

Drilled & driven Pile Wall, finalized (?), rock anchors

slide-27
SLIDE 27

www.bredenbergteknik.se 27

Drilled MicroPile Wall, Limmared

slide-28
SLIDE 28

www.bredenbergteknik.se 28

Liljeholmen, drilled MicroPile wall for new subway station

slide-29
SLIDE 29

www.bredenbergteknik.se 29

Drilled MicroPile Wall at Ringhals nuclear power plant

slide-30
SLIDE 30

www.bredenbergteknik.se 30

MicroPile Wall was drilled into rock

slide-31
SLIDE 31

www.bredenbergteknik.se 31

Drilled MicroPile Wall for new theatre building, Norrköping, Sweden

slide-32
SLIDE 32

www.bredenbergteknik.se 32

Drilled MicroPile Wall – shotcreted – note boulders.

slide-33
SLIDE 33

www.bredenbergteknik.se 33

Drilled MicroPile Wall – under & close to existing building

slide-34
SLIDE 34

www.bredenbergteknik.se 34

Drilled MicroPile Wall finalized

slide-35
SLIDE 35

www.bredenbergteknik.se 35

Drilled MicroPile Wall used as formwork

slide-36
SLIDE 36

www.bredenbergteknik.se 36

Drilled MicroPiles for temporary column support

slide-37
SLIDE 37

www.bredenbergteknik.se 37

Drilled MicroPile Wall support

  • soil / rock anchors
  • beam struts
  • tie-backs
  • … others
slide-38
SLIDE 38

www.bredenbergteknik.se 38

Drilled MicroPile Wall – supported by drilled soil anchors

slide-39
SLIDE 39

www.bredenbergteknik.se 39

Corner supported by H-beams

slide-40
SLIDE 40

www.bredenbergteknik.se 40

Anchor rod fixed to slab

slide-41
SLIDE 41

www.bredenbergteknik.se 41

Design of drilled MicroPile walls

  • Soil pressure active/passive
  • Forces, bending moments
  • Section analysis :

– Axial capacity – Bending capacity – Buckling – Local buckling (thin wall structures)

  • Deflection, soil movements
slide-42
SLIDE 42

www.bredenbergteknik.se 42

Soil – tube interaction

slide-43
SLIDE 43

www.bredenbergteknik.se 43

Bending moment capacity

slide-44
SLIDE 44

www.bredenbergteknik.se 44

Drilled MicroPile Wall – bending capacity

slide-45
SLIDE 45

www.bredenbergteknik.se 45

Design details

slide-46
SLIDE 46

www.bredenbergteknik.se 46

Conclusions

  • Consider to use Drilled MicroPile walls when:

– Obstacles in soil prevents sheet piling – Small equipment required at site – Time schedule of critical importance – Temporary piles can be used for permanent use – If below ground water level, lowering is required – If soil flow use jet grouting/small excavation steps – Thats all for now …drill carefully out there !
