Building Johnson County Governments Largest Project Tomahawk Creek Wastewater Treatment Facility Why Wastewater Treatment 2 About JCW Located in northeast Kansas Established in 1945 Enterprise funded 220 employees 6

SLIDE 1

Building Johnson County Government’s Largest Project – Tomahawk Creek Wastewater Treatment Facility

SLIDE 2

Why Wastewater Treatment

SLIDE 3

About JCW

Located in northeast Kansas
Established in 1945
Enterprise funded
220 employees
6 WWTFs
32 pump stations
2,200 miles of sewer
500,000+ residents served
60 million gallons treated

each day

SLIDE 4

SLIDE 5

About Tomahawk Creek WWTF

Leawood. Mission Rd and Lee Blvd
Established in 1955
Trickling Filter Facility
1980s Linking Interceptor
7 mgd onsite/10 mgd to KCMO
150,000 – 190,000 residents

SLIDE 6

Blue River Basin

Kansas Missouri

SLIDE 7

Drivers for Upgrade

Age of equipment
New regulations for

water quality

Increasing operational costs

SLIDE 8

Planning Process

Previous Studies 2006 and 2013

– Evaluated 8 Alternatives – Evaluated 0 MGD, 10 MGD, and 19 MGD – Recommend 19 MGD Option

Project Definition Phase 2014-2015
Design and GMP Development 2017 – 2018
Construction 2018 - current

SLIDE 9

Missouri River Load Reductions Relative to Existing Condition Baseline

SLIDE 10

All flow Some Flow No Flow

Financial Evaluation of Options

SLIDE 11

Operating Cost Comparison

Reduced Costs: $453 Million

SLIDE 12

Goals for Long-Term Investment

Preserve high quality of life
Improve water quality
Provide the most cost-

effective long-term solutions for customers

SLIDE 13

Existing Tomahawk Creek WWTF

SLIDE 14

Preliminary Design Concept

Reuse Influent Pumping

Station and Digester Complex

IFAS BNR Basins & Blower

Building

Separate Sludge

Processing

Dual Purpose

Compressible Media Filters

Disinfection and

Reaeration Facilities

Concrete Lined Excess

Flow Holding Lagoon

SLIDE 15

Dual Purpose Compressible Media Filters

SLIDE 16

Tomahawk Creek Proposed Delivery Methods

SLIDE 17

Why CMAR for this Project

Collaboration between All

parties

Signiant Pre-design already

completed

High risk, complicated project
Earlier cost certainty
Optimize design

SLIDE 18

Tomahawk Creek Proposed CMAR Schedule

SLIDE 19

Value Engineering led to Design Evolution

SLIDE 20

Evolution of the Site

April 2017 July 2017

SLIDE 21

Facility Protection Without Flood Rise

SLIDE 22

Bedrock is at Different Elevations at Site

Rock Fill Only Piers Only Piers with Rock Fill

SLIDE 23

Power Limitations were Addressed

SLIDE 24

BIM / VR Tools were Utilized for Project

SLIDE 25

SLIDE 26

Bluebeam was Used to Review Documents

SLIDE 27

VE Analysis Continues during Construction

SLIDE 28

Construction Statistics

250,000 CY of Earth to Move
53,000 CY of Structural Concrete
3 Miles of Electrical Ductbank
110,000 LF of Pipe (Above & Below

Grade)

SLIDE 29

Plant Flow Diagram

SLIDE 30

Startup Process Overview

SLIDE 31

BNR Basin & Basin Blower Building

SLIDE 32

Filter Disinfection Complex

SLIDE 33

Solids Processing Building

SLIDE 34

Administration Building

SLIDE 35

Construction Challenges

2018 & 2019 - Wettest Water

Calendar Year in Kansas (57.88 inches)

Adjusting to COVID-19

Procedures

Tight Construction Footprint
Unforeseen Rubbish During

Excavations

SLIDE 36

Project Successes

MOPO: Collection System Diversion Evergy Substation Energized

SLIDE 37

Facility Startup

Coordination Meetings w/ Key

Personnel

Energization & LOTO Plan
System Startup Plans
Key Construction Milestones

SLIDE 38

SLIDE 39

Lessons Learned

Know your site and existing facilities
Exploratory digging
SCADA Screen Development

– Big project – a lot to take on at once

Engage CMAR early
Communication, Trust, Teamwork

SLIDE 40

For Updates: www.jcwtomahawk.com
