Johnson Noise: Determinations of k and Absolute Zero Edwin Ng | 12 - PowerPoint PPT Presentation

Johnson Noise: Determinations of k and Absolute Zero Edwin Ng | 12 December 2011 Nyquists Theory of Johnson Noise Johnson noise is thermal noise in circuits Nyquists Theory of Johnson Noise Johnson noise is thermal noise in circuits


  1. Johnson Noise: Determinations of k and Absolute Zero Edwin Ng | 12 December 2011

  2. Nyquist’s Theory of Johnson Noise  Johnson noise is thermal noise in circuits

  3. Nyquist’s Theory of Johnson Noise  Johnson noise is thermal noise in circuits  Two resistors R connected by a wire: I = V 2 / 2R

  4. Nyquist’s Theory of Johnson Noise  Johnson noise is thermal noise in circuits  Two resistors R connected by a wire: I = V 2 / 2R  By equipartition, each mode at frequency f has energy kT

  5. Theory of Johnson Noise (cont.)  For an RC circuit,

  6. Theory of Johnson Noise (cont.)  For an RC circuit,  Governing formula for Johnson-Nyquist noise:

  7. Johnson Noise Setup Adapted from MIT Department of Physics, “Johnson Noise and Shot Noise” (2011).

  8. Johnson Noise Setup

  9. Gain and Frequency Band Calibration  Will measure RMS voltage through band pass filter (from ~1kHz to ~50kHz)

  10. Gain and Frequency Band Calibration  Will measure RMS voltage through band pass filter (from ~1kHz to ~50kHz)  Define gain ratio g ( f ) = V out ( f )/ V in ( f )

  11. Gain and Frequency Band Calibration  Will measure RMS voltage through band pass filter (from ~1kHz to ~50kHz)  Define gain ratio g ( f ) = V out ( f )/ V in ( f )  Integrate the Johnson noise with G ( R , C ) integral

  12. Gain and Band Calibration (cont.)

  13. Measuring RMS Voltages

  14. Measuring RMS Voltages (cont.)

  15. Resistance Measurements  Measure RMS voltages of various resistors across ~1k Ω to ~1000 k Ω at T = (23.6 ± 0.2) °C

  16. Resistance Measurements  Measure RMS voltages of various resistors across ~1k Ω to ~1000 k Ω at T = (23.6 ± 0.2) °C  Governing equation:

  17. Resistance Measurements  Measure RMS voltages of various resistors across ~1k Ω to ~1000 k Ω at T = (23.6 ± 0.2) °C  Governing equation:  Need to determine C

  18. Determination of Capacitance

  19. Determination of k with Resistances

  20. Temperature Measurements  Measure RMS voltages of 500 k Ω resistors across temperature range -196°C to 150°C

  21. Temperature Measurements  Measure RMS voltages of 500 k Ω resistors across temperature range -196°C to 150°C  Governing equation:

  22. Temperature Measurements  Measure RMS voltages of 500 k Ω resistors across temperature range -196°C to 150°C  Governing equation:  T c measured in Celsius: T 0 is absolute zero

  23. k and T 0 with Temperature

  24. Conclusions  Best estimate on k  (1.361 ± 0.026 rand. ± 0.081 syst. ) x 10 -23 J/K  Correct value: 1.381 x 10 -23 J/K (≈ 1.5% error)  Determination of absolute zero  T 0 = (-274.3 ± 9.3) °C  Correct value: -273.15 ° C (≈ 2.0% error)  Verified existence and behavior of Johnson- Nyquist noise

  25. Question and Answer
