slide-1
SLIDE 1

Precision Monitoring Inc.

ISM Micropile Test

Instrumentation

slide-2
SLIDE 2

Precision Monitoring Inc.

ISM Micropile – Our Scope

1. Design two engineered fills – with 10 kPa and 20 kPa shear. (Thanks - Wing) 2. Set-up instrumentation to monitor – load, displacement and bending in real-time (Thanks to Ivan and Gabriel, Measurand). 3. Set-Up video and data feed between the two locations (Thanks to Lewko).

slide-3
SLIDE 3

Precision Monitoring Inc.1. Engineered Fills

  • Literature search and discussions plastic slurry wall and cement-

bentonite specialists.

  • Feedback and previous experience gave us a starting point plus

warnings about predictability and repeatability.

  • Starting point - grouts consisting of 6.5% bentonite slurries mixed

with percentages by weight of cement, ranging from 2% to 12%.

slide-4
SLIDE 4

Precision Monitoring Inc.

  • Shear testing -

ASTM standard test method for laboratory miniature vane shear test (ASTM D 4648-05).

  • Initial results lower

than expected.

  • 1. Engineered Fills
slide-5
SLIDE 5

Precision Monitoring Inc.

  • Additional mixes of 14%, 16%, 18% and 20% cement

mixes were batched to extend the data set to greater shear strengths.

  • Two distinct curves from each data set?
  • A smaller mixer and half batches for the first set of tests

and larger mixer and full batches for the second set of tests.

  • 1. Engineered Fills
slide-6
SLIDE 6

Precision Monitoring Inc.

Grout Shear Strength

10 20 30 40 50 60 70 80 90 0% 2% 4% 6% 8% 10% 12% 14% 16% 18% 20% 2 Cement % Shear Strength (kPa) 7 Day Tests 2%-12% 15 Day Tests 2%-12% 7 Day Averages 15 Day Averages 7 Day Tests 14%-20% Extrapolated from first set of tests 14 day shear strengths. Extrapolated from second set of tests 7 day shear strengths.

slide-7
SLIDE 7

Precision Monitoring Inc.

  • 2. Real-Time

Instrumentation:

  • Cap displacement in relation to

the applied load

  • Displacement vs. load in plotted
  • n screen in real-time
  • Bending or buckling of the bar.
  • Movement of the reaction piles.
  • Archive data
slide-8
SLIDE 8

Precision Monitoring Inc.

The Set up

Micropile Reaction Beam Jack Tiedown 1) Monitor the displacement of the cap 2) Measure the pressure applied by the jack 3) Observe any bending or buckling

  • f the micropile

4) As a safety precaution, see the pullout motion

  • n reaction piles
slide-9
SLIDE 9

Precision Monitoring Inc.

LVDT’s

  • Linear Variable differential Transformer
  • - Instruments similar in function to electronic dial gauges.

– Accurate and precise as dial gauges and infinity resolution. – More suitable for rugged site conditions, and unlike dial gauges, interface easily with computers.

=

slide-10
SLIDE 10

Precision Monitoring Inc.

Pressure Transducer

– This sensor transforms pressure into an analogue electrical signal. – Easily connected to a datalogger or a computer.

slide-11
SLIDE 11

Precision Monitoring Inc.

Measurand ShapeAccelArray

  • Measurand ShapeAccelArray

– A series of sensor (accelerometers) linked together (MEMS Technology). – It produces a 3D representation of the borehole, bar, etc. – Better resolution that a series of in-place inclinometers.

slide-12
SLIDE 12

Precision Monitoring Inc.

slide-13
SLIDE 13

Precision Monitoring Inc.

slide-14
SLIDE 14

Precision Monitoring Inc.

The method used:

  • To see the vertical movement of the cap, four

LVDT’s were placed on the cap.

  • The pressure transducer was attached to the

hydraulic jack.

  • Each tie-down also had a LVDT for any possible

pull-out during the test.

  • A ShapeAccelArray was inserted inside the

micropile to see any bending during the compression.

slide-15
SLIDE 15

Precision Monitoring Inc.

  • All LVDT’s and the pressure transducer

were connected to a datalogger that collected readings every second.

  • A graph showing the Displacement vs.

Load was produced in real time.

  • Using Measurand SAArecorder software,

the bending of the bar was monitored as the bar was loaded.

slide-16
SLIDE 16

Precision Monitoring Inc.

slide-17
SLIDE 17

Precision Monitoring Inc.

slide-18
SLIDE 18

Precision Monitoring Inc.

ShapeAccelArray Screen shot Hewlett Packard Displacement vs. Load graph

slide-19
SLIDE 19

Precision Monitoring Inc.

?

Lessons Learned

  • SAA – installation details
  • 1. annulus webbing or no webbing
  • 2. supported on bottom / hung from top

2 to 4 mm

slide-20
SLIDE 20

Precision Monitoring Inc.

Conclusions

  • Engineered fill shear values lower than design targets:

15 kPa and 2 to 3 kPa

  • The LVDT’s, pressure transducers, datalogger and related software

worked as expected.

  • ShapeAccelArray and Measurand’s software worked well. We

gained experience regarding installation details and using the instrument as a real-time monitoring instrument.

  • All the instrumentation performed as it was designed to: providing

accurate measurements and allowing further analysis after the test.

  • Video and Data Feed – See it later today.
