US 51 Stoughton Roundabout Hoel/Silverado, STH 138, and Roby Road - PowerPoint PPT Presentation

Feb 20, 2024 •368 likes •574 views

US 51 Stoughton Roundabout Hoel/Silverado, STH 138, and Roby Road Alex Hagen, P.E. WisDOT Project Manager Public Information Meeting #2 March 12, 2020 Presentation Outline Project area Project purpose and need Proposed staging

  1. US 51 Stoughton Roundabout Hoel/Silverado, STH 138, and Roby Road Alex Hagen, P.E. WisDOT Project Manager Public Information Meeting #2 March 12, 2020

  2. Presentation Outline • Project area • Project purpose and need • Proposed staging • Project schedule • Comments and questions

  3. Project Area

  4. Project Purpose and Need • Project Purpose ▪ The purpose of the Hoel Avenue/Silverado Drive, STH 138, and Roby Road intersection improvements along US 51 is to provide a safe and efficient transportation system to serve present and long- term travel demand while minimizing disturbance to the environment. • Project Needs ▪ Improve intersection safety (Roby Road has received HSIP funding) ▪ Accommodate projected traffic volumes ▪ Improve bicycle and pedestrian accommodations

  5. Alternatives – STH 138 & Hoel/Silverado

  6. Alternatives – Roby Road

  7. Proposed Staging • Projects will be constructed together. • Jackson Street signal between the two project areas will maintain normal operation during construction. • We will review the staging concepts of each construction area.

  8. Proposed Staging – STH 138 and Hoel/Silverado Stage 1

  9. Proposed Staging – STH 138 and Hoel/Silverado Stage 2

  10. Proposed Staging – STH 138 and Hoel/Silverado Stage 2B

  11. Proposed Staging – STH 138 and Hoel/Silverado Stage 2C

  12. Proposed Staging – STH 138 and Hoel/Silverado Stage 3

  13. Proposed Staging – STH 138 and Hoel/Silverado Stage 4

  14. Proposed Staging – Roby Road Stage 1

  15. Proposed Staging – Roby Road Stage 2

  16. Proposed Staging – Roby Road Stage 3A

  17. Proposed Staging – Roby Road Stage 3B

  18. Proposed Staging – Roby Road Stage 4

  19. Project Schedule • Spring 2022 – Begin Construction ▪ Plans will be ready for 2021 construction if funding becomes available.

  20. Comments and Questions • Questions?
