Upper Mississippi River Bacteria TMDL Project Minnesota Pollution Control Agency Barb Peichel TMDL Project Manager, MPCA UMR Bacteria TMDL Meeting, 6/12/09 Upper Mississippi River Bacteria TMDL Project Overall Goal Minnesota Pollution

SLIDE 1

Minnesota Pollution Control Agency

Upper Mississippi River Bacteria TMDL Project

Barb Peichel TMDL Project Manager, MPCA UMR Bacteria TMDL Meeting, 6/12/09

SLIDE 2

Minnesota Pollution Control Agency

Upper Mississippi River Bacteria TMDL Project

Overall Goal

Improve and restore the water quality of the Upper Mississippi River

Joint Effort

MPCA & MDH, Partners, EOR (Consultant) Beneficial use designation MDH Source Water Protection/MPCA TMDL

Draft Timeline

2008 - Project Start (Work Plan, Stakeholder Meetings) 2009-2011 - Additional monitoring/ID pollution sources 2012-2014 - Draft TMDL/Implementation Plan

SLIDE 3

Minnesota Pollution Control Agency

TMDL Scope

07010206-568 07010203-510 07010203-574 07010206-509 07010206-505 07010206-503

SLIDE 4

Minnesota Pollution Control Agency

08-10 09-10 08-11 09-15 2009? 2013? 8

SLIDE 5

Minnesota Pollution Control Agency

Upper Mississippi River Bacteria TMDL Project

Past Project Objectives: June 08 - Jan 09

TMDL Work Plan (MPCA/MDH) – 136 www.pca.state.mn.us/water/tmdl Task A. Form Stakeholder/Technical Committees - 126 2008 Stakeholder Mtgs – Mpls/St. Cloud Task C. Review/Analyze Existing Data Verify Listing Data New additions – Phil & EOR

SLIDE 6

Minnesota Pollution Control Agency

Upper Mississippi River Bacteria TMDL Project

Present Project Objectives Feb - Oct 2009

Task A. Form/Manage Project Committees Hold 2 Stakeholder Meetings* & Form Policy Committee* Task B1. ID Relationships between Bacteria Data and other Parameters Literature Review*/Expert Consultation (i.e. E. coli ~ sediment) Task B2. Review Safe Drinking Water/Clean Water Act policies & efforts Guidance Document - ID Statewide Program/Policy Gaps/Opportunities Task C. Review and Analyze Existing Data Summary Existing Data*/ID Gaps/Monitoring Plan* *Stakeholder/Technical Team Involvement

SLIDE 7

Minnesota Pollution Control Agency

Upper Mississippi River Bacteria TMDL Project -

Future Objectives & Involvement Opportunities

Future Project Objectives

Task C. Review and Analyze Existing Data Task D. Conduct Additional Monitoring and Gather Information Task E. Identify Pollutant Sources and Conduct Modeling Efforts Task F. Develop a Draft and a Final TMDL Report Task G. Produce an Implementation Plan

Future Project Opportunities for Stakeholders

Assist in filling data gaps and the identification of “Hot Spots” & Sources
Assist in conducting additional monitoring and data gathering
Participation in future Stakeholder Meetings (every 4-6 months)
Meetings would be held after the completion of a milestone task.

SLIDE 8

Minnesota Pollution Control Agency

Minnesota’s Impaired Waters

Upper Mississippi River Bacteria TMDL Project

Phil Votruba North Central Region Project Manager, MPCA Brainerd/Baxter

SLIDE 9

Minnesota Pollution Control Agency

Upper Mississippi River Basin

M ississ ip p i R iv er B as in - H ea d w a ters to S t. C ro ix R iver

10 20 30 40 50 M ile s

Ap prox im a te B a sin Are a: 2 0,1 00 s q. m ile s

# Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y # Y Ano k a Fo ley Aitk in C has k a M ilac a W ad ena W alk e r Bem idji Buffalo Gle nc oe W illm ar Bra ine rd H as ting s

St. P au l

C am br idg e Elk R iv er

St. C lo ud

Ale x and ria Litc hfie ld M inn eap oli s Par k R a pid s Gra nd R a pid s Little F all s Lon g Pra irie Ca ss Itasc a Aitkin Cr ow W in g Hu bba r d B eltr am i Mille Lac s Mor r ison S tea r ns Ben ton S he rb ur ne Isan ti Ra ms e y He nne pin W righ t M ee k er M cL eod Re nville Kan diy oh i B eck e r O tte r Ta il W ade na To dd W ashin gto n Da k ota Ca rve r Douglas Pine

M ill e La cs L Sau k R Le ech L R u m R B ig San d y L W h itefish L Lo n g Pra irie R Gu ll L Crow Wing R R e d e y e R M iss iss ip pi R Pin e R Po keg a m a L L eech L R L W in n ib ig o sh is h C ass L L Ita sca C ro w R , S F k Crow R, N Fk

Clearwater Ca rlto n

St. Louis

Pope Sibley A no k a

W ater s hed Mis s is sip pi R ive r (H ea dw a ters ) Lee ch L ak e R ive r Mis s is sip pi R ive r (G ra nd R apid s) Mis s is sip pi R ive r (B r aine rd ) Pin e R iv e r C r ow W ing R ive r R ed ey e R iv er (L eaf R iv e r) Lon g P rair ie R ive r Mis s is sip pi R ive r (S a rtell) Sa uk Riv er Mis s is sip pi R ive r (S t. C lou d) C r ow R iv er, No rth F o rk C r ow R iv er, S outh F o rk Mis s is sip pi R ive r (T w in C itie s) R um R iv er C ou nty B ou nda ry Ma jor R iv er o r La ke

# Y

C ou nty S ea t

SLIDE 10

Minnesota Pollution Control Agency

Completed Bacteria TMDLs (6/09)

Final TMDLs

Blue Earth River Carver-Bevens-Silver Creeks Chippewa River Lower Mississippi River Basin Pipestone Creek Pomme de Terre Rock River Sunrise River (North Branch) Yellow Medicine (South Branch) High Island Cr. And Rush River (11/08)

W. Fork Des Moines R. Watershed (12/08)
TMDL Bacteria Protocol & Fact Sheet
Guidance Manual - Assessing MN Surface Waters

SLIDE 11

Minnesota Pollution Control Agency

Beneficial Uses

SLIDE 12

Minnesota Pollution Control Agency

Use Class Beneficial Use Class 1 Drinking Water Class 2 2A 2Bd 2B 2C 2D Aquatic life and recreation Cold water fisheries, trout waters Cool and warm water fisheries, drinking water Cool and warm water fisheries Indigenous fish and associated aquatic community Wetlands Class 3 Industrial uses and cooling Class 4A Agriculture and wildlife uses Class 5 Aesthetics and navigation Class 6 Other uses Class 7 Limited resource value waters

Beneficial Use Classifications

SLIDE 13

Minnesota Pollution Control Agency

Water Quality Standards

Aquatic Recreation (1o and 2o body contact)

Bacteria Standard Units Notes Assessment

E. coli

126 orgs per 100 ml Indicator Geometric mean of > 5 samples/month (April – October)

SLIDE 14

Minnesota Pollution Control Agency

Best Management Practices: Bacteria Removal

Potential sources

Septic systems Livestock operations Stormwater (sources vary)

Potential solutions

Enforce compliance for failing septic systems Reduce feedlot/pasture runoff in priority areas (fencing, buffers) Filter stormwater (rain gardens, infiltration basins), reduce sediment (street sweeping)

SLIDE 15

Minnesota Pollution Control Agency

Best Management Practices: Bacteria Removal

Potential sources

Wildlife and pet populations Wastewater treatment facilities Manure spreading & storage

Potential solutions

Evaluate pet waste & wildlife feeding ordinances, create educational materials Identify illicit sewer connections Reduce bacteria from land application of manure (stream/ditch buffers, immediate incorporation, conservation tillage, lined structures)

SLIDE 16

Minnesota Pollution Control Agency

TMDL Process

Determine Sources Causing Impairment Analyze existing data Conduct additional monitoring Allocate Pollutant Loads Use models/other tools - ID stresses/develop loads Assign loads – permitted/non-permitted sources *Deliverable: TMDL Report Develop Implementation Strategies/Plan Identify leads & partners Create monitoring and evaluation plan *Deliverable: Implementation Plan

SLIDE 17

Minnesota Pollution Control Agency LA(s) + WLA(s) + Margin of Safety + Reserve Capacity = Total Maximum Daily Load

A TMDL Study must complete this pollution load allocation formula:

Where: LA = Load allocations from nonpoint sources “non-permitted sources” WLA = Waste load allocations from point sources “permitted sources” Margin of Safety = to account for potential scientific error “uncertainties” Reserve capacity = set aside for future development

Quantifying a TMDL Number

Sum of the allowable loads of a single pollutant from all contributing permitted and non-permitted sources

SLIDE 18

Minnesota Pollution Control Agency

What do TMDL Projects mean for Stakeholders?

Increased funding

pportunities for

implementation activities & improved WQ Increased understanding

f links between water

quality monitoring data and potential pollutant sources Better partnerships

SLIDE 19
