Update on SET Reliability Project

18 Jun 2014

Keith Avery

Program Manager Space Electronics Technology Space Vehicles Directorate Air Force Research Laboratory

DISTRIBUTION STATEMENT A: Distribution A. Approved for public release; distribution unlimited.

slide-2
SLIDE 2

Outline of Talk

  • Background
  • Our Focus
  • Fundamental Research

– N/PBTI Research – Potential Trust Application – Modeling NBTI

  • Applied Research

– Temperature Behavior of NBTI & HCI – JNT Demo/Eval

  • Future Plans
  • Summary

2 Distribution A, Approved for public release.

slide-3
SLIDE 3

Reliability Research Group

3

Rod Devine Think Strategically Lead, Experimenter Ken Kambour LEIDOS Modeling Ed Gonzales Think Strategically Process Engineer Duc Nguyen* COSMIAC Graduate UNM Camron Kouhestani COSMIAC Graduate UNM

* Started work at Sandia on 1 Jun 14

Distribution A, Approved for public release.

slide-4
SLIDE 4
  • As IC feature size decreases, average IC lifetime decreases

From: State of the Art Semiconductor Devices in Future Aerospace Systems

  • L. Condra, Boeing, J. Qin

and J.B. Bernstein, U of Maryland 2007 1995 2005 2015 0.1 1.0 10 100 1000 Year produced Mean Service life, yrs. Computers laptop/palm cell phones Airplanes/ Military/ Telecom

0.5 µm 0.25 µm 130 nm 65 nm 35 nm

Process Variability confidence bounds

Technology

2004 2008 2012

Note: between 1997 and 2008 the service lifetime decreased by 10 x Note – MTTFIC = (∑n

i=1 λi)-1

where λn = degradation rate for mechanism i and n is the number of mechanisms in the IC

Reliability of modern electronics less than satellite mission life

Reliability is maintained in RH devices in many ways including by reducing performance to well below that of related commercial devices—1995 Motorola PPC750 was 366 MHz, 2003 Rad 750 was 133 MHz (.26µ vs .25µ)

Distribution A, Approved for public release. 4/14

slide-5
SLIDE 5

Many (Especially in Government) are Increasingly Concerned About Reliability…

5

Government Microcircuit Applications and Critical Technologies Conference 2014 Conference Theme: Reliability, Remembering the Recipe NIST-Sponsored Workshop (2014): Resilient, Robust, Reliable Electronic Materials and Devices Beyond Silicon

As the end of silicon scaling approaches, new materials are being exploited…High-K (Hf based) gate dielectrics and metal gates are already in use…finally device-level quality has been obtained but their reliability issues are largely unexplored. In addition, the geometry of the basic planar device is being changed – FINFET’s, gate all around (nanowire)… Taking this all together, it means lifetime prediction of new devices is extremely difficult. … Generally, parts are qualified by accelerated testing. …accurate prediction of lifetime requires accurate models of the underlying physical mechanisms.

We’ve focused on NBTI mechanisms for advanced space electronics

Distribution A, Approved for public release.

slide-6
SLIDE 6

…but Industry is Not

6

Gonza´lez: Any idea on how we can measure reliability? Mukherjee: We fundamentally need a mechanism to measure these things. For hard errors, the problem may be tractable. For soft errors—induced by radiation—this is still a hard problem. For gradual errors, such as wear-out, we still don’t know how to measure the reliability of an individual

  • part. So, the answer is that, in many cases,

we don’t know how to measure reliability. But, the majority of consumers care little about the reliable operation of electronic devices, and their concerns are decreasing as these devices become more

  • disposable. In 2006, the average lifetime of

a business cell phone was nine months. The average lifetimes of a desktop and a laptop computer were about two years and one year, respectively……... Therefore, building devices whose hardware functions flawlessly for 20 years is simply unnecessary. Reliability: fallacy or reality? Gonzalez, A. (INTEL)(Univ. Polytech. de Catalunya, Barcelona, Spain); Mahlke, S.; Mukherjee, S.;(INTEL) Sendag, R.; Chiou, D.; Yi, J.J.(Freescale) Source: IEEE Micro, v 27, n 6, p 36-45, Nov.-Dec. 2007

Industry will not attempt to provide lifetimes required for space applications

Distribution A, Approved for public release.

slide-7
SLIDE 7

Outline of Talk

  • Background
  • Our Focus
  • Fundamental Research

– N/PBTI Research – Potential Trust Application – Modeling NBTI

  • Applied Research

– Temperature Behavior of NBTI & HCI – JNT Demo/Eval

  • Future Plans
  • Summary

7 Distribution A, Approved for public release.

slide-8
SLIDE 8

Our Focus

  • NBTI, HCI, & EM dominate failure mechanisms in sub-45nm ICs

– We focus on NBTI and HCI since HiREV has others working EM

  • Fundamental research

– Identify physics of failure responsible for N/PBTI – Model time-dependent behavior of N/PBTI in circuits – Investigate synergy of radiation and reliability mechanisms – Identify physics of failure responsible for HCI

  • Applied Research

– Explore new device types with improved intrinsic reliability

  • Currently, the Junctionless Nanowire Transistor (JNT)
  • Collaborate with colleagues

– Develop measurement protocols that accelerate reliability testing and yield accurate results – Collaboration with multiple research establishments: NRL, SEMATECH, HIREV, Ariel U, Sandia, CINT, DMEA, …

8 Distribution A, Approved for public release.

slide-9
SLIDE 9

Outline of Talk

  • Background
  • Our Focus
  • Fundamental Research

– N/PBTI PoF Research – Potential Trust Application – Modeling NBTI

  • Applied Research

– Temperature Behavior of NBTI & HCI – JNT Demo/Eval

  • Future Plans
  • Summary

9 Distribution A, Approved for public release.

slide-10
SLIDE 10

Fundamental Research

  • Expanded research into NBTI and PBTI in 130 nm and 90

nm devices with SiON gate dielectrics

  • Began NBTI research on 32 nm high-k gate dielectric

(HfO2/SiO2) PMOS devices

– Observed RC and FRC trapped charges with less IS – Establishing electric field and temperature dependencies

  • Evaluating comparative reliability of SiON and high-k gate

dielectric devices

  • Began initial investigation of methods to evaluate

complex circuit reliability based on individual device response

10 RC: Recoverable Charge FRC: Field Recoverable Charge IS: Interface State Distribution A, Approved for public release.

slide-11
SLIDE 11

Our Measurements Reveal the Multi-Defect Origin of NBTI

Previously Published

  • We have developed a unique

measurement protocol enabling extraction of the time dependence of degradation components based upon continuous & pulsed stressing

− This is essential for incorporation into long-term reliability models − Now know several defects types are responsible for NBTI

2000 4000 6000 8000 10000 12000

  • 0.16
  • 0.14
  • 0.12
  • 0.10
  • 0.08
  • 0.06
  • 0.04
  • 0.02

0.00

FRC IS RC

Threshold voltage shift, ∆Vth (V) Accumulated total time (seconds at 120o C)

Recoverable charge Field recoverable charge

Vgs = -3.25 V Vgs = 0 V Vgs = + 1.5 V then – 1V

Interface state buildup

IS

∑ ∑

= =

=

n i j

j i

1 m 1 MTTF 1 IC

,

1 MTTF

Interface : Si-H + h+  Si+ + H or 1/2H2 Insulator “bulk”: X1 + h+  X1

+

Insulator “bulk”: X2 + h+  X2

+  Y

  • Used protocol to measure lifetime

characteristics of various transistors

Findings: Contrary to widely held hypothesis, increasing number of transistors in an IC contributes more to reduced lifetime than change in transistor reliability

11 Distribution A, Approved for public release.

slide-12
SLIDE 12
  • 0.25
  • 0.2
  • 0.15
  • 0.1
  • 0.05

500 1000 1500 2000 2500 3000 3500 4000 4500

∆VTh (V) Time (s)

NBTI in HfO2

Our NBTI Measurements

12

Vgs = -3.25V Vgs = 0V Vgs = 1.5V Recoverable Charge IS FRC IS: Interface States FRC: Field Recoverable Charge

Distribution A, Approved for public release.

slide-13
SLIDE 13
  • 0.25
  • 0.2
  • 0.15
  • 0.1
  • 0.05

500 1000 1500 2000 2500 3000 3500 4000 4500

∆VTh (V) Time (s)

NBTI in HfO2 & SION

NBTI in HfO2 NBTI in SiON

Our NBTI Measurements

13

SiON: 90 nm HfO2: 35 nm

NBTI in HfO2 & SiON

HfO2 has greater RC HfO2 has greater FRC

Distribution A, Approved for public release.

slide-14
SLIDE 14

Potential Trust Applications

  • Can NBTI characteristics of a device be used in

fingerprinting an IC?

– NBTI characteristics are determined by a combination of the manufacturing process and the transistor design – We expect they are “impossible” to duplicate

14

  • 0.25
  • 0.2
  • 0.15
  • 0.1
  • 0.05

500 1000 1500 2000 2500 3000 3500 4000 4500

∆VTh (V) Time (s)

NBTI in HfO2 & SION

Distribution A, Approved for public release.

slide-15
SLIDE 15

Reliability Modeling

  • Have taken first steps in developing

lifetime modeling capability for complex circuits

  • Model based on simple

measurements to estimate device lifetime

– Use high-temp to accelerate ∆VTh – Use circuit simulation to measure the effect of permanent change in threshold voltage on a ring oscillator – When oscillator operation goes outside

  • f circuit spec, device has failed
  • Validation of model in process

10 10

1

10

2

10

3

10

4

10

5

10

6

10

7

10

8

5 10 15 20

Permanent Threshold Voltage Shift (mV) Time (seconds)

“Permanent” interface state term (IS) + field recoverable charge (FRC) Δf = 1.75% MTTF ~ 5 years

15 Distribution A, Approved for public release.

slide-16
SLIDE 16

Outline of Talk

  • Background
  • Our Focus
  • Fundamental Research

– N/PBTI PoF Research – Potential Trust Application – Modeling NBTI

  • Applied Research

– Temperature Behavior of NBTI & HCI – JNT Demo/Eval

  • Future Plans
  • Summary

16 Distribution A, Approved for public release.

slide-17
SLIDE 17

Distinct HCI & NBTI Mechanisms

  • Work by Dr. Joe Bernstein of Ariel University
  • Data from Xilinx Spartan 6

– 45nm commercial device – 21 Stage ring oscillator

  • At -35C HCI dominates the degradation
  • At +140C NBTI dominates the degradation
  • Current lifetime estimates require single dominant

mechanism across the temperature range

17

Fundamentally challenges lifetime analysis methods

Distribution A, Approved for public release.

slide-18
SLIDE 18

The JNT—How does it work?

18

Gate oxide Drain Gate Source Heavily doped Silicon Nanowire

The work function difference between the heavily doped wire and the gate electrode creates a field which depletes the wire under the gate → conductivity = 0 Apply a compensating potential: field → 0 wire is uniform cond- uctor. Note: when there is a field there are no charges in the wire. when there are charges, there’s no field. In a MOSFET, NBTI degradation results from charge injection from the Si into the gate dielectric Several organizations are working on Junctionless Nanowire Transistors (JNTs) but their focus in optimizing design Structure is reminiscent of the FINFET but it’s just an illusion !

Hypothesis: JNT Eliminates NBTI, HCI, TDDB, … No Field, No Charge, No Reliability Issues

Distribution A, Approved for public release.

slide-19
SLIDE 19

Junctionless Nanowire Transistor

  • Concentrated on building Junctionless

Nanowire Transistors (JNTs)

– Developed 27 step process flow. – Performed e-beam lithography at Center for Integrated Nano Technologies (DOE)

19

Gate oxide Drain Gate Source Silicon Nanowire

Target Si thickness = 10 nm Target gate oxide = 3 nm Target channel length ≤ 1 µm

No Gate, 10nm wire Multiple Wires in Parallel for Current Reqirements

Distribution A, Approved for public release.

slide-20
SLIDE 20

Outline of Talk

  • Background
  • Our Focus
  • Fundamental Research

– N/PBTI PoF Research – Potential Trust Application – Modeling NBTI

  • Applied Research

– Temperature Behavior of NBTI & HCI – JNT Demo/Eval

  • Future Plans
  • Summary

20 Distribution A, Approved for public release.

slide-21
SLIDE 21

Near and Medium Term Plans

  • Basic research

– Continue evaluating single-device reliability as technology evolves

  • Is device-level reliability constant or does it degrade with

generation?

– Continue modeling how single-device reliability affects circuit response (in house) – Develop “black box” circuit reliability evaluation (contract) – Determine if radiation changes reliability

  • They have similar mechanisms
  • Applied Research

– Reproducibly build JNTs and evaluate rad & rel hardness

  • Build and evaluate small circuits such as NAND gates, etc
  • Determine feasibility of 3D JNT circuits

21 Distribution A, Approved for public release.

slide-22
SLIDE 22

Roadmap

22

FY13 FY14 FY15 FY16 FY17 FY18 NTBI/PTBI research in 130 & 90nm w/ SiON Initial lifetime model NTBI/PTBI research in 32nm w/ Hi-k oxide Develop JNTs at CINT Investigate rel/rad combined effects Develop IC-Level lifetime model

  • Incorp. Hi-k Data

End Data Acq Eval sub-32nm Hi-k Demo complex circuit forecast model Deliver reliability Eval JNT circuits

Distribution A, Approved for public release.

slide-23
SLIDE 23

Summary

  • AFRL Space Electronics Technology Program has

focused on a few aspects of reliability in deep- submicron ICs

– Basic mechanisms responsible for NBTI/PBTI – Combined effects of radiation and NBTI – Basic mechanisms responsible for HCI and combined effects – Black-box approach to forecasting IC lifetime – Evaluation of Junctionless Nanowire Tranistors

  • Expect immunity to radiation, NBTI, etc.

23 Distribution A, Approved for public release.

slide-24
SLIDE 24

24

Questions?

Distribution A, Approved for public release.

slide-25
SLIDE 25

25

Backup Charts

Distribution A, Approved for public release.

slide-26
SLIDE 26

Pubs Since 1 Oct 13

Published presentations at conferences (in Proceedings)

  • Electrochemical Society – San Francisco 2013

2 papers

  • Electrochemical Society – Orlando 2014

1 paper

  • International Integrated Reliability

Workshop 2013 2 papers

  • MRQW December 2013 (invited)

1 pres’t Journal publication

  • Journal of the Vacuum Science &

Technology B 1 paper Thesis

  • Master’s Thesis with distinction, Duc Nguyen, Dec 2013
  • Master’s Thesis with distinction, Camron Kouhestani,

May 2014

26 Distribution A, Approved for public release.

slide-27
SLIDE 27

Reliability Project Milestones

27

Topic Timeline Action 130 nm/90 nm Q2 FY 14 End data acquisition cycle Initial lifetime model Q2 FY 14 transfer 130/90 nm data Q2 FY 15 transfer prelim. High k data Q4 FY 15 transfer advanced high k data High k Q4 FY 14 Data transfer to initial lifetime model Q2 FY 15 Measurements on devices < 32 nm channel Q4 FY 15 Data transfer to initial lifetime model JNT Q2 FY 14 1st P type JNT prototype Q4 FY 14 Device characterization complete Q2 FY 15 1st N type JNT prototype Q4 FY 15 Device characterization complete Q2 FY 16 Simple circuit (inverter) Q2 FY 17 Complex circuit (multistage ring oscillator) Rad/Rel effects Q4 FY 14 Experimental set-up determined Q2 FY15 Test first short channel devices Q4 FY 15 Test first JNTl devices Q2 FY 16 Test new FETs IC level modeling Q2 FY 14 First data on complex circuit Q4 FY 14 Confront complex circuit results with results of single device analysis Q4 FY15 Confront complex circuit results with results of single device analysis using rad hard technology Q4 FY 16 Develop accurate long term reliability prediction protocol

Distribution A, Approved for public release.

slide-28
SLIDE 28

FY14 Fundamental Research Accomplishments

Comparison of SiON/HfO2 data

28

500 1000 1500 2000 2500 3000 3500 4000

  • 0.20
  • 0.15
  • 0.10
  • 0.05

0.00

high-κ (-2.0 V_0 V) high-κ (+1.0 V_0 V) SiON (-3.25 V_0 V) SiON (+1.5 V_0 V) Threshold Voltage Shift (V) Accumulated Total Time (seconds)

RC FRC IS

RC: Recoverable Charge FRC: Field Recoverable Charge IS: Interface State

Are these differences significant relative to the device-to-device differences of a single type?

Distribution A, Approved for public release.

slide-29
SLIDE 29

FY14 Fundamental Research Accomplishments

Potential Trust Application

  • Hypothesis: NBTI characteristics of a device can be used to

fingerprint ICs

  • The characteristics are determined by a combination of the

manufacturing process and the transistor design—it is likely they are impossible to duplicate in another foundry

29 500 1000 1500 2000 2500 3000 3500 4000

  • 0.20
  • 0.15
  • 0.10
  • 0.05

0.00

high-κ (-2.0 V_0 V) high-κ (+1.0 V_0 V) SiON (-3.25 V_0 V) SiON (+1.5 V_0 V) Threshold Voltage Shift (V) Accumulated Total Time (seconds)

Distribution A, Approved for public release.
