Tyco Product Range American Dynamics Overview

The AD Philosophy

• To provide an “end to end solution”
• Choice of IP, Analogue or a mixture
• To provide upgrade paths
• Future proof the end user
• Get best value from existing AD equipment

Product Range – Cameras

• Analogue Fixed

– Discover Series

• Choice of MiniDome or Bullit
• Resolutions from 380 TVL to 520 TVL
• Very cost effective
• IR illumination on many models for optimal

viewing in low-light and no-light environments

• Including vari-focal or fixed lens
• 1/3” format CCD

Product Range – Cameras

• IP Fixed

– Discover and Illustra 400 Series

• Power over Ethernet
• Day / Night options with LEDs
• D1 and 2/3rds MP (Illustra 400)
• Dual stream support on Illustra cameras

– Record and view live at different rates

Product Range – Cameras

• PTZ Dome

– Proven heritage! – Analogue – IP Power over Ethernet – 22x Optical Zoom – 35x Optical Zoom

• True Day / Night
• Wide Dynamic Range
• Image Stabilisation

Illustra Connect - Discovery & Config Tool

• Making life easier!

– Save time and money on installations

• ADTVR

– H.264 compression – 30ips/CIF, 15ips/2CIF, 8ips/4CIF per channel – 4, 8 and 16 video and audio channels – Control via front panel, USB mouse, Wireless remote or Client application – Supports multiple PTZ protocols – Powerful remote client and browser application – Continuous, Event, Continuous/Event recording modes

Product Range – Value DVR

ADTVR - Flexible Access

• Access your cameras:

– Via Local User Interface – Via Web Client – Via Remote Client – Via Mobile Client

 Local and remote clients let you manage your system... ... even if you’re not there ... even outside working hours

ADTVR - Advanced Features

• Independent video encoding parameters for each

channel

• Mapping on the Client application

– Enhancing value and functionality

• ADTVR is easy to setup & maintain

– Setup wizard – Flexible management

• Locally at the ADTVR
• From the Remote Client
• From a web client

Product Range – DVR

• Intellex

– 4, 8 16 Channels – Tyco pedigree – over 14 years of manufacturing, research & development – Over 500,000 sales – Integration with Kantech & C·CURE – Tyco compression method (ACC)

Product Range – DVR

• Intellex

– Version 5 now available

• Windows 7 platform
• Network Client Password Protection to

Intellex

– Added security for client connection

• Intellex Double Password Protection

– Two passwords/PIN’s need to be accessed to enable certain functionality on Intellex

Product Range – HDVR

• Hybrid HDVR

– 16 or 32 Analogue Channels – Up to 64 IP Channels – Includes H.264 Compression – RAID 5

– Integration with Kantech & C·CURE access control

Product Range – HDVR

• Bridging the gap

– Keep existing analogue cameras (inc PTZ domes)

• Why throw away what works?

– Add IP / megapixel cameras when needed – Migrate at your pace

CCTV Network Business Network

• HDVR Console is actually a client

– Monitor other HDVRs from your HDVR – Use the same interface locally and remotely

• Easy to use therefore minimal training needed
• Access your HDVR remotely, with live PTZ

control

– Via an Internet browser – From your Mobile device

15

Product Range – HDVR

16

Product Range – HDVR

• Import and Display multiple maps, many

formats

Product Range – NVR

• VideoEdge NVR

– Up To 128 IP Cameras

• Tested!

– Up to 104TB of storage – Linux OS

• More secure and no updates!

– Failover and RAID 5 as standard

– Integration with C·CURE 9000 access control

Product Range – NVR

• VideoEdge NVR

– Dual Stream Support

• Live and recorded can be 2 separate

frame rates and resolutions

– Records MetaData

• For “true” VMD and SmartSearch

– IT “friendly” as the NVR only uses standard ports

Storage Network Business Network

Intellex DVR

VideoEdge NVR

Seamless integration of AD analogue and IP systems

A single operator interface for Intellex, VideoEdge and future technologies

Product Range – victor Client

• Why use the victor client?

– No equipment made “obsolete” – One client for all systems

• Minimal re-training
• Lower cost of ownership

– A single manufacturer

• Backwards compatibility
• Single point of support
• Interoperability
• Future proofing

Product Range – victor Client

• Search, Smart Search & Instant Playback

– Time based search – Meta-data driven motion smart search

• Easy transition from search results to investigation
• Search performed on the recording unit

– Quick and bandwidth efficient

– Streaming Instant Playback

• V4.0 NVRs and Intellex 4.2+
• Time sync playback multiple cameras
• Frame by frame or fast video viewing
• Mix live and recorded cameras in same layout
• 30 sec, 1, 5,10,30, 60 min jump

Product Range – victor Client

Product Range – victor Client

• Live and recorded video

management

• Virtual matrix functionality

– Inc. salvos and keyboard use

• Full audit trail
• HDVR integration (Jan 12)

Analogue CCTV IP CCTV

• Single operator experience (GUI)

Intruder Access

Future-proofing

• Analogue cameras

– Discover Domes

• IP cameras

– Fixed

• Discover and Illustra
• PTZ Domes

– SpeedDomes

• Analogue and IP

Summary

• ADTVR

– Value analogue recorder

• Intellex

– 14 years of history, version 5 launched

• HDVR

– Bridging the gap of analogue and IP

• VideoEdge NVR

– Full NVR IP solution up to 128 cameras

• The victor client
• Interoperability, Integration and future-proofing

Summary

Thank you for your time Do you have any questions?
