Tutorials By Dr Sharon Truter To the Tutorials By Dr Sharon Truter - - PowerPoint PPT Presentation

Tutorials

By Dr Sharon Truter

To the Tutorials

By Dr Sharon Truter

What to expect from the Tutorials

 What to expect from these tutorials

 Outlines, structure, guided reading, explanations,

mnemonics

 Begin with anatomy.  Final tutorial: Articles and aspects important for

practicing as a neuropsychologist but not part of required learning for exam (court work & working with

• ther disciplines)

 Pathology covered with anatomy  Reading to be received after each tutorial

Additional Information

 What is SACNA?  What is NeuropsychologySA?  The SACNA exam

 Cost  Dates of exams  Associate membership  Contact Frances Hemp for more information:

franhemp@yebo.co.za

 Additional information

 Linked-In group  Study groups  Contact me regarding questions

Study Tips

 ±15 Hours a week of study.  Start with Kolb.  Anatomy of Lezak: Use as revision.  Laminate pg. 53 of Kolb book.  Make use of Latin and Greek references on website

Latin and Greek for Neuropsychologists: Part 1 Neuroanatomy Latin and Greek for Neuropsychologists: Part 2 Neuroanatomy

 Read: Sage advice from Successful SACNA

Examinees

 Summaries available: Didi at

creativepromotions@webmail.co.za.

The Skull, Meninges and Blood Supply

By Dr Sharon Truter

By Dr Sharon Truter

Skull

Falx

Cribriform Plate

Pathology: Base of Skull/Basilar Fracture

 Typically involving the temporal bone, occipital

bone, sphenoid bone, and/or ethmoid bone.

 Also anterior bones.  Such fractures can cause tears in the meninges, with

resultant leakage of the cerebrospinal fluid (CSF).

 CSF may dribble out through a perforated eardrum

(CSF otorrhea), into the nasopharynx (causing a salty taste), or drip from the nose (CSF rhinorrhea)

 Battles Sign  Bilateral Raccoon eyes

Base of Skull Fracture

Battle’s sign (William Henry Battle) Bilateral raccoon eyes

CT Scan of Basilar Skull Fracture

By Dr Sharon Truter

Meninges

Meninges

Pathology: Meningitis

 Inflammation of meninges (-itis = inflammation)  Caused by viruses, bacteria or other micro organisms.  Common symptoms:

 Headache  Neck stiffness  Fever  Confusion or altered consciousness,  Vomiting  Photophobia and phonophobia

 A lumbar puncture diagnoses.  Meningitis can lead to serious long-term consequences such

as: deafness, epilepsy, hydrocephalus and cognitive deficits

Pathology: Epidural and Subdural Haematoma

Pathology: Subarachnoid haemorrhage

 Scalp Haematoma

Scalp Haemtoma

 Occur on the outside of the skull between the bone and

the skin of the scalp.

 There are numerous layers to the scalp and the

hematoma may be located in any of those layers.

 While a scalp hematoma cannot press on the brain and

cause symptoms, it is a signal that a head injury has

• ccurred and there may also be underlying brain injury.

This is especially true for neonates and infants.

By Dr Sharon Truter

Arteries and Veins

Arteries Veins

Cerebral Arteries

Anterior Cerebral Artery Middle Cerebral Artery Posterior Cerebral Artery

Blood Flow

ACA = Anterior cerebral artery MCA = Middle Cerebral Artery PCA = Posterior Cerebral Artery

Circle of Willis

 Made up of:

 Anterior cerebral artery (left and right).  Anterior communicating artery.  Internal carotid artery (left and right).  Posterior cerebral artery (left and right).  Posterior communicating artery (left and

right).

Circle of Willis

 The basilar artery and middle cerebral

arteries, supplying the brain, are not considered part of the circle.

 If one part of the circle becomes

blocked or narrowed (stenosed) or one

• f the arteries supplying the circle is

blocked or narrowed, blood flow from the other blood vessels can often preserve the cerebral perfusion well enough to avoid the symptoms

• f ischemia.

Pathology of the Arteries and Veins

 Cerebral ischemia (stroke).

 Thrombosis: blood clot in vessel.  Embolism: blood clot from larger vessel forced into a

smaller one.

 Reduction in blood flow: cerebral arteriosclerosis.  Transient ischemia.

 Cerebral haemorrhage (bleeding).  Angioma: Congenital collections of abnormal vessels that

divert normal blood flow.

 Aneurisms: Vascular dilations from localised defects in the

elasticity of the vessels.

Pathology: Stroke

A sudden appearance of neurological symptoms as a result of severe interruption of blood flow.

Pathology: Aneurism

Angiography

A substance that absorbs X-rays is injected into the blood stream.

Angiogram showing aneurism

Pathology: Headaches

 Headaches

 Pain caused by pressure, displacement or inflammation.  Pain sensitive structures: dura mater, large arteries of the brain,

branches of some of the cranial nerves (5th, 9th & 10th).

 Migraine (Greek: hemi = half; kranion = skull)

 Aura: constriction of one or more cerebral arteries has produced

ischemia of the occipital cortex.

 Actual headache: begins as the vasoconstriction reverses and

vasodilation takes place.

 Types:

 Classic.  Common.  Cluster headache.  Hemiplegic migraine (loss of movement of limbs).  Opthalmologic migraine (loss of movement of eyes).

Reading for Tutorial 1:

 Kolb & Wishaw (Kolb) Chapter 1 (The Development of Neuropsychology) & Chapter

2 (Origins of the Human Brain and Behaviour).

 Kolb Chapter 3 (Organisation of the Nervous System) & Chapter 10 (Principles of

Neocortical Function). Review Kolb pg. 57- 59, Review Kolb pg. 76 - 78 (Cellular Organisation of the Cortex), Kolb pg. 253 - 273 (The Structure of the Cortex), Kolb Chapter 4 (The Structure and Electrical Activity of Neurons) & Kolb Chapter 5 (Communication between Neurons).

 Kolb pg. 55 (Support and protection) & Kolb pg. 764 (Meningitis).  Review Kolb pg. 56 - 57 (Blood Supply), Kolb pg. 147 (Angiography), Kolb pg. 51

(Stroke), Kolb pg. 749 - 751 (Vascular Disorders), Lezak pg. 229 - 242 (Cerebrovascular Disorders) & Kolb pg. 760 - 762 (Headaches). Kolb pg. 759 - 760 (Tumours). Lezak pg. 333 - 338 (Brain Tumours). Kolb pg. 107 (Snapshot of MS). Lezak pg. 290 - 303 (Multiple Sclerosis).

Nothing worth having comes easy
