USDA Subsurface Banding Implement Soil Trencher Improvements Critical Design Review Corp 10 Fall 2010 Christina Locklear Alex Peterson Alex Scammell Patrick Smyth Matt Turberville Outline Mission Objective Architectural Design

slide-1
SLIDE 1

USDA Subsurface Banding Implement Soil Trencher Improvements

Critical Design Review Corp 10 – Fall 2010

Christina Locklear Alex Peterson Alex Scammell Patrick Smyth Matt Turberville

slide-2
SLIDE 2

Outline

  • Mission Objective
  • Architectural Design
  • Bill of Materials
  • Comprehensive Analysis
  • Questions
slide-3
SLIDE 3

“The Trencher”

Direction of travel

Way, Thomas et al. “Applicator System and Method for the Agricultural Distribution of Biodegradable and Non-Biodegradable Materials.” Patent 7,721,662 B2. 25 May 2010

slide-4
SLIDE 4

Mission Objective

  • Litter Application Component:

“To improve or redesign the walls of the poultry litter implement so that litter can be more effectively distributed to the soil, mitigating the clogging that currently occurs during normal operation”

  • Dirt Recovery Component

“To improve or replace the current press-wheel system used

  • n the implement for dirt recovery so that the extricated

soil is more effectively replaced over the deposited litter band”

slide-5
SLIDE 5

Architectural Design

  • Final Concept
slide-6
SLIDE 6

Architectural Design

  • Trencher Wall
slide-7
SLIDE 7

Architectural Design

  • Soil Recovery Device
slide-8
SLIDE 8

Bill of Materials

  • Trencher Wall
  • Parts

$ 38.40

  • Labor

$ 70.00

  • Soil Recovery Device
  • Parts

$ 54.06

  • Labor

$ 140.00 Grand Total $ 302.46

slide-9
SLIDE 9

Comprehensive Analysis

  • Trencher Wall Pressure Measurement
  • Trencher Wall ANSYS Analysis
  • Dirt Recovery Mechanism Analysis
slide-10
SLIDE 10

Trencher Wall Pressure Analysis

http://content.honeywell.com/sensing/sensotec/pdf_catalog08/008602-1-EN_Model_F.pdf

Trencher Wall

slide-11
SLIDE 11

Trencher Wall Pressure Analysis

  • 10
  • 5

5 10 15 20 25 30 35 40 45 752 753 754 755 756 757 758 759 760 761 762 763 764 765

Pressure (psi) Time (s) Oktibbeha Clay Soil, First Run

(PASS1.ASC. Data collected 11/5/2010)

P1_Front P2_2nd P3_3rd P4_Rear

1 2 3 4

slide-12
SLIDE 12

Trencher Wall ANSYS Analysis

Mesh

  • Brick 8Node45 Tetrahedral

Boundary Conditions

  • Structural Displacement
  • Pressure on Bent Area

Pressure

  • 15 and 30 psi
slide-13
SLIDE 13

Trencher Wall ANSYS Analysis

Results

  • 15 psi → 0.091 in deflection
  • 30 psi → 0.202 in deflection
slide-14
SLIDE 14

Preliminary Analysis

  • Dirt Recovery Mechanism FBD Analysis

TRENCHER WALL Component F21 FG FF FW R  Fx = max  Fy = 0  MCB = 0 Use MATLAB to solve force equations and find shear stress on pivots FB FT2

1 2

F12

slide-15
SLIDE 15

Conclusions

  • Redesigned Trencher Walls

– Increase thickness to ¼ inch, flare outward at 10 degrees – As proven by ANSYS, deflection will not inhibit poultry litter flow

  • Soil Recovery Component

– Maximum shear in pivots is 14 lbs – Materials chosen are sufficiently strong for intended application

slide-16
SLIDE 16

Questions?
