De Devils Slide Coastal T vils Slide Coastal Trail Improvements Project ail Improvements Project County of San Mateo Project History Measure T Nov.1996 Plans and Permits Task Force meetings Hired a team Board support

slide-1
SLIDE 1

De Devil’s Slide Coastal T vil’s Slide Coastal Trail Improvements Project ail Improvements Project

County of San Mateo

slide-2
SLIDE 2

Devil’s Slide Coastal Trail Improvements Project

Project History

  • Measure T Nov.1996
  • Plans and Permits
  • Task Force meetings
  • Hired a team
  • Board support
  • Budget
slide-3
SLIDE 3

Devil’s Slide Coastal Trail Improvements Project

Project Overview

slide-4
SLIDE 4

Devil’s Slide Coastal Trail Improvements Project

Programming and Linkages

  • Park hours
  • Multi use trail
  • Pedestrians
  • Equestrian
  • Bicycle
  • Dogs on leash
  • Future trail linkages
  • Caltrans parking lot
slide-5
SLIDE 5

Devil’s Slide Coastal Trail Improvements Project

Public Comment Process

  • Received comments in the following

topic areas on 30% drawings

  • Programming and trail linkages
  • Paving surface durability and safety
  • Equestrian access
  • K-rail improvements
  • Trail safety
  • Bird protection fencing aesthetics
  • Today’s presentation of 90%

drawings will attempt to address these comments

slide-6
SLIDE 6

Devil’s Slide Coastal Trail Improvements Project

Next Steps

  • Transfer title to County

(August 2013)

  • Board of Supervisors approval

(October 1st)

  • Construction

(Winter 2013/ 2014)

  • Trail opening

(March 2014)

slide-7
SLIDE 7

Devil’s Slide Coastal Trail Improvements Project

Presentation Overview

  • Pavement, Striping,

Signage & K-rail, and Other Improvements

  • Environmental Review

& Overlooks

  • Maintenance, Schedule

& Next Steps

  • Questions

Roland Haga, P.E, LEED AP BKF Engineers Sarah Sutton, ASLA, LEED AP, The Planning Center | DC&E Gary Lockman County of San Mateo Project Team

slide-8
SLIDE 8

Devil’s Slide Coastal Trail Improvements Project

Overview of Trail Improvements

  • 1.3 Mile Trail
  • Paving and Striping
  • Signage/Interpretation
  • Accessibility
  • Accessibility
  • K-Rail Improvements
  • Overlooks
slide-9
SLIDE 9

Devil’s Slide Coastal Trail Improvements Project

Paving/ Striping

  • 6’ bike lanes each way
  • 10-12’ pedestrian/

equestrian

  • Repair and resurface

existing asphalt pavement (microsurfacing)

slide-10
SLIDE 10

Devil’s Slide Coastal Trail Improvements Project

Before K-Rail simulation

slide-11
SLIDE 11

Devil’s Slide Coastal Trail Improvements Project

slide-12
SLIDE 12

Devil’s Slide Coastal Trail Improvements Project

Microsurfacing

  • Prevents pavement

degradation- seals underlying surface from water and air intrusion

  • More skid resistant than

slurry (micro 0.8 vs. slurry 0.5 friction coefficient)

  • Longer lifespan than slurry

(5-7 years vs. 3-5 years)

  • Widely used throughout Bay

Area and California

slide-13
SLIDE 13

Devil’s Slide Coastal Trail Improvements Project

Paving and Striping

slide-14
SLIDE 14

Devil’s Slide Coastal Trail Improvements Project

User Safety

  • Signage
  • Speed limit paint on trail pavement

and posted on each end

  • Horse signs posted at each trailhead
  • K-rails and cable fencing

keeping people back from cliff edge

  • 2’ buffer between bike lane and

K-rail

  • Ambassadors- verbal warnings
slide-15
SLIDE 15

Devil’s Slide Coastal Trail Improvements Project

Signage

  • Remove existing

roadway signage

  • New regulatory

signage (minimize number, and location to protect views)

  • Interpretive panels
slide-16
SLIDE 16

Devil’s Slide Coastal Trail Improvements Project

Accessibility Improvements

  • Bathroom & drinking

fountains (north and south trailheads)

  • Interpretive panels
  • Overlooks
  • Observation scopes
  • ADA access

provided to

  • verlooks from

parking per County trail standards

slide-17
SLIDE 17

Devil’s Slide Coastal Trail Improvements Project

K-Rail Improvements

  • Moving K-rail for smooth

trail edge

  • Removing limited K-rail to

expose old rock wall

  • Power wash and paint tan
  • Clear debris and weeds

along K-rail

  • Future opportunities

artistic teaming/ fundraising

slide-18
SLIDE 18

Devil’s Slide Coastal Trail Improvements Project

Environmental Review

  • May 2002 EIS/EIR supplement

to 1986 certified by Caltrans

  • Sept. 2004 California Coastal

Commission upheld July 2004 approved CDP

  • Trail improvements are

consistent with CDP

  • Project will provide

memorandum including detailed analysis of biological resources

slide-19
SLIDE 19

Devil’s Slide Coastal Trail Improvements Project

Potential Wetlands

  • Four potential

Wetlands

  • Two require K-rail

relocation

  • Supervision of a

qualified wetland biologist

slide-20
SLIDE 20

Devil’s Slide Coastal Trail Improvements Project

Bird Nesting Protection

  • Trail is directly adjacent to

important bird nesting locations

  • Birds are acclimated to

vehicular traffic only

  • Views of pedestrians may

cause nests to be abandoned

  • Bird nest protection is

critical

philseu.blogspot.com/2011/

Bird species include: Peregrine Falcon, Murres, Brandt’s, Pelagic Cormorants, Western Gulls, Pigeon Guillemots, Brown Pelicans

slide-21
SLIDE 21

Devil’s Slide Coastal Trail Improvements Project

Bird Nesting Protection

  • 2011 Common

Murre Report recommends visual barrier

  • Nesting season

January- September

  • Year round

fencing option is preferred

Sensitive Nests/ Breeding Areas Visual Barrier

slide-22
SLIDE 22

Devil’s Slide Coastal Trail Improvements Project

Bird Nesting Protection

  • Movable blinds- view &

maintenance concerns, not required due to line of sight

  • 6’ Chain-link fencing-

aesthetic concerns

  • Clear fencing-

maintenance concerns

  • Cable fencing- climbing

concerns

  • Preferred Option- 4’ Tall

mesh with vegetation behind

sierrafencetx.com www.yaboofence.com www.crl-arch.com

slide-23
SLIDE 23

Devil’s Slide Coastal Trail Improvements Project

Bird Nesting

Similar fence example showing transparency

slide-24
SLIDE 24

Devil’s Slide Coastal Trail Improvements Project

Bird Nesting Protection

slide-25
SLIDE 25

Devil’s Slide Coastal Trail Improvements Project

Bird Nesting Protection

  • 4’ tall mesh fencing
  • Durable vandal proof

wire

  • Small mesh openings

and top spikes difficult to climb

  • See-through

transparent panels

  • Galvanized steel with

black powder coating finish 10 year warranty

4’ Omega Secur Fence

slide-26
SLIDE 26

Devil’s Slide Coastal Trail Improvements Project

Before photo

  • f trail
slide-27
SLIDE 27

Devil’s Slide Coastal Trail Improvements Project

After photo simulation of trail (BKF)

slide-28
SLIDE 28

Devil’s Slide Coastal Trail Improvements Project

Bunker

  • Historic value
  • Site protection

fencing

  • 6’ high mesh

fencing and gate

slide-29
SLIDE 29

Devil’s Slide Coastal Trail Improvements Project

Northern Overlook

slide-30
SLIDE 30

Devil’s Slide Coastal Trail Improvements Project

Northern Overlook

Plan view color

slide-31
SLIDE 31

Devil’s Slide Coastal Trail Improvements Project

Northern Overlook

Plan view color

  • Added 2 benches

and included in wall design

Similar approach

slide-32
SLIDE 32

Devil’s Slide Coastal Trail Improvements Project

Northern Overlook

  • Replaced chain-link

with relocated K-rail for aesthetics

slide-33
SLIDE 33

Devil’s Slide Coastal Trail Improvements Project

slide-34
SLIDE 34

Devil’s Slide Coastal Trail Improvements Project

Northern Overlook

slide-35
SLIDE 35

Devil’s Slide Coastal Trail Improvements Project

Northern Overlook

slide-36
SLIDE 36

Devil’s Slide Coastal Trail Improvements Project

Northern Overlook

slide-37
SLIDE 37

Devil’s Slide Coastal Trail Improvements Project

Material Palette

slide-38
SLIDE 38

Devil’s Slide Coastal Trail Improvements Project

Material Palette

slide-39
SLIDE 39

Devil’s Slide Coastal Trail Improvements Project

Interpretive Area

slide-40
SLIDE 40

Devil’s Slide Coastal Trail Improvements Project

Interpretive Area

slide-41
SLIDE 41

Devil’s Slide Coastal Trail Improvements Project

Interpretive Area

Plan color

slide-42
SLIDE 42

Devil’s Slide Coastal Trail Improvements Project

Interpretive Area

Plan color

  • Added 3 benches
  • Added 1 interpretive

sign

slide-43
SLIDE 43

Devil’s Slide Coastal Trail Improvements Project

Interpretive Area

Section color

slide-44
SLIDE 44

Devil’s Slide Coastal Trail Improvements Project

Interpretive Area

slide-45
SLIDE 45

Devil’s Slide Coastal Trail Improvements Project

Southern Overlook

slide-46
SLIDE 46

Devil’s Slide Coastal Trail Improvements Project

Southern Overlook

slide-47
SLIDE 47

Devil’s Slide Coastal Trail Improvements Project

Southern Overlook

Plan color

slide-48
SLIDE 48

Devil’s Slide Coastal Trail Improvements Project

Southern Overlook

Plan color

  • Moved observation scopes
  • Added 2 interpretive signs
slide-49
SLIDE 49

Devil’s Slide Coastal Trail Improvements Project

Southern Overlook

slide-50
SLIDE 50

Devil’s Slide Coastal Trail Improvements Project

Southern Overlook

slide-51
SLIDE 51

Devil’s Slide Coastal Trail Improvements Project

Future Maintenance

  • Bird monitoring
  • Wetland monitoring
  • Pampas grass removal
  • Rock removal
  • Rock slide repair

(funding and expectations)

slide-52
SLIDE 52

Devil’s Slide Coastal Trail Improvements Project

Questions/ Comments

  • Gary Lockman

County of San Mateo

  • Roland Haga, P.E, LEED AP

BKF Engineers

  • Sarah Sutton, ASLA, LEED AP,

The Planning Center | DC&E

slide-53
SLIDE 53

De Devil’s Slide Coastal T vil’s Slide Coastal Trail Improvements Project ail Improvements Project

County of San Mateo
