slide-1

SLIDE 1

1/8

Transducer-Based Rewriting Games for Active XML

Martin Schuster

TU Dortmund

Highlights 2016

slide-2

SLIDE 2

2/8

Active XML

slide-3

SLIDE 3

2/8

Active XML

City → Name, Meteo, Events Name → STRING Meteo → @meteo_svc Events → @event_svc event_svc: → (Sports|Concert)*@event_svc meteo_svc: → STRING

. . .

City Name Brussels Meteo @meteo_svc centigrade Events @event_svc Brussels

slide-4

SLIDE 4

2/8

Active XML

City → Name, Meteo, Events Name → STRING Meteo → @meteo_svc Events → @event_svc event_svc: → (Sports|Concert)*@event_svc meteo_svc: → STRING

. . .

City Name Brussels Meteo 24◦/sunny Events Sports football @event_svc Brussels

slide-5

SLIDE 5

3/8

The Schema Rewriting Problem

Server Client City → Name, Meteo, Events Events → @event_svc City → Name, Meteo, Events Events → (Sports|Concert)* event_svc: → (Sports|Concert)*

Server (CC-BY-SA 3.0) RRZE Icons, Client (LGPL) Everaldo Coelho

slide-6

SLIDE 6

3/8

The Schema Rewriting Problem

Server Client City → Name, Meteo, Events Events → @event_svc City → Name, Meteo, Events Events → (Sports|Concert)* event_svc: → (Sports|Concert)*

Server (CC-BY-SA 3.0) RRZE Icons, Client (LGPL) Everaldo Coelho

Goal: Rewrite source document into target schema using function calls

slide-7

SLIDE 7

3/8

The Schema Rewriting Problem

Server Client City → Name, Meteo, Events Events → @event_svc City → Name, Meteo, Events Events → (Sports|Concert)* event_svc: → (Sports|Concert)*

Server (CC-BY-SA 3.0) RRZE Icons, Client (LGPL) Everaldo Coelho

Goal: Rewrite source document into target schema using function calls Only schemas for remote services known in advance

slide-8

SLIDE 8

3/8

The Schema Rewriting Problem

Server Client City → Name, Meteo, Events Events → @event_svc City → Name, Meteo, Events Events → (Sports|Concert)* event_svc: → (Sports|Concert)*

Server (CC-BY-SA 3.0) RRZE Icons, Client (LGPL) Everaldo Coelho

Goal: Rewrite source document into target schema using function calls Only schemas for remote services known in advance find a safe rewriting strategy

slide-9

SLIDE 9

3/8

The Schema Rewriting Problem

Server Client City → Name, Meteo, Events Events → @event_svc City → Name, Meteo, Events Events → (Sports|Concert)* event_svc: → (Sports|Concert)*

Server (CC-BY-SA 3.0) RRZE Icons, Client (LGPL) Everaldo Coelho

Goal: Rewrite source document into target schema using function calls Only schemas for remote services known in advance find a safe rewriting strategy Context-free game on nested words

slide-10

SLIDE 10

4/8

Nested Words

slide-11

SLIDE 11

4/8

Nested Words

Idea: Correct nesting of tags over label alphabet Σ Example a/aabc/c/ba/a/a

slide-12

SLIDE 12

4/8

Nested Words

Idea: Correct nesting of tags over label alphabet Σ Linearisations of Σ-labelled forests Example a/aabc/c/ba/a/a a a b c a

slide-13

SLIDE 13

5/8

Context-Free Games on Nested Words: Example

slide-14

SLIDE 14

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement

slide-15

SLIDE 15

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

slide-16

SLIDE 16

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a}

slide-17

SLIDE 17

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} |f/ff/f

slide-18

SLIDE 18

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f|/ff/f

slide-19

SLIDE 19

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/f|f/f

slide-20

SLIDE 20

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f

slide-21

SLIDE 21

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f

slide-22

SLIDE 22

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓

slide-23

SLIDE 23

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/f|ag/g/a

slide-24

SLIDE 24

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fa|g/g/a

slide-25

SLIDE 25

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fag|/g/a

slide-26

SLIDE 26

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fag|/g/a

slide-27

SLIDE 27

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fag|/g/a ↓

slide-28

SLIDE 28

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fag|/g/a ↓ f/faa/a/a

slide-29

SLIDE 29

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fag|/g/a ↓ f/faa/a/a

slide-30

SLIDE 30

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f

slide-31

SLIDE 31

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓

slide-32

SLIDE 32

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fagg/g/g/a

slide-33

SLIDE 33

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fagg/g|/g/a

slide-34

SLIDE 34

5/8

Context-Free Games on Nested Words: Example

Intuition: JULIET picks function node to call, ROMEO chooses replacement JULIET wins once a target language string is reached

Example T = {f/fan/an | n ≥ 0}, f → {angm/gm/an | n, m ≥ 0}, g → {a/a} f/ff|/f ↓ f/fagg/g|/g/a ↓ ???

slide-35

SLIDE 35

6/8

Dealing with function parameters

In previous work:

slide-36

SLIDE 36

6/8

Dealing with function parameters

In previous work: Basic setting: Ignore and overwrite

slide-37

SLIDE 37

6/8

Dealing with function parameters

In previous work: Basic setting: Ignore and overwrite Validation games: Overwrite if valid w.r.t. input schema

slide-38

SLIDE 38

6/8

Dealing with function parameters

In previous work: Basic setting: Ignore and overwrite Validation games: Overwrite if valid w.r.t. input schema

Events @event_svc Brussels

slide-39

SLIDE 39

6/8

Dealing with function parameters

In previous work: Basic setting: Ignore and overwrite Validation games: Overwrite if valid w.r.t. input schema

Events @event_svc Brussels

Events

Sports football @event_svc Brussels

slide-40

SLIDE 40

6/8

Dealing with function parameters

In previous work: Basic setting: Ignore and overwrite Validation games: Overwrite if valid w.r.t. input schema

Events @event_svc Brussels

Events

Sports football @event_svc Brussels

How to model dependencies between input and output?

slide-41

SLIDE 41

6/8

Dealing with function parameters

In previous work: Basic setting: Ignore and overwrite Validation games: Overwrite if valid w.r.t. input schema

Events @event_svc Brussels

Events

Sports football @event_svc Brussels

How to model dependencies between input and output?

Nested Word Transducers

slide-42

SLIDE 42

6/8

Dealing with function parameters

In previous work: Basic setting: Ignore and overwrite Validation games: Overwrite if valid w.r.t. input schema

Events @event_svc Brussels

Events

Sports football @event_svc Brussels

How to model dependencies between input and output?

Nested Word Transducers Closely related to (variants of) visibly pushdown transducers

slide-43

SLIDE 43

7/8

Research goals and restrictions

slide-44

SLIDE 44

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy

slide-45

SLIDE 45

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case

slide-46

SLIDE 46

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness:

slide-47

SLIDE 47

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness: General NWT

slide-48

SLIDE 48

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness: General NWT ǫ-free NWT: Limited insertion

slide-49

SLIDE 49

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness: General NWT ǫ-free NWT: Limited insertion Relabelling NWT: No insertion

slide-50

SLIDE 50

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness: General NWT ǫ-free NWT: Limited insertion Relabelling NWT: No insertion . . .

slide-51

SLIDE 51

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness: General NWT ǫ-free NWT: Limited insertion Relabelling NWT: No insertion . . . Restrictions to strategies for JULIET:

slide-52

SLIDE 52

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness: General NWT ǫ-free NWT: Limited insertion Relabelling NWT: No insertion . . . Restrictions to strategies for JULIET: Unbounded/bounded/no recursion

slide-53

SLIDE 53

7/8

Research goals and restrictions

Algorithmic problem: Determine if JULIET has a winning strategy Main goal: Find tractable case Restrictions to transducer expressiveness: General NWT ǫ-free NWT: Limited insertion Relabelling NWT: No insertion . . . Restrictions to strategies for JULIET: Unbounded/bounded/no recursion . . .

slide-54

SLIDE 54

8/8

(Some) Results

Complexity of deciding if JULIET has a winning strategy: (Completeness results)

slide-55

SLIDE 55

8/8

(Some) Results

Complexity of deciding if JULIET has a winning strategy: (Completeness results)

No recursion Bounded Unbounded NWT 2-EXPTIME undecidable undecidable

slide-56

SLIDE 56

8/8

(Some) Results

Complexity of deciding if JULIET has a winning strategy: (Completeness results)

No recursion Bounded Unbounded NWT 2-EXPTIME undecidable undecidable ǫ-free NWT

CO-NEXPTIME

non-elementary undecidable

slide-57

SLIDE 57

8/8

(Some) Results

Complexity of deciding if JULIET has a winning strategy: (Completeness results)

No recursion Bounded Unbounded NWT 2-EXPTIME undecidable undecidable ǫ-free NWT

CO-NEXPTIME

non-elementary undecidable Relabelling PSPACE PSPACE EXPTIME

slide-58

SLIDE 58

8/8

(Some) Results

Complexity of deciding if JULIET has a winning strategy: (Completeness results)

No recursion Bounded Unbounded NWT 2-EXPTIME undecidable undecidable ǫ-free NWT

CO-NEXPTIME

non-elementary undecidable Relabelling PSPACE PSPACE EXPTIME

Tractable cases (not shown here) of little practical interest.

slide-59

SLIDE 59

8/8

(Some) Results

Complexity of deciding if JULIET has a winning strategy: (Completeness results)

No recursion Bounded Unbounded NWT 2-EXPTIME undecidable undecidable ǫ-free NWT

CO-NEXPTIME

non-elementary undecidable Relabelling PSPACE PSPACE EXPTIME

Tractable cases (not shown here) of little practical interest. Next step: Transducers that express practical schema languages (DTDs/XML Schema).

slide-60

SLIDE 60

8/8

Literature I

R. Alur, P

. Madhusudan. Adding nesting structure to words.

J. ACM, 56.3, 2009
E. Filiot, J. Raskin, P

. Reynier, F. Servais, J. Talbot. Properties of Visibly Pushdown Transducers. MFCS, 355–367, 2010.

T. Milo, S. Abiteboul, B. Amann, O. Benjelloun, F. Dang Ngoc.

Exchanging intensional XML data. ACM Trans. Database Syst.,30(1):1–40, 2005

A. Muscholl, T. Schwentick, L. Segoufin.

Active Context-Free Games. Theory Comput. Syst., 39(1):237–276, 2006

J. Raskin, F. Servais.

Visibly Pushdown Transducers. ICALP, (2)386–397, 2008.

A. Thomo, S. Venkatesh, Y. Ye.

Visibly Pushdown Transducers for Approximate Validation of Streaming XML. FoIKS, 219–238, 2008.
