Towards GV/m single-cycle THz pulses from undulators Vitaliy Goryashko 2016 Outline Accelerator physics in Uppsala and FREIA Laboratory Work on a linac-based THz source Concept of generation of single-cycle pulses with undulators

slide-1
SLIDE 1

Towards GV/m single-cycle THz pulses from undulators

Vitaliy Goryashko

2016

slide-2
SLIDE 2

Vitaliy Goryashko Single-cycle THz pulses

2

Outline

  • Accelerator physics in Uppsala and FREIA Laboratory
  • Work on a linac-based THz source
  • Concept of generation of single-cycle pulses with

undulators

  • Optimal tapering
  • Proposal for a THz Light at Uppsala
slide-3
SLIDE 3

Vitaliy Goryashko Single-cycle THz pulses

3

Background: accelerator physics in Uppsala

1940's: The(odore) Svedberg proposes to build a cyclotron

  • Gustaf Werner synchro-cyclotron (1947 – present)

– nuclear physics & cancer treatment

  • CELSIUS ring (1984 – 2005)

– nuclear physics

  • External

– CTF3/CLIC at CERN (since 2005) – FLASH/XFEL at DESY (since 2008) – ESS (since 2009)

  • FREIA laboratory (since 2011)
  • Skandion clinic (2015)

– cancer treatment

slide-4
SLIDE 4

Vitaliy Goryashko Single-cycle THz pulses

4

European Spallation Source (ESS), Sweden

slide-5
SLIDE 5

Vitaliy Goryashko Single-cycle THz pulses

5

FREIA

slide-6
SLIDE 6

Vitaliy Goryashko Single-cycle THz pulses

6

FREIA: Facility for Research Instrumentation & Accelerator Development

cryogenics

  • liquid helium
  • liquid nitrogen

control room

  • equipment controls
  • data acquisition

radio-frequency (RF) power sources 3 bunkers with test stands horizontal cryostat vertical cryostat Competent and motivated staff

collaboration of physics (IFA) and engineering (Teknikum).

Funded by KAWS, Government, Uppsala Univ.

State-of-the-art Equipment

slide-7
SLIDE 7

Vitaliy Goryashko Single-cycle THz pulses

7

Low-energy excitations: D. N. Basov et al., Rev. of Mod. Phys. 2011

slide-8
SLIDE 8

Vitaliy Goryashko Single-cycle THz pulses

8

Combined THz/X-ray source: old design

slide-9
SLIDE 9

Vitaliy Goryashko Single-cycle THz pulses

9

How to generate GV/m single- cycle pulses with MeV bunches?

slide-10
SLIDE 10

Vitaliy Goryashko Single-cycle THz pulses

10

Single-cycle synchrotron radiation

slide-11
SLIDE 11

Vitaliy Goryashko Single-cycle THz pulses

11

Single-cycle radiation from a segmented undulator

slide-12
SLIDE 12

Vitaliy Goryashko Single-cycle THz pulses

12

Single-cycle radiation from a segmented undulator: cont’d

Magnetic field of segments

slide-13
SLIDE 13

Vitaliy Goryashko Single-cycle THz pulses

13

Single-cycle radiation from a segmented undulator If instead of increasing the distance between the segments I will decrease it, I will recover Takashi’s tapered undulator.

slide-14
SLIDE 14

Vitaliy Goryashko Single-cycle THz pulses

14

slide-15
SLIDE 15

Vitaliy Goryashko Single-cycle THz pulses

15

What is the optimum taper profile? Can one generate just one cycle?

slide-16
SLIDE 16

Vitaliy Goryashko Single-cycle THz pulses

16

Simple reasoning from Takashi

total field is a convolution of the current density and the field of a single electron Suppose that the time profile of the current density is the same as the single-electron field profile The convolution boils down to the inverse Fourier transform of the spectral power.

Let us optimize ()

via undulator tapering

in order to get as few cycles as possible.

slide-17
SLIDE 17

Vitaliy Goryashko Single-cycle THz pulses

17

0, = −

  • 2
  • 2
  • (′) sin #$

1 + ' − ′ #

  • ( )*+ ,- .$

/0/ /0/

On-axis field in a tapered undulator

  • E. Saldin et al. "A simple method for the determination of the structure of ultrashort

relativistic electron bunches." NIMA 539.3 (2005): 499-526.

2 = 3 34 , 34 = 3 2

slide-18
SLIDE 18

Vitaliy Goryashko Single-cycle THz pulses

18

3 = 3 2 1 + 2

  • (4) ,

Stationary phase method

stationary point

slide-19
SLIDE 19

Vitaliy Goryashko Single-cycle THz pulses

19

I equate the spectral power of radiation from a tapered undulator 5 to that of the quasi-half-cycle pulse

It turns out that the minimum number of cycles is 1.5. Optimal taper profile

slide-20
SLIDE 20

Vitaliy Goryashko Single-cycle THz pulses

20

Radiation from the optimally-tapered undulator

slide-21
SLIDE 21

Vitaliy Goryashko Single-cycle THz pulses

21

Proposal for a THz Light Source in Uppsala

slide-22
SLIDE 22

Vitaliy Goryashko Single-cycle THz pulses

22

Wish list for intense THz radiation.

Parameter Quasi-half-cycle pulses for time- resolved experiments Narrowband pulses for frequency-resolved experiments Spectral range (THz) 1.5-15 1.5-15 Pulse duration (ps) 0.1-1 1-10 Pulse energy (mJ) 1000 100 Peak electric field (GV/m) 1 0.1 Relative bandwidth FWHM 100% 10% Repetition rate (kHz) 1-100 1-100

+ Polarization control, pump-probe configuration

slide-23
SLIDE 23

Vitaliy Goryashko Single-cycle THz pulses

23

The source

  • it covers the spectral range from 5 to 15 THz, exceeding that
  • f laser-based sources;
  • polarization variable from linear to circular or elliptical;
  • tunability of the central frequency and bandwidth;
  • mutli-kilohertz repetition rate;
  • light carrying orbital angular momentum.
slide-24
SLIDE 24

Vitaliy Goryashko Single-cycle THz pulses

24

Source 1: quasi-half-cycle pulses

slide-25
SLIDE 25

Vitaliy Goryashko Single-cycle THz pulses

25

Source 2: multi-cycle pump and single-cycle probe Source 2a Source 2b
