slide-1
SLIDE 1

Topological Structures in the Analysis of Images and Data

Chao Chen

City University of New York (CUNY)

  • Oct. 2016
  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 1 / 43

slide-2
SLIDE 2

Outline

1

Topological Structures

2

High Dimensional Data Algorithms Applications

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 2 / 43

slide-3
SLIDE 3

Topological Structures

global, multi-scale, independent to geometry 0 dim 1 dim 2 dim

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 3 / 43

slide-4
SLIDE 4

Topological Structures of Data

For a dataset, what are the components and loops of the data? TDA: detect these structures in a robust way.

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 4 / 43

slide-5
SLIDE 5

Topological Structures of Data

For a dataset, what are the components and loops of the data? TDA: detect these structures in a robust way.

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 4 / 43

slide-6
SLIDE 6

Persistent Homology: A Robust Way to Extract Topological Structures

Input: a (density) function, f Output: topological structures & their persistence

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 5 / 43

slide-7
SLIDE 7

Persistent Homology: A Robust Way to Extract Topological Structures

Input: a (density) function, f Output: topological structures & their persistence Def: given threshold t, the superlevel set f −1[t, +∞) := {x|f (x) ≥ t}

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 5 / 43

slide-8
SLIDE 8

Persistent Homology (continued)

the true structures are hidden in superlevel sets consider the whole stack of superlevel sets identify structures that often appear (high persistence) Output: persistence diagram – dots representing all structures

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 6 / 43

slide-9
SLIDE 9

Persistent Homology (continued)

the true structures are hidden in superlevel sets consider the whole stack of superlevel sets identify structures that often appear (high persistence) Output: persistence diagram – dots representing all structures Diagram

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 6 / 43

slide-10
SLIDE 10

Why Topological Structures: Cardiac data (Demo)

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 7 / 43

slide-11
SLIDE 11

Why Topological Structures: Cardiac data (Demo)

Thresholding Thresholding: local evidence, minimize energy E(y) E(y) =

  • v

Ev(yv), yv ∈ {BG, FG}

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 7 / 43

slide-12
SLIDE 12

Why Topological Structures: Cardiac data (Demo)

Thresholding Advanced Thresholding: local evidence, minimize energy E(y) E(y) =

  • v

Ev(yv), yv ∈ {BG, FG} Advanced: pairwise local evidence E(y) =

  • v

Ev(yv) +

  • (u,v)

Eu,v(yu, yv)

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 7 / 43

slide-13
SLIDE 13

Why Topology Data Analysis?

Recovering missing trabeculae: [Gao, Chen , et al. IPMI’13]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 8 / 43

slide-14
SLIDE 14

Why Topology Data Analysis?

Recovering missing trabeculae: [Gao, Chen , et al. IPMI’13]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 8 / 43

slide-15
SLIDE 15

Morphological Analysis

Endocardial Surface [ISBI’14]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 9 / 43

slide-16
SLIDE 16

Follow-up Questions (Ongoing)

Validation on a specimen Homology localization problem Ground Truth Simulation Bad Generator Good Generator

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 10 / 43

slide-17
SLIDE 17

Topological Information as Constraints in Segmentation

[Chen et al. CVPR 2011]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 11 / 43

slide-18
SLIDE 18

Topological Information as Constraints in Segmentation

[Chen et al. CVPR 2011] Input Stencil 1 2 3 4 Final [Jain, Chen , et al. , Computer & Graphics, 2015]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 11 / 43

slide-19
SLIDE 19

Additional Application: Multi-Layer Stencil Creation

Canvas/wall result: Website, interactive [Jain, Chen , et al. , Computer & Graphics, 2015]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 12 / 43

slide-20
SLIDE 20

Outline

1

Topological Structures

2

High Dimensional Data Algorithms Applications

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 13 / 43

slide-21
SLIDE 21

Topological Structures for High Dimensional Data

Plenty have been done: data centric, simplicial complex, mapper, etc.

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 14 / 43

slide-22
SLIDE 22

Topological Structures for High Dimensional Data

Plenty have been done: data centric, simplicial complex, mapper, etc. My focus: density function.

◮ Need a good model: high dim, flexibility, computation

– graphical model

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 14 / 43

slide-23
SLIDE 23

Topological Structures for High Dimensional Data

Plenty have been done: data centric, simplicial complex, mapper, etc. My focus: density function.

◮ Need a good model: high dim, flexibility, computation

– graphical model

◮ Locations that contribute to major topological events, critical points

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 14 / 43

slide-24
SLIDE 24

Graphical Model

Markov Random Field (MRF) D dimension; values/labels L = {1, . . . , L} configurations/labelings: X = LD = {1, · · · , L}D

V1 V2 V4 V6 V3 V5 V7 V8

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 15 / 43

slide-25
SLIDE 25

Graphical Model

Markov Random Field (MRF) D dimension; values/labels L = {1, . . . , L} configurations/labelings: X = LD = {1, · · · , L}D

V1 V2 V4 V6 V3 V5 V7 V8 1 1 1 1 1

θij(0, 0)

xi xj

1 1 θij(0, 1) θij(1, 1) θij(1, 0) Binary Potentials θij(xi, xj)

Energy: E(x) =

(i,j)∈E θij(xi, xj)

Probability: P(x) = exp (−E(x))/Z

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 15 / 43

slide-26
SLIDE 26

What can we do with a graphical model?

Previously: Computing the maximum a posteriori (MAP): argmaxx∈X P(x) = argminx∈X E(x) marginals, sampling, etc.

P(x) MAP

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 16 / 43

slide-27
SLIDE 27

What can we do with a graphical model?

Previously: Computing the maximum a posteriori (MAP): argmaxx∈X P(x) = argminx∈X E(x) marginals, sampling, etc.

mode mode P(x) MAP

New Question: How about modes (local maxima)?

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 16 / 43

slide-28
SLIDE 28

Why modes?

A concise description of the probabilistic landscape

mode mode P(x) MAP

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 17 / 43

slide-29
SLIDE 29

Why modes?

A concise description of the probabilistic landscape Multiple predictions

◮ model is not perfect, ambiguity ◮ multiple hypotheses, diverse, highly possible

Other applications: biology, NLP Previous: mean-shift

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 17 / 43

slide-30
SLIDE 30

Definitions

Given a distance function d(·, ·) and a scalar δ

◮ Neighborhood: Nδ(x) = {x′ | d(x, x′) ≤ δ} ◮ x is a mode if it has a bigger prob. than all its neighbors ◮ Mδ : the set of all modes for a given scale δ

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 18 / 43

slide-31
SLIDE 31

Definitions

Given a distance function d(·, ·) and a scalar δ

◮ Neighborhood: Nδ(x) = {x′ | d(x, x′) ≤ δ} ◮ x is a mode if it has a bigger prob. than all its neighbors ◮ Mδ : the set of all modes for a given scale δ

P(x)

δ = 1

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 18 / 43

slide-32
SLIDE 32

Definitions

Given a distance function d(·, ·) and a scalar δ

◮ Neighborhood: Nδ(x) = {x′ | d(x, x′) ≤ δ} ◮ x is a mode if it has a bigger prob. than all its neighbors ◮ Mδ : the set of all modes for a given scale δ

P(x)

δ = 4

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 18 / 43

slide-33
SLIDE 33

Definitions

Given a distance function d(·, ·) and a scalar δ

◮ Neighborhood: Nδ(x) = {x′ | d(x, x′) ≤ δ} ◮ x is a mode if it has a bigger prob. than all its neighbors ◮ Mδ : the set of all modes for a given scale δ

P(x)

δ = 7

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 18 / 43

slide-34
SLIDE 34

Definitions

D the dimension; L = {1, . . . , L} the label set; X = LD the domain Given a distance function d(·, ·) and a scalar δ

◮ Neighborhood: Nδ(x) = {x′ | d(x, x′) ≤ δ} ◮ x is a mode if it has a bigger prob. than all its neighbors ◮ Mδ : the set of all modes for a given scale δ

X = M0 ⊇ M1 ⊇ · · · ⊇ M∞ = {global maximum (MAP)}

δ = 1 δ = 4 δ = 7 δ = 0

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 19 / 43

slide-35
SLIDE 35

Problem

Problem (MModes)

Given a scale δ, compute the top M elements in Mδ. Challenge: exponential domain, exponential neighborhood

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 20 / 43

slide-36
SLIDE 36

Problem

Problem (MModes)

Given a scale δ, compute the top M elements in Mδ. Challenge: exponential domain, exponential neighborhood Contributions Algorithms (chains, trees):

◮ Dynamic programming (DP) ◮ Heuristic search ◮ Local neighborhood search

Applications [AISTATS 2013, NIPS 2014, IJCAI 2016, ICML 2016]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 20 / 43

slide-37
SLIDE 37

Outline

1

Topological Structures

2

High Dimensional Data Algorithms Applications

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 21 / 43

slide-38
SLIDE 38

Algorithm: Chains

1 2 3 D xD = 0 xD = 1 x1 = 0 x1 = 1

configurations/labelings = paths MAP: the optimal path (dynamic programming), O(DL2)

◮ from right to left ◮ each step: best energy for subchain [i, D] with given label on i

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 22 / 43

slide-39
SLIDE 39

Algorithm: Chains

1 2 3 D xD = 0 xD = 1 x1 = 0 x1 = 1

configurations/labelings = paths MAP: the optimal path (dynamic programming), O(DL2)

◮ from right to left ◮ each step: best energy for subchain [i, D] with given label on i

MBest: best M configurations/labelings x1 = argminx∈X E(x) xm = argminx∈X\{x1,··· ,xm−1} E(x) Nilsson’98 (fancy DP) O(DL2 + MDL + MD log(MD))

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 22 / 43

slide-40
SLIDE 40

Algorithm: Modes on Chains [AISTATS 2013] Key Idea

The whole chain [1, D] → subchains [i, j] of a fixed length Global modes → local modes

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 23 / 43

slide-41
SLIDE 41

Algorithm: Modes on Chains [AISTATS 2013] Key Idea

The whole chain [1, D] → subchains [i, j] of a fixed length Global modes → local modes A partial labeling xi:j

· · · · · · i j

xi:j is a local mode iff for any yi:j s.t. yi = xi, yj = xj E(xi:j) < E(yi:j)

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 23 / 43

slide-42
SLIDE 42

Algorithm: Modes on Chains [AISTATS 2013] Key Idea

The whole chain [1, D] → subchains [i, j] of a fixed length Global modes → local modes A partial labeling xi:j

· · · · · · i j

xi:j is a local mode iff for any yi:j s.t. yi = xi, yj = xj E(xi:j) < E(yi:j)

Lemma

any [i, j] has L2 local modes, computable in polynomial time

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 23 / 43

slide-43
SLIDE 43

Algorithm: Modes on Chains

Theorem (local-global)

x is a mode iff any length δ + 2 partial labeling xi:j is a local mode An example: D = 7, δ = 3

1 2 3 5 6 7 4 1 2 3 5 6 7 4

x1:5 x2:6 x3:7

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 24 / 43

slide-44
SLIDE 44

Algorithm: Modes on Chains

Intuition

◮ Combinations of local modes → global modes ◮ Consistent: agree at common vertices

[1, 5] [2, 6] [3, 7]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 25 / 43

slide-45
SLIDE 45

Algorithm: Modes on Chains

Intuition

◮ Combinations of local modes → global modes ◮ Consistent: agree at common vertices

[1, 5] [2, 6] [3, 7]

Step 1: construct a new chain,

◮ supernodes [i, j] ◮ labels {local modes of [i, j]} ◮ feasible only if consistent ◮ preserve the energy of the

  • riginal graph

Fact

New chain labeling space: X = Mδ

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 25 / 43

slide-46
SLIDE 46

Algorithm: Modes on Chains

Step 1: construct a new chain,

◮ Configuration space:

  • X = Mδ

◮ Energy:

E( x) = E(x)

[1, 5] [2, 6] [3, 7]

Step 2: M-Modes is reduced to M-Best in the new chain

◮ M-Best: compute the top M configurations ◮ Use Nilsson’98

Total Complexity O(DL3δ + MDL2 + MD log(MD))

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 26 / 43

slide-47
SLIDE 47

Trees

Chains

· · · · · · i j

Subchain of δ plus two adjacent nodes Local modes (L2) Trees Subtree of size δ plus all adjacent nodes Local modes (exponential to the number of adjacent nodes)

Theorem (local-global)

x is a mode iff within any subchain/subtree it is a local mode. Can extend to any graph!

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 27 / 43

slide-48
SLIDE 48

General Situations

Extending the Algorithm Trees (DP) [NIPS’14] Systematic search [IJCAI’16] Local neighborhood search [ICML’16]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 28 / 43

slide-49
SLIDE 49

General Situations

Extending the Algorithm Trees (DP) [NIPS’14] Systematic search [IJCAI’16] Local neighborhood search [ICML’16] Model Unknown Input: samples Algorithm:

◮ Step 1: estimate a tree distribution (Chow-Liu algorithm) ◮ Step 2: compute modes

Theoretical guarantee P( Mδ = Mδ) → 1 as S → ∞

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 28 / 43

slide-50
SLIDE 50

Outline

1

Topological Structures

2

High Dimensional Data Algorithms Applications

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 29 / 43

slide-51
SLIDE 51

Application: Multiple Predictions

High Probability; Diversity Image Partitioning Task (Berkeley, Stanford Datasets) Ground Truth 1st Mode 2nd Mode 3rd Mode Standford RI Berkeley RI Standford VOI Berkeley VOI

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 30 / 43

slide-52
SLIDE 52

Application: Video Analysis

Gesture recognition: [Chen et al. AISTATS] Pic from [Liu, Chen et al. CVIU]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 31 / 43

slide-53
SLIDE 53

Clustering Discrete Data [ICML 2016]

Start from each data, local search until stops at a mode Synthetic data: D = 110, L = 4, 4 clusters randomly perturb 5% and 10% attributes Visualized in 2D (using MDS) GT/Ours ROCK AP kmodes Performance (in NMI)

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 32 / 43

slide-54
SLIDE 54

Clustering Discrete Data [ICML 2016]

DNA Barcoding data ([Kuksa & Pavlovic BMC Bioinformatics]) 600 to 900 dimension Alignment free Also UCI datasets.

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 33 / 43

slide-55
SLIDE 55

Application: User Interaction (Ongoing)

Electron Microscopy (EM) Images of Fly/Mouse Brains Input: 2D or 3D EM images; boundary likelihood map Output: partitioning of the image EM Images Likelihood Results

Pic from Takemura et al. Nature’13

[Uzunba¸ s, Chen and Metaxas, MICCAI’14, MedIA’15]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 34 / 43

slide-56
SLIDE 56

Application: User Interaction (Ongoing)

Multiple proposals for user to select and modify

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 35 / 43

slide-57
SLIDE 57

Conclusion

Topological structures: global structure/prior/information Individual data/images Whole dataset

◮ New perspective to the model: inference and more

Thank You! Questions?

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 36 / 43

slide-58
SLIDE 58

Appendix

Convergence rate for modes estimation d dimension, L label set size, n sample size

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 37 / 43

slide-59
SLIDE 59

Trees: Idea 1, Fancy DP [NIPS 2014]

Build a new tree

◮ Supernodes ← subtrees ◮ Labels ← local modes ◮ M-Best configurations ← M-Modes

Issue: number of local modes can be exponential to the tree-degree, even for small δ

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 38 / 43

slide-60
SLIDE 60

Trees: Idea 1, Fancy DP [NIPS 2014]

Complexity O

  • D2dLδ2(L + δ)(Ld + λd) + Dλ2 + MDλ + MD log(MD)
  • d tree degree

λ max # of local modes for any ball

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 39 / 43

slide-61
SLIDE 61

Trees: Idea 1, Fancy DP [NIPS 2014]

Complexity O

  • D2dLδ2(L + δ)(Ld + λd) + Dλ2 + MDλ + MD log(MD)
  • d tree degree

λ max # of local modes for any ball In practice (bounded tree degree)

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 39 / 43

slide-62
SLIDE 62

Trees: Idea 2, Heuristic Search [IJCAI 2016]

Compute all local modes → only compute when necessary Heuristic search:

◮ For each state, verify whether one local pattern is a local mode ⋆ if not, prune the whole subtree ◮ Many states (and thus local modes) may never be reached ◮ A*, Death First Search Branch and Bound (DFBnB)

V1 V2 V3

xxx 0xx 1xx 00x 01x 10x 11x

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 40 / 43

slide-63
SLIDE 63

Trees: Idea 2, Heuristic Search [IJCAI 2016]

Compute all local modes → only compute when necessary Heuristic search:

◮ For each state, verify whether one local pattern is a local mode ⋆ if not, prune the whole subtree ◮ Many states (and thus local modes) may never be reached ◮ A*, Death First Search Branch and Bound (DFBnB)

V1 V2 V3

xxx 0xx 1xx 00x 01x 10x 11x Caveat:

◮ Not any cheaper in the worst case senario ◮ Needs the MAP computation

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 40 / 43

slide-64
SLIDE 64

Trees: Idea 2, Heuristic Search [IJCAI 2016]

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 41 / 43

slide-65
SLIDE 65

Trees: Idea 2, Heuristic Search [IJCAI 2016]

Also UCI datasets.

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 41 / 43

slide-66
SLIDE 66

Trees: Idea 3, Local Search

Pic from Nowozin and Lampert

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 42 / 43

slide-67
SLIDE 67

Trees: Idea 3, Local Search

Each step: to compute the best neighbor in Nδ(y), argminz∈Nδ(y)\{y} E(z) Complexity O(DdLδ2(L + δ))

  • C. Chen (CUNY)

Topological Structures in the Analysis of Images and Data 43 / 43
