SLIDE 1
Certified Engineer Course
The Visual Library API Anton Epple http://www.eppleton.de What is - - PowerPoint PPT Presentation
The Visual Library API Anton Epple http://www.eppleton.de What is - - PowerPoint PPT Presentation
The Visual Library API Anton Epple http://www.eppleton.de What is the Visual Library? Generic Visualization Library Especially useful for displaying Graphs Widgets as Graphic primitives Certified Engineer Course What is the Visual Library?
SLIDE 2
SLIDE 3
Certified Engineer Course
What is the Visual Library?
Can be used in any Swing Application
Only one dependency. Lookup (util)
Documentation & Demo Projects:
http://graph.netbeans.org/documentation.html http://graph.netbeans.org/examples.html
Used in NetBeans & many independent applications
SLIDE 4
Certified Engineer Course
Used in many Applications
Inside NetBeans ( Visual Mobile Designer ) Jarvis (Jasperreports Visual Designer) MindMap GeeWhiz (Prolog Editor & Tutorial ) ChipInspector (Genome Browser) InstantJChem (Form Designer) BlueMarine (Photo Editor)
SLIDE 5
Certified Engineer Course
VMD
SLIDE 6
Certified Engineer Course
Instant JChem
SLIDE 7
Certified Engineer Course
Jarvis
SLIDE 8
Certified Engineer Course
How does it work?
Similar to Swing: Components organized in a tree Widgets = Graphics primitive (like JComponent)
Scene (Root element)
ObjectScene
Graph Scene GraphPinScene
LayerWidget LabelWidget ImageWidget ...
Demo...
SLIDE 9
Certified Engineer Course
How does it work?
Layouts:
AbsoluteLayout, FlowLayout, CardLayout, OverlayLayout Demo...
Actions:
MoveAction, HoverAction, ZoomAction, PanAction... Every Widget has a WidgetAction.Chain to receive Events and forward them to the matching Action widget.getActions().addAction(ActionFactory.c reateMoveAction()); Demo...
SLIDE 10
Certified Engineer Course
Custom Behaviour - Providers
Use Providers to create Custom Behaviour:
ActionFactory.createXXXAxtion(new MyXXXProvider ());
Example:
private static class MyHoverProvider implements HoverProvider { public void widgetHovered(Widget widget) { if (widget != null){ widget.setForeground(Color.RED); } } }
Demo...
SLIDE 11
Certified Engineer Course
Create your own Widgets
public class IconNodeWidget extends Widget { public IconNodeWidget(Scene scene, String icon, String label) { super(scene); setOpaque(true); setLayout(LayoutFactory.createVerticalFlowLayout(LayoutFactory. SerialAlignment.CENTER, 4)); // use vertical layout Image image = Utilities.loadImage(icon); addChild(new ImageWidget(scene, image)); addChild (new LabelWidget (scene, label)); } } Demo...
SLIDE 12
Certified Engineer Course
Create a Visual Database Explorer
DEMO
