Biogas digester types

  • Biogas produced in anaerobic digesters consists of methane (50-80%), carbon dioxide

(20-50%) and trace levels of other gases such as hydrogen, carbon monoxide, nitrogen, oxygen and hydrogen sulphide.

  • Anaerobic digesters are made out of concrete, steel, bricks or plastic. They are

shaped such as troughs, basins or ponds, and may be placed underground or on the surface depending on the design and climatic conditions of an area.

  • There are two basic types of digesters, which are batch type and continuous type.
  • There are three types of continuous digesters, these are: Vertical tank systems,

horizontal tank or plug-flow systems and multi tank systems.

slide-4
SLIDE 4

4

The digestion process

  • Anaerobic decomposition occurs in three basic stages as a result of the activity of a

variety of microorganisms. Initially, a group of microorganisms converts organic material into a form that a second group of organisms utilizes to form organic acids and complete the decomposition process.

  • A number of factors affect the rate of digestion and biogas production. The most

important is temperature.

  • Anaerobic bacteria communities can endure temperatures ranging from below

freezing to above 57 oC, but they thrive best at temperatures of about 37oC (mesophillic bacteria) and 55oC (thermophillic bacteria).

  • Bacteria activity, and thus biogas production, falls off significantly between 39oC

and 51oC and gradually from 35oC to 0oC.

slide-5
SLIDE 5

5

The digestion process

  • Hydrolysis is an enzyme mediated stage where insoluble organic compounds such

as proteins, fats, lipids and carbohydrates are converted into soluble organic components such as amino acids, fatty acids, monosaccharides, and other simple

  • rganic compounds.
  • Acidogenesis or fermentation is the next step where soluble compounds produced

in the first stage are further degraded resulting in the production of carbon dioxide (CO2), hydrogen (H2), organic acids, alcohols and some organic sulphur compounds.

  • Acetogenesis is the third stage of acetic acid formation (acetogenesis) combines the

prior acidification with methane formation. The starting substrates are a number of final products from the acidification phase. Examples include, chain fatty acids, propionic acid, polymer substrates (carbohydrates, fats, proteins) and butyric acid. Together with lactic acid, alcohols and glycerol, these substrates are converted by the acetogenic micro-organisms into acetic acid, hydrogen and carbon dioxide

  • Methanogenesis: Methanogens convert the acetate and hydrogen to methane and

carbon dioxide. Methanogenic bacteria are divided into three categories. Hydrogenotrophic methanogens use hydrogen to convert carbon dioxide to

  • methane. Acetotrophic methanogens split acetate into methane and carbon dioxide.

Finally, methylotrophic methanogens produce methane directly from methyl groups, such as methanol, and mono-, di-, and trimethylamines.

slide-6
SLIDE 6

6

The digestion process

Biomass

Carbohydrates Proteins Fats Sugars Amino acids Fatty acids Fatty acids (Propionic acid) Alcohols Hydrogen Carbon dioxide Acetic acid Hydrogen Carbon dioxide

Biogas Methane Carbon dioxide

  • 1. STEP

Hydrolysis macromolecule (Hydrolytic phase)

  • 2. STEP

Acidification (Acidogene phase)

  • 3. STEP

Acetic acid formed (Acetogene phase)

  • 4. STEP

Methane formation (Methanogene phase)

pH: 5-6 pH: 5.5-6.7 pH: 6.6-8.0

slide-7
SLIDE 7

7

Energy from biogas

  • Approximately 1.15 kg of organic waste

provides 1 m3 of biogas, equivalent of 1.7 kWh of energy.

  • The energy can be used for direct heating or

power generation purposes.

slide-8
SLIDE 8

8

Biogas digesters installations at UFH

The research is focused on:

– Design, installation and performance monitoring

  • f biogas digesters.

– 5 biogas digesters installed at Fort Cox college, Melani village and UFH. – 110 digesters planned for Nkonkobe municipality-implementation imminent. – At least 4 digesters planned for schools in Chris Hani District Municipality – Demonstrate the use of biogas technology as a cheap and sustainable option.

slide-9
SLIDE 9

9

Biogas digesters research activities

  • Design, installation and performance monitoring

Reinforced Concrete dome 30 cm blade COMPUTER Data logger Gas sensors Brick wall Inner Brick wall Sawdust Slurry outlet Stirrer 106 cm 20 cm Concrete slab BIOGAS SLURRY Temperature probe1 Temperature probe 2 Sensor output Temperature probes 1 and 2 Gas to house Flow meter Inlet pipe Digester floor 20 cm

slide-10
SLIDE 10

10

Biogas digesters research activities

  • Design, installation and performance monitoring

CO2 sensor Gas pump H2 sensor

Hydrophobic filter

Flow meter Laptop Data logger 12V battery H2S sensor CH4 sensor Biogas hose

slide-11
SLIDE 11

11

Biogas digesters research activities

  • Biogas yield from cowdung before digester insulation

y = 0.002x2 - 0.0199x + 0.0356 R² = 0.9489 0.05 0.1 0.15 0.2 0.25 0.3 0.35 2 4 6 8 10 12 14 16 18 20 Gas yield / m3 Time / days

slide-12
SLIDE 12

12

Biogas digesters research activities

  • Biogas yield from cow dung vs COD concentration

5000 10000 15000 20000 25000 30000 35000 40000 45000 0.1 0.2 0.3 0.4 0.5 0.6 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 pH Biogas yield / m3 Retention time / days Gas yield COD

slide-13
SLIDE 13

13

Biogas digesters research activities

  • Biogas yield from cow dung and donkey dung

0.1 0.2 0.3 0.4 0.5 0.6 4 6 8 10 12 14 16 18 20 22 24 26 28 30 Biogas yield / m3 Retention time / days Cow Donkey

slide-14
SLIDE 14

14

Biogas digesters research activities

  • Bacteria activity in cowdung

– Bacteria that has been well documented in cow manure include Salmonella Sp, Escherichia coli and Camphilobacter species. – These are associated with human gastrointestinal infection.

slide-15
SLIDE 15

15

5 10 15 20 0.5 1 1.5 2 2.5 3 3.5 4 4.5 Time/Days log bacteria counts (cfu/g) 20 40 60 80 1 2 3 4 5 6 Time/Days log bacteria counts (cfu/g) 25 50 75 100 125 150 1 2 3 4 5 6 Time/Days log bacteria counts(cfu/g) measured data regression line measured data regression line measured data regression line

(a) Reduction of Campylobacter sp counts with retention time. (b) Reduction of E. coli counts with retention time. (c) Reduction of Salmonella sp counts with retention time. (a) (b) (c)

slide-16
SLIDE 16

16

Digesters at UFH

slide-17
SLIDE 17

17

BIOMASS GASIFICATION

  • Biomass gasifier converts wood and wood waste into charcoal

giving gas as a by-product.

  • The gas is a mixture of CO2, CH4, H2, CO, H2O and N2.
  • It has a heating value of 3-6MJ/kg and is used for heating and

electricity generation.

  • The University of Fort Hare installed a150kVA System Johanson

Biomass Gasifier at Melani village for powering a community bakery and for research purposes.

slide-18
SLIDE 18

18

Gasification process

Drying Biomass + H2O Pyrolysis Oxidation Reduction

Producer gas

H2O N2,Tar,CH4 CO,H2O CO2,H2

slide-19
SLIDE 19

The Gas Producer

The pollution-free answer to providing inexpensive energy through consumption of Bio-mass material!

THE PROCESS

slide-20
SLIDE 20

Gasifier

1.Fuel Compartment with Condensate trap 2.Inverted Reduction Cone

  • 3. Combustion Chamber

4.Hearth

  • 5. Ash Grate Activator
slide-21
SLIDE 21

The Cyclone

The Raw Gas is passed through the Cyclone, which removes the course dust from the raw gas

slide-22
SLIDE 22

The Gas Scrubber / Cooler.

After the course dust has been removed from the cyclone, the fine dust(5ml/N³) is carried with the sprayed scrubbing water over a low resistance porous scrubbing media. The water is recycled through an ambient cooling pond. The gas is cooled to ambient temp.

slide-23
SLIDE 23

The long life particle interference filter….

The Particle Interference Filter

The cooled gas is passed through the filter filled with course sawdust

slide-24
SLIDE 24

The safety filter….

The Safety Filter

Before reaching the engine, the clean gas is finally passed through a standard 5 micron double cartridge Donaldson Filter.

slide-25
SLIDE 25

The generator….

The Generator…….

slide-26
SLIDE 26

The engine….

The Engine……

slide-27
SLIDE 27

The engine….

(CO) Emissions from Engine Carbon neutral

slide-28
SLIDE 28

The cooling pond….

The Cooling Pond…… Water contains no toxic elements and can be used for irrigation purposes!

slide-29
SLIDE 29

29

Prototype for R&D

slide-30
SLIDE 30

BIOMASS CHARACTERIZATION

30

slide-31
SLIDE 31

31

  • 150 kVA Melani village gasifier
slide-32
SLIDE 32

32

The gasifier

slide-33
SLIDE 33

33

Presented by: Sampson Mamphweli Thank you
