The Panorama Applications to Science and Heritage Visualisation Paul Bourke Cyclorama In 1787 Robert Baker was awarded the patent for La Nature a Coup dOeil. (Nature at a Glance) What we now call the cyclorama, large

slide-1
SLIDE 1

The Panorama Applications to Science and Heritage Visualisation

Paul Bourke

slide-2
SLIDE 2

Cyclorama

  • In 1787 Robert Baker was awarded the patent for “La Nature a Coup d’Oeil”.

(Nature at a Glance)

  • What we now call the cyclorama, large paintings often presented on architecture

matching the place represented in the painting. Heightens the suspension of belief, the sensation of “being there”.

“... to make observers,

  • n whatever situation he may choose they should imagine themselves,

feel as if really on the very spot”

slide-3
SLIDE 3

Panorama 1453 - Istanbul

Panorama 1453: Capture of Istanbul by the Turks

slide-4
SLIDE 4

Panorama 1453 - Istanbul

slide-5
SLIDE 5

Charles Chase

  • In 1896 Charles Chase employed recent advances in photography to create more

literal panoramic experiences.

  • Targeted virtual tourism

“... everything in view from the point where the photograph is taken will be reproduced exactly as it appears when seen from such point” “By this manner of reproducing views a person can get a better idea of the different parts of the world without actually going there than in any other manner heretofore devised. In fact he may see such views exactly as they would appear if seen on the ground”

slide-6
SLIDE 6
slide-7
SLIDE 7

Video Panorama

  • The next logical step is video panoramas
  • A number of cameras available for this although most are low resolution
  • Early (first?) large scale application was in 1957 at the Hamburg planetarium.
slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10

Motivation for Visualisation

  • Visualisation employs advanced algorithms and computer graphics to provide

insights to researchers.

  • Value in maximising the capabilities of the human visual system.
  • In the context of the panorama this involves images that
  • 1. capture everything visible from some position
  • 2. present the panorama so as to give a sense of immersion
  • 3. form a convenient format for extremely high resolution digital recordings
  • Recurring themes from 200 years ago
  • 1. create a sense of immersion, of being in another place
  • 2. create highly realistic and detailed representations
slide-11
SLIDE 11

Spherical panoramas: Science visualisation

Inside the eyeball of a placoderm fish, circa 400 million years old

  • 180 degrees

180 degrees

  • 90 degrees

90 degrees North pole South pole Longitude Latitude Movie

slide-12
SLIDE 12

Spherical panoramas: Science visualisation

Rabbits liver - Cancer research Movie

slide-13
SLIDE 13

Spherical panoramas: Science visualisation

Synthetic crystal Movie

slide-14
SLIDE 14

iDome

Movie

slide-15
SLIDE 15

Spherical panorama video: Cultural heritage

  • A number of cameras have been built that can capture spherical panorama video.
  • Employed in visualisation in cultural heritage: providing insight into a different

culture.

slide-16
SLIDE 16

Hashbecktashi Dancers

Kardeslik Semahi & Aliyar Semahi (Hacibektas Veli Museum) Bektasi Semahi (Hacibektas Veli Museum performers)

slide-17
SLIDE 17

Spherical panorama video: Cultural heritage

Hashibektashi performance, Turkiye

  • 180 degrees

180 degrees

  • 90 degrees

90 degrees North pole South pole Longitude Latitude

  • 50 degrees

Movie

slide-18
SLIDE 18

iDome

Hashibektashi performance, Turkiye Movie

slide-19
SLIDE 19

Camera

Mah Meri tribal healing ritual, West Malaysia

slide-20
SLIDE 20

Spherical panorama video: Cultural heritage

Mah Meri tribal dance, West Malaysia Movie

slide-21
SLIDE 21

Spherical panorama video: Cultural heritage

Ngintaka story Movie

slide-22
SLIDE 22

iDome

Movie

slide-23
SLIDE 23

Cylindrical panoramas: Virtual heritage

  • If the vertical field of view is limited then referred to as a cylindrical panorama.
  • “Cylindrical” refers to the fact the image wraps around in longitude,

left and right edge join seamlessly.

Place Turkiye

  • 180 degrees

180 degrees

  • FOV/2 degrees

FOV/2 degrees Longitude Latitude

slide-24
SLIDE 24

Cylindrical panoramas: Virtual heritage

Place Turkiye

slide-25
SLIDE 25

AVIE

Advanced Visualisation and Interaction Environment

slide-26
SLIDE 26

AVIE: Stereoscopic 3D

Left eye Right eye Place Hampi

slide-27
SLIDE 27

Camera

Roundshot camera

slide-28
SLIDE 28

Cylindrical panoramas: Augmented

Place Hampi Left eye Right eye Movie

slide-29
SLIDE 29

Cylindrical panoramas: Augmented

Place Hampi Left eye Right eye Movie

slide-30
SLIDE 30

Gigapixel panoramas: Recordings in archaology

  • Gigapixel refers to the number of pixels in the image.

A good SLR camera may capture 20+ Megapixels, how to photograph at 1,000 Megapixels?

  • Cannot buy arbitrary high resolution sensor, solution is to stitch large numbers of

images together.

  • Capture detail and the context in one image.

May or may not be a full cylindrical panorama.

  • Results in a much richer digital recording than
  • single image of the extended area but no ability to zoom
  • lots of single images of small parts of the scene
slide-31
SLIDE 31

Gigapixel panoramas: Recordings in archaology

13 x 3 grid 60,000 x 15,000 pixels

slide-32
SLIDE 32

Gigapixel panoramas: Recordings in archaology

Wanmanna

slide-33
SLIDE 33

Gigapixel panoramas: Recordings in archaology

Beacon Island

slide-34
SLIDE 34

Gigapixel panoramas: Recordings in archaology

slide-35
SLIDE 35

Bubbles = Spherical panorama

  • 180 degrees

180 degrees

  • 90 degrees

90 degrees North pole South pole Longitude Latitude UWA boat shed

slide-36
SLIDE 36

Cube maps

UWA boat shed

  • Everything is recorded about the camera point.
  • Means we can recreate ANY other projection.
slide-37
SLIDE 37

Stereographic projection

slide-38
SLIDE 38

Little planet photographs

UWA boat shed

slide-39
SLIDE 39

... and just for fun

Coming and going Movie
